PRECAUTION
- IGNITION SWITCH EXPRESSION HINT: The type of ignition switch used on this model differs according to the specifications of the vehicle. The expressions listed in the table below are used in this information. Expression Ignition Switch (position) Engine Switch (condition) Ignition Switch off Off Off Ignition Switch ON ON On (IG) Ignition Switch ACC ACC On (ACC) Engine Start START Start
Scheme 31
Scheme 32
Scheme 33
Scheme 34
CUSTOMIZE PARAMETERS
- CUSTOMIZING FUNCTION WITH TECHSTREAM HINT: The following items can be customized. NOTE: When the customer requests a change in a function, first make sure that the function can be customized. Record the current settings before customizing. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Customize Setting. Select the setting by referring to the table below. ILLUMINATED ENTRY Display Default Content Setting Lighting Time 15s Changes the lighting time after closing all of the doors. (It will fade out immediately in case of turning the ignition switch from off to ACC or ON). 7.5s, 15s or 30s I/L when ACC OFF ON A function that turns on the lights when the ignition switch is turned from ON or ACC to off (the room light turns on when the interior light switch is set to DOOR). ON or OFF I/L ON W/Door Key Unlock*2 ON A function that turns on the room light when the door is unlocked with the door key cylinder (the room light turns on when the map light switch is set to DOOR). ON or OFF Room Light when Aprchd*1 ON A function that turns on the room light when the key is brought within the vehicle exterior detection area (the room light turns on when the map light switch is set to DOOR). ON or OFF Inside Foot Light*3 ON Changes the interior foot lights control. ON or OFF Center Console Spot Light ON Lights up the center console spot light when ignition switch is turned ACC or ON. ON or OFF Mirr-Foot-Lgt Approached*4 ON Door mirror foot light (when approaching vehicle) ON or OFF Mirr-Foot-Lgt Unlocked*4 ON Door mirror foot light (when unlocking doors) ON or OFF Mirror Foot Light Time*4 15s Door mirror foot light illumination duration 0s, 7.5s, 15s or 30s Light Control*5 ON Change the inside handle illumination control. ON or OFF Interior Light Control ON Change the engine switch illumination*1 or ignition key cylinder light*2 control. ON or OFF Exterior Light Control*4 ON Change the door mirror foot light control. ON or OFF *1: w/ Smart Key System *2: w/o Smart Key System *3: w/ Interior Foot Light *4: w/ Door Mirror Foot Light *5: w/ Inside Handle Illumination
PROCEDURE
- PERFORM ACTIVE TEST USING TECHSTREAM (DOOR MIRROR FOOT LIGHT) Using the Techstream, perform the Active Test. Refer to «DATA LIST / ACTIVE TEST»(ref-422216-S12064364352011092600000) . MAIN BODY Tester Display Test Part Control Range Diagnostic Note Side Mirror Foot Light Door mirror foot light ON/OFF - OK Door mirror foot light comes on. NG --> See step 3 OK --> See step 2
- PROCEED TO NEXT SUSPECTED AREA SHOWN IN PROBLEM SYMPTOMS TABLE. Refer to «PROBLEM SYMPTOMS TABLE»(ref-422216-S05551403972011092600000)
- CHECK HARNESS AND CONNECTOR (OUTER MIRROR - MAIN BODY ECU AND BODY GROUND) Disconnect the I4 and H4 outer mirror connectors. Disconnect the F10 main body ECU connector. Measure the resistance according to the value(s) in the table below. Standard Resistance for LH for RH Tester Connection Condition Specified Condition I4-1 (MLP) - F10-4 (MILE) Always Below 1 ohms I4-7 (MLP-) - Body ground Always Below 1 ohms I4-1 (MLP) - Body ground Always 10 kohms or higher Tester Connection Condition Specified Condition H4-1 (MLP) - F10-4 (MILE) Always Below 1 ohms H4-7 (MLP-) - Body ground Always Below 1 ohms H4-1 (MLP) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 2
