Removal & Installation
Remove door trim panel and waterproof shield. Remove glass retaining bolts and glass. Remove window regulator bolts, and remove window regulator/power window motor assembly. Remove power window motor retaining screws, and remove motor from window regulator. To install, reverse removal procedure. Tighten window regulator motor retaining bolts or nuts to 44 INCH lbs. (5 N.m). Apply multipurpose grease to window regulator rollers.
Disconnect negative battery cable. Using a small flat blade screwdriver, pry and lift power window switch from door panel. Disconnect power window switch connector(s) and remove switch. To install, reverse removal procedure.
Power Window System Wiring Diagram (2000 Tundra). Scheme 1
Scheme 1: Power Window System Wiring Diagram (2000 Tundra)
Power Window System Wiring Diagram (Land Cruiser). Scheme 2
Scheme 2: Power Window System Wiring Diagram (Land Cruiser)
Power Window System Wiring Diagram (RAV4 - 2-Door). Scheme 3
Scheme 3: Power Window System Wiring Diagram (RAV4 - 2-Door)
Power Window System Wiring Diagram (RAV4 - 4-Door). Scheme 4
Scheme 4: Power Window System Wiring Diagram (RAV4 - 4-Door)
Power Window System Wiring Diagram (Sienna). Scheme 5
Scheme 5: Power Window System Wiring Diagram (Sienna)
Power Window System Wiring Diagram (Tacoma). Scheme 6
Scheme 6: Power Window System Wiring Diagram (Tacoma)
Power Window System Wiring Diagram (4Runner). Scheme 7
Scheme 7: Power Window System Wiring Diagram (4Runner)
Tailgate Power Window System Wiring Diagram (4Runner). Scheme 8
Scheme 8: Tailgate Power Window System Wiring Diagram (4Runner)
Rear Quarter Power Window System Wiring Diagram (Land Cruiser). Scheme 9
Scheme 9: Rear Quarter Power Window System Wiring Diagram (Land Cruiser)
