| Accessory Drive Belt Tensioner Bolt/Nut |
| 1ZZ-FE |
| Bolt | 51 (69) |
| Nut | 21 (29) |
| 2ZZ-GE |
| Bolt | 74 (100) |
| Nut | 21 (29) |
| A/C Compressor Bolt | 18 (25) |
| Axle Shaft Nut | 166 (225) |
| Ball Joint-To-Lower Control Arm Bolt/Nut | 105 (142) |
| Camshaft Bearing Cap Bolt |
| 1ZZ-FE | (1) |
| 2ZZ-GE | 14 (19) |
| Camshaft Sprocket Bolt |
| Celica |
| 1ZZ-FE | 33 (45) |
| 2ZZ-GE | 40 (54) |
| Corolla & MR2 | 40 (54) |
| Coolant Drain Union |
| 1ZZ-FE | 14 (20) |
| 2ZZ-GE | 18 (25) |
| Connecting Rod Bolt |
| 1ZZ-FE |
| Step 1 | 15 (20) |
| Step 2 | Additional 90 Degrees |
| 2ZZ-GE |
| Step 1 | 22 (30) |
| Step 2 | Additional 90 Degrees |
| Crankshaft Pulley Bolt |
| 1ZZ-FE | 102 (138) |
| 2ZZ-GE | 87 (120) |
| Cylinder Head Bolt (2) |
| 1ZZ-FE |
| Step 1 | 36 (49) |
| Step 2 | Additional 90 Degrees |
| 2ZZ-GE |
| Step 1 | 26 (35) |
| Step 2 | Additional 180 Degrees |
| Drive Belt Tensioner-To-Timing Chain Cover |
| Bolt |
| 1ZZ-FE | 51 (69) |
| 2ZZ-GE | 74 (100) |
| Nut | 21 (29) |
| Drive Belt Idler Pulley | 32 (43) |
| Drive Shaft Heat Insulator Bolt | 13 (18) |
| Engine Coolant Temperature Sensor | 15 (20) |
| Engine Hanger Bolt | 28 (38) |
| Exhaust Manifold Nut |
| 1ZZ-FE | 27 (37) |
| 2ZZ-GE | 37 (50) |
| Exhaust Manifold Support Bracket Bolt | 36 (49) |
| Exhaust Pipe | 32 (43) |
| Flywheel/Drive Plate Bolt |
| A/T | 65 (88) |
| M/T |
| Step 1 | 36 (49) |
| Step 2 | Additional 90 Degrees |
| Front Exhaust Pipe-To-Center Exhaust Pipe Clamp Bolt | 24 (33) |
| Front Exhaust Pipe-To-Exhaust Manifold Bolt | 46 (62) |
| Front (Radiator Side) Engine Mount Bracket-To-Cylinder Block Bolt | 57 (77) |
| Front (Radiator Side) Engine Mount Through-Bolt/Nut | 64 (87) |
| Fuel Rail-To-Cylinder Head Bolt | 14 (19) |
| Generator Mounting Bolt |
| Small Bolt | 18 (24) |
| Large Bolt | 40 (54) |
| Intake Manifold Bolt/Nut |
| 1ZZ-FE | 14 (19) |
| 2ZZ-GE |
| M8 | 20 (27) |
| M10 | 34 (46) |
| All Others | 25 (34) |
| Intake Manifold Support Stay Bolt | 18 (24) |
| Knock Sensor | 29 (39) |
| Left Side Engine Mount |
| Celica | 59 (80) |
| Left (Transaxle Side) Engine Mount Through-Bolt/Nut | 64 (87) |
| Left (Transaxle Side) Engine Mount-To-Transaxle Bolt | 48 (65) |
| Main Bearing Cap Subassembly-To-Cylinder Block Bolt |
| 12-Point Bolt (3) |
| Step 1 | 16 (22) |
| Step 2 | 32 (43) |
| Step 3 | Additional 45 Degrees |
| Step 4 | Additional 45 Degrees |
| 6-Point Bolt |
| 1ZZ-FE | 14 (19) |
| 2ZZ-GE | 13 (18) |
| Screw Plug (2ZZ-GE) | 32 (43) |
| Oil Control Valve Filter | 22 (29) |
| Oil Filter Union | 22 (30) |
| Oil Pan Drain Plug | 27 (37) |
| Oxygen Sensor-To-Front Exhaust Pipe Nut | 15 (20) |
| Power Steering Gear Bolt | 33 (45) |
| Power Steering Pump Bolt/Nut | 27 (37) |
| Power Steering Pump Pulley Nut | 32 (43) |
| Rear Engine Mount-To-Transaxle Bolt | 47 (64) |
| Rear Engine Mount Bracket-To-Cylinder Block Bolt | 57 (77) |
| Rear Engine Mount Through-Bolt/Nut | 64 (87) |
| Rear Suspension Member Bolts | 38 (52) |
| Rear Suspension Upper Brace Bolts & Nuts | 59 (80) |
| Relief Valve Plug | 27 (37) |
| Right (Timing Chain Side) Engine Mount Bracket-To-Cylinder Block Bolt |
| 1ZZ-FE | 35 (47) |
| 2ZZ-GE | 36 (49) |
| Right (Timing Chain Side) Engine Mount Insulator-To-Body Bolt |
| Large Bolt | 47 (64) |
| Small Bolt | 38 (52) |
| Right (Timing Chain Side) Engine Mount Insulator-To-Engine Mount Bracket Bolt/Nut |
| Bolt | 47 (64) |
| Nut | 38 (52) |
| Support Bracket-To-Left (Transaxle Side) Engine Mount Bolt | 15 (20) |
| Throttle Body Bolt/Nut | 15 (20) |
| Tie Rod-To-Steering Knuckle Nut | 36 (49) |
| Timing Chain Cover Bolt/Nut & Stud Bolt | (4) |
| Timing Chain Tensioner Slipper Bolt |
| 1ZZ-FE | 14 (19) |
| 2ZZ-GE | 15 (20) |
| Timing Chain Vibration Damper |
| 1ZZ-FE | 8 (11) |
| 2ZZ-GE | 15 (21) |
| Valve Timing Controller Assembly |
| Celica |
| 1ZZ-FE | 33 (45) |
| 2ZZ-GE | 40 (54) |
| Corolla & MR2 | 40 (54) |
| Water Pump Bolt | (5) |
| Wheel Lug Nut | 76 (103) |
| INCH Lbs. (N.m) |
| ABS Speed Sensor Bolt | 71 (8) |
| Camshaft Position Sensor Bolt | 80 (9) |
| Chain Tensioner-To-Timing Chain Cover Bolt | 80 (9) |
| Clutch Release Cylinder Bolt | 106 (12) |
| Coolant Bypass Pipe |
| 1ZZ-FE | 80 (9) |
| 2ZZ-GE |
| Bolt | 75 (8.5) |
| Nut | 89 (10) |
| Coolant Inlet Housing Nut | 80 (9) |
| Crankshaft Position Sensor Bolt | 80 (9) |
| Fuel Pipe Clamp-To-Cylinder Head Bolt | 80 (9) |
| Heat Insulator-To-Exhaust Manifold Bolt | 106 (12) |
| Ignition Coil-To-Cylinder Head Bolt/Nut | 62 (7) |
| Oil Control Valve | 80 (9.0) |
| Oil Pan Baffle | 80 (9) |
| Oil Pan Bolt/Nut | 80 (9) |
| Oil Pressure Switch | 80 (9) |
| Oil Pump Body Cover Screw | 93 (10.5) |
| Oil Pump Pick-Up Tube Bolt/Nut | 80 (9) |
| Oil Pump-To-Cylinder Block Bolt | 80 (9) |
| Rockers-To-Cylinder Head Bolt | 66 (7.5) |
| Timing Chain Cover-To-Cylinder Head Bolts |
| 10 mm Bolt | 89 (10) |
| 10 mm Nut | 97 (11) |
| Stud | 84 (9.5) |
| Timing Chain Cover-To-Cylinder Block Bolts |
| 10 mm | 97 (11) |
| 12 mm | (6) |
| Valve Cover Bolt/Nut (7) |
| 1ZZ-FE |
| With Washer | 80 (9) |
| Without Washer | 97 (11) |
| 2ZZ-GE | 89 (10) |
| Ventilation Pipe |
| At Cylinder Head | 89 (10) |
| At Intake Manifold | (8) |
| Water Bypass Pipe | 80 (9) |
| (1) Tighten bolts to specification in sequence. see scheme 316 Tighten bolts on front camshaft bearing cap to 17 ft. lbs. (23 N.m). Tighten bolts for all other camshaft bearing caps to 115 INCH lbs. (13.0 N.m). (2) Tighten bolts to specification in sequence. see scheme 317 (3) Tighten bolts to specification in sequence. see scheme 318 (4) Tighten all bolts with 12-mm head to 14 ft. lbs. (19 N.m). Tighten bolt "A" with 10-mm head to 115 INCH lbs. (13 N.m). see scheme 319 Tighten bolt "C" with 10-mm head to 80 INCH lbs. (9.0 N.m). Tighten all others to 97 INCH lbs. (11.0 N.m). (5) Tighten bolt "B" to 97 INCH lbs. (11.0 N.m) and bolt "C" to 80 INCH lbs. (9.0 N.m). see scheme 319 (6) Tighten to 14 Ft. Lbs (18.5 N.m). (7) Tighten bolts to specification in sequence. see scheme 320 (8) Tighten to 18 Ft. Lbs (25 N.m). |
