Using Door Indicator Light
- Open door and determine that DOOR OPEN indicator lights up. If indicator does not light up, repair indicator before diagnosing multiplex control system. See INSTRUMENT PANELS - CARS article. If DOOR OPEN indicator does light up, go to next step.
- Using jumper wire, connect DLC1 terminals Tc and E1 together. Observe DOOR OPEN indicator flashing sequence. If no DTCs are stored, indicator will flash 2 times a second. If a DTC is stored, first number of DTC will flash, then a 1.5 second pause will occur, then the second number of DTC will flash. If more than one DTC is stored, a 4.5 second pause will occur, then next DTC will flash.
Scheme 5
| DTC | Description |
|---|---|
| B1211/11 | DTC 11: DRIVER'S DOOR ECU COMMUNICATION STOPPED |
| B1212/12 | DTC 12: FRONT PASSENGER'S DOOR COMMUNICATION STOPPED |
| B1214/14 | DTC 14 & 15: SYSTEM COMMUNICATION BUS MALFUNCTION (B+ OR GROUND CIRCUIT PROBLEM) |
| B1215/15 | DTC 14 & 15: SYSTEM COMMUNICATION BUS MALFUNCTION (B+ OR GROUND CIRCUIT PROBLEM) |
| B1221/21 | DTC 21: DRIVER'S POWER WINDOW SWITCH CIRCUIT |
| B1222/22 | DTC 22: DRIVER'S DOOR LOCK SWITCH CIRCUIT |
| B1223/23 | DTC 23: PASSENGER'S POWER WINDOW SWITCH CIRCUIT |
| B1224/24 | DTC 24: PASSENGER'S DOOR LOCK SWITCH CIRCUIT |
| B1231/31 | DTC 31: DRIVER'S DOOR JAM PROTECTION LIMIT SWITCH CIRCUIT |
| B1232/32 | DTC 32: DRIVER'S DOOR JAM PROTECTION PULSE SWITCH CIRCUIT |
| B1241/41 | DTC 41: ONE OF MONITORED SWITCHES HAS ABNORMAL OUTPUT |
| B1242/42 | DTC 42: WIRELESS DOOR LOCK RECEIVER MALFUNCTION |
| B1243/43 | DTC 43: GSW TERMINAL CIRCUIT MALFUNCTION |
| B1244/44 | DTC 44: LIGHT SENSOR CIRCUIT MALFUNCTION |
| B1251/51 | DTC 51: MIRROR CONTROL SWITCH |
| B1269/69 | DTC 69: THEFT DETERRENT ECU COMMUNICATION STOPPED |
| B1272/72 | DTC 72: POWER SEAT ECU COMMUNICATION STOPPED |
DIAGNOSTIC TROUBLE CODE INDEX
