Note. The link mechanism of the heater varies depending on the specifications.

The heater, an in and out air selectable-type hot water heater, is so constructed that it is possible to assure an agreeable ventilation at all times by providing the ventilator air outlets at the center and both sides (right and left) of the instrument panel, the hot air outlet at a place close to the feet of front passengers, and the defroster air outlets at places, right and left, along the windshield glass.

The heater and ventilation consist of the following parts.

Scheme 34

Scheme 34: HEATER & VENTILATION CONSTRUCTION

BODY VENTILATION CONSTRUCTION

The body ventilation system of this vehicle has a fresh air intake located at the cowl top panel. When fresh air intake control lever is at FRESH AIR position, ventilating air is drawn into the interior from the cowl center garnish and drawn out from the ventilator outlet provided at each side body outer panel (both right and left side).

Scheme 35

Scheme 35: BODY VENTILATION CONSTRUCTION

Scheme 36

Scheme 36: HEATER & VENTILATION WIRING CIRCUIT DIAGRAM

Scheme 37

Scheme 37: REAR DUCT LOCATION

Scheme 38

Scheme 38: HEATER & VENTILATION SYMPTOM DIAGNOSIS

Scheme 39

Scheme 39: HEATER BLOWER UNIT COMPONENTS

Scheme 40

Scheme 40: REMOVAL

Scheme 41

Scheme 41

Scheme 42

Scheme 42

Scheme 43

Scheme 43
  1. Disconnect negative (-) cable at battery.
  2. Disable air bag system, if equipped. See «DISABLING & ACTIVATING AIR BAG SYSTEM»(ref-160470-S11816149552004021000000) .
  3. Open glove box, then remove screw.
  4. Remove glove box.
  5. Remove passenger lower member (1).
  6. Remove ECM (1) with bracket (2) from blower motor unit (4).
  7. Disconnect blower motor, blower motor relay (2) and resistor lead wires at couplers (3).
  8. Remove cooling unit (If equipped). See «HEATER UNIT REMOVAL & INSTALLATION»(ref-182730-S18178435722005080900000) .
  9. Disconnect fresh air control cable from blower motor case.
  10. Remove fastening nuts (1), remove blower motor unit.
