Air Conditioning: Overhaul Toyota 4Runner IV рестайлинг

REASSEMBLY

1. INSTALL BLOWER WITH FAN MOTOR SUB-ASSEMBLY
2. INSTALL BLOWER MOTOR CONTROL
3. INSTALL BLOWER DAMPER SERVO MOTOR SUB-ASSEMBLY
4. INSTALL AIR FILTER COVER PLATE
5. INSTALL CLEAN AIR FILTER
6. INSTALL CLEAN AIR FILTER SUB-ASSEMBLY

Scheme 198

1. INSTALL BLOWER ASSEMBLY Install the blower assembly with the claw fitting. Install the bolt, 2 screws and nut. Torque: Bolt 9.8 N*m (100 kgf*cm, 87 in.*lbf) Nut 5.4 N*m (55 kgf*cm, 48 in.*lbf) Install the 7 clamps and connect the connectors.
2. INSTALL AIR DUCT NO. 2
3. INSTALL INSTRUMENT PANEL REGISTER ASSEMBLY NO. 2
4. INSTALL INSTRUMENT PANEL FINISH PANEL LOWER NO. 2
5. INSTALL GLOVE COMPARTMENT DOOR SUB-ASSEMBLY
6. INSTALL GLOVE COMPARTMENT DOOR STOPPER SUB-ASSEMBLY
7. INSTALL INSTRUMENT PANEL UNDER COVER SUB-ASSEMBLY NO. 2
8. INSTALL COWL SIDE TRIM BOARD RH
9. INSTALL CONSOLE BOX ASSEMBLY REAR
10. INSTALL CONSOLE UPPER PANEL GARNISH NO. 2
11. INSTALL CONSOLE UPPER PANEL GARNISH NO. 1
12. INSTALL CONSOLE PANEL SUB-ASSEMBLY UPPER
13. INSTALL CONSOLE UPPER REAR PANEL SUB-ASSEMBLY

Scheme 199

Scheme 200

Scheme 201

Scheme 202

1. DISCHARGE REFRIGERANT FROM REFRIGERATION SYSTEM (See «REPLACEMENT»(ref-280565-S20898576202008022200000) )
2. REMOVE ENGINE UNDER COVER SUB-ASSEMBLY NO. 1
3. REMOVE FAN AND GENERATOR V BELT
4. DISCONNECT DISCHARGE HOSE SUB-ASSEMBLY Remove the nut and disconnect the discharge hose sub-assembly from the compressor and magnetic clutch. Remove the O-ring from the discharge hose sub-assembly. NOTE: Seal the opening of the disconnected parts using vinyl tape to prevent moisture and foreign matters from entering.
5. DISCONNECT SUCTION HOSE SUB-ASSEMBLY Remove the nut and disconnect the suction hose sub-assembly from the compressor and magnetic clutch. Remove the O-ring from the suction hose sub-assembly. NOTE: Seal the opening of the disconnected parts using vinyl tape to prevent moisture and foreign matters from entering.
6. REMOVE COMPRESSOR AND MAGNETIC CLUTCH Disconnect the connector. Remove the 4 bolts and the compressor and magnetic clutch.

Scheme 203

Scheme 204

Scheme 205

1. REMOVE MAGNETIC CLUTCH ASSEMBLY Place the compressor and magnetic clutch in a vise. Using SST, remove the bolt, the magnetic clutch hub and the magnetic clutch washer. SST 09960-10010 (09962-01000, 09963-00500) Using a snap ring expander, remove the snap ring and the magnetic clutch rotor. Remove the screw and disconnect the connector. Using a snap ring expander, remove the snap ring and the magnetic clutch starter.
2. REMOVE COOLER COMPRESSOR ASSEMBLY

Scheme 206

1. INSPECT MAGNETIC CLUTCH CLEARANCE Set the dial indicator to the magnetic clutch hub. Connect the battery positive lead to terminal 1 of magnetic clutch connector and the negative lead to the earth wire. Turn on and off the magnetic clutch and measure the clearance. Standard clearance: 0.35 to 0.60 mm (0.013 to 0.023 in.) If the measured value is outside the standard range, remove the magnetic clutch hub and adjust it with the magnetic clutch washers. NOTE: Adjustment shall be performed with 3 or less magnetic clutch washers.
2. INSPECT COMPRESSOR OIL When replacing the compressor and magnetic clutch with a new one, after gradually removing the refrigerant gas from the service valve, drain the following amount of oil from the new compressor and magnetic clutch before installation. Standard: (Oil capacity inside new compressor and magnetic clutch: 120 +15 cc (4.0 + 0.5 fl. oz.)) - (Remaining oil amount in the removed compressor and magnetic clutch) = (Oil amount to be removed when replacing) NOTE: When checking the compressor oil level, observe the precautions on the cooler removal/installation. Because compressor oil remains in the pipes of the vehicle, if a new compressor and magnetic clutch is installed without removing some oil inside, the oil amount becomes excessive, preventing heat exchange in the refrigerant cycle and causing refrigerant failure. If the remaining oil in the removed compressor and magnetic clutch is too small in volume, check for oil leakage. Be sure to use ND-OIL8 for compressor oil.

Scheme 207

Scheme 208

Scheme 209

Scheme 210

1. INSTALL MAGNETIC CLUTCH ASSEMBLY Install the magnetic clutch starter. Using a snap ring expander, install a new snap ring with the chamfered side facing up. Install the screw and connect the connector. Using a snap ring expander, install the magnetic clutch rotor and a new snap ring with the chamfered side facing up. Install the magnetic clutch washer and the magnetic clutch hub. NOTE: Do not change the combination of the magnetic clutch washers used before disassembly. Using SST, install the magnetic clutch hub and magnetic clutch washer with the bolt. SST 09960-10010 (09962-01000, 09963-00500) Torque: 18 N*m (183 kgf*cm, 13 ft.*lbf)

1. INSTALL COOLER CONTROL SWITCH BULB (INDEPENDENCE TEMPERATURE CONTROL)
2. INSTALL COOLER CONTROL SWITCH BULB (EXCEPT INDEPENDENCE TEMPERATURE CONTROL)
