Smart Key System (For Entry Function) (Diagnostics - Introduction): Overview Toyota 4Runner V

Scheme 92

1. PRECAUTIONS FOR USERS WITH PACEMAKERS Weak electric waves are emitted from the key. If a pacemaker is being used, read the pacemaker instruction manual before using the smart key system. If implanted pacemakers or cardioverter defibrillators are being used, make sure they are not brought near the electrical key antenna and indoor electrical key antenna. The electric waves may affect them. If electric devices (for medical purposes) other than an implantable pacemaker or implantable cardioverter defibrillator are used, confirm with the manufacturer if electric waves affect their operation. Electric waves may affect the electric devices. The smart key system can be set so that it does not operate. Refer to Key Cancel for more information. Refer to «CUSTOMIZE PARAMETERS»(ref-422211-S38349874092011092600000) . TEXT IN ILLUSTRATION *1 Electrical Key Antenna *2 Indoor Electrical Key Antenna
2. PRECAUTIONS FOR SMART KEY SYSTEM AND KEY The smart key system does not operate in the following situations. If it does not operate at all, check that the following is not the cause. The key cancel operation has been performed. There is no key battery (key indicator does not blink when key switches are pressed). The key must be in the possession of the user (this is a requirement of the smart key system to make sure the user maintains a habit of carrying the key). As the key only emits weak electric waves, if any of the following conditions are met, the detection area of the key may become smaller or the key may become undetectable. The battery is depleted. There are TV towers, electric power plants, broadcasting stations, gas stations or other areas of strong electric wave output nearby. Wireless products such as cell phones, etc. are carried with the key. The key is covered by or in contact with metal. Electric wave type keyless entry systems are being operated nearby. The key is placed near high-voltage, electric noise emitting equipment. Film with some metallic content is applied to the back glass. HINT: In this case, remove the film or unlock the door using the mechanical key. Even if the key is in the vehicle exterior key detection area, the key may not operate properly due to the vehicle body design. Even if the key is in the vehicle exterior key detection area, the key may not be properly detected if the key is near a window, door handle or bumper. Even if the key is in the vehicle interior key detection area, the key may not be properly detected if the key is on the instrument panel, in the glove box or on the floor. Depending on the way the key is held, the key may not operate properly.
3. PRECAUTIONS WHEN USING TECHSTREAM When troubleshooting the smart key system using the Techstream with the engine switch off, connect the Techstream to the vehicle and turn any of the courtesy light switches on and off until communication between the Techstream and vehicle begins (make sure the interval between on and off operations is less than 1.5 seconds). The reason this procedure is necessary is that when the engine switch is off, the main body ECU may be in sleep mode. When the main body ECU is in sleep mode, communication with the Techstream is not possible. After DTCs are cleared, check if the trouble occurs again 6 seconds after the engine switch is turned on (IG).
4. PRECAUTIONS FOR EACH FUNCTION Precautions for the key: The key is a precision instrument. Be sure to observe the following: Do not drop or strike the key. Do not keep the key in a high temperature area for a long time. Do not use an ultrasonic washing machine to clean the key. Keep the key away from magnets or magnetized items during use. Do not attach any stickers to the key. If a key is lost, clear all registered key ID codes and then register the remaining keys. Precautions for the entry unlock function: As the sensor is built into the backside of the outside door handle, the user must touch the backside part of the handle when performing the unlock function. If the sensor is touched with gloved hands, the response of the door may be delayed. During the entry unlock operation, if the door handle is pulled before the door unlocks, the unlock function cannot be completed. Confirm that the door has been unlocked before pulling the door handle to open the door. Make sure that the doors unlock when touching the unlock sensor on the door outside handle while the key is being carried. If the doors cannot be unlocked, the certification ECU orders the main body ECU to perform the door unlock operation 4 times at intervals of 0.75 seconds. At this time, the door may not be unlocked because the handle is being pulled due to some mechanical reasons. Be sure to return the door handle to its original position. If the door cannot be opened by pulling the handle, perform the entry unlock operation again. If the key is too close to the antenna on the outside of the vehicle, the door may not be unlocked because the key cannot react to the strong wave output from the transmitter. If the key is within the vehicle exterior detection area, the door can be unlocked even when a person other than the person carrying the key holds the door handle. However, the doors other than the door around which a matching code is detected are not unlocked. If the key is within the detection area of the driver side door outside the vehicle, the doors are unlocked when the person carrying the key holds the driver side door handle. However, if any door handle other than that of the driver side door is held, the doors are not unlocked. If a door is not opened after the door unlock operation, the doors automatically lock after approximately 30 seconds. If a large amount of water is applied to the door handle due to a car wash or heavy rain, the key being brought within the vehicle exterior detection area may cause the doors to be unlocked. However, the doors are locked again after approximately 30 seconds if a door is not opened. If the key of the smart key system is used while it is being carried with the key of another smart key system, the time before the entry unlock operation occurs is more than usual. This is not a malfunction. Precautions for the entry lock function: When performing the entry lock operation, touch the lock sensor on the door outside handle. If touched too quickly or lightly, the entry lock may not operate. It is possible that signals output from the indoor electrical key antenna may leak through the window. Also, if the key is too close to an electrical key antenna, the electrical key antenna output signals are too strong and the key cannot respond. As a result, when the key is near the vehicle interior (window, door handle), the entry lock function may not operate. Also, the key reminder warning buzzer may sound and the entry unlock operation may stop functioning. In this situation, move the key away from the vehicle interior (window, door handle), perform the entry lock operation and then perform the entry unlock operation. Do not touch the lock sensor while opening or closing the door. If the lock sensor is touched when opening or closing the door while the key is being carried, the door ajar warning buzzer sounds (beeps outside the vehicle for 10 seconds). If the key is on the instrument panel or floor, or in the glove box, the key reminder function may not operate and the key may be locked in the vehicle. Always carry the key. If the key is outside the vehicle but is very close to a window or door handle (the ECU determines that the key is inside the vehicle) and the transmitter or mechanical key is used to lock the doors (entry lock is not used), entry unlock does not operate. To unlock the doors, perform a wireless door unlock operation. The entry lock function operates in this way to prevent the doors from being unlocked by the electrical key antenna without the knowledge of the user. For example, when a user operates the wireless door lock operation from inside the vehicle, radio waves from an electrical key antenna may leak into the vehicle interior and the doors may unlock. To allow the user enough time to check if the doors are locked after performing a door lock operation (entry lock function or wireless door lock operation), the entry unlock function is not permitted for 3 seconds after the door lock operation. Precautions for the entry ignition function: To start the engine system, first depress the brake pedal firmly until the engine switch indicator illuminates green, and then press the engine switch. Be sure to continue depressing the brake pedal until the engine has completely started. When operating the engine switch, firmly press the switch. If the switch is pressed too quickly, power source control and engine system starting may not operate. While driving the vehicle, continuously pressing the engine switch for 3 seconds or more turns off the engine system. Do not touch the engine switch while driving, except in an emergency. Do not touch the engine switch with oily hands. If the vehicle has been in a hot location for an extended period of time, be careful when touching the engine switch. It may be very hot and cause burns. Take care to avoid spilling beverages on the engine switch. Keep all liquids away from the engine switch. Do not use the engine switch if it seems to be sticking or feels abnormal. The vehicle continually records the power source mode [off, on (ACC), on (IG), start]. When the battery cable is disconnected and reconnected, the power source mode returns to the mode it was in before disconnecting the battery cable. Always turn the engine switch off before disconnecting the battery cable. When the vehicle battery is fully depleted, power is cut and the power source mode before the power was cut is unknown, so be extremely careful. Do not connect any electronic products to the ACC, IG1 or IG2 coil side wiring, as the vehicle power supply may be unable to be turned on, or other problems may occur. When the key battery is depleted and the key is held up to the engine switch to start the engine system, the following warning alarms sound. Driver side door is opened and closed: Shift lever in P power source cut reminder exit warning Shift lever not in P power source cut reminder exit warning Door other than driver side door is opened and closed: Occupant leaves with key warning The warning alarms do not indicate an actual malfunction. The alarms sound because the key battery is depleted and the system cannot determine if the key is inside the vehicle or not. With the engine switch on (ACC), the engine can be started by pressing the engine switch for 15 seconds without depressing the brake pedal. Precautions for back door entry unlock function: Even if the key is within the electrical key antenna (outside luggage) detection area, the back door cannot be opened if the key is in the following areas: Near the bumper Too close to the ground or in a high place Precautions for the battery built into the key and the vehicle battery: The key is constantly checking for signals from the vehicle, which requires power from the built-in battery. The life of the battery is approximately 1 to 2 years depending on usage conditions. Also, if the key is in contact with a cell phone while the user walks around (by putting them together into a pocket, etc.), the battery may become significantly depleted. Be sure to replace the battery when its power is low. When replacing the battery, do not touch the inner circuit board or other inner parts. The key is constantly checking for signals from the vehicle and using battery power, whether the key is being used or not. Even if the user is carrying 2 keys and only 1 key is used, both keys consume battery power. If the key continuously receives strong, identical frequency waves, this may drain the key battery. Store the key at least 1 m (3.28 ft.) from TVs, personal computers, chargers for cell phones or other electrical products. When the door is being locked, the vehicle battery is used to transmit radio waves. The battery may be fully depleted if the vehicle remains stopped for a long time. If the vehicle is not used for a long time, remove the battery from the vehicle or cancel the smart key system. When the door is being locked with the key in the detection area of a door electrical key antenna, the battery is used for regular communication between the key and vehicle. If the vehicle is not used, keep the key away from the vehicle (more than 2 m [6.56 ft.]). After disconnecting and reconnecting the battery cable, the entry unlock function may not operate. If this occurs, perform a wireless door unlock and lock operation. When the battery is fully depleted and the engine does not start even after recharging, perform the following: 1) move the shift lever to P, 2) turn the engine switch off, and 3) open and close the driver door. Then start the engine. When starting the engine system after the removal and installation of the vehicle battery, first perform the following: 1) open and close the driver door, and 2) wait 10 seconds or more. When an engine system start is attempted after the above procedures, the engine system does not start. However, this is not a malfunction. The engine system starts normally from the second attempt. Precautions for the entry unlock mode switching function: Use the entry unlock mode switching function within a 1 m (3.28 ft.) radius around the vehicle or from inside the vehicle. After changing modes, it is necessary to wait 5 seconds before the modes can be changed again.

Scheme 93

Scheme 94

Scheme 95

Scheme 96

Scheme 97

Scheme 98

Scheme 99

COMMUNICATION TABLE

SYSTEM DESCRIPTION

Scheme 100

Scheme 101

Scheme 102

Scheme 103

Scheme 104

Scheme 105

Scheme 106

Scheme 107

1. SMART KEY SYSTEM DESCRIPTION In addition to conventional mechanical key and wireless door lock control functions, the smart key system enables door locking/unlocking, steering lock releasing, engine control system starting and back door opening without operating the key. The only requirement is that the key is in the possession of the user. This system is controlled by the certification ECU. When the certification ECU detects the presence of the key in one of the detection areas, it identifies and checks the ID code, and outputs operation signals to the related ECU in accordance with their functions. The detection areas are formed by 6 antennas.
2. DETECTION AREA TEXT IN ILLUSTRATION *1 Indoor No. 1 Electrical Key Antenna Assembly (Front Floor) *2 Electrical Key Antenna *3 Indoor No. 2 Electrical Key Antenna Assembly (Rear Floor) *4 Indoor No. 2 Electrical Key Antenna Assembly (Inside Luggage) *5 Electrical Key Antenna (Outside Luggage) - - *a Approximately 0.7 to 1.0 m (2.30 to 3.28 ft.) - - Interior Detection Area Exterior Detection Area Precautions for the entire system: Be sure to carry the key during inspection of the smart key system. As weak radio waves are used to detect the key, the key detection area may decrease, or the key may not be detected correctly in the following situations. The key battery is depleted. Any facilities that generate strong radio waves, such as a TV tower, power plant, broadcast station or gas station, are located near the inspection site. A wireless device, such as a cell phone, is carried with the key. The key is in contact with or covered by metal. Electric wave type keyless entry systems are being operated nearby. The key is located near a device that generates high voltage or noise. Film with some metallic content is applied to the back glass. HINT: In this case, remove the film or unlock the door using the mechanical key. Even if the key is in the vehicle exterior key detection area, the key may not operate properly due to the vehicle body design. The key may not be detected correctly if it is around the vehicle windows, door handles or bumpers, even when it is in the detection area outside the vehicle. The key may not be detected correctly if it is on the instrument panel or floor, or in the glove box, even when it is in the detection area inside the vehicle. The key may not operate if the key is not held properly. The smart key system does not operate under the following conditions: The smart key system is canceled. The key battery is completely depleted (the indicator does not blink when pushing any of the switches on the key).
3. FUNCTION OF MAIN COMPONENTS Component Function Certification ECU Controls the smart key system in accordance with signals from each antenna, various switches, ECUs and the key. Performs key verification. Performs vehicle interior/exterior transmission. Performs occupant sensor control. Sends lock/unlock commands during entry function. Sends steering lock/unlock commands. Sends immobiliser set/unset commands. Records verification codes. Main body ECU Receives request signals from the certification ECU and actuates each door lock motor to unlock or lock the doors. Transmits each door condition to the certification ECU. Power management control ECU Controls the push button start function in accordance with signals from various switches, ECUs and the combination meter. Transmits the electrical key verification request signal to the certification ECU in accordance with the engine switch signal and turns relays on and off. Multiplex network door ECU (back door P/W) Transmits a back door window open (door unlock) request signal to the certification ECU. ID code box Receives a command from the certification ECU and sends an immobiliser set/unset command to the ECM. Records verification codes. Indoor electrical key antenna assembly (front floor, rear floor and inside luggage) Receives a request signal from the certification ECU and forms the detection area in the vehicle interior. Door control receiver Receives the ID code from the key in the detection area and transmits it to the certification ECU. Electrical key antenna (outside luggage) Receives a request signal from the certification ECU and forms the detection area around the back door. Back door control switch Transmits a back door window open (door unlock) request signal to the multiplex network door ECU. Transmits a door lock request signal to the certification ECU. Back door opener switch assembly Transmits a door unlock request signal to the certification ECU. Front door outside handle assembly (for driver, front passenger side doors) Receives a request signal from the certification ECU and forms the detection area around front door. Transmits door unlock request signals to the certification ECU. Transmits door lock request signals to the certification ECU. Key Consists of a mechanical key, a transmitter for wireless door lock control and a transceiver for the smart key system. Wireless door lock buzzer Combination meter assembly Multi-information display Buzzer When the certification ECU detects human errors, such as those below, it warns the driver by sounding the wireless door lock buzzer, displays information and sounds the buzzer in accordance with the request signal from the ECU. Example: The key is brought out of the vehicle while the engine is still running. The key is brought out of the vehicle while the shift lever is in a position other than P.
4. CONSTRUCTION AND OPERATION Key: A total of 7 keys can be registered. Electrical key transmitter: The electrical key transmitter consists of a mechanical key, a transmitter function for the wireless door lock control and a transceiver for the smart key system. The transceiver function for the smart key system receives the signals from the antennas and sends the ID code to the door control receiver. The transmitter function for the wireless door lock control has a lock switch, unlock switch and panic switch. The mechanical key can lock/unlock all the doors. To lock or unlock the doors, insert the key into the door key cylinder, and then turn it to the lock or unlock position. TEXT IN ILLUSTRATION *1 Lock Switch *2 Unlock Switch *3 Panic Switch *4 Mechanical Key Antenna (front door, front floor, rear floor, inside luggage and outside luggage): Each antenna transmits the request signal received from the certification ECU, and forms a key detection area to detect the presence of a key. The detection area formed by the front door antenna and outside luggage antenna is approximately 0.7 to 1.0 m (2.30 to 3.28 ft.) from the outside handle of the front door and rear bumper. The detection area of the front door antenna is formed by transmitting a request signal every 0.25 seconds while the engine switch is off and all the doors are locked. In this way, it detects the proximity of a key. During entry lock, the detection area is formed with the lock sensor on. The detection area of the outside luggage antenna is formed when the unlock switch is on. The detection area of the indoor antennas (front floor, rear floor and inside luggage) is formed when the driver door is open or closed, during starting, when a warning is activated, or when the lock sensor is on.
5. ENTRY FUNCTION OPERATION The smart key system has the following functions. Function Outline Mechanical Key Operation is the same as a conventional mechanical key. Wireless Door Lock Control This function remotely locks and unlocks all the doors and the back door. Operation is the same as the wireless door lock control system. However, the receiver in the certification ECU uses the door control receiver to control locking and unlocking. Entry Unlock When the key is located in the detection area of the electrical key antenna, the door can be unlocked by touching the inside of the front door outside handle. Entry Unlock Mode Switching. Refer to «CUSTOMIZE PARAMETERS»(ref-422211-S38349874092011092600000) Changes the doors that can be unlocked with the entry unlock function between 2 modes. Driver door unlock mode. All door unlock mode. Entry Lock When the key is located in the detection area of the electrical key antenna and the engine switch is off, the door can be locked by touching the lock sensor on the front door outside handle. When the key is located in the detection area of the outside luggage electrical key antenna and the engine switch is off, the door can be locked by pressing the lock switch on the back door control switch. Entry Back Door Unlock When the key is in the detection area of the electrical key antenna (outside luggage), the door can be unlocked by pressing the unlock switch on the back door control switch or the back door opener switch. Back Door Power Window Function Pressing the unlock switch on the back door control switch for approximately 1 second or more causes the back door window to open while sounding wireless buzzer. Pressing the lock switch on the back door control switch for approximately 1 second or more causes the back door window to close while sounding wireless buzzer. Key Lock-in Prevention Prevents lock-in of the key if the door is locked while the key is still inside the vehicle. Prevents lock-in of the key if the glass hatch is closed while the key is still inside the vehicle. Entry Illumination When a person carrying the key enters the detection area, the door enters unlock standby mode and the room light illuminates. Warning When any of the situations below occur, the smart key system causes the certification ECU to sound the buzzer in the combination meter and the wireless door lock buzzer, and display information in order to alert the driver. Shift lever not in P (power source cut reminder) vehicle exit warning Key reminder warning Shift lever in P (power source cut reminder) vehicle exit warning Entry door ajar warning Passenger has brought key out of vehicle warning Key is not within detection area warning Key lock-in prevention function buzzer Key battery low warning Battery Saving If the key is constantly located within the detection area of the door antenna, the system maintains periodic communication with the key. Therefore, if the vehicle remains parked in that state for a long time, the key battery and vehicle battery may be drained. For this reason, the vehicle has controls for saving battery power. Key Cancel. Refer to «CUSTOMIZE PARAMETERS»(ref-422211-S38349874092011092600000) The following key functions can be canceled: Entry unlock/lock Entry ignition Entry back door open Key lock-in prevention Warning
6. ENTRY UNLOCK FUNCTION The detection area is formed by communication between an electrical key antenna and the certification ECU when the door is locked in order to detect the person carrying the key. When the person carrying the key enters the detection area around the vehicle, the matching of the ID codes for an electrical key antenna and key is automatically performed. After the matching is completed, the door enters unlock standby mode. In unlock standby mode, the electrical key antenna built into the outside handle starts operating. If the outside handle is held (the back side of the handle is touched), the door unlock operation is performed. At this time, the hazard warning lights blink twice. If any of the doors are not opened after a door unlock operation, all the doors automatically lock after 30 seconds.
7. ENTRY LOCK FUNCTION After leaving the vehicle while carrying the key, touch the lock sensor on the outside handle or push the unlock switch on the back door control switch when all the doors are closed. The certification ECU determines whether the key is located inside or outside of the cabin based on the information from an electrical key antenna and indoor electrical key antenna. Then matching of the ID codes is performed. When the matching result shows that the key is not detected inside the vehicle and the ID codes of the key and electrical key antenna match, the door lock function operates. At this time, the hazard warning lights blink once. If the key is located inside of the cabin, the door lock function does not operate and the alarm buzzer (beep sound) sounds for 2 seconds.
8. ENTRY BACK DOOR UNLOCK FUNCTION Stand in front of the back door with the key and push the unlock switch on the back door control switch or back door opener switch to start the matching of the ID codes for the electrical key antenna. If the ID codes match, the back door unlock operation is performed.
9. BACK DOOR POWER WINDOW FUNCTION Pressing the unlock switch on the back door control switch for approximately 1 second or more operates the back door window open operation. Pressing the lock switch on the back door control switch for approximately 1 second or more operates the back door window close operation. If the back door power window function is operating and the unlock switch or lock switch is released, the back door power window operation stops. The wireless buzzer sounds while the back door power window function is operating. HINT: For more information about the back door power window function, refer to the power window control system. Refer to «SYSTEM DESCRIPTION»(ref-421963-S36343926222011092600000) .
10. PREVENTION OF KEY LOCK-IN FUNCTION If the key is in the cabin, the doors are closed and the entry lock operation is attempted (the lock sensor on the door outside handle is touched), the system determines that the key is located in the cabin and unlocks the doors. If the back door is closed and the lock switch is pressed with the key in the vehicle and the other doors locked, the alarm sounds and the back door does not lock.
11. ENTRY ILLUMINATION FUNCTION In order to improve ease of entering and exiting the vehicle at night, the vehicle lights illuminate when the key is brought near the vehicle.
12. WARNING FUNCTION General: When any of the situations below occur, the smart key system responds to alert the driver. Warning Function Operation Condition Situation Shift lever not in P (power source cut reminder) vehicle exit warning A Key reminder warning B Shift lever in P (power source cut reminder) vehicle exit warning C Entry door ajar warning D Passenger has brought key out of vehicle warning E Key is not within detection area warning F Key lock-in prevention function buzzer (for cabin) G Key battery low warning H Situation A: Shift lever not in P (power source cut reminder) vehicle exit warning With the shift lever not in P, the driver door is opened and vehicle exit (while holding key) is attempted. Reason for warning: Sudden vehicle start prevention, vehicle theft prevention, vehicle roll-away prevention Warning start condition: Shift lever is not in P, engine switch is on (ACC) or on (IG), driver side door is opened and vehicle speed is 0 km/h (0 mph) Warning stop condition: Engine switch is off, shift lever is in P, vehicle speed is above 0 km/h (0 mph) or driver side door is closed Warning description Combination meter buzzer Multi-buzzer Sounds continuously (beep) Combination meter display Combination meter information "Shift to P Range" Telltale None Wireless buzzer None Recommended user action Move shift lever to P With the shift lever not in P, the driver door is opened, the key is brought out of vehicle, the driver door is closed and movement away from the vehicle is attempted. Reason for warning: Sudden vehicle start prevention, vehicle theft prevention, vehicle roll-away prevention Warning start condition: Shift lever is not in P, engine switch is on (ACC) or on (IG), opened driver side door is closed, vehicle speed is 0 km/h (0 mph) and key is not in detected in vehicle interior or luggage interior Warning stop condition: Key is detected in vehicle interior or luggage interior: Buzzer stops and "Shift to P Range" is displayed on combination meter Vehicle speed is more than 0 km/h (0 mph): Buzzer stops and "Key is not detected" - "Check key position" is displayed on combination meter Engine switch off: All warnings are turned off Warning description Combination meter buzzer Multi-buzzer Sounds continuously (beep) Combination meter display Combination meter information Information below is displayed alternately on combination meter "Shift to P Range" "Key is not detected" - "Check key position" Telltale None Wireless buzzer Sounds continuously (beep) Recommended user action Move shift lever to P Situation B: Key reminder warning The steering lock is unlocked, the driver door is opened and movement away from the vehicle is attempted. Reason for warning: Vehicle theft prevention, required by law Precondition: Remote start is not operating Warning start condition: One of following conditions is met Engine switch is off, steering lock is unlocked and driver door is opened Warning stop condition: One of following conditions is met Engine switch is on (IG) or driver door is closed Engine switch is on (ACC) or off, and steering lock is locked Warning description Combination meter buzzer Multi-buzzer Sounds intermittently (several "pon" sounds) Combination meter display Combination meter information None Telltale None Wireless buzzer None Recommended user action If engine switch is on (ACC) or on (IG), turn engine switch off and close driver door Situation C: Shift lever in P (power source cut reminder) vehicle exit warning With the shift lever in P, the driver door is opened, the key is brought out of the vehicle, the driver door is closed and movement away from the vehicle is attempted. Reason for warning: Vehicle theft prevention, "Engine control system cannot be restarted" prevention, battery depletion prevention Warning start condition: Shift lever is in P, engine switch is on (ACC) or on (IG), opened driver side door is closed and key is not in detected in vehicle interior or luggage interior Warning stop condition: Engine switch is off, or key is detected in vehicle interior or luggage interior Warning description Combination meter buzzer Multi-buzzer Sounds once (1 "pon" sound) (when key is not detected continuously, sounds again when vehicle is first driven) Combination meter display Combination meter information "Key is not detected" - "Check key position" Telltale None Wireless buzzer Sounds 3 times (short beeps) Recommended user action Turn engine switch off and exit vehicle while holding key With the shift lever in P and the engine switch on (ACC) or on (IG), the driver door is opened, the user moves away from the vehicle and the door handle lock sensor is touched in an attempt to perform the entry lock operation. Reason for warning: Vehicle theft prevention, battery depletion prevention Precondition: Door control lock switch is turned from off to on Warning start condition: Shift lever is in P, engine switch is on (ACC) or on (IG), all doors are closed, driver side door is opened and closed, key is detected outside of vehicle, key is not detected in vehicle interior and lock sensor is on Warning stop condition: One of following conditions is met Engine switch is off Key is detected in vehicle interior or luggage interior Vehicle speed is more than 0 km/h (0 mph) Shift lever is not in P Warning description Combination meter buzzer Multi-buzzer Sounds once (1 "pon" sound) (when key is not detected continuously, sounds again when vehicle is first driven) Combination meter display Combination meter information None Telltale None Wireless buzzer Sounds continuously (beep) Recommended user action Turn engine switch off and perform entry lock operation Situation D: Entry door ajar warning With one vehicle door open, the entry lock operation is attempted. Reason for warning: Vehicle theft prevention Precondition: Engine switch is on (ACC) or off, and one door is open Warning start condition: Preconditions are met and entry lock operation is performed Warning stop condition: Engine switch is on (ACC) or on (IG), all doors are closed, wireless unlock is performed, entry unlock operation is performed or 10 seconds have passed after warning start Warning description Combination meter buzzer Multi-buzzer None Combination meter display Combination meter information None Telltale None Wireless buzzer Sounds continuously (beep) Recommended user action Close all doors and perform entry lock operation Situation E: Passenger has brought key out of vehicle warning With the engine switch in a condition other than off, the key is brought out of the vehicle by the passenger. Reason for warning: "Engine control system cannot be started" prevention Warning start condition: Engine switch is on (ACC) or on (IG), opened door other than driver side door is closed, vehicle speed is 0 km/h (0 mph) and key is not in detected in vehicle interior or luggage interior Warning stop condition: Engine switch is off or key is detected in vehicle interior or luggage interior Warning description Combination meter buzzer Multi-buzzer Sounds once (1 "pon" sound) (when key is not detected continuously, sounds again when vehicle is first driven) Combination meter display Combination meter information "Key is not detected" - "Check key position" Telltale None Wireless buzzer Sounds 3 times (short beeps) Recommended user action Check if passenger who exited vehicle has key or not Situation F: Key is not within detection area warning With the key not in the vehicle cabin or the key battery depleted, an attempt is made to turn the engine switch on (ACC) or on (IG). Reason for warning: User confusion prevention Warning condition: Engine switch is not off and key is not detected in vehicle interior Warning description Combination meter buzzer Multi-buzzer Sounds once (1 "pon" sound) Combination meter display Combination meter information "Key is not detected" - "Check key position" is displayed for 10 seconds and then display ends Telltale None Wireless buzzer None Recommended user action Check if key is within detection area of vehicle cabin If key is within vehicle interior, built-in battery may be depleted If wireless door lock switch on key is pressed, check if indicator on key illuminates If indicator does not illuminate, replace built-in battery It is recommended that battery be bought at dealer, but battery can be replaced according to user preference Situation G: Key lock-in prevention function buzzer (for cabin) With the key in the vehicle cabin, the vehicle is exited and the door handle lock switch is touched in an attempt to perform the entry lock operation. Reason for warning: Key reminder, vehicle theft warning prevention Warning condition: Engine switch is off, all doors are closed, door handle lock sensor is on and key is detected in vehicle interior Warning description Combination meter buzzer Multi-buzzer None Combination meter display Combination meter information None Telltale None Wireless buzzer Sounds continuously (beep) Recommended user action Pick up key that is in vehicle interior and perform entry lock operation again Situation H: Key battery low warning A key with an almost depleted battery is used to drive the vehicle. Reason for warning: Helpful function Warning condition: After engine switch is not off for 20 minutes or more, engine switch is turned off, key battery is low and key is detected in vehicle interior Warning description Combination meter buzzer Multi-buzzer Sound once (1 "pon" sound) Combination meter display Combination meter information "Low Key Battery" - "Have your vehicle checked by a dealer" Telltale None Wireless buzzer None Recommended user action Replace built-in key battery with new one It is recommended that battery be bought at dealer, but battery can be replaced according to user preference
13. BATTERY SAVING Vehicle battery saving function: While the smart key system is operating, signals are emitted outside of the vehicle at a set interval (0.25 seconds) when the doors are locked. Therefore, the vehicle battery may be drained if the vehicle remains parked for a long time. For this reason, the controls listed below exist. Condition Control Both conditions below are met for 5 days: Key is not in detection area Touch sensor or lock sensor operation is not performed Signal transmission interval is extended from 0.25 to 0.75 seconds Both conditions below are met for 14 days: Key is not in detection area Touch sensor or lock sensor operation is not performed Automatically deactivates the smart key system Reinstatement Conditions: A wireless door lock control signal (lock, unlock) is input and the ID matches. A user carries the key and touches the lock sensor on a door outside handle assembly. The driver door is locked or unlocked by the mechanical key. Key battery and vehicle battery saving function: While the smart key system is operating, if the key is constantly located within the vehicle exterior detection area of the doors, the system maintains periodic communication with the key. Therefore, if the vehicle remains parked in that state for a long time, the key battery and the vehicle battery may be drained. For this reason, if this state continues for more than 10 minutes, the smart key system is automatically deactivated. Reinstatement Conditions: A wireless door lock control signal (lock, unlock) is input and the ID code matches. A user carries the key and touches the lock sensor on a door outside handle assembly. The driver door is locked or unlocked by the mechanical key.
14. KEY DIAGNOSTIC MODE (Using the Techstream) HINT: Key diagnostic mode checks if the electrical key transmitter within a selected antenna detection area is operating normally. The results are output through the wireless door lock buzzer (in the front fender). Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Body Electrical / Smart Key / Utility / Key Communication Check. Check the values by referring to the table below. SMART KEY Tester Display Inspection Range Overhead + Driver Side*1 Electrical key antenna (for Driver Side) Overhead + Passenger Side*2 Electrical key antenna (for Front Passenger Side) Overhead + Front Room*3 Indoor No. 1 electrical key antenna (Front Floor) Overhead + Rear Room*4 Indoor No. 2 electrical key antenna (Rear Floor) Overhead + Back Door (inside)*5 Indoor No. 2 electrical key antenna (Inside Luggage) Overhead + Back Door*6 Electrical key antenna (Outside Luggage) When the electrical key transmitter is brought near the selected antenna, check that the wireless door lock buzzer sounds. *1: Electrical key antenna (for driver side) TEXT IN ILLUSTRATION *a 0.7 to 1.0 m (2.30 to 3.28 ft.) HINT: Hold the key at the same height as the door outside handle (0.7 to 1.0 m [2.30 to 3.28 ft.]). Pay attention to the direction of the key in the illustration. *2: Perform the same inspection above for the other electrical key antenna (for front passenger side). *3: Indoor No. 1 electrical key antenna (front floor) TEXT IN ILLUSTRATION *a Inspection Point HINT: Place the electrical key transmitter on the driver or front passenger seat cushion. *4: Indoor No. 2 electrical key antenna (rear floor) TEXT IN ILLUSTRATION *a Inspection Point HINT: Pay attention to the direction of the key in the illustration. *5: Indoor No. 2 electrical key antenna (inside luggage) TEXT IN ILLUSTRATION *A w/ Rear No. 2 Seat Assembly *B w/o Rear No. 2 Seat Assembly *a Inspection Point HINT: Pay attention to the direction of the key in the illustration. *6: Electrical key antenna (outside luggage) TEXT IN ILLUSTRATION *a 0.7 to 1.0 m (2.30 to 3.28 ft.) HINT: Hold the electrical key transmitter at the same height as the rear bumper upper surface. Pay attention to the direction of the key in the illustration.
