Removal & Installation
Remove door trim panel and waterproof shield. Remove glass retaining bolts and glass. If removing rear quarter window motor on Celica convertible, remove quarter trim panel. On all models, remove window regulator nuts and remove window regulator. Remove power window motor retaining screws, and remove motor from window regulator. To install, reverse removal procedure. On Avalon, reset power window motor reset and pulse switch. See RESETTING POWER WINDOW MOTOR RESET & PULSE SWITCH under PROGRAMMING.
Disconnect negative battery cable. Pry out power window switch from door panel or trim panel using flat screwdriver. Disconnect power window switch connectors and remove switch. To install, reverse removal procedure.
Power Window System Wiring Diagram (Avalon). Scheme 7
Scheme 7: Power Window System Wiring Diagram (Avalon)
Power Window System Wiring Diagram (Camry 2.2L & 3.0L). Scheme 8
Scheme 8: Power Window System Wiring Diagram (Camry 2.2L & 3.0L)
Power Window System Wiring Diagram (Camry 2.2L CNG). Scheme 9
Scheme 9: Power Window System Wiring Diagram (Camry 2.2L CNG)
Power Window System Wiring Diagram (Camry Solara). Scheme 10
Scheme 10: Power Window System Wiring Diagram (Camry Solara)
Power Window System Wiring Diagram (Celica). Scheme 11
Scheme 11: Power Window System Wiring Diagram (Celica)
Power Window System Wiring Diagram (Corolla). Scheme 12
Scheme 12: Power Window System Wiring Diagram (Corolla)
Power Window System Wiring Diagram (ECHO). Scheme 13
Scheme 13: Power Window System Wiring Diagram (ECHO)
Power Window System Wiring Diagram (MR2). Scheme 14
Scheme 14: Power Window System Wiring Diagram (MR2)
