Starting System: Removal & Installation Suzuki Kizashi I

Removal

1. Disconnect negative (-) cable at battery.
2. Remove engine cover.
3. Remove air cleaner outlet hose, see «AIR CLEANER ASSEMBLY REMOVAL AND INSTALLATION»(ref-585578-S10930133882013111200000) .
4. Disconnect magnetic switch lead wire (1) and starting motor cable (2) from starting motor.
5. Remove starting motor mounting bolts (3).
6. Remove starting motor (4).

Installation

Reference: STARTING MOTOR INSPECTION

Reverse removal procedure, noting the following points.

Scheme 7

1. Tighten starting motor mounting bolts (3) and starting motor cable nut (5) to specified torques. Tightening torque Starting motor cable nut (a): 11 N.m (1.1 kg-m, 8.5 lbf-ft) Starting motor mounting bolt (b): 45 N.m (4.6 kg-m, 33.5 lbf-ft)

Scheme 8
