Data Communication System: Removal & Installation Suzuki XL7 I

Communication Devices 4 illustrations ~165 words

Removal Procedure

Note. If data is not retrieved from the malfunctioning body control module (BCM), additional time will be required to program the replacement BCM.

Scheme 20

Scheme 20: Removal Procedure

Scheme 21

Scheme 21
  1. Retrieve data from the malfunctioning BCM. Refer to «CONTROL MODULE REFERENCES»(ref-268408-S27515093052007102300000) .
  2. Rotate the ignition switch to the OFF position.
  3. Remove the Instrument Panel Lower Brace Bezel. Refer to «INSTRUMENT PANEL LOWER BRACE BEZEL REPLACEMENT»(ref-268421-S11188834192007102300000) .
  4. Disconnect the BCM electrical harnesses.
  5. Remove the BCM (1) from the instrument panel (I/P) retainer: Pry the BCM tabs from the locking tabs on the underside of the restraint. Slide the BCM out of the retainer.

Scheme 22

Scheme 22: Installation Procedure

Scheme 23

Scheme 23
  1. Install the BCM.
  2. Install the Instrument Panel Lower Brace Bezel. Refer to «INSTRUMENT PANEL LOWER BRACE BEZEL REPLACEMENT»(ref-268421-S11188834192007102300000) .
  3. Slide the BCM (1) tabs into the slots in the I/P retainer until the tabs lock into place.
  4. Connect the electrical connectors.
  5. Program a new or a remanufactured BCM. Refer to «CONTROL MODULE REFERENCES»(ref-268408-S27515093052007102300000) .
