Engine Control System (2ZR-FE) (Service Information): Diagnosis Toyota Corolla X рестайлинг

ON-VEHICLE INSPECTION

1. INSPECT CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY Connect the Techstream to the DLC3. Start the engine. Turn the Techstream on. Inspect the oil control valve (for intake camshaft). Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the VVT System (Bank 1). Check the engine speed when the oil control valve is operated using the Techstream with the engine coolant temperature at 50°C (122°F) or less. HINT: When performing the active test, the air conditioning should be on. Engine coolant temperature when the engine is started should be 30°C (86°F) or less. Standard Control Range Specified Condition OFF Normal engine speed ON Rough idle or engine stalls (soon after oil control valve switched from OFF to ON) Inspect the oil control valve (for exhaust camshaft). Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the VVT Exhaust Linear (Bank 1). Check the engine speed when the oil control valve is operated using the Techstream with the engine coolant temperature at 50°C (122°F) or less. HINT: When performing the active test, the air conditioning should be on. Engine coolant temperature when engine is started should be 30°C (86°F) or less. Standard Control Range Specified Condition 100% Rough idle or engine stalls (soon after oil control valve switched from OFF to ON) -100% Normal engine speed

Scheme 218

Scheme 219

Scheme 220

Scheme 221

Scheme 222

1. REMOVE NO. 2 CYLINDER HEAD COVER . Refer to «REMOVAL - Step 10»(ref-426025-S04676574782011101200000)
2. REMOVE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY Exhaust camshaft side: Remove the bolt and the wire harness bracket. Disconnect the camshaft timing oil control valve assembly connector. Remove the bolt and the camshaft timing oil control valve assembly and separate the wire harness bracket. Remove the O-ring from the camshaft timing oil control valve assembly. Intake camshaft side: Disconnect the camshaft timing oil control valve assembly connector. Remove the bolt and remove the camshaft timing oil control valve assembly. Remove the O-ring from the camshaft timing oil control valve assembly.

Scheme 223

Scheme 224

1. INSPECT CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY Measure the resistance between the terminals. Standard Resistance Tester Connection Condition Specified Condition 1 - 2 20°C (68°F) 6.9 to 7.9 ohms If the result is not as specified, replace the oil control valve assembly. Check the operation. Connect a positive (+) battery lead to terminal 1 and a negative (-) lead to terminal 2, and check the movement of the valve. NOTE: Confirm that the valve moves freely and does not stick in any position. If necessary, replace the camshaft timing oil control valve assembly. HINT: Accumulation of foreign matter can cause minor pressure leaks. Minor pressure leaks will cause the camshaft to advance or retard, and this will cause a DTC to be set.

1. INSPECT THROTTLE BODY ASSEMBLY Check for throttle control motor operating sound. Turn the ignition switch to ON. When depressing the accelerator pedal, check the operating sound of the motor. Make sure that no friction noises are emitted from the motor. If any friction noise exists, replace the throttle body assembly. Check the throttle position sensor. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Throttle Position. When the throttle valve is fully opened, check that the value of "Throttle Pos. Sensor Output." is within the specification. Standard Throttle Valve Opening Percentage Tester Display Standard Value Throttle Pos. Sensor Output 60% or more NOTE: When checking the throttle valve opening percentage, the shift lever should be in N. Fully depress the accelerator pedal. If the percentage is less than 60%, replace the throttle body assembly.

Scheme 225

Scheme 226

Scheme 227

Scheme 228

Scheme 229

Scheme 230

1. DRAIN ENGINE COOLANT . Refer to «REPLACEMENT - Step 1»(ref-426029-S32896581692011101200000)
2. REMOVE NO. 2 CYLINDER HEAD COVER . Refer to «REMOVAL - Step 10»(ref-426025-S04676574782011101200000)
3. REMOVE AIR CLEANER CAP SUB-ASSEMBLY Disconnect the mass air flow meter connector and the 2 wire harness clamps. Disconnect the ventilation hose and loosen the hose clamp. Release the 2 clamps and remove the air cleaner cap sub-assembly with hose.
4. REMOVE THROTTLE BODY ASSEMBLY Disconnect the throttle body connector and the 2 water by-pass hoses. Remove the 2 bolts and 2 nuts, and remove the throttle body assembly. Remove the gasket from the intake manifold.

Scheme 231

1. INSPECT THROTTLE BODY ASSEMBLY Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 1 (M-) - 2 (M+) 20°C (68°F) 0.3 to 100 ohms If the result is not as specified, replace the throttle body assembly.

Scheme 232

Scheme 233

1. INSTALL THROTTLE BODY ASSEMBLY Install a new gasket onto the intake manifold. Install the throttle body assembly with the 2 bolts and 2 nuts. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf) Connect the 2 water by-pass hoses and the throttle body connector.
2. INSTALL AIR CLEANER CAP SUB-ASSEMBLY Install the air cleaner cap sub-assembly with hose with the 2 clamps. Tighten the hose clamp to the specified torque. Torque: 2.0 N*m (20 kgf*cm, 18 in.*lbf) Connect the ventilation hose. Connect the 2 wire harness clamps and mass air flow meter connector.
3. ADD ENGINE COOLANT . Refer to «REPLACEMENT - Step 2»(ref-426029-S32896581692011101200000)
4. INSPECT FOR COOLANT LEAK . Refer to «ON-VEHICLE INSPECTION - Step 1»(ref-426065-S06392484952011101200000)
5. INSTALL NO. 2 CYLINDER HEAD COVER . Refer to «INSTALLATION - Step 85»(ref-426025-S24152213092011101200000)
6. PERFORM INITIALIZATION NOTE: Be sure to perform this procedure after reassembling the throttle body assembly, removing and reinstalling any throttle body component or replacing the ECM. Disconnect the cable from the negative (-) battery terminal. Wait at least 60 seconds and reconnect the cable. Turn the ignition switch to ON without operating the accelerator pedal. NOTE: If the accelerator pedal is operated, perform the above steps again. Connect the Techstream to the DLC3 and clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-425888-S21843066702011101200000) . Start the engine and check that the MIL is not illuminated and that the idle speed is within the specified range when the air conditioning is switched off after the engine is warmed up. Standard Condition Engine Idle Speed A/C switched off 600 to 700 rpm NOTE: Be sure to perform this step with all accessories off. Make sure that the shift lever is in N or P. Enter the following menus: Powertrain/ Engine and ECT/ Data List/ Throttle Pos. Sensor Output. Fully depress the accelerator pedal and check that the value is 60% or more. Perform a road test and confirm that there are no abnormalities.

Scheme 234

Scheme 235

Scheme 236

Scheme 237

Scheme 238

1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL
2. REMOVE AIR CLEANER CAP SUB-ASSEMBLY See step 3
3. REMOVE AIR CLEANER CASE SUB-ASSEMBLY . Refer to «REMOVAL - Step 12»(ref-426025-S04676574782011101200000)
4. REMOVE ECM Separate the wire harness clamp. Disconnect the 2 ECM connectors. Push the locks on the 2 levers, then raise the levers, and disconnect the 2 ECM connectors. NOTE: After disconnecting the connectors, make sure that dirt, water or other foreign matter does not contact the connecting parts of the connectors. Remove the 3 bolts and the ECM. Remove the 4 screws and 2 ECM brackets.

Scheme 239

1. INSTALL ECM Install the 2 ECM brackets onto the ECM with the 4 screws. Torque: 8.8 N*m (90 kgf*cm, 78 in.*lbf) Install the ECM with the 3 bolts. Torque: 8.0 N*m (82 kgf*cm, 71 in.*lbf) Connect the 2 ECM connectors. Connect the 2 ECM connectors and lower the 2 levers. NOTE: When connecting the connectors, make sure that dirt, water or other foreign matter does not get caught between the connectors and other parts. Make sure that the 2 levers are securely locked. Install the wire harness clamp.
2. INSTALL AIR CLEANER CASE SUB-ASSEMBLY . Refer to «INSTALLATION - Step 62»(ref-426025-S24152213092011101200000)
3. INSTALL AIR CLEANER CAP SUB-ASSEMBLY See step 2
4. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL . Refer to «INSTALLATION - Step 8»(ref-426061-S00919535152011101200000)
5. PERFORM INITIALIZATION HINT: Initialization cannot be completed by only removing the battery. Perform the Reset Memory (AT initialization) when replacing the ECM. Refer to «INITIALIZATION»(ref-425891-S07333937102011101200000) . (for Automatic Transaxle) Perform the Registration (VIN registration) when replacing the ECM. Refer to «REGISTRATION»(ref-425888-S09735947722011101200000) .

Scheme 240

1. INSPECT ACCELERATOR PEDAL Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Accelerator Position No. 1, Accelerator Position No. 2. Read the values displayed on the Techstream. Accelerator Position No. 1 Standard Voltage Condition Specified Condition Accelerator pedal is released 0.5 to 1.1 V Accelerator pedal is depressed 2.6 to 4.5 V Accelerator Position No. 2 Standard Voltage Condition Specified Condition Accelerator pedal is released 1.2 to 2.0 V Accelerator pedal is depressed 3.4 to 5.0 V If the result is not as specified, check the accelerator pedal, wire harness and ECM.

Scheme 241

1. REMOVE ACCELERATOR PEDAL ASSEMBLY Disconnect the accelerator pedal position sensor connector. Remove the 2 bolts and accelerator pedal.

Note. Perform the mass air flow meter inspection in accordance with the following procedure. Only replace the mass air flow meter when foreign matter adheres to the sensor and the MAF value in the Data List (with the engine stopped) is not within the normal operating range.

1. INSPECT MASS AIR FLOW METER Read the values using the Techstream (MAF). NOTE: Perform the inspection with the vehicle indoors and on a level surface. Perform the inspection of the mass air flow meter while it is installed into the air cleaner case (installed on the vehicle). During the test, do not use an exhaust air duct on the exhaust pipe. Connect the Techstream to the DLC3. Turn the ignition switch to ON (do not run the engine). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / MAF. Wait 30 seconds, and read the values on the Techstream. Standard Condition Tester Display Condition Standard Condition MAF Engine not running 30 seconds after ignition switch is turned to ON Less than 0.26 g/sec If the result is not as specified, replace the mass air flow meter. If the result is within the specified range, remove and inspect the mass air flow meter. Refer to «INSPECTION»(ref-426060-S06905863822011101200000) .

Scheme 242

1. REMOVE MASS AIR FLOW METER Disconnect the mass air flow meter connector. Remove the 2 screws and the mass air flow meter.

Scheme 243

Scheme 244

1. INSPECT MASS AIR FLOW METER Perform a visual check for any foreign matter on the platinum hot wire (heater) of the mass air flow meter shown in the illustration. Result No foreign matter attached. If the result is not as specified, replace the mass air flow meter. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 1 (THA) - 2 (E2) -20°C (-4°F) 13.6 to 18.4 kohms 20°C (68°F) 2.21 to 2.69 kohms 60°C (140°F) 0.49 to 0.67 kohms
