PRECAUTION

1. Always use new gaskets when replacing the fuel tank or component parts.
2. Apply the proper torque to all parts tightened.

Scheme 123

Scheme 124

1. Check the fuel lines for cracks or leakage, and all connections for deformations.
2. Check the fuel tank for deformation, cracks fuel leakage or tank band looseness.
3. Check the filter neck for damage or fuel leakage.
4. Hose and tube connections are as shown in the illustration.

If a problem is found, repair or replace the part as necessary.

Scheme 125

Scheme 126

INSTALL AIR FLOW METER

Install the air flow meter and a new O-ring with 2 screws.

Scheme 127

Scheme 128

Scheme 129

1. INSPECT THROTTLE BODY Check that the throttle linkage moves smoothly.
2. INSPECT THROTTLE POSITION SENSOR Remove the air cleaner assembly with air flow meter. Disconnect the throttle position sensor connector. Using an ohmmeter, measure the resistance between each terminal. Reconnect the throttle position sensor connector. Reinstall the air cleaner assembly with air flow meter.

Scheme 130

Scheme 131

Scheme 132

Scheme 133

Scheme 134

1. DRAIN ENGINE COOLANT
2. DISCONNECT ACCELERATOR CABLE
3. REMOVE NO. 2 CYLINDER HEAD COVER
4. REMOVE AIR CLEANER HOSE AND CAP WITH MAF METER Disconnect the VSV for EVAP. Disconnect the 2 air hoses from air cleaner cap. Loosen the air cleaner hose clamp bolt. Disconnect the mass air flow meter connector. Disconnect the 3 air cleaner cap clips. Disconnect the air cleaner hose from the throttle body, and remove the air cleaner cap together with the air cleaner hose.
5. REMOVE THROTTLE BODY Disconnect the throttle position sensor connector. Disconnect the IAC valve connector. Disconnect the PCV hose from throttle body. Remove the 2 bolts and disconnect the No. 2 water bypass pipe. Disconnect the 2 water bypass hoses. Remove the 2 bolts, 2 nuts and throttle body from the intake manifold. Remove the throttle body gasket.

Scheme 135

Scheme 136

Scheme 137

1. INSPECTION THROTTLE VALVE Check that there is no clearance between the throttle stop screw and throttle lever when the closed throttle position.
2. INSPECTION THROTTLE POSITION SENSOR Using an ohmmeter, measure the resistance between each terminal.

Scheme 138

Scheme 139

Scheme 140

Scheme 141

Scheme 142

1. INSTALL THROTTLE BODY Install a new gasket on the intake manifold, as shown in the illustration. Install the throttle body with the 2 bolts and 2 nuts. Torque: 21 N.m (210 kgf.cm, 15 ft.lbf) Connect the 2 water bypass hoses to the throttle body. Install the No. 2 watery by-pass pipe with the 2 bolts. Connect the IAC valve connector. Connect the throttle position sensor connector. Connect the PCV hose to throttle body.
2. INSTALL AIR CLEANER HOSE AND CAP WITH MAF METER
3. INSTALL NO. 2 CYLINDER HEAD COVER
4. FILL RADIATOR WITH ENGINE COOLANT

Scheme 143

Scheme 144

Scheme 145

Scheme 146

1. INSPECT SYSTEM OPERATION Inspect the throttle control motor for operating sound. Turn the ignition switch to ON. When turning the accelerator pedal, check the running sound of the motor. If operation is not as specified, check the throttle control motor (See step 3), wiring and ECM. Inspect the accelerator pedal position sensor. Connect the TOYOTA hand-held tester to the DLC3. Turn the ignition switch to ON. Check that the MIL does not light up. When turning the accelerator pedal position sensor lever to the full-open position, check that the throttle valve opening percentage (THROTTLE POS) of the CURRENT DATA shown the standard value. Standard throttle valve opening percentage: 60% or more If operation is not as specified, check that the accelerator pedal position sensor (See «DTC P0120: THROTTLE PEDAL POSITION SENSOR/SWITCH "A" CIRCUIT»(ref-206112-S34883280952005112400000) ), wiring and ECM. If you have no TOYOTA hand-held tester, measure voltage between terminals VPA and E2 of the ECM connector (See «TERMINALS OF ECM»(ref-206112-S40952162522005112400000) ). Inspect the idle speed. Start the engine and check that the MIL does not light up. Allow the engine to warm up to normal operating temperature. Turn the A/C conditioning ON to OFF, and check the idle speed. Idle speed (Transmission in neutral): AT: 750 +/- 50 RPM MT: 800 +/- 50 RPM NOTE: Perform inspection under condition without electrical load. After checking the above (b) to (d), perform the driving test and check that there is no sense of incongruity.
2. INSPECT THROTTLE CONTROL MOTOR Disconnect the throttle control motor connector. Using an ohmmeter, measure the motor resistance between terminal 1 (M-) and 2 (M+). Motor resistance: 0.3 - 100 ohm at 20°C (68°F) If the resistance is not as specified, replace the throttle body (See «REMOVAL»(ref-206126-S15436777132006062000000) ). Reconnect the throttle control motor connector.
3. INSPECT THROTTLE POSITION SENSOR (See «DTC P2120: THROTTLE/PEDAL POSITION SENSOR/SWITCH "D" CIRCUIT»(ref-206112-S08871642662005112400000) ) If necessary, replace the throttle position sensor (See «ACCELERATOR PEDAL POSITION SENSOR»(ref-206126-S33027981912006062000000) ).

Scheme 147

Scheme 148

Scheme 149

Scheme 150

Scheme 151

1. DISCONNECT BATTERY NEGATIVE TERMINAL
2. DRAIN ENGINE COOLANT
3. REMOVE NO. 2 CYLINDER HEAD COVER
4. REMOVE AIR CLEANER HOSE CAP WITH MAF METER Disconnect the VSV for EVAP. Disconnect the 2 air hoses from air cleaner cap. Loosen the air cleaner hose clamp bolt. Disconnect the mass air flow meter connector. Disconnect the 3 air cleaner cap clips. Disconnect the air cleaner hose from the throttle body, and remove the air cleaner cap together with the air cleaner hose.
5. DISCONNECT THROTTLE BODY CONNECTOR Disconnect the throttle body connector.
6. DISCONNECT THROTTLE BODY WIRE HARNESS CLAMP Remove the bolt and disconnect the throttle body wire harness clamp from the throttle body.
7. REMOVE THROTTLE BRACKET Remove the 2 bolts and throttle bracket from the throttle body.
8. DISCONNECT PCV HOSE Slid the clip and disconnect the PCV hose.
9. DISCONNECT 2 WATER BY-PASS HOSES Slid the clips and disconnect the 2 water bypass hoses.
10. REMOVE THROTTLE BODY Remove the 4 nuts and throttle body from the intake manifold. Remove the 4 bolts and throttle body gasket.

Scheme 152

Scheme 153

Scheme 154

Scheme 155

1. INSTAL THROTTLE BODY Install a new gasket on the intake manifold with the 4 bolts. Torque: 22 N.m (220 kgf.cm, 16ft.lbf) Install the throttle body with the 4 nuts. Torque: 22 N. m (220 kgf.cm, 16ft.lbf)
2. CONNECT 2 WATER BYPASS HOSES Connect the 2 water bypass hoses with the clips.
3. CONNECT PCV HOSE Connect the PCV hose with the clip.
4. INSTALL THROTTLE BRACKET Install the throttle bracket with the 2 bolts.
5. CONNECT THROTTLE BODY WIRE HARNESS CLAMP Connect the throttle body wire harness clamp with the bolt to the throttle body. Torque: 5.0 N. m (51 kgf.cm, 44in..lbf)
6. CONNECT THROTTLE BODY CONNECTOR Connect the throttle body connector.
7. INSTALL AIR CLEANER HOSE AND CAP WITH MAF METER
8. INSTALL NO. 2 CYLINDER HEAD COVER
9. FILL RADIATOR WITH ENGINE COOLANT
10. CONNECT BATTERY NEGATIVE TERMINAL

Scheme 156

1. Initial conditions: Engine at normal operating temperature Idle speed set correctly Transmission in neutral A/C switch OFF
2. Using SST, connect terminals TC and CG of the DLC3. SST 09843-18020
3. After engine speed are kept at 900-1,300 RPM for 5 seconds, check that they return to idle speed. If the RPM operation is not as specified, check the IAC valve, wiring and ECM.
4. Remove the SST from the DLC3. SST 09843-18020

Scheme 157

Scheme 158

1. REMOVE THROTTLE BODY (See «REMOVAL»(ref-206126-S25015568562006062000000) )
2. REMOVE IAC VALVE Remove the 4 screws, IAC valve and gasket.

Scheme 159

1. Check that the IAC valve is half opened.
2. Connect the IAC valve connector to the IAC valve.
3. Disconnect the ECT sensor connector from the ECT sensor.
4. Turn the ignition switch ON.
5. Check that the IAC valve moves. HINT: Repeat connecting and disconnecting of IAC valve connector several times and check the operation of the valve. If operation is not as specified, replace the IAC valve.
6. Turn the ignition switch OFF
7. Connect the ECT sensor connector to the ECT sensor.
8. Disconnect the IAC valve connector from the IAC valve.
