Steering Column - Tilt Toyota 4Runner I

DESCRIPTION

Tilt steering wheels incorporate an upper steering shaft, attached by a universal joint, with an intermediate steering shaft. These shafts are held in place by upper and lower brackets.

Brackets are pinned together so upper bracket can move up or down. Upper bracket is locked in place by pawl attached to lever. Steering columns are collapsible.

Some models of Cressida and Supra use a Progressive Power Steering (PPS) system and/or a Toyota Electronically Modulated Suspension (TEMS). the steering sensor for either system is located under the steering column near the break-away bracket.

Note. For models without tilt wheel steering columns, see STEERING COLUMN - FIXED article in this section.

Removal

1. Disconnect battery ground cable. Remove steering wheel. Refer to «STEERING WHEEL & COLUMN SWITCHES»(/toyota/4runner/i-1984-1989/remont/steering-column-switches/#steering-wheel-column-switches) in this section. On Cressida, FWD Corolla, MR2 and Tercel models, remove fuse box cover, lower instrument trim panel and heater duct (located under steering column).
2. On all models, remove upper and lower steering column covers. Remove combination switch. Refer to «STEERING WHEEL & COLUMN SWITCHES»(/toyota/4runner/i-1984-1989/remont/steering-column-switches/#steering-wheel-column-switches) in this section.
3. Mark position of universal joints and shaft for reassembly. On models with universal joints, remove universal joint retaining bolt. Remove intermediate steering shaft.
4. On models with flexible joint, remove flexible joint retaining bolt. Mark position of flexible joint and gearbox shaft for reassembly.
5. Remove floor pan cover bolts. Remove tilt bracket-to-dashboard bolts. Remove steering column toward inside of vehicle.

Exploded View of Camry, Corolla, MR2 & Tercel Steering Column Assembly Camry is shown. Corolla, MR2 and Tercel are similar. Courtesy of Toyota Motor Sales, U.S.A., Inc. Scheme 1

Exploded View of Celica, Cressida & Supra Steering Column Assembly Celica is shown. Cressida and Supra are similar. Courtesy of Toyota Motor Sales, U.S.A., Inc. Scheme 2

Exploded View of Landcruiser, Truck, Van & 4Runner Steering Column Assembly Truck is shown. Landcruiser, Truck and 4Runner are similar. Courtesy of Toyota Motor Sales, U.S.A., Inc. Scheme 3

Note. Remove steering column with intermediate shaft attached on 2WD Pickup models.

Installation (Landcruiser Pickup, Van & 4Runner)

1. To install steering columns, reverse disassembly procedures. Grease main steering shaft and all bearings.
2. Ensure marks made to flexible couplings and to "U" joints are aligned. Ensure steering column and shafts do not bind after installation.

Disassembly (Camry, Corolla, MR2 & Tercel)

Note. The Camry, Corolla, MR2 and Tercel all have similar steering column assemblies. Some of the following procedures will not pertain to all models.

1. Remove torsion springs and grommets. Remove 2 screws from tilt bracket. Remove tilt lever reverse-thread set bolt. Remove column upper support lock bolt.
2. Remove tilt steering support bolts and pawl set bolts. Place bushings and "O" rings aside and keep them clean. Remove ignition lock cylinder. Refer to «STEERING WHEEL & COLUMN SWITCHES»(/toyota/4runner/i-1984-1989/remont/steering-column-switches/#steering-wheel-column-switches) in this section.
3. Using a screwdriver, push two thrust stoppers into bearing retainers. Pull out shaft from column. Remove the No. "1" column ring, bearing retainer, thrust stoppers and No. "2" column ring from shaft.
4. Remove snap ring and lower bearing from shaft. Remove bearing inner snap ring. Remove upper bracket retaining bolts and ground strap. Separate upper bracket from column.

Inspection (Camry, Corolla, MR2 & Tercel)

1. Check that steering lock mechanism operates properly. Check upper bearing for smooth rotation or excessive noise. Replace upper bearing (if necessary).
2. Using Drift (09631-00020 ) and Adapter (09627-30010 ), drive bearing from upper bracket. Pack new bearing with grease. Using the same drift and adapter used in removal, drive new bearing into upper bracket.
3. Inspect lower bearing for smooth rotation or excessive noise. If damaged, replace lower bearing when reasssembling.

Scheme 4

Scheme 5

Scheme 6

1. Install upper bracket onto column. Make sure ground strap is in position and tighten retaining bolts to 14 ft. lbs. (19 N.m). Install inner snap ring on shaft groove nearest to center of shaft.
2. Install lower bearing. Install lower bearing snap ring. Place No. "2" column ring into position next to bearing on side nearest center of shaft. (Scheme 4)
3. With thrust stoppers installed in the bearing retainers, place bearing retainers over lower bearing. Install No. "1" column ring over the 2 bearing retainer grooves to secure bearing retainers.
4. Insert shaft into column. Align thrust stoppers with notches at bottom of column. Holding thrust stoppers in with a screwdriver, insert shaft into column until snap ring nearest center of shaft bottoms.
5. Turn bearing retainers to seat thrust stoppers in column slots (if necessary). Install snap ring on shaft at upper bracket end of shaft. Replace ignition lock cylinder. Insert key and turn to "ACC" position. Insert cylinder into upper bracket.
6. Install tilt steering support. (Scheme 5) Apply lithium grease to bushings and "O" rings. Install bushings to column. Install tilt steering support and pawl set bolts with bushings and "O" rings in place. Tighten nuts to 108 INCH lbs. (10 N.m).
7. Lubricate and then install tilt lever lock bolt, washer and adjusting nut. (Scheme 6) Hand tighten adjusting nut. Adjust upper column support so that lock bolt is in center of oval and so that support bracket is parallel with column as seen from the side of upper column support.
8. Tighten adjusting nut to 96 INCH lbs. (10 N.m). Install tilt lever. Tighten reverse threaded set bolt to 25 ft. lbs. (33 N.m). Install 2 screws with washers to tilt bracket. Install torsion springs and grommets.

Disassembly (Celica, Cressida & Supra)

Note. The Celica, Cressida and Supra all have similar steering column assemblies. Some of the following procedures will not pertain to all models.

1. Remove the Progressive Power Steering (PPS) sensor cover. Remove PPS sensor. Make sure to keep sensing part of sensor clean. Remove column cover. Remove combination switch. Refer to «STEERING WHEEL & COLUMN SWITCHES»(/toyota/4runner/i-1984-1989/remont/steering-column-switches/#steering-wheel-column-switches) in this section.
2. Tilt steering mainshaft all the way up in the tilt mechanism. Remove mainshaft retaining bolt. Remove 4 column bracket retaining bolts. Pull column along with intermediate shaft from column bracket.
3. On Cressida models, push two thrust stoppers into bearing retainers. Pull out intermediate shaft from column. Remove the No. "1" column ring, bearing retainer, thrust stoppers and No. "2" column ring from shaft.
4. Remove snap ring and lower bearing from shaft. Remove bearing. Remove next snap ring. Remove dust seal from column. With the tilt bracket tilted up fully and using a screwdriver, remove springs and cords from tilt bracket.
5. Using Steering Shaft Retainer (09950-20016 ), tighten steering mainshaft against the upper bracket. Take care not to overtighten the steering shaft retainer. Remove snap ring. Remove Steering mainshaft.
6. On Celica models, remove 2 thrust stopper set bolts. Remove intermediate shaft. Remove 4 breakaway bracket retainer bolts. Remove column from breakaway bracket.
7. With the tilt bracket tilted up fully and using a screwdriver, remove springs and cords from breakaway bracket. Remove snap ring. Remove mainshaft. Remove spring and collar from mainshaft.
8. On Supra models, with the tilt bracket tilted up fully and using a screwdriver, remove springs and cords from tilt bracket. Remove 4 tilt mechanism bolts. Separate tilt mechanism from column.
9. Remove tilt bracket support reinforcement from tilt steering support. Remove 3 bracket-to-support attaching bolts. Remove snap ring. Remove mainshaft from upper bracket.
10. On all models, Remove 2 tilt lever springs from side of column. Remove all bracket attaching nuts and bolts. Remove tilt lever retainer. Remove release pin from pawl.
11. Temporarily install the nut on the serrated bolt to protect the threads. Using a light soft mallet, drive out serrated bolt. Remove nut from serrated bolt. Remove column cover support. Remove breakaway bracket nut and bolt.
12. Separate breakaway bracket and upper bracket. Place in order of removal 2 bushings, tilt control lever, shim, tilt adjust lever, memory cover and memory lever. Remove pawl set bolt. Remove ignition key/lock cylinder by pushing lock pin in and removing cylinder (if necessary).

Inspection (Celica, Cressida & Supra)

1. Check that steering lock mechanism operates properly. Check upper bearing for smooth rotation or excessive noise. Replace upper bearing (if necessary).
2. Using Drift (09631-00020 ), Adapter (09627-30010 ) and Sleeve (09636-20010 ), drive bearing from upper bracket. Pack new bearing with grease. Using the same drift and adapter used in removal, place upper bracket on block of wood and drive new bearing into upper bracket.
3. Inspect lower bearing for smooth rotation or excessive noise. If damaged, replace. Using Bearing Collar (09527-20011 ) and a press, drive lower bearing from shaft.
4. Using Sleeve (09612-22011 ) and Bearing Plates (09237-00010 ) and vise, drive new bearing onto shaft. Check PPS sensor ring and intermediate shaft bearing for wear or damage. NOTE: If bearing is damaged and needs to be replaced, it is necessary to first remove the PPS sensor ring. Whenever the PPS sensor ring is removed, it must be replaced with a new sensor ring.
5. Place intermediate shaft in a soft-jawed vise. Remove sensor ring from intermediate shaft. (Scheme 2) Remove bearing snap ring. Tap bearing from shaft. Pack new bearing with grease.
6. Place bearing over intermediate shaft and slide into position to be installed. Lay intermediate shaft between jaws of soft vise with bearing at side of shaft next to universal joint.
7. Using a plastic hammer, lightly tap the shaft towards the vise to drive the bearing onto the larger section of the shaft. Install snap ring. Using a press and Collar (09515-21010 ), press the new PPS sensor ring onto shaft with lettering facing away from universal joint.

Note. Make sure that Toyota lettering on PPS sensor ring faces away from universal joint when installing new sensor ring to intermediate shaft.

Reassembly (Celica, Cressida & Supra)

1. Coat all moving, rubbing or sliding parts with grease. Use new "O" rings where needed. Install adjuster memory cover to upper bracket. Install pawl set bolt. Tighten pawl set bolt nut to 14 lbs. (19 N.m). (Scheme 2)
2. Install tilt lever and tilt control lever over the mounting pin. Use a bushing that will eliminate all play between tilt adjust lever and tilt control lever and the mounting pin.
3. Bushings are available in sizes between.7087-.7100" (18.002-18.026 mm) in.0002" (.007 mm) increments. Install tilt steering pawl over pawl pivot pin. Align holes and install release pin.
4. Install tilt lever retainer. Install retainer attaching nut and bolt and tighten to 14 ft. lbs. (19 N.m). Using a drift and hammer, drive serrated bolt into breakaway bracket. Check that bolt collar is firmly installed into pivot of control lever inside plate.
5. Install nut onto serrated bolt and tighten to 14 ft. lbs. (19 N.m). Select bushing for opposite side of tilt bracket that will eliminate all play. Bushings for this side are available in sizes between.7089-.7100" (18.005-18.035 mm) in.0005" (.015 mm) increments.
6. Select a shim or shims that will fit snugly between pivot points of upper bracket. Shims are available in sizes between.0067-.0728" (.17-1.85 mm) in increments of.011" (.30 mm).
7. Install selected bushing and shim or shims into upper bracket pivot. Install bolt with a new nut and tighten to 14 ft. lbs. (19 N.m). Install column cover support. Install stopper bolt and a new nut. Tighten to 96 INCH lbs. (11 N.m).
8. Install 2 springs to side of tilt bracket. Install collar and spring over mainshaft. Turn ignition to "ACC" position and insert mainshaft assembly into upper bracket.
9. Using Steering Shaft Retainer (09950-20016 ), tighten steering mainshaft against the upper bracket. Take care not to overtighten steering shaft retainer. Install snap ring. Remove steering shaft retainer.
10. Connect tilt bracket springs to cords and install into top of tilt bracket. Install dust seal to column. Install column tube to breakaway bracket. Tighten bolts to 14 ft. lbs. (19 N.m).
11. With thrust stoppers installed in the bearing retainers, place bearing retainers over lower bearing. Install No. "1" column ring over the 2 bearing retainer grooves to secure bearing retainers.
12. Insert shaft into column. Align thrust stoppers with notches at bottom of column. Holding thrust stoppers in with a screwdriver, insert intermediate shaft into column until snap ring nearest center of shaft bottoms.
13. Turn bearing retainers to seat thrust stoppers in column slots (if necessary). Connect main shaft-to-intermediate shaft universal joint. Tighten attaching bolt to 19 ft. lbs (25 N.m).
14. Install PPS sensor to bottom of column. Check that sensor does not touch sensor ring by turning steering shaft and listening for rubbing sound. Install PPS sensor cover.
15. Check for smooth operation of all shafts and universal joints. Using the tilt lever, check that the mainshaft locks in all 8 positions. With the mainshaft in the neutral position, pull the tilt lever and check that the mainshaft rises to the uppermost position.
16. Check that the mainshaft locks in the bottom position. Install combination switch, steering wheel and column covers. Refer to «STEERING WHEEL & COLUMN SWITCHES»(/toyota/4runner/i-1984-1989/remont/steering-column-switches/#steering-wheel-column-switches) in this section.

Disassembly (Landcruiser, Pickup, Van & 4Runner)

1. Remove ignition key cylinder. Refer to «STEERING WHEEL & COLUMN SWITCHES»(/toyota/4runner/i-1984-1989/remont/steering-column-switches/#steering-wheel-column-switches) in this section. Mark intermediate shaft and universal joints for reassembly reference. Remove universal joint retaining bolts. Disconnect intermediate shaft from mainshaft.
2. Remove upper tension springs and cords. Remove bracket from column. Press in ignition cylinder retaining pin and pull out ignition cylinder. Remove upper bracket retaining bolts. remove upper bracket.
3. Remove mainshaft retaining snap ring. Remove mainshaft from upper bracket. Remove tilt lever side tension springs, "E" clip, bushings, nut and washer. Remove tilt lever.
4. Remove tilt lever retaining bolt, nuts and washers. Remove tilt lever retainer and bushing. Remove tilt lever. Remove release pin. Remove serrated bolt. Remove tilt pawl.
5. Remove column cover support nuts, bolts, bushings washers and shims. Remove column cover support. Remove tilt steering support with tilt lever subassembly. Remove pawl set bolt.

Inspection (Landcruiser, Pickup, Van & 4Runner)

Inspect all components for wear or damage. Check bearings for smooth operation. Check steering shafts for collision damage. Check steering lock mechanism (located in upper bracket) for proper operation. Inspect universal joints for excessive play. Replace components as necessary.

Note. If replacing pin and bearing blocks, make sure new bearing blocks have the small anti-rattle rubber inserts installed before assembling intermediate shaft to main steering shaft.

Reassembly (Landcruiser, Pickup, Van & 4Runner)

1. Lubricate all moving parts with multipurpose grease before reassembly. Install pawl set bolt. Tighten pawl set bolt to 13 lbs. (18 N.m).
2. Assemble tilt lever assembly. Select a bushing to eliminate all play. Bushings are available in sizes between .7086-.7100" (17.998-18.033 mm) in increments of .0003" (.007 mm). 3)Install tilt pawl. Install tilt steering support to column bracket. Using a drift and hammer, drive in serrated bolt. Install shim and bolt to tilt pawl. Select a shim to eleminate all play.
3. Shims are available in thicknesses between .0078-.0711" (.193-1.805 mm) in increments of .117" (.302 mm). Install column cover support. Install release pin to tilt pawl.
4. Install tilt lever retainer attaching bolt, nuts and washers. Tighten bolt and nuts to 13 ft. lbs. (18 N.m). Install tilt lever. Install tilt lever tension spring, "E" clip, bushings, nut and washer.
5. Install mainshaft to upper bracket. Install snap ring. Install ignition switch. Refer to «STEERING WHEEL & COLUMN SWITCHES»(/toyota/4runner/i-1984-1989/remont/steering-column-switches/#steering-wheel-column-switches) in this section. Install upper bracket to column bracket.
6. Apply a thread locking compound and tighten upper bracket-to-column bracket bolts to 65 INCH. lbs. (7.4 N.m). Install steering column to column bracket. Tighten to 14 ft. lbs. (19 N.m). Connect intermediate shaft using marks made during disassembly. Tighten to 19 ft. lbs. (25 N.m). Install tension springs and cords.
