Engine Controls - Specifications Toyota Celica T180

Specifications 1 illustration ~131 words

INTRODUCTION

Use this article to quickly find specifications related to servicing and on-vehicle adjustments. This is a quick-reference article for when you are familiar with an adjustment procedure and only need a specification.

CAPACITIES

ApplicationAmp Hr. Rating
Celica60

BATTERY SPECIFICATIONS

ApplicationQuantity
Automatic Transaxle (Dexron-II) (1)2.6 Qts. (2.5L)
Cooling System (Includes Heater)
1.6L
Auto. Trans.5.9 Qts. (5.6L)
Man. Trans.5.5 Qts. (5.2L)
2.0L (All-Trac)6.8 Qts. (6.4L)
2.2L
Auto. Trans.6.4 Qts. (6.1L)
Man. Trans.6.6 Qts. (6.2L)
Crankcase (Includes Filter)
1.6L3.4 Qts. (3.2L)
2.0L3.8 Qts. (3.6L)
2.2L(2) 4.2 Qts. (4.1L)
Differential All-Trac (SAE 90 With GL-5 Rating)1.2 Qts. (1.1L)
Manual Transaxle
1.6L (SAE 75W-90 With GL-5 Rating)2.7 Qts. (2.6L)
2.2L 2WD (Dexron-II)2.7 Qts. (2.6L)
2.2L All-Trac (SAE 75W-90 With GL-5 Rating)5.5 Qts. (5.2L)
(1) Drain and refill capacity. (2) Specification listed is without oil cooler. With oil cooler, 4.5 qts. (4.2L).
(1)Drain and refill capacity.
(2)Specification listed is without oil cooler. With oil cooler, 4.5 qts. (4.2L).

FLUID CAPACITIES

SERVICE INTERVALS & SPECIFICATIONS

ComponentMonthsMiles
Air Filter3630,000
Coolant36(1) 45,000
Fuel FilterN/A60,000
Oil & Filter (2)127500
Oxygen SensorN/A(3) 80,000
Spark Plugs3630,000
Timing BeltN/A60,000
(1) After first coolant change, replace coolant every 30,000 miles or 24 months. (2) For severe service, replace every 3500 miles or 6 mos. Severe service is taxi, trailer towing or local delivery service. (3) Except Calif.
(1)After first coolant change, replace coolant every 30,000 miles or 24 months.
(2)For severe service, replace every 3500 miles or 6 mos. Severe service is taxi, trailer towing or local delivery service.
(3)Except Calif.

REPLACEMENT INTERVALS

ApplicationMonthsMiles
Celica7260,000

VALVE ADJUSTMENT INTERVALS

ApplicationNew BeltUsed Belt
A/C160 (73)100 (45)
Alternator
With A/C175 (79)130 (59)
Without A/C125 (57)95 (43)
Power Steering125 (57)80 (36)
(1) Tension in Lbs. (kg) Using Burroughs Tension Gauge.
(1)Tension in Lbs. (kg) Using Burroughs Tension Gauge.

BELT ADJUSTMENT (1)

ENGINE COMPRESSION

ApplicationSpecification
Compression Ratio
1.6L9.5:1
2.0L8.8:1
2.2L9.5:1
Normal Compression Pressure
Turbo128 psi (9.0 kg/cm 2 )
Non-Turbo178 psi (12.5 kg/cm 2 )
Minimum Compression Pressure
Turbo164 psi (11.5 kg/cm 2 )
Non-Turbo142 psi (10.0 kg/cm 2 )
Maximum Variation Between Cylinders14 psi (1.0 kg/cm 2 )

COMPRESSION SPECIFICATIONS

VALVE CLEARANCE

Application (1)In. (mm)
1.6L & 2.2L
Exhaust.008-.012 (.20-.30)
Intake.006-.010 (.15-.25)
2.2L
Exhaust.011-.015 (.28-.38)
Intake.007-.011 (.18-.28)
(1) Adjust valves with engine cold.
(1)Adjust valves with engine cold.

VALVE CLEARANCE SPECIFICATIONS

DISTRIBUTOR

ApplicationIn. (mm)
All Models.008-.016 (.20-.40)

DISTRIBUTOR PICK-UP COIL AIR GAP

ApplicationOhms
1.6L
Gray130-210
Green185-265
2.0L
Pick-up Coil G1 & G2125-190
Pick-up Coil NE155-240
2.2L150-230

DISTRIBUTOR PICK-UP COIL RESISTANCE

IGNITION COIL

ApplicationPrimarySecondary
1.6L1.3-1.610,400-14,000
2.0L & 2.2L.4-.510,200-13,800

IGNITION COIL RESISTANCE - Ohms @ 68°F (20°C)

HIGH TENSION WIRE RESISTANCE

ApplicationMaximum Ohms
All Models25,000

HIGH TENSION WIRE RESISTANCE

SPARK PLUGS

ApplicationNGKNippondenso
1.6LBCPR5EYQ16R-U
2.0LBKR6EP8PK20R8
2.2LBKR5EYA11K16R-U11

SPARK PLUG TYPE

ApplicationGap: In. (mm)Torque: Ft. Lbs. (N.m)
1.6L & 2.0L.031 (.80)13 (18)
2.2L.043 (1.10)13 (18)

SPARK PLUG SPECIFICATIONS

IGNITION TIMING

ApplicationBase Timing (1)Advance Timing
1.6L10 @ Idle5-15 @ Idle
2.0L10 @ 75014-19 @ Idle
2.2L10 @ 70013-22 @ Idle
(1) With check connector terminals TE1 and E1 jumpered.
(1)With check connector terminals TE1 and E1 jumpered.

IGNITION TIMING - Degrees BTDC @ RPM

Firing Order & Distributor Rotation. Scheme 1

Scheme 1: Firing Order & Distributor Rotation
Scheme 1: Firing Order & Distributor Rotation

FUEL PUMP

Application(1) psi (kg/cm 2 )(2) psi (kg/cm 2 )
1.6L & 2.2L38-44 (2.7-3.1)33-37 (2.3-2.6)
2.0L33-38 (2.3-2.7)27-31 (1.9-2.2)
(1) With pressure regulator vacuum hose disconnected and plugged. (2) With vacuum hose connected to pressure regulator.
(1)With pressure regulator vacuum hose disconnected and plugged.
(2)With vacuum hose connected to pressure regulator.

FUEL PUMP PERFORMANCE

IDLE SPEED

ApplicationRPM
1.6L800
2.0L750-850
2.2L(1) 650
(1) Idle speed with jumper wire removed is 650-750 RPM.
(1)Idle speed with jumper wire removed is 650-750 RPM.

IDLE SPEED SPECIFICATIONS

THROTTLE POSITION SENSOR

ApplicationClearance In. (mm)TerminalOhmmeter Reading
1.6L.024 (.60)IDL-E2Continuity
""PSW-E2No Continuity
".031 (.80)IDL-E2No Continuity
""PSW-E2No Continuity
"Fully OpenIDL-E2No Continuity
""PSW-E2Continuity
2.0L0 (0)VTA & E2200-800
".020 (.51)IDL & E22300 or Less
".028 (.71)IDL & E2Infinity
"Fully OpenVTA & E23300-10,300
""VC & E23000-8300
2.2L W/O ECT.020 (.50)IDL-E2Continuity
""PSW-E2No Continuity
".035 (.90)IDL-E2No Continuity
""PSW-E2No Continuity
"Fully OpenIDL-E2No Continuity
""PSW-E2Continuity
2.2L W/ECT0 (0)VTA & E2200-800
".020 (.51)IDL & E22300 or Less
".028 (.71)IDL & E2Infinity
"Fully OpenVTA & E23300-10,000
""VC & E23000-7000

TPS RESISTANCE SPECIFICATIONS
