MONITOR STRATEGY
| Related DTCs | P0010: Camshaft timing oil control valve range check |
| Required Sensors/Components (Main) | Camshaft timing oil control valve |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 1 second |
| MIL Operation | Immediate |
| Sequence of Operation | None |
TYPICAL ENABLING CONDITIONS
| Monitor runs whenever following DTCs not present | None |
| All of the following conditions are met | |
| Starter | Off |
| Ignition switch | ON |
| Time after ignition switch off to ON | 0.5 seconds or more |
TYPICAL MALFUNCTION THRESHOLDS
| One of the following conditions is met | A, B or C |
| A. All of following conditions are met | |
| Battery voltage | 11 to 13 V |
| Target duty ratio | Less than 70% |
| Output signal duty ratio | 100% |
| B. All of the following conditions are met | |
| Battery voltage | 13 V or more |
| Target duty ratio | Less than 80% |
| Output signal duty ratio | 100% |
| C. Both of the following conditions are met | |
| Current cut status | Not cut |
| Output signal duty ratio | 3% or less |
COMPONENT OPERATING RANGE
| Camshaft timing oil control valve output signal duty ratio | 3 to 100% |
CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation). Refer to «DTC CHECK / CLEAR»(ref-425888-S21843066702011101200000) .
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on.
- Wait 5 seconds.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0010.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-425888-S21843066702011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 187
Scheme 187: WIRING DIAGRAM
PROCEDURE
- PERFORM ACTIVE TEST USING TECHSTREAM (OPERATE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY) Connect the Techstream to the DLC3. Start the engine. Turn the Techstream on. Turn the A/C switch to ON. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the VVT Linear (Bank 1). Check the engine speed while operating the camshaft timing oil control valve assembly (for intake camshaft) using the Techstream. Result Techstream Operation Specified Condition 0% Normal engine speed 100% Engine idles roughly or stalls HINT: If the result is not acceptable, cool the engine and perform the Active Test again. Start the engine when the engine coolant temperature is 30°C (86°F) or less. Turn the Techstream on. Turn the A/C switch to ON. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the VVT Linear (Bank 1). Check the engine speed while operating the camshaft timing oil control valve assembly (for intake camshaft) using the Techstream with the engine coolant temperature is 50°C (122°F) or less. Result Techstream Operation Specified Condition 0% Normal engine speed 100% Engine idles roughly or stalls HINT: Refer to "Data List / Active Test" [VVT OCV Duty #1 and VVT Change Angle #1]. Refer to «DATA LIST / ACTIVE TEST»(ref-425888-S33770332412011101200000) . NG --> See step 2 OK --> See step 6
- INSPECT CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (FOR INTAKE CAMSHAFT) Inspect the camshaft timing oil control valve assembly (for intake camshaft). Refer to «INSPECTION»(ref-426060-S30340203862011101200000) . NG --> See step 5 OK: Go to next step
- CHECK HARNESS AND CONNECTOR (CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY - ECM) Disconnect the camshaft timing oil control valve assembly (for intake camshaft) connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for Open) Tester Connection Condition Specified Condition B23-1 - B31-74 (OC1+) Always Below 1 ohms B23-2 - B31-96 (OC1-) Always Below 1 ohms Standard Resistance (Check for Short) Tester Connection Condition Specified Condition B23-1 or B31-74 (OC1+) - Body ground Always 10 kohms or higher B23-2 or B31-96 (OC1-) - Body ground Always 10 kohms or higher Reconnect the camshaft timing oil control valve assembly (for intake camshaft) connector. Reconnect the ECM connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY - ECM) OK --> See step 4
- REPLACE ECM. Refer to «REMOVAL»(ref-426060-S19785503332011101200000)
- REPLACE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (FOR INTAKE CAMSHAFT). Refer to «REMOVAL»(ref-426060-S01733107132011101200000)
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-425888-S02484986942011101200000)
| Related DTCs | P0011: Advanced camshaft timing P0012: Retarded camshaft timing |
| Required Sensors/Components (Main) | Camshaft timing oil control valve and VVT controller |
| Required Sensors/Components (Related) | Crankshaft position sensor Camshaft position sensor Engine coolant temperature sensor |
| Frequency of Operation | Continuous |
| Duration | Within 10 seconds |
| MIL Operation | Advanced camshaft timing: Immediate Retarded camshaft timing: 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not present | P0010 (VVT Oil Control Valve) P0016 (VVT System - Misalignment) P0102, P0103 (Mass Air Flow Meter) P0115, P0117, P0118 (Engine Coolant Temperature Sensor) P0125 (Insufficient Engine Coolant Temperature for Closed Loop Fuel Control) P0335 (Crankshaft Position Sensor) P0340 (Camshaft Position Sensor) |
| Battery voltage | 11 V or more |
| Engine speed | 400 to 4000 RPM |
| Engine coolant temperature | 75 to 100°C (167 to 212°F) |
| Both of following conditions are met | |
| Deviation of actual valve timing and target valve timing | More than 5°CA (Crankshaft Angle) for 5 seconds or more after the VVT hold duty ratio learned value reaches the upper or lower limit. |
| Valve timing | No change at advanced valve timing |
| Both of following conditions are met | |
| Deviation of actual valve timing and target valve timing | More than 5°CA (Crankshaft Angle) for 5 seconds or more after the VVT hold duty ratio learned value reaches the upper or lower limit. |
| Valve timing | No change at retarded valve timing |
If the difference between the target and actual camshaft timing is greater than the specified value, the ECM operates the VVT actuator (camshaft timing oil control valve assembly) for 10 seconds by applying and releasing oil pressure.
Then, the ECM monitors the camshaft timing change for 10 seconds.
MONITOR RESULT
Refer to Checking Monitor Status. Refer to CHECKING MONITOR STATUS .
Scheme 188
Scheme 188: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation). Refer to «DTC CHECK / CLEAR»(ref-425888-S21843066702011101200000) .
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher [B].
- Drive the vehicle at approximately 37 mph (60 km/h) for 10 minutes or more [C]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
- Idle the engine for 3 minutes or more [D].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [E].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0011 or P0012.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [F] through [H].
- Repeat the pattern of accelerating the vehicle from rest to approximately 37 mph (60 km/h) and then decelerating the vehicle 10 to 15 times [F]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: Depress the accelerator pedal by a large amount.
- Idle the engine for 3 minutes or more [G].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [H].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Check the DTC judgment result again. HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform the following procedure.
- Perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-425888-S21843066702011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
| Related DTCs | P0013: Exhaust camshaft timing oil control valve range check |
| Required Sensors/Components (Main) | Exhaust camshaft timing oil control valve |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 1 second |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not present | None |
| All of the following conditions are met | |
| Starter | Off |
| Ignition switch | ON |
| Time after ignition switch off to ON | 0.5 seconds or more |
| One of the following conditions is met | A, B or C |
| A. All of the following conditions are met | |
| Battery voltage | 11 to 13 V |
| Target duty ratio | Less than 70% |
| Output signal duty ratio | 100% |
| B. All of the following conditions are met | |
| Battery voltage | 13 V or more |
| Target duty ratio | Less than 80% |
| Output signal duty ratio | 100% |
| C. Both of the following conditions are met | |
| Current cut status | Not cut |
| Output signal duty ratio | 3% or less |
| Camshaft timing oil control valve output signal duty ratio | 3 to 100% |
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation). Refer to «DTC CHECK / CLEAR»(ref-425888-S21843066702011101200000) .
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on.
- Wait 5 seconds.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0013.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-425888-S21843066702011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 189
Scheme 189: WIRING DIAGRAM
- PERFORM ACTIVE TEST USING TECHSTREAM (OPERATE CAMSHAFT TIMING OIL CONTROL VALVE) Connect the Techstream to the DLC3. Start the engine. Turn the Techstream on. Turn the A/C switch to ON. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the VVT Exhaust Linear (Bank 1). Check the engine speed while operating the camshaft timing oil control valve assembly (for exhaust camshaft) using the Techstream. Result Techstream Operation Specified Condition 0% Normal engine speed 100% Engine idles roughly or stalls HINT: If the result is not acceptable, cool the engine and perform the Active Test again. Start the engine when the engine coolant temperature is 30°C (86°F) or less. Turn the Techstream on. Turn the A/C switch to ON. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the VVT Exhaust Linear (Bank 1). Check the engine speed while operating the camshaft timing oil control valve assembly (for exhaust camshaft) using the Techstream with the engine coolant temperature is 50°C (122°F) or less. Result Techstream Operation Specified Condition 0% Normal engine speed 100% Engine idles roughly or stalls HINT: Refer to "Data List / Active Test" [VVT Ex OCV Duty #1 and VVT Ex Chg Angle #1]. Refer to «DATA LIST / ACTIVE TEST»(ref-425888-S33770332412011101200000) . NG --> See step 2 OK --> See step 4
- INSPECT CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (FOR EXHAUST CAMSHAFT) Inspect the camshaft timing oil control valve assembly (for exhaust camshaft). Refer to «INSPECTION»(ref-426060-S30340203862011101200000) . NG --> See step 5 OK: Go to next step
- CHECK HARNESS AND CONNECTOR (CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY - ECM) Disconnect the camshaft timing oil control valve assembly (for exhaust camshaft) connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for Open) Tester Connection Condition Specified Condition B22-1 - B31-75 (OE1+) Always Below 1 ohms B22-2 - B31-97 (OE1-) Always Below 1 ohms Standard Resistance (Check for Short) Tester Connection Condition Specified Condition B22-1 or B31-75 (OE1+) - Body ground Always 10 kohms or higher B22-2 or B31-97 (OE1-) - Body ground Always 10 kohms or higher Reconnect the camshaft timing oil control valve assembly (for exhaust camshaft) connector. Reconnect the ECM connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY - ECM) OK --> See step 6
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-425888-S02484986942011101200000)
- REPLACE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (FOR EXHAUST CAMSHAFT). Refer to «REMOVAL»(ref-426060-S01733107132011101200000)
- REPLACE ECM. Refer to «REMOVAL»(ref-426060-S19785503332011101200000)
| Related DTCs | P0014: Advanced camshaft timing P0015: Retarded camshaft timing |
| Required Sensors/Components (Main) | Camshaft timing oil control valve and VVT controller |
| Required Sensors/Components (Related) | Crankshaft position sensor Camshaft position sensor Engine coolant temperature sensor |
| Frequency of Operation | Continuous |
| Duration | Within 10 seconds |
| MIL Operation | Advanced camshaft timing: 2 driving cycles Retarded camshaft timing: Immediate |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not present | P0013 (Exhaust VVT Oil Control Valve) P0017 (Exhaust VVT System - Misalignment) P0102, P0103 (Mass Air Flow Meter) P0115, P0117, P0118 (Engine Coolant Temperature Sensor) P0125 (Insufficient Engine Coolant Temperature for Closed Loop Fuel Control) P0335 (Crankshaft Position Sensor) P0340 (Camshaft Position Sensor) |
| Battery voltage | 11 V or more |
| Engine speed | 500 to 4000 RPM |
| Engine coolant temperature | 75 to 100°C (167 to 212°F) |
| Both of the following conditions are met | |
| Deviation of actual valve timing and target valve timing | More than 5°CA (Crankshaft Angle) for 5 seconds or more after the VVT hold duty ratio learned value reaches the upper or lower limit. |
| Valve timing | No change at advanced valve timing |
| Both of the following conditions are met | |
| Deviation of actual valve timing and target valve timing | More than 5°CA (Crankshaft Angle) for 5 seconds or more after the VVT hold duty ratio learned value reaches the upper or lower limit. |
| Valve timing | No change at retarded valve timing |
Refer to Checking Monitor Status. Refer to CHECKING MONITOR STATUS .
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation). Refer to «DTC CHECK / CLEAR»(ref-425888-S21843066702011101200000) .
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher [B].
- Drive the vehicle at approximately 37 mph (60 km/h) for 10 minutes or more [C]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
- Idle the engine for 3 minutes or more [D].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [E].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0014 or P0015.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [F] through [H].
- Repeat the pattern of accelerating the vehicle from rest to approximately 37 mph (60 km/h) and then decelerating the vehicle 10 to 15 times [F]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: Depress the accelerator pedal by a large amount.
- Idle the engine for 3 minutes or more [G].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [H].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Check the DTC judgment result again. HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform the following procedure.
- Perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-425888-S21843066702011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0014 OR P0015) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P0014 or P0015 is output A DTC P0014 or P0015 and other DTCs are output B HINT: If any DTCs other than P0014 or P0015 are output, troubleshoot those DTCs first. B --> See step 10 A: Go to next step
- PERFORM ACTIVE TEST USING TECHSTREAM (OPERATE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY) Connect the Techstream to the DLC3. Start the engine. Turn the Techstream on. Turn the A/C switch to ON. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the VVT Exhaust Linear (Bank 1). Check the engine speed while operating the camshaft timing oil control valve assembly (for exhaust camshaft) using the Techstream. Result Techstream Operation Specified Condition 0% Normal engine speed 100% Engine idles roughly or stalls HINT: If the result is not acceptable, cool the engine and perform the Active Test again. Start the engine when the engine coolant temperature is 30°C (86°F) or less. Turn the Techstream on. Turn the A/C switch to ON. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the VVT Exhaust Linear (Bank 1). Check the engine speed while operating the camshaft timing oil control valve assembly (for exhaust camshaft) using the Techstream with the engine coolant temperature is 50°C (122°F) or less. Result Techstream Operation Specified Condition 0% Normal engine speed 100% Engine idles roughly or stalls HINT: Refer to "Data List / Active Test" [VVT Ex OCV Duty #1 and VVT Ex Chg Angle #1]. Refer to «DATA LIST / ACTIVE TEST»(ref-425888-S33770332412011101200000) . NG --> See step 5 OK: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS (DTC P0014 OR P0015) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear DTCs. Refer to «DTC CHECK / CLEAR»(ref-425888-S21843066702011101200000) . Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes / Pending. Read DTCs. Result Result Proceed to DTC is not output A DTC P0014 or P0015 is output B B --> See step 8 A --> See step 4
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-425888-S02484986942011101200000)
- INSPECT CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (FOR EXHAUST CAMSHAFT) Inspect the camshaft timing oil control valve assembly (for exhaust camshaft). Refer to «INSPECTION»(ref-426060-S30340203862011101200000) . NG --> See step 11 OK: Go to next step
- INSPECT CAMSHAFT TIMING GEAR ASSEMBLY (FOR EXHAUST CAMSHAFT) Inspect the camshaft timing gear assembly (for exhaust camshaft). Refer to «REMOVAL»(ref-426025-S22392223042011101200000) . NG --> See step 13 OK: Go to next step
- INSPECT OIL CONTROL VALVE FILTER Remove the oil control valve filter. Refer to «DISASSEMBLY - Step 36»(ref-426025-S06857858072011101200000) . Check that the filter is not clogged. OK Filter is not clogged. Reinstall the oil control valve filter. Refer to «REASSEMBLY - Step 13»(ref-426025-S11532057382011101200000) . NG --> See step 12 OK: Go to next step
- ADJUST VALVE TIMING HINT: There are no marks on the cylinder head to match-up for the purpose of checking valve timing. Valve timing can only be inspected by lining up the colored plates on the timing chain with the marks on the pulleys. It may be necessary to remove and reinstall the chain to match-up the alignment marks. Refer to «REASSEMBLY»(ref-426025-S06214335662011101200000) . NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS (DTC P0014 OR P0015) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear DTCs. Refer to «DTC CHECK / CLEAR»(ref-425888-S21843066702011101200000) . Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes / Pending. Read DTCs. Result Result Proceed to DTC is not output A DTC P0014 or P0015 is output B B --> See step 14 A --> END
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-425888-S24994798172011101200000)
- REPLACE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (FOR EXHAUST CAMSHAFT). Refer to «REMOVAL»(ref-426060-S01733107132011101200000)
- REPLACE OIL CONTROL VALVE FILTER. Refer to «DISASSEMBLY - Step 36»(ref-426025-S06857858072011101200000)
- REPLACE CAMSHAFT TIMING GEAR ASSEMBLY (FOR EXHAUST CAMSHAFT). Refer to «REMOVAL»(ref-426025-S22392223042011101200000)
- REPLACE ECM. Refer to «REMOVAL»(ref-426060-S19785503332011101200000)
| Related DTCs | P0016: Camshaft Timing Misalignment at idling (for intake camshaft) P0017: Camshaft Timing Misalignment at idling (for exhaust camshaft) |
| Required Sensors/Components (Main) | VVT controller (camshaft timing gear assembly) |
| Required Sensors/Components (Related) | Camshaft position sensor Crankshaft position sensor |
| Frequency of Operation | Once per driving cycle |
| Duration | Less than 1 minute |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not present | P0010 (VVT Oil Control Valve) P0102, P0103 (Mass Air Flow Meter) P0115, P0117, P0118 (Engine Coolant Temperature Sensor) P0125 (Insufficient Engine Coolant Temperature for Closed Loop Fuel Control) P0335 (Crankshaft Position Sensor) P0340 (Camshaft Position Sensor) |
| Engine speed | 500 to 1000 RPM |
| Monitor runs whenever following DTCs not present | P0013 (Exhaust VVT Oil Control Valve) P0102, P0103 (Mass Air Flow Meter) P0115, P0117, P0118 (Engine Coolant Temperature Sensor) P0125 (Insufficient Engine Coolant Temperature for Closed Loop Fuel Control) P0335 (Crankshaft Position Sensor) P0340 (Camshaft Position Sensor) |
| Engine speed | 500 to 1000 RPM |
| Either of following conditions is met | |
| VVT learning value at maximum retarded valve timing | Less than 22°CA (Crankshaft Angle) |
| VVT learning value at maximum retarded valve timing | More than 47°CA (Crankshaft Angle) |
| Either of following conditions is met | |
| VVT learning value at maximum retarded valve timing | Less than 82.5°CA (Crankshaft Angle) |
| VVT learning value at maximum retarded valve timing | More than 104.4°CA (Crankshaft Angle) |
Scheme 190
Scheme 190: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation). Refer to «DTC CHECK / CLEAR»(ref-425888-S21843066702011101200000) .
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher [B].
- Idle the engine for 5 minutes or more [C].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [D].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0016 or P0017.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [E] through [G].
- Drive the vehicle for 2 to 3 minutes [E]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
- Idle the engine for 5 minutes or more [F].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [G].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Check the DTC judgment result.
- If the judgment result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-425888-S21843066702011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0016 AND P0017) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P0016 or P0017 is output A DTC P0016 or P0017 and other DTCs are output B HINT: If any DTCs other than P0016 or P0017 are output, troubleshoot those DTCs first. B --> See step 12 A: Go to next step
- PERFORM ACTIVE TEST USING TECHSTREAM (OPERATE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY) Connect the Techstream to the DLC3. Start the engine. Turn the Techstream on. Warm up the engine. Check the camshaft timing oil control valve assembly for intake camshaft. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the VVT Linear (Bank 1). Check the engine speed while operating the camshaft timing oil control valve assembly (for intake camshaft) using the Techstream. Result Techstream Operation Specified Condition 0% Normal engine speed 100% Engine idles roughly or stalls Check the camshaft timing oil control valve assembly for exhaust camshaft. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the VVT Exhaust Linear (Bank 1). Check the engine speed while operating the camshaft timing oil control valve assembly (for exhaust camshaft) using the Techstream. Result Techstream Operation Specified Condition 0% Normal engine speed 100% Engine idles roughly or stalls HINT: If the VVT system can be operated using the Active Test, it can be assumed that the VVT system is operating normally. NG --> See step 5 OK: Go to next step
- ADJUST VALVE TIMING HINT: There are no marks on the cylinder head to match-up for the purpose of checking valve timing. Valve timing can only be inspected by lining up the colored plates on the timing chain with the marks on the pulleys. It may be necessary to remove and reinstall the chain to match-up the alignment marks. Refer to «REASSEMBLY»(ref-426025-S06214335662011101200000) . NEXT: Go to next step
- CONFIRM WHETHER MALFUNCTION HAS BEEN SUCCESSFULLY REPAIRED Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear DTCs. Refer to «DTC CHECK / CLEAR»(ref-425888-S21843066702011101200000) . Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes / Pending. Read the DTCs. Result Result Proceed to DTC is not output A DTC P0016 or P0017 is output B B --> See step 9 A --> END
- INSPECT CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (FOR INTAKE OR EXHAUST CAMSHAFT) HINT: Inspect the specified camshaft timing oil control valve assembly (for intake or exhaust camshaft) in accordance with the inspection result of step 2. Inspect the camshaft timing oil control valve assembly (for intake or exhaust camshaft). Refer to «INSPECTION»(ref-426060-S30340203862011101200000) . NG --> See step 11 OK: Go to next step
- INSPECT OIL CONTROL VALVE FILTER Remove the oil control valve filter. Refer to «DISASSEMBLY - Step 36»(ref-426025-S06857858072011101200000) . Check that the filter is not clogged. OK Filter is not clogged. Reinstall the oil control valve filter. Refer to «REASSEMBLY - Step 13»(ref-426025-S11532057382011101200000) . NG --> See step 10 OK: Go to next step
- REPLACE CAMSHAFT TIMING GEAR ASSEMBLY (INTAKE OR EXHAUST) HINT: Replace the specified camshaft timing gear (camshaft timing gear for intake camshaft or exhaust camshaft) in accordance with the inspection result of step 2. Replace the camshaft timing gear assembly (camshaft timing gear for intake camshaft or exhaust camshaft). Refer to «REMOVAL»(ref-426025-S22392223042011101200000) . NEXT: Go to next step
- CONFIRM WHETHER MALFUNCTION HAS BEEN SUCCESSFULLY REPAIRED Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear DTCs. Refer to «DTC CHECK / CLEAR»(ref-425888-S21843066702011101200000) . Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes / Pending. Read the DTCs. Result Result Proceed to DTC is not output A DTC P0016 or P0017 is output B B --> See step 9 A --> END
- REPLACE ECM. Refer to «REMOVAL»(ref-426060-S19785503332011101200000)
- REPLACE OIL CONTROL VALVE FILTER. Refer to «DISASSEMBLY - Step 36»(ref-426025-S06857858072011101200000)
- REPLACE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (INTAKE OR EXHAUST). Refer to «REMOVAL»(ref-426060-S01733107132011101200000)
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-425888-S24994798172011101200000)
| Related DTCs | P0031: Air fuel ratio sensor heater current (Low current) P0032: Air fuel ratio sensor heater current (High current) |
| Required Sensors/Components (Main) | Air fuel ratio sensor heater |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 10 seconds |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not present | None |
| Battery voltage | 10.5 V or more |
| Air fuel ratio sensor heater output duty | 30% or more |
| Time after engine start | 10 seconds or more |
| Battery voltage | Less than 20 V |
| Time after engine start | 10 seconds or more |
| Air fuel ratio sensor heater current | Less than 0.8 A |
| Hybrid IC high current limiter monitor input | Fail |
| Heater current | 0.8 A or more |
| Hybrid IC high current limiter monitor input | Pass |
Scheme 191
Scheme 191: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation). Refer to «DTC CHECK / CLEAR»(ref-425888-S21843066702011101200000) .
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine and idle it for 5 minutes or more [B].
- With the vehicle stationary, depress the accelerator pedal and maintain an engine speed of 3000 RPM for 1 minute [C].
- Idle the engine for 5 minutes or more [D].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [E].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0031 or P0032.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [B] through [E] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-425888-S21843066702011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
| Related DTCs | P0037: Heated oxygen sensor (sensor 2) heater current (Low current) P0038: Heated oxygen sensor (sensor 2) heater current (High current) P0141: Heated oxygen sensor (sensor 2) heater performance |
| Required Sensors/Components (Main) | Heated oxygen sensor heater (sensor 2) |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous: P0037, P0038 Once per driving cycle: P0141 |
| Duration | 0.2 seconds: P0038 (Case 3) 0.5 seconds: P0037 1 second: P0038 (Case 1, 2) 10 seconds: P0141 |
| MIL Operation | Immediate: P0037, P0038 2 driving cycles: P0141 |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | None |
| Battery voltage | 10.5 to 20 V |
| Battery voltage | 10.5 V or more |
| Engine | Running |
| Starter | Off |
| Battery voltage | 10.5 to 20 V |
| One of the following conditions is met | Condition A or B |
| A. All of the following conditions are met | Condition 1, 2, 3, 4, 5, 6 and 7 |
| 1. Air fuel ratio sensor circuit fail (P0031, P0032) | Not detected |
| 2. Heated oxygen sensor circuit fail (P0037, P0038) | Not detected |
| 3. Battery voltage | 10.5 V or more |
| 4. Fuel cut | Off |
| 5. Time after fuel cut on to off | 30 seconds or more |
| 6. Accumulated heater on time | 100 seconds or more |
| 7. Learned heater off current operation | Completed |
| B. Duration that heated oxygen sensor impedance is less than 15 kohms | 2 seconds or more |
When the values for the Data List items O2 Heater Curr Val B1S2 is not 0 A, the heater is on.
| Heater current | Less than 0.3 A |
| Learned heater off current | More than 2 A |
| Heater current | 2 A or more |
| Accumulated heater resistance | Varies with sensor element temperature (Example: More than 23 ohms) |
| Heated oxygen sensor heater current | 0.3 to 2 A (when engine idles, heated oxygen sensor warmed up and battery voltage 11 to 14 V) |
- Refer to Checking Monitor Status. Refer to «CHECKING MONITOR STATUS»(ref-425888-S30440143772011101200000) .
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation). Refer to «DTC CHECK / CLEAR»(ref-425888-S21843066702011101200000) .
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine and idle it for 5 minutes or more [B].
- With the vehicle stationary, depress the accelerator pedal and maintain an engine speed of 3000 RPM for 1 minute [C].
- Idle the engine for 5 minutes or more [D].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [E].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0037, P0038 or P0141.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [B] through [E] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-425888-S21843066702011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
| Related DTCs | P0101: Mass air flow meter rationality |
| Required Sensors/Components (Main) | Mass air flow meter |
| Required Sensors/Components (Related) | Crankshaft position sensor Camshaft position sensor Engine coolant temperature sensor Throttle position sensor |
| Frequency of Operation | Continuous |
| Duration | 10 times |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not present | None |
| Time after engine starts | 5 seconds or more |
| Battery voltage | 10.5 V or more |
| Throttle position (Throttle position sensor voltage) | 0.2 to 2 V |
| Estimated Load | 30 to 70% |
| Engine coolant temperature | 70°C (158°F) or more |
| Mass air flow meter circuit | OK |
| Intake air temperature sensor circuit | OK |
| Engine coolant temperature sensor circuit | OK |
| Crankshaft position sensor circuit | OK |
| Throttle position sensor circuit | OK |
| EVAP system pressure sensor circuit | OK |
| EVAP leak detection pump | OK |
| EVAP system vent valve | OK |
| Both of following conditions 1 and 2 met | |
| 1. Averaged engine load value ratio | Less than 0.85, or more than 1.301 (varies with estimated engine load) |
| 2. Averaged air fuel ratio | Less than -20%, or more than 20% |
Scheme 192
Scheme 192: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON.
- Turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation). Refer to «DTC CHECK / CLEAR»(ref-425888-S21843066702011101200000) .
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on.
- Start the engine and warm it up until the engine coolant temperature reaches 70°C (158°F) or higher [A].
- Drive the vehicle at approximately 50 mph (80 km/h) to 70 mph (112 km/h) for 5 minutes or more [B]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: Drive while keeping the engine load as stable as possible.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [C].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0101.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [B] through [C] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-425888-S21843066702011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0101) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P0101 is output A DTC P0101 and other DTCs are output B HINT: If any DTCs other than P0101 are output, troubleshoot those DTCs first. B --> See step 4 A: Go to next step
- CHECK INTAKE SYSTEM Check the intake system for vacuum leaks. Refer to «ON-VEHICLE INSPECTION»(ref-426062-S30607190082011101200000) . OK No leaks from intake system. NG --> REPAIR OR REPLACE INTAKE SYSTEM OK: Go to next step
- CHECK PCV HOSE CONNECTIONS Check the PCV hose connections. Refer to «ON-VEHICLE INSPECTION»(ref-426062-S30607190082011101200000) . OK PCV hose is connected correctly and is not damaged. NG --> REPAIR OR REPLACE PCV HOSE OK --> See step 5
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-425888-S24994798172011101200000)
- REPLACE MASS AIR FLOW METER. Refer to «REMOVAL»(ref-426060-S22042440052011101200000)
| Related DTCs | P0102: Mass air flow meter range check (Low voltage) P0103: Mass air flow meter range check (High voltage) |
| Required Sensors/Components (Main) | Mass air flow meter |
| Required Sensors/Components (Related) | Crankshaft position sensor Throttle position sensor |
| Frequency of Operation | Continuous |
| Duration | 3 seconds |
| MIL Operation | Immediate: Engine speed less than 4000 RPM 2 driving cycles: Engine speed 4000 RPM or more |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not present | None |
| Mass air flow meter voltage | Less than 0.2 V |
| Mass air flow meter voltage | More than 4.9 V |
| Mass air flow meter voltage | Between 0.2 V and 4.9 V |
Scheme 193
Scheme 193: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation). Refer to «DTC CHECK / CLEAR»(ref-425888-S21843066702011101200000) .
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine.
- Idle the engine for 5 seconds [B].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [C].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Run the engine at an engine speed of 4000 RPM or higher for 5 seconds [D].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [E].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0102 or P0103.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [B] through [C] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-425888-S21843066702011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 194
Scheme 194: WIRING DIAGRAM
| Related DTCs | P0111: Intake air temperature sensor rationality (After engine stop) P0111: Intake air temperature sensor rationality (After cold engine start) |
| Required Sensors/Components (Main) | Intake air temperature sensor |
| Required Sensors/Components (Sub) | |
| Frequency of Operation | Once per driving cycle |
| Duration | |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | None |
| Time after engine start | 10 seconds or more |
| Battery voltage | 10.5 V or more |
| Intake air temperature sensor circuit | OK |
| Engine coolant temperature sensor circuit | OK |
| Mass air flow meter circuit | OK |
| Engine coolant temperature before engine stop | 70°C (158°F) or more |
| Time that mass air flow is low before engine stop | 2100 seconds |
| Accumulated mass air flow amount before engine stop | Manual transaxle models: 1222 g or more Automatic transaxle models: 2720 g or more |
| Key-off duration | 30 minutes |
| Key-off duration | 5 hours |
| Time after engine start | 10 seconds or more |
| Intake air temperature sensor circuit | OK |
| Engine coolant temperature sensor circuit | OK |
| Mass air flow meter circuit | OK |
| Engine coolant temperature | 70°C (158°F) or more |
| Accumulated mass air flow amount | Manual transaxle models: 1222 g or more Automatic transaxle models: 2720 g or more |
| Either of the following conditions 1 or 2 is met | |
| 1. Duration while engine load is low | 120 seconds or more |
| 2. Duration while engine load is high | 10 seconds or more |
| Intake air temperature change | Less than 1°C (1.8°F) |
| Intake air temperature change | Less than 1°C (1.8°F) |
Scheme 195
Scheme 195: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation). Refer to «DTC CHECK / CLEAR»(ref-425888-S21843066702011101200000) .
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher [B].
- Idle the engine for 5 minutes or more [C]. HINT: During steps [A] through [C], if the change in the intake air temperature is less than 1°C (1.8°F), the intake air temperature sensor (mass air flow meter assembly) is malfunctioning. It is not necessary to continue this procedure.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [D].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0111.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [E] and [F].
- Drive the vehicle at 25 mph (40 km/h) or more for a total of 5 minutes or more [E]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
- Check the DTC judgment result again [F]. HINT: If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [E] and [F] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-425888-S21843066702011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0111) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P0111 and other DTCs are output A DTC P0111 is output B HINT: If any DTCs other than P0111 are output, troubleshoot those DTCs first. B --> See step 3 A --> See step 2
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-425888-S24994798172011101200000)
- REPLACE MASS AIR FLOW METER. Refer to «REMOVAL»(ref-426060-S22042440052011101200000)
Scheme 196
- The intake air temperature sensor, mounted in the mass air flow meter, monitors the intake air temperature. The intake air temperature sensor has a built-in thermistor with a resistance that varies according to the temperature of the intake air. When the intake air temperature becomes low, the resistance of the thermistor increases. When the temperature becomes high, the resistance drops. These variations in resistance are transmitted to the ECM as voltage changes see scheme 1
- The intake air temperature sensor is powered by a 5 V supply from the THA terminal of the ECM, via resistor R which is located inside the ECM.
- Resistor R and the intake air temperature sensor are connected in series. When the resistance value of the intake air temperature sensor changes, according to changes in the intake air temperature, the voltage at terminal THA also varies. Based on this signal, the ECM increases the fuel injection volume when the engine is cold to improve driveability. HINT: When any of DTCs P0112 and P0113 are set, the ECM enters fail-safe mode. During fail-safe mode, the intake air temperature is estimated to be 20°C (68°F) by the ECM. Fail-safe mode continues until a pass condition is detected.
| DTC No. | DTC Detection Condition | Trouble Area |
| P0112 | Short in intake air temperature sensor circuit for 0.5 seconds (1 trip detection logic) | Short in intake air temperature sensor circuit Intake air temperature sensor (built into mass air flow meter) ECM |
| P0113 | Open in intake air temperature sensor circuit for 0.5 seconds (1 trip detection logic) | Open in intake air temperature sensor circuit Intake air temperature sensor (built into mass air flow meter) ECM |
When any of these DTCs are set, check the intake air temperature by entering the following menus: Powertrain / Engine and ECT / Intake Air.
| Temperature Displayed | Malfunction |
| 40°C (-40°F) | Open circuit |
| Higher than 128°C (262°F) | Short circuit |
| Related DTCs | P0112: Intake Air Temperature sensor range check (Low voltage) P0113: Intake air temperature sensor range check (High voltage) |
| Required Sensors/Components (Main) | Intake air temperature sensor |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 0.5 seconds |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not present | None |
| Battery voltage | 8 V or more |
| Ignition switch | ON |
| Starter | Off |
| Intake air temperature sensor voltage (intake air temperature) | Less than 0.18 V (Higher than 128°C [262°F]) |
| Intake air temperature sensor voltage (intake air temperature) | More than 4.91 V (Below -55°C [-67°F]) |
| Intake air temperature sensor voltage (intake air temperature) | 0.18 to 4.91 V (-55 to 128°C [-67 to 262°F]) |
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation). Refer to «DTC CHECK / CLEAR»(ref-425888-S21843066702011101200000) .
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on.
- Wait 0.5 seconds or more.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0112 or P0113.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-425888-S21843066702011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 197
Scheme 197: WIRING DIAGRAM
| Related DTCs | P0115: Engine coolant temperature sensor range check (Chattering) P0117: Engine coolant temperature sensor range check (Low voltage) P0118: Engine coolant temperature sensor range check (High voltage) |
| Required Sensors/Components (Main) | Engine coolant temperature sensor |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 0.5 seconds |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not present | None |
| Engine coolant temperature sensor voltage (engine coolant temperature) | Less than 0.14 V, or more than 4.91 V (Less than -60°C [-76°F], or more than 135°C [275°F]) |
| Engine coolant temperature sensor voltage (engine coolant temperature) | Less than 0.14 V (More than 135°C [275°F]) |
| Engine coolant temperature sensor voltage (engine coolant temperature) | More than 4.91 V (Less than -60°C [-76°F]) |
| Engine coolant temperature sensor voltage (engine coolant temperature) | 0.14 to 4.91 V (-60 to 135°C [-76 to 275°F]) |
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation). Refer to «DTC CHECK / CLEAR»(ref-425888-S21843066702011101200000) .
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on.
- Wait 0.5 seconds or more.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0115, P0117 or P0118.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-425888-S21843066702011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 198
Scheme 198: WIRING DIAGRAM
| Related DTCs | P0116: Engine coolant temperature sensor cold start monitor P0116: Engine coolant temperature sensor soak monitor |
| Required Sensors/Components (Main) | Engine coolant temperature sensor |
| Required Sensors/Components (Related) | None |
| Frequency of Operation | Once per driving cycle |
| Duration | |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not present | None |
| Battery voltage | 10.5 V or more |
| Time after engine start | 1 second or more |
| Engine coolant temperature at engine start | Less than 60°C (140°F) |
| Engine coolant temperature sensor circuit | OK |
| Intake air temperature sensor circuit | OK |
| Thermostat | OK |
| Soak time | 0 sec or more |
| Accumulated mass air flow | Manual transaxle models: 825 g or more Automatic transaxle models: 1422 g or more |
| Fuel cut | Off |
| Difference between engine coolant temperature at engine start and intake air temperature | Less than 40°C (72°F) |
ENGINE COOLANT TEMPERATURE SENSOR COLD START MONITOR
| Monitor runs whenever following DTCs not present | None |
| Battery voltage | 10.5 V or more |
| Engine | Running |
| Engine coolant temperature sensor circuit | OK |
| Intake air temperature sensor circuit | OK |
| Thermostat | OK |
| Soak timer circuit | OK |
| Soak time | 5 hours or more |
| Either (a) or (b) condition met | |
| (a) Engine coolant temperature | 60°C (140°F) or more |
| (b) Accumulated mass air flow | Manual transaxle models: 1661 g or more Automatic transaxle models: 3185 g or more |
ENGINE COOLANT TEMPERATURE SENSOR SOAK MONITOR
| Engine coolant temperature sensor value change | Less than 5°C (9°F) |
ENGINE COOLANT TEMPERATURE SENSOR COLD START MONITOR
| Difference between current engine coolant temperature sensor value and previous engine coolant temperature sensor value when engine stopped | Less than 5°C (9°F) |
ENGINE COOLANT TEMPERATURE SENSOR SOAK MONITOR
| Engine coolant temperature | Engine coolant temperature sensor value changes in accordance with actual engine coolant temperature |
Scheme 199
Scheme 199: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Enter the following menus: Powertrain / Engine and ECT / Data List / Coolant Temp.
- Check that the coolant temperature is 60°C (140°F) or less.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation). Refer to «DTC CHECK / CLEAR»(ref-425888-S21843066702011101200000) .
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine and idle it for 5 minutes or more [B]. HINT: If the engine coolant temperature does not change by 5°C (9°F) or more, the engine coolant temperature sensor is malfunctioning. It is not necessary to continue this procedure.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [C].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0116.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [D] and [E].
- Drive the vehicle at 25 mph (40 km/h) or more for a total of 5 minutes or more [D]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: In the event of the driving pattern being interrupted (possibly due to factors such as traffic conditions), the driving pattern can be resumed.
- Check the DTC judgment result again [E]. HINT: If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [D] and [E] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-425888-S21843066702011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0116) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P0116 is output A DTC P0116 and other DTCs are output B HINT: If any DTCs other than P0116 are output, troubleshoot those DTCs first. B --> See step 3 A: Go to next step
- INSPECT THERMOSTAT Remove the thermostat. Refer to «REMOVAL»(ref-426029-S36589332712011101200000) . Measure the valve opening temperature of the thermostat. Standard value 80 to 84°C (176 to 183°F) HINT: In addition to the above check, confirm that the valve is completely closed when the temperature is below the standard. Reinstall the thermostat. Refer to «INSTALLATION»(ref-426029-S41342633892011101200000) . NG --> See step 4 OK --> See step 5
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-425888-S24994798172011101200000)
- REPLACE THERMOSTAT. Refer to «REMOVAL»(ref-426029-S36589332712011101200000)
- REPLACE ENGINE COOLANT TEMPERATURE SENSOR. Refer to «REMOVAL»(ref-426060-S19018012212011101200000)
| Related DTCs | P011B: Engine coolant temperature / Intake air temperature sensor correlation |
| Required Sensors/Components (Main) | Engine coolant temperature Intake air temperature sensor |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Once per driving cycle |
| Duration | |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| The monitor will run whenever these DTCs are not present | None |
| Both of the following conditions are met | Conditions 1 and 2 |
| 1. All of the following conditions are met | Conditions (a), (b), (c) and (d) |
| (a) After ignition switch ON and engine not running time | Less than 20 seconds |
| (b) Soak Time | 7 hours or more |
| (c) Battery voltage | 10.5 V or more |
| (d) Time after engine start | 39 seconds or more |
| 2. Either of the following conditions is met | Condition (e) and (f) |
| (e) Minimum intake air temperature after engine start | 10°C (14°F) or more |
| (f) Engine coolant temperature before engine start | 10°C (14°F) or more |
| Deviated engine coolant temperature and intake air temperature | Less than -20°C (-36°F) or more than 20°C (36°F) |
Scheme 200
Scheme 200: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation). Refer to «DTC CHECK / CLEAR»(ref-425888-S21843066702011101200000) [A].
- Turn the ignition switch off.
- With the engine stopped, leave the vehicle as is for 7.5 hours or more [B].
- Start the engine and wait 60 seconds or more [C].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [D].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P011B.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [A] through [D] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-425888-S21843066702011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO P011B) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read DTCs. Result Result Proceed to DTC P011B is output A DTC P011B and other DTCs are output B HINT: If any DTCs other than P011B are output, troubleshoot those DTCs first. B --> See step 4 A: Go to next step
- READ VALUE USING TECHSTREAM (INTAKE AIR TEMPERATURE) Leave the vehicle for 7 hours or more. HINT: It is necessary leave the vehicle for 7 hours or more to allow conditions similar to the DTC detection conditions. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Intake Air. Read the value displayed on the Techstream. OK The difference between the intake air temperature and the actual outside air temperature is within 10°C (18°F). HINT: Temperature readings on the vehicle's outside temperature gauge (if equipped) are not suitable for comparing to the intake air temperature reading. The outside temperature gauge has a significant delay built in to prevent temperature swings from being displayed on its display. Use an accurate thermometer to determine the outside air temperature. NG --> See step 5 OK: Go to next step
- READ VALUE USING TECHSTREAM (COOLANT TEMPERATURE) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Coolant Temp. Read the value displayed on the Techstream. OK The difference between the coolant temperature and the actual outside air temperature is within 10°C (18°F). HINT: If the result is not as specified, check if there are heat sources such as a block heater in the engine compartment. NG --> See step 7 OK --> See step 6
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-425888-S24994798172011101200000)
- REPLACE MASS AIR FLOW METER. Refer to «REMOVAL»(ref-426060-S22042440052011101200000)
- REPLACE ECM. Refer to «REMOVAL»(ref-426060-S19785503332011101200000)
- REPLACE ENGINE COOLANT TEMPERATURE SENSOR. Refer to «REMOVAL»(ref-426060-S19018012212011101200000)
| Related DTCs | P0120: Throttle position sensor 1 range check (Chattering) P0121: Throttle position sensor rationality P0122: Throttle position sensor 1 range check (Low voltage) P0123: Throttle position sensor 1 range check (High voltage) P0220: Throttle position sensor 2 range check (Chattering) P0222: Throttle position sensor 2 range check (Low voltage) P0223: Throttle position sensor 2 range check (High voltage) P2135: Throttle position sensor range check (Correlation) |
| Required Sensors/Components (Main) | Throttle position sensor |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 2 seconds: P0120, P0122, P0123, P0220, P0222 and P0223 Within 2 seconds: P0121 0.5 seconds: P2135 Case 1 0.4 seconds: P2135 Case 2 |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not present | None |
| Either of following conditions A or B is met | |
| A. Ignition switch ON | 0.012 seconds or more |
| B. Electronic throttle actuator power | On |
P0120, P0122, P0123, P0220, P0222, P0223, P2135
| Either of following conditions A or B set | |
| A. Ignition switch | ON |
| B. Electric throttle motor power | On |
| Throttle position sensor malfunction (P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135) | Not detected |
| VTA1 voltage | 0.2 V or less, or 4.54 V or more |
| Either of following conditions set | |
| Difference of throttle position sensor voltage between VTA1 and (VTA2 x 0.8) | More than 1.6 V |
| Difference of throttle position sensor voltage between VTA1 and (VTA2 x 0.8) | Less than 0.8 V |
| VTA1 voltage | 0.2 V or less |
| VTA1 voltage | 4.54 V or more |
| Either of the following conditions is met | |
| VTA2 voltage | 1.75 V or less |
| VTA2 voltage when VTA1 0.2 V or more, and 2.02 V or less | 4.8 V or more |
| VTA2 voltage | 1.75 V or less |
| VTA2 voltage when VTA1 0.2 V or more, and 2.02 V or less | 4.8 V or more |
| Difference between VTA1 and VTA2 voltages | 0.02 V or less |
| VTA1 voltage | 0.2 V or less |
| VTA2 voltage | 1.75 V or less |
| VTA1 voltage | 0.2 to 4.54 V |
| VTA2 voltage | 1.75 to 4.8 V |
Scheme 201
Scheme 201: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation). Refer to «DTC CHECK / CLEAR»(ref-425888-S21843066702011101200000) .
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine.
- With the vehicle stationary, fully depress and release the accelerator pedal [B].
- Idle the engine for 2 seconds or more [C].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [D].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0120, P0121, P0122, P0123, P0220, P0222, P0223 or P2135.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [B] through [D] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-425888-S21843066702011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
FAIL-SAFE
When any of these DTCs, as well as other DTCs relating to electronic throttle control system malfunctions, are set, the ECM enters fail-safe mode. During fail-safe mode, the ECM cuts the current to the throttle actuator, and the throttle valve is returned to a 5.5° throttle angle by the return spring. The ECM then adjusts the engine output by controlling the fuel injection (intermittent fuel-cut) and ignition timing, in accordance with the accelerator pedal angle, to allow the vehicle to continue at a minimal speed. If the accelerator pedal is depressed firmly and gently, the vehicle can be driven slowly.
Fail-safe mode continues until a pass condition is detected, and the ignition switch is then turned off.
Scheme 202
Scheme 202: WIRING DIAGRAM
| Related DTCs | P0125: Insufficient engine coolant temperature for closed-loop fuel control |
| Required Sensors/Components (Main) | Engine coolant temperature sensor Thermostat Cooling system |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Once per driving cycle |
| Duration | 65 seconds: Engine coolant temperature at engine start -8.33°C (17.01°F) or more 129 seconds: Engine coolant temperature at engine start -19.44 to -8.33°C (-2.99 to 17.01°F) 1200 seconds: Engine coolant temperature at engine start less than -19.44°C (-2.99°F) |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not present | None |
| Thermostat fail (P0128) | Not detected |
| Intake air temperature sensor circuit fail (P0112, P0113) | Not detected |
| Engine coolant temperature sensor circuit fail (P0115, P0117, P0118) | Not detected |
| Mass air flow meter circuit fail (P0101, P0102, P0103) | Not detected |
| Time until actual engine coolant temperature reaches closed-loop fuel control enabling temperature | 65 seconds: Engine coolant temperature at engine start -8.33°C (17.01°F) or more 129 seconds: Engine coolant temperature at engine start -19.44 to -8.33°C (-2.99 to 17.01°F) 1200 seconds: Engine coolant temperature at engine start less than -19.44°C (-2.99°F) |
- Leave the vehicle outside overnight.
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Enter the following menus: Powertrain / Engine and ECT / Data List / Coolant Temp.
- Check that the engine coolant temperature is 10°C (50°F) or less.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation). Refer to «DTC CHECK / CLEAR»(ref-425888-S21843066702011101200000) .
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on.
- Start the engine.
- Wait 21 minutes or more.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0125.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-425888-S21843066702011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0125) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P0125 is output A DTC P0125 and other DTCs are output B HINT: If any DTCs other than P0125 are output, troubleshoot those DTCs first. B --> See step 4 A: Go to next step
- INSPECT THERMOSTAT Remove the thermostat. Refer to «REMOVAL»(ref-426029-S36589332712011101200000) . Check the valve opening temperature of the thermostat. Standard value 80 to 84°C (176 to 183°F) HINT: In addition to the above check, confirm that the valve is completely closed when the temperature is below the standard. Reinstall the thermostat. Refer to «INSTALLATION»(ref-426029-S41342633892011101200000) . NG --> See step 5 OK: Go to next step
- CHECK COOLING SYSTEM Check for defects in the cooling system that might cause the system to be too cold, such as abnormal radiator fan operation or any modifications. NG --> See step 6 OK --> See step 7
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-425888-S24994798172011101200000)
- REPLACE THERMOSTAT. Refer to «REMOVAL»(ref-426029-S36589332712011101200000)
- REPAIR OR REPLACE COOLING SYSTEM. Refer to «ON-VEHICLE INSPECTION»(ref-426065-S37954669082011101200000)
- REPLACE ENGINE COOLANT TEMPERATURE SENSOR. Refer to «REMOVAL»(ref-426060-S19018012212011101200000)
| Related DTCs | P0128: Coolant Thermostat |
| Required Sensors/Components (Main) | Thermostat Engine coolant temperature sensor |
| Required Sensors/Components (Related) | Intake air temperature sensor Vehicle speed sensor |
| Frequency of Operation | Once per driving cycle |
| Duration | 900 seconds |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not present | P0010 (VVT Oil Control Valve) P0011 (VVT System - Advance) P0012 (VVT System - Retard) P0013 (Exhaust VVT Oil Control Valve) P0014 (Exhaust VVT System - Advance) P0015 (Exhaust VVT System - Retard) P0016 (VVT System - Misalignment) P0017 (Exhaust VVT System - Misalignment) P0031, P0032 (Air Fuel Ratio Sensor Heater - Sensor 1) P0102, P0103 (Mass Air Flow Meter) P0112, P0113 (Intake Air Temperature Sensor) P0115, P0117, P0118 (Engine Coolant Temperature Sensor) P0120, P0121 P0122, P0123, P0220, P0222, P0223, P2135 (Throttle Position Sensor) P0171, P0172 (Fuel System) P0301, P0302, P0303, P0304 (Misfire) P0335 (Crankshaft Position Sensor) P0340, P0342, P0343 (Camshaft Position Sensor) P0351, P0352, P0353, P0354 (Igniter) P0365, P0367, P0368 (Exhaust Camshaft Position Sensor) P0500 (Vehicle Speed Sensor) P2195, P2196, P2237, P2238, P2239, P2252, P2253, P2A00 (Air Fuel Ratio Sensor - Sensor 1) P219A (Air Fuel Ratio Imbalance) |
| Battery voltage | 11 V or more |
| Either of following conditions 1 or 2 is met | |
| 1. All of following conditions are met | |
| Engine coolant temperature at engine start - Intake air temperature at engine start | 15 to 7°C (-27 to 12.6°F) |
| Engine coolant temperature at engine start | 10 to 56°C (14 to 133°F) |
| Intake air temperature at engine start | 10 to 56°C (14 to 133°F) |
| 2. All of following conditions are met | |
| Engine coolant temperature at engine start - Intake air temperature at engine start | More than 7°C (12.6°F) |
| Engine coolant temperature at engine start | 56°C (133°F) or less |
| Intake air temperature at engine start | 10°C (14°F) or more |
| Accumulated time at 80 mph (128 km/h) or more of vehicle speed | Less than 20 seconds |
| Duration that both of following conditions (a) and (b) are met | 5 seconds or more |
| (a) Estimated engine coolant temperature | 75°C (167°F) or more |
| (b) Engine coolant temperature sensor output | Below 75°C (167°F) |
Scheme 203
Scheme 203: CONFIRMATION DRIVING PATTERN
- Stop the engine and allow it to soak.
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Enter the following menus: Powertrain / Engine and ECT / Data List / All Data / Coolant Temp and Intake Air.
- Check that "Coolant Temp" is 56°C (133°F) or less and "Intake Air" is between 0 and 35°C (32 and 95°F).
- Set the heater to MAX HOT with fresh air mode selected and turn the A/C off.
- Start the engine and drive the vehicle at 50 mph (80 km/h) for 15 minutes [B]. HINT: Data can be captured relatively easily by using the snapshot function in the Data List. Enter the following menus: Data List / Function / Snap-shot configuration / Record time / 5 min. Data capture can be started by using the target point function. For example, setting the target point to an engine speed of 4000 RPM and then racing the engine, etc. to raise the engine speed to a speed of 4000 RPM or more will cause data capture to start.
- After "Coolant Temp" stabilizes, check that "Coolant Temp" is 75°C (167°F) or higher [C]. HINT: If "Coolant Temp" is below 75°C (167°F) while driving the vehicle at 50 mph (80 km/h), inspect the cooling system and thermostat.
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0128) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P0128 is output A DTC P0128 and other DTCs are output B HINT: If any DTCs other than P0128 are output, troubleshoot those DTCs first. B --> See step 4 A: Go to next step
- CHECK COOLING SYSTEM Check for defects in the cooling system that might cause the system to be too cold, such as abnormal radiator fan operation or any modifications. NG --> REPAIR OR REPLACE COOLING SYSTEM OK: Go to next step
- INSPECT THERMOSTAT Remove the thermostat. Refer to «REMOVAL»(ref-426029-S36589332712011101200000) . Measure the valve opening temperature of the thermostat. Standard value 80 to 84°C (176 to 183°F) HINT: In addition to the above check, confirm that the valve is completely closed when the temperature is below the standard. Reinstall the thermostat. Refer to «INSTALLATION»(ref-426029-S41342633892011101200000) . NG --> See step 5 OK --> See step 6
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-425888-S24994798172011101200000)
- REPLACE THERMOSTAT. Refer to «REMOVAL»(ref-426029-S36589332712011101200000)
- REPLACE ECM. Refer to «REMOVAL»(ref-426060-S19785503332011101200000)
| Related DTCs | P0136: Heated oxygen sensor output voltage (Output voltage) P0136: Heated oxygen sensor impedance (Low) P0137: Heated oxygen sensor output voltage (Low voltage) P0137: Heated oxygen sensor impedance (High) P0138: Heated oxygen sensor output voltage (Extremely high) P0139: Heated oxygen sensor output voltage during fuel cut |
| Required Sensors/Components (Main) | Heated oxygen sensor (sensor 2) |
| Required Sensors/Components (Related) | Crankshaft position sensor Engine coolant temperature sensor Mass air flow meter Throttle position sensor |
| Frequency of Operation | Once per driving cycle: Active air fuel ratio control detection, Heated oxygen sensor output voltage during fuel cut Continuous: Other |
| Duration | 90 seconds: Heated oxygen sensor impedance (High) 30 seconds: Heated oxygen sensor impedance (Low) 20 seconds: Heated oxygen sensor output (Output voltage, Low voltage) 10 seconds: Heated oxygen sensor voltage (Extremely high) 7 seconds: Heated oxygen sensor voltage during fuel cut |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not present | P0016 (VVT System - Misalignment) P0017 (Exhaust VVT System - Misalignment) P0031, P0032 (Air Fuel Ratio Sensor Heater - Sensor 1) P0037, P0038 (Heated Oxygen Sensor Heater - Sensor 2) P0102, P0103 (Mass Air Flow Meter) P0112, P0113 (Intake Air Temperature Sensor) P0115, P0117, P0118 (Engine Coolant Temperature Sensor) P0120, P0121 P0122, P0123, P0220, P0222, P0223, P2135 (Throttle Position Sensor) P0125 (Insufficient Engine Coolant Temperature for Closed Loop Fuel Control) P0128 (Thermostat) P0171, P0172 (Fuel System) P0301, P0302, P0303, P0304 (Misfire) P0335 (Crankshaft Position Sensor) P0340 (Camshaft Position Sensor) P0451, P0452, P0453 (EVAP System) P0500 (Vehicle Speed Sensor) P2195, P2196, P2237, P2238, P2239, P2252, P2253, P2A00 (Air Fuel Ratio Sensor - Sensor 1) P219A (Air Fuel Ratio Imbalance) |
| Catalyst monitor precondition | Met |
| Catalyst monitor precondition defined as when all of following conditions met | |
| Battery voltage | 11 V or more |
| Intake air temperature | 10°C (140°F) or more |
| Engine coolant temperature | 75°C (167°F) or more |
| Atmospheric pressure | 76 kPa (570 mmHg) or more |
| Idle | Off |
| Engine speed | Less than 4000 RPM |
| Air fuel ratio sensor | Activated |
| Fuel system status | Closed loop |
| Engine load | 10 to 80% |
HEATED OXYGEN SENSOR OUTPUT VOLTAGE (OUTPUT VOLTAGE AND LOW VOLTAGE)
| Battery voltage | 11 V or more |
| Estimated oxygen sensor temperature | Less than 700°C (1292°F) |
| ECM monitor | Completed |
| DTC P0607 | Not set |
HEATED OXYGEN SENSOR IMPEDANCE (LOW)
| Battery voltage | 11 V or more |
| Estimated oxygen sensor temperature | 450 to 750°C (842 to 1382°F) or higher |
| DTC P0607 | Not set |
HEATED OXYGEN SENSOR IMPEDANCE (HIGH)
| Battery voltage | 11 V or more |
| Time after engine start | 2 seconds or more |
HEATED OXYGEN SENSOR OUTPUT VOLTAGE (EXTREMELY HIGH)
| Engine coolant temperature | 75°C (167°F) or more |
| Catalyst temperature | 400°C (752°F) or more |
| Fuel cut | On |
HEATED OXYGEN SENSOR VOLTAGE DURING FUEL-CUT
| All of following conditions (a), (b) and (c) met | |
| (a) Commanded air fuel ratio | 14.2 or less |
| (b) Heated oxygen sensor voltage | 0.21 to 0.59 V |
| (c) Oxygen storage capacity of catalyst | 2 g or more |
HEATED OXYGEN SENSOR OUTPUT VOLTAGE (OUTPUT VOLTAGE)
| All of following conditions (a), (b) and (c) met | |
| (a) Commanded air fuel ratio | 14.2 or less |
| (b) Heated oxygen sensor voltage | Less than 0.21 V |
| (c) Oxygen storage capacity of catalyst | 2 g or more |
HEATED OXYGEN SENSOR OUTPUT VOLTAGE (LOW OUTPUT VOLTAGE)
| Duration of following condition | 30 seconds or more |
| Heated oxygen sensor impedance | Less than 5 ohms |
HEATED OXYGEN SENSOR IMPEDANCE (LOW)
| Duration of following condition | 90 seconds or more |
| Heated oxygen sensor impedance | 15 kohms or more |
HEATED OXYGEN SENSOR IMPEDANCE (HIGH)
| Duration of following condition | 10 seconds or more |
| Heated oxygen sensor voltage | 1.2 V or more |
HEATED OXYGEN SENSOR OUTPUT VOLTAGE (EXTREMELY HIGH)
| Duration until rear heated oxygen sensor voltage drops to 0.2 V after fuel cut | 7 seconds or more |
| Duration until rear heated oxygen sensor voltage drops to from 0.35 to 0.2 V after fuel cut | 1 second or more |
HEATED OXYGEN SENSOR VOLTAGE DURING FUEL-CUT
| Duration of following condition | 30 seconds or more |
| Heated oxygen sensor voltage | Varies between 0.1 V and 0.9 V |
Refer to Checking Monitor Status. Refer to CHECKING MONITOR STATUS .
Scheme 204
Scheme 204: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation). Refer to «DTC CHECK / CLEAR»(ref-425888-S21843066702011101200000) .
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher [B].
- With the transaxle in 4th gear or higher, drive the vehicle at a speed between 37 and 75 mph (60 and 120 km/h) for 10 minutes or more [C]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [D].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0136, P0137 or P0138.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [C] through [D].
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-425888-S21843066702011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 205
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation). Refer to «DTC CHECK / CLEAR»(ref-425888-S21843066702011101200000) .
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher [B].
- Drive the vehicle at 37 mph (60 km/h), and then decelerate the vehicle by releasing the accelerator pedal for 5 seconds or more to perform the fuel-cut [C]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [D].
- Read the pending DTCs. HINT: If a pending DTC or current DTC is output, the system is malfunctioning. If a pending DTC or current DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0139.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, shift the transaxle to 2nd gear, and then perform steps [C] and [D] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-425888-S21843066702011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 206
Scheme 206: WIRING DIAGRAM
| Related DTCs | P0171: Fuel trim lean P0172: Fuel trim rich |
| Required Sensors/Components (Main) | Fuel system |
| Required Sensors/Components (Related) | Air fuel ratio sensor Mass air flow meter Crankshaft position sensor |
| Frequency of Operation | Continuous |
| Duration | Within 10 seconds |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not present | P0010 (VVT Oil Control Valve) P0011 (VVT System - Advance) P0012 (VVT System - Retard) P0013 (Exhaust VVT Oil Control Valve) P0014 (Exhaust VVT System - Advance) P0015 (Exhaust VVT System - Retard) P0016 (VVT System - Misalignment) P0017 (Exhaust VVT System - Misalignment) P0031, P0032 (Air Fuel Ratio Sensor Heater - Sensor 1) P0102, P0103 (Mass Air Flow Meter) P0115, P0117, P0118 (Engine Coolant Temperature Sensor) P0120, P0121 P0122, P0123, P0220, P0222, P0223, P2135 (Throttle Position Sensor) P0125 (Insufficient Engine Coolant Temperature for Closed Loop Fuel Control) P0335 (Crankshaft Position Sensor) P0340, P0342, P0343 (Camshaft Position Sensor) P0351, P0352, P0353, P0354 (Igniter) P0365, P0367, P0368 (Exhaust Camshaft Position Sensor) P0500 (Vehicle Speed Sensor) P219A (Air Fuel Ratio Imbalance) |
| Fuel system status | Closed-loop |
| Battery voltage | 11 V or more |
| Either of following conditions 1 or 2 set | |
| 1. Engine speed | Less than 720 RPM |
| 2. Engine load | 13% or more |
| Catalyst monitor | No executed |
| EVAP purge-cut | Executing |
| Either of following conditions 1 or 2 met | |
| 1. Average between short-term fuel trim and long-term fuel trim | 35% or more (varies with engine coolant temperature) |
| 2. Average between short-term fuel trim and long-term fuel trim | 35% or less (varies with engine coolant temperature) |
Scheme 207
Scheme 207: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation). Refer to «DTC CHECK / CLEAR»(ref-425888-S21843066702011101200000) .
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine and warm it up until the engine coolant temperature is 75°C (167°F) or higher with all the accessories switched off [B].
- With the engine warmed up, idle the engine for 2 minutes or more [C].
- Drive the vehicle at a speed between 37 and 84 mph (60 and 135 km/h) for 5 minutes or more [D]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [E].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-425888-S21843066702011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0171 OR P0172) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P0171 or P0172 is output A DTC P0171 or P0172 and other DTCs are output B HINT: If any DTCs other than P0171 or P0172 are output, troubleshoot those DTCs first. B --> See step 22 A: Go to next step
- CHECK PCV HOSE CONNECTIONS Inspect the PCV hose connections. Refer to «ON-VEHICLE INSPECTION»(ref-426062-S30607190082011101200000) . OK PCV hose is connected correctly and is not damaged. NG --> REPAIR OR REPLACE PCV HOSE OK: Go to next step
- CHECK INTAKE SYSTEM Check the intake system for vacuum leaks. Refer to «ON-VEHICLE INSPECTION»(ref-426062-S30607190082011101200000) . OK No leaks in intake system. NG --> REPAIR OR REPLACE INTAKE SYSTEM OK: Go to next step
- PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE INJECTION VOLUME) Connect the Techstream to the DLC3. Start the engine. Turn the Techstream on. Warm up the engine and run the engine at an engine speed of 2500 RPM for approximately 90 seconds. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the Injection Volume / Data List / All Data / AFS Voltage B1S1 and O2S B1S2. Perform the Control the Injection Volume operation with the engine idling. Monitor the output voltages of the air fuel ratio and heated oxygen sensors (AFS Voltage B1S1 and O2S B1S2) displayed on the Techstream. HINT: Change the fuel injection volume within the range of -12.0% to +12.0%. The injection volume can be changed in fine gradations. The air fuel ratio sensor has an output delay of a few seconds and the heated oxygen sensor has a maximum output delay of approximately 20 seconds. If there is almost no response from the air fuel ratio sensor, a malfunction of the air fuel ratio sensor is suspected. Techstream Display (Sensor) Injection Volume Status Voltage AFS Voltage B1S1 (Air fuel ratio) +12% Rich Below 3.1 V -12% Lean Higher than 3.4 V O2S B1S2 (Heated oxygen) +12% Rich Higher than 0.55 V -12% Lean Below 0.4 V RESULT Status of AFS Voltage B1S1 Status of O2S B1S2 Air Fuel Ratio Condition and Air Fuel Ratio Sensor Condition Misfire Suspected Trouble Area Proceed to Lean/Rich Lean/Rich Normal - - A Lean Lean Actual air fuel ratio lean May occur PCV valve and hose PCV hose connections Fuel injector assembly blockage Gas leaks from exhaust system Intake system Fuel pressure Mass air flow meter assembly Engine coolant temperature sensor A Rich Rich Actual air fuel ratio rich - Fuel injector assembly leakage or blockage Gas leaks from exhaust system Ignition system Fuel pressure Mass air flow meter assembly Engine coolant temperature sensor A Lean Lean/Rich Air fuel ratio sensor malfunction - Air fuel ratio sensor B Rich Lean/Rich Air fuel ratio sensor malfunction - Air fuel ratio sensor B Lean: During the Control the Injection Volume Active Test, the air fuel ratio sensor output voltage (AFS Voltage) is consistently higher than 3.4 V, and the heated oxygen sensor output voltage (O2S) is consistently below 0.4 V. Rich: During the Control the Injection Volume Active Test, the AFS Voltage is consistently below 3.1 V, and the O2S is consistently higher than 0.55 V. Lean/Rich: During the Control the Injection Volume Active Test, the output voltage of the heated oxygen sensor alternates correctly. HINT: Refer to "Data List / Active Test" [AFS Voltage B1S1 and O2S B1S2]. Refer to «DATA LIST / ACTIVE TEST»(ref-425888-S33770332412011101200000) . B --> See step 11 A: Go to next step
- READ VALUE USING TECHSTREAM (COOLANT TEMP) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Coolant Temp. Read the Coolant Temp twice, when the engine is both cold and warmed up. Standard value With cold engine: Same as ambient air temperature. With warm engine: Between 75 and 100°C (167 and 212°F). NG --> See step 23 OK: Go to next step
- READ VALUE USING TECHSTREAM (MAF) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / All Data / MAF and Coolant Temp. Allow the engine to idle until Coolant Temp reaches 75°C (167°F) or higher. Read MAF with the engine speed at 3000 RPM. Standard Between 5 gm/sec and 10 gm/sec (Shift lever: Neutral; A/C: Off). NG --> See step 16 OK: Go to next step
- CHECK FUEL PRESSURE Check the fuel pressure. Refer to «ON-VEHICLE INSPECTION - Step 2»(ref-426066-S40052748752011101200000) . NG --> REPAIR OR REPLACE FUEL SYSTEM OK: Go to next step
- CHECK FOR EXHAUST GAS LEAK Check for exhaust gas leaks. OK No gas leaks. NG --> REPAIR OR REPLACE EXHAUST SYSTEM OK: Go to next step
- CHECK FOR SPARK AND IGNITION See step 8 NG --> REPAIR OR REPLACE IGNITION SYSTEM OK: Go to next step
- INSPECT FUEL INJECTOR ASSEMBLY (INJECTION AND VOLUME) Check the inspection and volume. Refer to «INSPECTION»(ref-426061-S07944050932011101200000) . NG --> See step 24 OK --> See step 15
- INSPECT AIR FUEL RATIO SENSOR (HEATER RESISTANCE) See step 1 NG --> See step 25 OK: Go to next step
- CHECK TERMINAL VOLTAGE (+B OF AIR FUEL RATIO SENSOR) See step 2 NG --> See step 21 OK: Go to next step
- CHECK HARNESS AND CONNECTOR (AIR FUEL RATIO SENSOR - ECM) See step 3 NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (AIR FUEL RATIO SENSOR - ECM) OK: Go to next step
- REPLACE AIR FUEL RATIO SENSOR Replace the air fuel ratio sensor. Refer to «REMOVAL»(ref-426060-S40759590382011101200000) . NEXT: Go to next step
- PERFORM CONFIRMATION DRIVING PATTERN Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-425888-S21843066702011101200000) . Turn the ignition switch off. Turn the ignition switch to ON and turn the Techstream on. Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P0171 or P0172 is output A DTC is not output B B --> END A: Go to next step
- CHECK HARNESS AND CONNECTOR Check the connection and terminal contact pressure of connectors and wire harness between the mass air flow meter and ECM. Refer to «ELECTRONIC CIRCUIT INSPECTION PROCEDURE»(ref-425882-S02362041192011101200000) . HINT: Repair any problems. NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS (DTC P0171 OR P0172) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-425888-S21843066702011101200000) . Turn the ignition switch off. Turn the ignition switch to ON and turn the Techstream on. Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P0171 or P0172 is output A DTC is not output B B --> END A: Go to next step
- CHECK HARNESS AND CONNECTOR (MASS AIR FLOW METER - ECM) Disconnect the mass air flow meter connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for Open) Tester Connection Condition Specified Condition B2-5 (VG) - B31-69 (VG) Always Below 1 ohms B2-4 (E2G) - B31-92 (E2G) Always Below 1 ohms Standard Resistance (Check for Short) Tester Connection Condition Specified Condition B2-5 (VG) or B31-69 (VG) - Body ground Always 10 kohms or higher Reconnect the mass air flow meter connector. Reconnect the ECM connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (MASS AIR FLOW METER - ECM) OK: Go to next step
- REPLACE MASS AIR FLOW METER Replace the mass air flow meter. Refer to «REMOVAL»(ref-426060-S22042440052011101200000) . HINT: If the result of the inspection performed in step 6 indicated no problem, proceed to the next step without replacing the mass air flow meter. NEXT: Go to next step
- CONFIRM WHETHER MALFUNCTION HAS BEEN SUCCESSFULLY REPAIRED Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-425888-S21843066702011101200000) . Turn the ignition switch off. Turn the ignition switch to ON and turn the Techstream on. Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Result Result Proceed to DTC is not output A DTC P0171 or P0172 is output B B --> See step 26 A --> END
- INSPECT FUSE (EFI NO. 2 FUSE) See step 5 NG --> REPLACE FUSE (EFI NO. 2 FUSE) OK --> REPAIR OR REPLACE HARNESS OR CONNECTOR (INTEGRATION RELAY (EFI MAIN RELAY) - AIR FUEL RATIO SENSOR)
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-425888-S24994798172011101200000)
- REPLACE ENGINE COOLANT TEMPERATURE SENSOR. Refer to «REMOVAL»(ref-426060-S19018012212011101200000)
- REPLACE FUEL INJECTOR ASSEMBLY. Refer to «REMOVAL»(ref-426061-S25769925372011101200000)
- REPLACE AIR FUEL RATIO SENSOR. Refer to «REMOVAL»(ref-426060-S40759590382011101200000)
- REPLACE ECM. Refer to «REMOVAL»(ref-426060-S19785503332011101200000)
Scheme 208
When the engine misfires, high concentrations of hydrocarbons (HC) enter the exhaust gas. High HC concentration levels can cause an increase in exhaust emission levels. Extremely high concentrations of HC can also cause increases in the three-way catalytic converter temperature, which may cause damage to the three-way catalytic converter. To prevent this increase in emissions and to limit the possibility of thermal damage, the ECM monitors the misfire rate. When the temperature of the three-way catalytic converter reaches the point of thermal degradation, the ECM blinks the MIL. To monitor misfires, the ECM uses both the Camshaft Position (CMP) sensor and the Crankshaft Position (CKP) sensor. The camshaft position sensor is used to identify any misfiring cylinders and the crankshaft position sensor is used to measure variations in the crankshaft rotation speed. Misfires are counted when the crankshaft rotation speed variations exceed predetermined thresholds. If the misfire count exceeds the threshold levels, and could cause emission control system performance deterioration, the ECM illuminates the MIL and sets a DTC.
| DTC No. | DTC Detection Condition | Trouble Area |
| P0300 | Simultaneous misfiring of several cylinders occurs and one of the following conditions below is detected (2 trip detection logic): High temperature misfire occurs in three-way catalytic converter (MIL blinks) Emission deterioration misfire occurs (MIL illuminates) | Open or short in engine wire harness Connector connection Vacuum hose connections Ignition system Fuel injector Fuel pressure Mass air flow meter Engine coolant temperature sensor Compression pressure Valve timing PCV valve and hose PCV hose connections Intake system ECM |
| P0301 P0302 P0303 P0304 | Misfiring of specific cylinder occurs and one of the following conditions below is detected (2 trip detection logic): High temperature misfire occurs in three-way catalytic converter (MIL blinks) Emission deterioration misfire occurs (MIL illuminates) |
When DTCs for misfiring cylinders are randomly set, but DTC P0300 is not set, it indicates that misfires have been detected in different cylinders at different times. DTC P0300 is only set when several misfiring cylinders are detected at the same time.
| Related DTCs | P0300: Multiple cylinder misfire P0301: Cylinder 1 misfire P0302: Cylinder 2 misfire P0303: Cylinder 3 misfire P0304: Cylinder 4 misfire |
| Required Sensors/Components (Main) | Crankshaft position sensor Camshaft position sensor |
| Required Sensors/Components (Related) | Engine coolant temperature Intake air temperature sensor Mass air flow meter |
| Frequency of Operation | Continuous |
| Duration | 1000 to 4000 crankshaft revolutions: Emission related misfire 200 to 600 crankshaft revolutions: Catalyst damaging misfire |
| MIL Operation | 2 driving cycles: Emission related misfire MIL flashes immediately: Catalyst damaging misfire |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not present | P0016 (VVT System - Misalignment) P0017 (Exhaust VVT System - Misalignment) P0102, P0103 (Mass Air Flow Meter) P0112, P0113 (Intake Air Temperature Sensor) P0115, P0117, P0118 (Engine Coolant Temperature Sensor) P0120, P0121 P0122, P0123, P0220, P0222, P0223, P2135 (Throttle Position Sensor) P0125 (Insufficient Engine Coolant Temperature for Closed Loop Fuel Control) P0327, P0328 (Knock Sensor) P0335 (Crankshaft Position Sensor) P0340 (Camshaft Position Sensor) P0351, P0352, P0353, P0354 (Igniter) P0500 (Vehicle Speed Sensor) |
| Battery voltage | 8 V or more |
| VVT system | Not operated by scan tool |
| Engine speed | 450 to 6400 RPM |
| Either of following conditions (a) or (b) met | |
| (a) Engine coolant temperature at engine start | More than -7°C (19°F) |
| (b) Engine coolant temperature | More than 20°C (68°F) |
| Fuel cut | Off |
| First 1000 revolutions after engine start, or Check Mode | Crankshaft 1000 revolutions |
| Except above | Crankshaft 1000 revolutions x 4 |
MONITOR PERIOD OF EMISSION-RELATED MISFIRE
| All of following conditions 1, 2 and 3 met | Crankshaft 200 revolutions x 3 |
| 1. Driving cycles | 1st |
| 2. Check mode | Off |
| 3. Engine speed | Less than 2450 RPM |
| Except above | Crankshaft 200 revolutions |
MONITOR PERIOD OF CATALYST DAMAGING MISFIRE (MIL BLINKS)
| The monitor will run whenever these DTCs are not present | P0016 (VVT System - Misalignment) P0017 (Exhaust VVT System - Misalignment) P0102, P0103 (Mass Air Flow Meter) P0112, P0113 (Intake Air Temperature Sensor) P0115, P0117, P0118 (Engine Coolant Temperature Sensor) P0120, P0121 P0122, P0123, P0220, P0222, P0223, P2135 (Throttle Position Sensor) P0327, P0328 (Knock Sensor) P0335 (Crankshaft Position Sensor) P0340 (Camshaft Position Sensor) P0351, P0352, P0353, P0354 (Igniter) P0500 (Vehicle Speed Sensor) |
| Battery voltage | 8 V or more |
| VVT system | Not operated by scan tool |
| Engine speed | 450 to 4500 RPM |
| Engine coolant temperature sensor | More than 65°C (149°F) |
| Fuel cut | Off |
MISFIRE: FOR MEXICO MODELS
| First 1000 revolutions after engine start, or check mode | Crankshaft 1000 revolutions |
| Except above | Crankshaft 1000 revolutions x 4 |
MONITOR PERIOD OF EMISSION-RELATED-MISFIRE: FOR MEXICO MODELS
| All of following conditions 1, 2 and 3 met | Crankshaft 200 revolutions |
| 1. Driving cycles | 1st |
| 2. Check mode | Off |
| Except above | Crankshaft 200 revolutions x 3 |
MONITOR PERIOD OF CATALYST-DAMAGED-MISFIRE (MIL BLINKS): FOR MEXICO MODELS
MONITOR PERIOD OF EMISSION RELATED MISFIRE
| Number of misfire per 200 revolutions | 124 or more (varies with intake air amount per engine speed) |
MONITOR PERIOD OF CATALYST DAMAGING MISFIRE (MIL BLINKS)
| Misfire rate | 50.0 % or more: for 1st 2000 revolutions 25.0 % or more: after 1st 2000 revolutions |
MONITOR PERIOD OF EMISSION-RELATED-MISFIRE: FOR MEXICO MODELS
| Number of misfire per 200 revolutions | 94 or more (varies with intake air amount and engine speed) |
| Paired cylinder misfire (MIL blinks immediately) | Detected |
MONITOR PERIOD OF CATALYST-DAMAGED-MISFIRE (MIL BLINKS): FOR MEXICO MODELS
Refer to Checking Monitor Status. Refer to CHECKING MONITOR STATUS .
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON.
- Turn the Techstream on.
- Record the DTC(s) and freeze frame data.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation). Refer to «DTC CHECK / CLEAR»(ref-425888-S21843066702011101200000) .
- Using the Techstream, switch the ECM from normal mode to check mode. Refer to «CHECK MODE PROCEDURE»(ref-425888-S16400726812011101200000) .
- Read the misfire counts of each cylinder, Cylinder #1 Misfire Count to Cylinder #4 Misfire Count, with the engine idling. If any misfire count is displayed, skip the following confirmation driving pattern.
- Drive the vehicle several times with the conditions, such as engine RPM and engine load, shown in Misfire RPM and Misfire Load in the freeze frame data. HINT: In order to store misfire DTCs, it is necessary to operate the vehicle for the period of time shown in the table below with the engine speed and engine load the same as Misfire RPM and Misfire Load in the freeze frame data. Engine Speed Duration Idling 7.0 minutes or more 1000 4.0 minutes or more 2000 2.0 minutes or more 3000 1.5 minute or more
- Check whether misfires have occurred by checking DTCs and freeze frame data. HINT: Do not turn the ignition switch off until the stored DTC(s) and freeze frame data have been recorded. When the ECM returns to normal mode (default), the stored DTC(s), freeze frame data and other data will be erased.
- Record the DTC(s), freeze frame data and misfire counts.
- Turn the ignition switch off and wait for at least 30 seconds.
Scheme 209
Scheme 209: WIRING DIAGRAM
Scheme 210
Refer to DTC P0102. Refer to WIRING DIAGRAM .
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO MISFIRE DTCS) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P0300, P0301, P0302, P0303 and/or P0304 is output A DTC P0300, P0301, P0302, P0303 and/or P0304 and other DTCs are output B HINT: If any DTCs other than P0300, P0301, P0302, P0303 and P0304 are output, troubleshoot those DTCs first. B --> See step 39 A: Go to next step
- CHECK PCV HOSE CONNECTIONS Check the PCV hose connected. OK PCV hose is connected correctly and is not damaged. NG --> REPAIR OR REPLACE PCV HOSE OK: Go to next step
- READ VALUE USING TECHSTREAM (MISFIRE RPM AND MISFIRE LOAD) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Misfire RPM and Misfire Load. Read and note the Misfire RPM and Misfire Load values. HINT: The Misfire RPM and Misfire Load values indicate the vehicle conditions under which the misfire occurred. NEXT: Go to next step
- READ VALUE USING TECHSTREAM (CATALYST OT MF F/C) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / Catalyst OT MF F/C. Read the value displayed on the Techstream. Result Data List Techstream Display Proceed to Catalyst OT MF F/C Avail A Not Avl B B --> See step 6 A: Go to next step
- PERFORM ACTIVE TEST USING TECHSTREAM (PROHIBIT THE CATALYST OT MISFIRE PREVENT F/C) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Active Test / Prohibit the Catalyst OT Misfire prevent F/C. Perform the Active Test. NOTE: When performing the Active Test, make sure the vehicle is stopped and the engine is either idling or being revved at 3000 RPM or less. NEXT: Go to next step
- READ VALUE USING TECHSTREAM (CYLINDER #1, #2, #3 AND #4 MISFIRE COUNT) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-425888-S21843066702011101200000) . Enter the following menus: Powertrain / Engine and ECT / Data List / All Data / Cylinder #1 (to #4) Misfire Count. Allow the engine to idle. Read each value for Cylinder #1 (to #4) Misfire Count displayed on the Techstream. If no misfire counts occur in any cylinders, perform the following procedures: Move the shift lever in D (for automatic transaxle models). Drive the vehicle (for manual transaxle models). Check Cylinder #1 (to #4) Misfire Count. If misfire counts are still not displayed, perform procedure "A" and "B", and then check the misfire counts again (for automatic transaxle models). Procedure A: Drive the vehicle while satisfying the Misfire RPM and Misfire Load values noted in the "Read Value Using Techstream (Misfire RPM and Misfire Load)" procedure above. Procedure B: Read the Cylinder #1 (to #4) Misfire Count or the DTCs output on the Techstream. Result Result Proceed to Most misfires occur in only 1 or 2 cylinders A 3 cylinders or more have equal misfire counts B HINT: If it is difficult to reproduce misfires for each cylinder, check the Data List item called Misfire Margin. Try to find vehicle driving conditions that lower the Misfire Margin value. Values above 30% are considered normal. If the freeze frame data record of the engine coolant temperature is below 75°C (167°F), the misfire may be detected only when the engine is cold. If the freeze frame data record of the Engine Run Time is below 120 seconds, the misfire may be detected immediately after the engine is started. B --> See step 19 A: Go to next step
- INSPECT SPARK PLUG Inspect the spark plug of misfiring cylinder. Refer to «ON-VEHICLE INSPECTION - Step 2»(ref-426031-S14559454242011101200000) . NG --> See step 40 OK: Go to next step
- CHECK FOR SPARK AND IGNITION Perform a spark test. Refer to «ON-VEHICLE INSPECTION - Step 1»(ref-426031-S14559454242011101200000) . WARNING: Always disconnect all injector connectors. NOTE: Do not crank the engine for more than 2 seconds. OK Sparks jump across electrode gap. NG --> See step 36 OK: Go to next step
- CHECK CYLINDER COMPRESSION PRESSURE Measure the cylinder compression pressure of the misfiring cylinder. Refer to «ON-VEHICLE INSPECTION - Step 10»(ref-426025-S41300403072011101200000) . NG --> CHECK ENGINE TO DETERMINE CAUSE OF LOW COMPRESSION OK: Go to next step
- CHECK FUEL INJECTOR ASSEMBLY (POWER SOURCE). Refer to «PROCEDURE - Step 1»(ref-426057-S29886961042011101200000) NG --> See step 41 OK: Go to next step
- CHECK HARNESS AND CONNECTOR (ECM - FUEL INJECTOR). Refer to «PROCEDURE - Step 3»(ref-426057-S29886961042011101200000) NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (ECM - FUEL INJECTOR) OK: Go to next step
- CHECK FUEL INJECTOR OF MISFIRING CYLINDER Check the injector injection (whether fuel volume is high or low, and whether injection pattern is poor). Refer to «INSPECTION»(ref-426061-S07944050932011101200000) . NG --> See step 42 OK: Go to next step
- CHECK INTAKE SYSTEM Check the intake system for vacuum leaks. Refer to «ON-VEHICLE INSPECTION»(ref-426062-S30607190082011101200000) . OK No leaks in intake system. NG --> See step 43 OK: Go to next step
- CHECK FUEL PRESSURE Check the fuel pressure. Refer to «ON-VEHICLE INSPECTION - Step 2»(ref-426066-S40052748752011101200000) . NG --> See step 38 OK: Go to next step
- READ VALUE USING TECHSTREAM (COOLANT TEMP) See step 5 NG --> See step 44 OK: Go to next step
- READ VALUE USING TECHSTREAM (MAF) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / All Data / MAF and Coolant Temp. Allow the engine to idle until Coolant Temp reaches 75°C (167°F) or higher. Read MAF with the engine speed at 3000 RPM. Standard Between 5 gm/sec and 10 gm/sec (Shift lever: Neutral; A/C: Off). NG --> See step 31 OK: Go to next step
- ADJUST VALVE TIMING See step 8 NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-425888-S21843066702011101200000) . Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON and turn the Techstream on. Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness. Input the DTC: P0300, P0301, P0302, P0303 or P0304. Check the DTC judgment result. Result Result Proceed to NORMAL (DTC is not output) A ABNORMAL (DTC P0300, P0301, P0302, P0303 or P0304 is output) B B --> See step 31 A --> END
- CHECK INTAKE SYSTEM Check the intake system for vacuum leaks. Refer to «ON-VEHICLE INSPECTION»(ref-426062-S30607190082011101200000) . OK No leaks in intake system. NG --> See step 43 OK: Go to next step
- CHECK FUEL PRESSURE Check the fuel pressure. Refer to «ON-VEHICLE INSPECTION - Step 2»(ref-426066-S40052748752011101200000) . NG --> See step 38 OK: Go to next step
- READ VALUE USING TECHSTREAM (COOLANT TEMP) See step 5 NG --> See step 44 OK: Go to next step
- READ VALUE USING TECHSTREAM (MAF) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List / All Data / MAF and Coolant Temp. Allow the engine to idle until Coolant Temp reaches 75°C (167°F) or higher. Read MAF with the engine speed at 3000 RPM. Standard Between 5 gm/sec and 10 gm/sec (Shift lever: Neutral; A/C: Off). NG --> See step 31 OK: Go to next step
- INSPECT SPARK PLUG Inspect the spark plug of misfiring cylinder. Refer to «ON-VEHICLE INSPECTION - Step 2»(ref-426031-S14559454242011101200000) . NG --> See step 40 OK: Go to next step
- CHECK FOR SPARKS AND IGNITION Perform a spark test. Refer to «ON-VEHICLE INSPECTION - Step 1»(ref-426031-S14559454242011101200000) . WARNING: Always disconnect all injector connectors. NOTE: Do not crank the engine for more than 2 seconds. OK Sparks jump across electrode gap. NG --> See step 36 OK: Go to next step
- CHECK CYLINDER COMPRESSION PRESSURE Measure the cylinder compression pressure of the misfiring cylinder. Refer to «ON-VEHICLE INSPECTION - Step 10»(ref-426025-S41300403072011101200000) . NG --> CHECK ENGINE TO DETERMINE CAUSE OF LOW COMPRESSION OK: Go to next step
- CHECK FUEL INJECTOR ASSEMBLY (POWER SOURCE). Refer to «PROCEDURE - Step 1»(ref-426057-S29886961042011101200000) NG --> See step 41 OK: Go to next step
- CHECK HARNESS AND CONNECTOR (ECM - FUEL INJECTOR). Refer to «PROCEDURE - Step 3»(ref-426057-S29886961042011101200000) NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (ECM - FUEL INJECTOR) OK: Go to next step
- CHECK FUEL INJECTOR OF MISFIRING CYLINDER Check the injector injection (whether fuel volume is high or low, and whether injection pattern is poor). Refer to «INSPECTION»(ref-426061-S07944050932011101200000) . NG --> See step 42 OK: Go to next step
- ADJUST VALVE TIMING See step 8 NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-425888-S21843066702011101200000) . Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON and turn the Techstream on. Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness. Input the DTC: P0300, P0301, P0302, P0303 or P0304. Check the DTC judgment result. Result Result Proceed to ABNORMAL (DTC P0300, P0301, P0302, P0303 or P0304 is output) A NORMAL (DTC is not output) B B --> END A: Go to next step
- CHECK HARNESS AND CONNECTOR Check the connection and terminal contact pressure of connectors and wire harness between the mass air flow meter and ECM. Refer to «ELECTRONIC CIRCUIT INSPECTION PROCEDURE»(ref-425882-S02362041192011101200000) . HINT: Repair any problems. NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-425888-S21843066702011101200000) . Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON and turn the Techstream on. Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness. Input the DTC: P0300, P0301, P0302, P0303 or P0304. Check the DTC judgment result. Result Result Proceed to ABNORMAL (DTC P0300, P0301, P0302, P0303 or P0304 is output) A NORMAL (DTC is not output) B B --> END A: Go to next step
- CHECK HARNESS AND CONNECTOR (MASS AIR FLOW METER - ECM) Disconnect the mass air flow meter connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for Open) Tester Connection Condition Specified Condition B2-5 (VG) - B31-69 (VG) Always Below 1 ohms B2-4 (E2G) - B31-92 (E2G) Always Below 1 ohms Standard Resistance (Check for Short) Tester Connection Condition Specified Condition B2-5 (VG) or B31-69 (VG) - Body ground Always 10 kohms or higher Reconnect the mass air flow meter connector. Reconnect the ECM connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (MASS AIR FLOW METER - ECM) OK: Go to next step
- REPLACE MASS AIR FLOW METER Replace the mass air flow meter. Refer to «REMOVAL»(ref-426060-S22042440052011101200000) . HINT: If the results of the inspections performed in steps 16 and 22 indicated no problem, proceed to the next step without replacing the mass air flow meter. NEXT: Go to next step
- CONFIRM WHETHER MALFUNCTION HAS BEEN SUCCESSFULLY REPAIRED Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-425888-S21843066702011101200000) . Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON and turn the Techstream on. Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness. Input the DTC: P0300, P0301, P0302, P0303 or P0304. Check the DTC judgment result. Result Result Proceed to NORMAL (DTC is not output) A ABNORMAL (DTC P0300, P0301, P0302, P0303 or P0304 is output) B B --> See step 45 A --> END
- CHANGE TO NORMAL SPARK PLUG AND CHECK SPARK OF MISFIRING CYLINDER Change the installed spark plug to a good spark plug that functions normally. Perform a spark test. Refer to «ON-VEHICLE INSPECTION - Step 1»(ref-426031-S14559454242011101200000) . WARNING: Always disconnect all injector connectors. NOTE: Do not crank the engine for more than 2 seconds. OK Sparks jump across electrode gap. NG --> See step 37 OK --> See step 40
- CHANGE TO NORMAL IGNITION COIL ASSEMBLY AND CHECK SPARK OF MISFIRING CYLINDER Change the ignition coil assembly to an ignition coil assembly that functions normally. Perform a spark test. Refer to «ON-VEHICLE INSPECTION - Step 1»(ref-426031-S14559454242011101200000) . WARNING: Always disconnect all injector connectors. NOTE: Do not crank the engine for more than 2 seconds. OK Sparks jump across electrode gap. NG --> See step 45 OK --> See step 46
- CHECK FUEL LINE Check the fuel lines for leaks or blockage. NG --> REPAIR OR REPLACE FUEL LINE OK --> See step 47
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-425888-S24994798172011101200000)
- REPLACE SPARK PLUG. Refer to «REMOVAL»(ref-426060-S30407496422011101200000)
- GO TO FUEL INJECTOR CIRCUIT. Refer to «Fuel Injector Circuit»(ref-426057-S03778012542011101200000)
- REPLACE FUEL INJECTOR. Refer to «REMOVAL»(ref-426061-S25769925372011101200000)
- REPAIR OR REPLACE INTAKE SYSTEM. Refer to «COMPONENTS»(ref-426067-S17515377522011101200000)
- REPLACE ENGINE COOLANT TEMPERATURE SENSOR. Refer to «REMOVAL»(ref-426060-S19018012212011101200000)
- REPLACE ECM. Refer to «REMOVAL»(ref-426060-S19785503332011101200000)
- REPLACE IGNITION COIL ASSEMBLY. Refer to «REMOVAL»(ref-426060-S30407496422011101200000)
- REPLACE FUEL PUMP. Refer to «REMOVAL»(ref-426061-S25070887422011101200000)
| Related DTCs | P0327: Knock sensor range check (Low voltage) P0328: Knock sensor range check (High voltage) |
| Required Sensors/Components (Main) | Knock sensor |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 1 second |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not present | None |
| Battery voltage | 10.5 V or more |
| Time after engine start | 5 seconds or more |
| Ignition switch | ON |
| Starter | Off |
| Knock sensor voltage | Less than 0.5 V |
KNOCK SENSOR RANGE CHECK (LOW VOLTAGE) P0327
| Knock sensor voltage | More than 4.5 V |
KNOCK SENSOR RANGE CHECK (HIGH VOLTAGE) P0328
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation). Refer to «DTC CHECK / CLEAR»(ref-425888-S21843066702011101200000) .
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on.
- Start the engine and wait 5 minutes.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0327 or P0328.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, idle the engine for 5 minutes and check the DTC judgment result again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-425888-S21843066702011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 211
Scheme 211: WIRING DIAGRAM
| Related DTCs | P0335: Crankshaft position sensor range check/rationality P0335: Crankshaft position sensor verify pulse input |
| Required Sensors/Components (Main) | Crankshaft position sensor |
| Required Sensors/Components (Related) | Camshaft position sensor |
| Frequency of Operation | Continuous |
| Duration | 15 seconds: Verify pulse input (case 1) 4.7 seconds: Verify pulse input (case 2) Within 1 second: Range check/rationality |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not present | None |
| Ignition switch | ON |
| Time after starter off to on | 3 seconds or more |
| Number of camshaft position sensor signal pulses | 6 times |
| Battery voltage | 7 V or higher |
| Minimum battery voltage while starter ON | Below 11 V |
| Camshaft position sensor circuit fail (P0340, P0342, P0343) | Not detected |
CRANKSHAFT POSITION SENSOR RANGE CHECK/RATIONALITY
| Ignition switch | ON |
| Starter | Off |
| Engine speed | 600 RPM or less |
| Time after starter from on to off | 3 seconds or more |
CRANKSHAFT POSITION SENSOR VERIFY PULSE INPUT (CASE 1)
| Ignition switch | ON |
| Starter | On |
| Minimum battery voltage while starter on | Below 11 V |
CRANKSHAFT POSITION SENSOR VERIFY PULSE INPUT (CASE 2)
| Number of crankshaft position sensor signal pulses | 132 times or less, and 174 times or more |
CRANKSHAFT POSITION SENSOR RANGE CHECK/RATIONALITY
| Engine speed signal | No signal |
CRANKSHAFT POSITION SENSOR VERIFY PULSE INPUT
| Crankshaft position sensor | Crankshaft position sensor output voltage fluctuates while crankshaft revolving 34 crankshaft position sensor signals per crankshaft revolution |
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation). Refer to «DTC CHECK / CLEAR»(ref-425888-S21843066702011101200000) .
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on.
- Start the engine.
- Idle the engine for 20 seconds or more [A].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [B].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0335 or P0339.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [A] and [B] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-425888-S21843066702011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 212
Scheme 212: WIRING DIAGRAM
| Related DTCs | P0340: Camshaft position sensor verify pulse input P0342: Camshaft position sensor range check (Low voltage) P0343: Camshaft position sensor range check (High voltage) |
| Required Sensors/Components (Main) | Camshaft position sensor |
| Required Sensors/Components (Related) | Crankshaft position sensor |
| Frequency of Operation | Continuous |
| Duration | 4 seconds: P0340 (case 1), P0342, P0343 5 seconds: P0340 (case 2) |
| MIL Operation | 2 driving cycles: P0340 (case 1) Immediate: P0340 (case 2), P0342, P0343 |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not present | None |
| Starter | On |
| Minimum battery voltage while starter on | Less than 11 V |
| Engine speed | 600 RPM or more |
| Starter | Off |
| Camshaft position sensor range check fail (P0342, P0343) | Not detected |
| Camshaft position sensor voltage | 0.3 to 4.7 V |
| Starter | Off |
| Ignition switch | ON |
| Time after ignition switch off to ON | 2 seconds |
| Camshaft position sensor pulse input fail (P0340) | Not detected |
| Camshaft position sensor signal | No signal |
| Camshaft position and crankshaft position phase | Misaligned |
| Camshaft position sensor signal | No signal |
| Camshaft position sensor voltage | Less than 0.3 V |
P0342 CAMSHAFT POSITION SENSOR RANGE CHECK
| Camshaft position sensor voltage | More than 4.7 V |
P0343 CAMSHAFT POSITION SENSOR RANGE CHECK
| Camshaft position sensor | Camshaft position sensor output voltage fluctuates while camshaft revolving 3 camshaft position sensor signals per 2 crankshaft revolutions |
| Camshaft position sensor voltage | 0.3 to 4.7 V |
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation). Refer to «DTC CHECK / CLEAR»(ref-425888-S21843066702011101200000) .
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on.
- Start the engine.
- Idle the engine for 10 seconds or more [A].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [B].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0340, P0342 or P0343.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [A] and [B] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-425888-S21843066702011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
| Related DTCs | P0351: Igniter (cylinder 1) range check/functional check P0352: Igniter (cylinder 2) range check/functional check P0353: Igniter (cylinder 3) range check/functional check P0354: Igniter (cylinder 4) range check/functional check |
| Required Sensors/Components (Main) | Igniter |
| Required Sensors/Components (Related) | Crankshaft position sensor |
| Frequency of Operation | Continuous |
| Duration | 0.256 seconds |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not present | None |
| Time after starter off to on | More than 0.256 seconds |
| Either of following conditions A or B is met | |
| A. Engine speed | 1500 RPM or less |
| B. Starter | Off |
| Either of following conditions C or D met | |
| C. Both of following conditions (a) and (b) are met | |
| (a) Engine speed | 500 RPM or less |
| (b) Battery voltage | 6 V or more |
| D. All of following conditions (c), (d) and (e) are met | |
| (c) Engine speed | More than 500 RPM |
| (d) Battery voltage | 10 V or more |
| (e) Number of sparks after CPU reset | 5 sparks or more |
| IGF signal | ECM does not receive any IGF signal despite ECM sending IGT signal to igniter |
| IGF signal | Igniter transmits IGF signal when it receives IGT signal from ECM |
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation). Refer to «DTC CHECK / CLEAR»(ref-425888-S21843066702011101200000) .
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on.
- Start the engine.
- Idle the engine for 10 seconds or more [A].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [B].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0351, P0352, P0353 or P0354.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [A] and [B] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-425888-S21843066702011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 213
Scheme 213: WIRING DIAGRAM
Scheme 214
Scheme 215
| Related DTCs | P0365: Exhaust camshaft position sensor verify pulse input P0367: Exhaust camshaft position sensor range check (Low voltage) P0368: Exhaust camshaft position sensor range check (High voltage) |
| Required Sensors/Components (Main) | Exhaust camshaft position sensor |
| Required Sensors/Components (Related) | Crankshaft position sensor |
| Frequency of Operation | Continuous |
| Duration | 4 seconds: P0367, P0368 5 seconds: P0365 |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not present | None |
| Engine speed | 600 RPM or more |
| Ignition switch | ON |
| Starter | Off |
| Exhaust camshaft position sensor range check fail (P0367, P0368) | Not detected |
| Exhaust camshaft position sensor voltage | 0.3 to 4.7 V |
| Starter | Off |
| Ignition switch | ON |
| Time after ignition switch off to ON | 2 seconds or more |
| Exhaust camshaft position sensor pulse input fail (P0365) | Not detected |
| Battery voltage | 8 V or more |
| Exhaust camshaft position signal | No signal |
| Exhaust camshaft position sensor voltage | Less than 0.3 V |
| Exhaust camshaft position sensor voltage | More than 4.7 V |
| Exhaust camshaft position sensor | Exhaust camshaft position sensor output voltage fluctuates while camshaft revolving 3 exhaust camshaft position sensor signals per 2 crankshaft revolutions |
| Exhaust camshaft position sensor voltage | 0.3 to 4.7 V |
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation). Refer to «DTC CHECK / CLEAR»(ref-425888-S21843066702011101200000) .
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on.
- Start the engine.
- Idle the engine for 10 seconds or more [A].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [B].
- Read the pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0365, P0367 or P0368.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [A] and [B] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-425888-S21843066702011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
| Related DTCs | P0420: Catalyst Deterioration |
| Required Sensors/Components (Main) | Air fuel ratio sensor Heated oxygen sensor |
| Required Sensors/Components (Related) | Intake air temperature sensor Mass air flow meter Crankshaft position sensor Engine coolant temperature sensor |
| Frequency of Operation | Once per driving cycle |
| Duration | About 30 seconds |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not present | P0010 (VVT Oil Control Valve) P0011 (VVT System - Advance) P0012 (VVT System - Retard) P0013 (Exhaust VVT Oil Control Valve) P0014 (Exhaust VVT System - Advance) P0015 (Exhaust VVT System - Retard) P0016 (VVT System - Misalignment) P0017 (Exhaust VVT System - Misalignment) P0031, P0032 (Air Fuel Ratio Sensor Heater - Sensor 1) P0037, P0038 (Heated Oxygen Sensor Heater - Sensor 2) P0102, P0103 (Mass Air Flow Meter) P0115, P0117, P0118 (Engine Coolant Temperature Sensor) P0120, P0121 P0122, P0123, P0220, P0222, P0223, P2135 (Throttle Position Sensor) P0125 (Insufficient Engine Coolant Temperature for Closed Loop Fuel Control) P0136, P0137, P0138, P0139 (Rear Oxygen sensor - Sensor 2) P0171, P0172 (Fuel System) P0301, P0302, P0303, P0304 (Misfire) P0335 (Crankshaft Position Sensor) P0340, P0342, P0343 (Camshaft Position Sensor) P0351, P0352, P0353, P0354 (Igniter) P0365, P0367, P0368 (Exhaust Camshaft Position Sensor) P0500 (Vehicle Speed Sensor) P0607 (Heated Oxygen Sensor - Sensor 2) P2195, P2196, P2237, P2238, P2239, P2252, P2253, P2A00 (Air Fuel Ratio Sensor - Sensor 1) P219A (Air Fuel Ratio Imbalance) |
| Battery voltage | 11 V or more |
| Intake air temperature | 10°C (14°F) or more |
| Engine coolant temperature | 75°C (167°F) or more |
| Atmospheric pressure | 76 kPa (570 mmHg) or more |
| Idle | Off |
| Engine speed | Less than 4000 RPM |
| Air fuel ratio sensor | Activated |
| Fuel system status | Closed loop |
| Engine load | 10 to 80% |
| All of the following conditions are met | Condition 1, 2 and 3 |
| 1. Mass air flow rate | 2.5 to 50 gm/sec |
| 2. Front catalyst temperature (estimated) | Automatic transaxle models: 655 to 860°C (1220 to 1580°F) Manual transaxle models: 675 to 860°C (1256 to 1580°F) |
| 3. Rear catalyst temperature (estimated) | 400 to 760°C (752 to 1400°F) |
| Heated oxygen sensor monitor | Completed |
| Shift position | 4th or more |
| Oxygen storage capacity of three-way catalytic converter | Less than 0.0449 g |
Refer to Checking Monitor Status. Refer to CHECKING MONITOR STATUS .
Performing this confirmation driving pattern will activate the catalyst efficiency monitor. This is very useful for verifying the completion of a repair.
Scheme 216
Scheme 216: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON.
- Turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation). Refer to «DTC CHECK / CLEAR»(ref-425888-S21843066702011101200000) .
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on.
- Enter the following menus: Powertrain / Engine and ECT / Monitor / Current Monitor.
- Check that Catalyst Efficiency / Current is Incomplete.
- Start the engine and warm it up until the engine coolant temperature is 75°C (167°F) or higher [A].
- Drive the vehicle at approximately 37 mph (60 km/h) for 10 minutes or more [B]. HINT: Drive the vehicle while keeping the engine load as constant as possible. The monitor item will change to Complete as the catalyst efficiency monitor operates [C].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
- Check if any DTCs (pending DTCs) are stored. HINT: If the monitor does not change to Complete and no pending DTCs are stored, perform the following procedure.
- Drive the vehicle at a speed between 47 and 63 mph (75 and 100 km/h) for 10 minutes or more [D]. HINT: Drive the vehicle while keeping the engine load as constant as possible. The monitor item will change to Complete as the catalyst efficiency monitor operates [E].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
- Check if any DTCs (pending DTCs) are stored.
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0420) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P0420 is output A DTC P0420 and other DTCs are output B HINT: If any DTCs other than P0420 are output, troubleshoot those DTCs first. B --> See step 4 A: Go to next step
- PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE INJECTION VOLUME FOR A/F SENSOR) Connect the Techstream to the DLC3. Start the engine and warm it up. Turn the Techstream on. Run the engine at an engine speed of 2500 RPM for approximately 90 seconds. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the Injection Volume for A/F Sensor / Data List / All Data / AFS Voltage B1S1 and O2S B1S2. Perform the Active Test operation with the engine in an idling condition (press the RIGHT or LEFT button to change the fuel injection volume). Monitor the voltage outputs of the air fuel ratio sensor and heated oxygen sensor (AFS Voltage B1S1 and O2S B1S2) displayed on the Techstream. HINT: The Control the Injection Volume for A/F Sensor operation lowers the fuel injection volume by 12.5% or increases the injection volume by 25%. Each sensor reacts in accordance with increases and decreases in the fuel injection volume. The air fuel ratio sensor has an output delay of a few seconds and the heated oxygen sensor has a maximum output delay of approximately 20 seconds. If there is almost no response from the air fuel ratio sensor, a malfunction of the air fuel ratio sensor is suspected. Standard Techstream Display (Sensor) Injection Volume Status Voltage AFS Voltage B1S1 (Air fuel ratio) +25% Rich Less than 3.1 V -12.5% Lean More than 3.4 V O2S B1S2 (Heated oxygen) +25% Rich More than 0.55 V -12.5% Lean Less than 0.4 V Result Status AFS Voltage B1S1 Status O2S B1S2 Air Fuel Ratio Condition and Air Fuel Ratio and Heated Oxygen Sensors Condition Misfire Main Suspected Trouble Area Proceed to Lean/Rich Lean/Rich Normal - Three-way catalytic converter Gas leakage from exhaust system A Lean Lean/Rich Air fuel ratio sensor malfunction - Air fuel ratio sensor B Rich Lean/Rich Air fuel ratio sensor malfunction - Air fuel ratio sensor Lean/Rich Lean Heated oxygen sensor malfunction - Heated oxygen sensor Gas leakage from exhaust system C Lean/Rich Rich Heated oxygen sensor malfunction - Heated oxygen sensor Gas leakage from exhaust system Lean Lean Actual air fuel ratio lean May occur Extremely rich or lean actual air fuel ratio Gas leakage from exhaust system D Rich Rich Actual air fuel ratio rich - Extremely rich or lean actual air fuel ratio Gas leakage from exhaust system Lean: During Control the Injection Volume for A/F Sensor, the air fuel ratio sensor output voltage (AFS Voltage) is consistently more than 3.4 V, and the heated oxygen sensor output voltage (O2S) is consistently less than 0.4 V. Rich: During the AFS Voltage is consistently less than 3.1 V, and the O2S is consistently more than 0.55 V. Lean/Rich: During Control the Injection Volume for A/F Sensor of the Active Test, the output voltage of the heated oxygen sensor alternates correctly. D --> See step 6 C --> See step 8 B --> See step 5 A: Go to next step
- INSPECT FOR EXHAUST GAS LEAK Check for exhaust gas leakage. OK No gas leaks. NG --> REPAIR OR REPLACE EXHAUST GAS LEAK POINT OK --> See step 7
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-425888-S24994798172011101200000)
- REPLACE AIR FUEL RATIO SENSOR (SENSOR 1). Refer to «REMOVAL»(ref-426060-S40759590382011101200000)
- CHECK ENGINE TO DETERMINE CAUSE OF EXTREMELY RICH OR LEAN ACTUAL AIR FUEL RATIO. Refer to «INSPECTION PROCEDURE»(ref-426059-S41447755392011101200000)
- REPLACE FRONT EXHAUST PIPE ASSEMBLY (TWC: FRONT AND REAR CATALYST). Refer to «COMPONENTS»(ref-426067-S21523790232011101200000)
- INSPECT FOR EXHAUST GAS LEAK Check for exhaust gas leakage. OK No gas leaks. NG --> REPAIR OR REPLACE EXHAUST GAS LEAK POINT OK --> See step 9
- REPLACE HEATED OXYGEN SENSOR (SENSOR 2). Refer to «REMOVAL»(ref-426060-S08558151242011101200000)
