Heater and Ventilation: Adjustments Suzuki Forenza I

Automatic HVAC System 7 illustrations ~318 words

Temperature Cable Adjustment

Because the cable and the cable housings have fixed lengths, it is impossible to make a temperature cable adjustment.

In addition, the heater/air distributor case linkage cannot be adjusted.

If a malfunction is suspected, verify the proper operation of the controller and the mechanical doors for the heater/air distributor case assembly.

Scheme 1

Scheme 1: Removal
Scheme 1: Removal

Scheme 2

Scheme 2
Scheme 2

Scheme 3

Scheme 3
Scheme 3
  1. Disconnect the negative battery cable.
  2. Remove the center molding. Refer to «CENTER MOLDING REMOVAL AND INSTALLATION»(ref-257070-S11505794982007062900000) .
  3. Disconnect the mode control cable from the mode door.
  4. Disconnect the temperature control cable eyelet from the post on the controller.
  5. Pry off the clip of the temperature control cable.
  6. Slide the cable eyelet off the post on the temperature door lever.
  7. Pry off the Clip of the temperature cable.

Scheme 4

Scheme 4: Installation
Scheme 4: Installation

Scheme 5

Scheme 5
Scheme 5
  1. Install the temperature control cable eyelet to the post on the temperature door lever.
  2. Install the clip of the temperature cable.
  3. Install the temperature control cable eyelet to the post on the controller.
  4. Install the clip of the temperature control cable.
  5. Install the mode control cable to the mode door.
  6. Insert the center molding into position on the instrument panel.
  7. Move the temperature control to verify the smooth operation and function of the door and the cable.
  8. Connect the negative battery cable.
  9. Operate the heating and cooling systems to verify proper function.

Scheme 6

Scheme 6: Removal
Scheme 6: Removal

Scheme 7

Scheme 7
Scheme 7
  1. Disconnect the negative battery cable.
  2. Remove the center molding. Refer to «CENTER MOLDING REMOVAL AND INSTALLATION»(ref-257070-S11505794982007062900000) .
  3. Disconnect the mode control cable from the mode door.
  4. Disconnect the electrical connectors.
  5. Disconnect the temperature control cable by gently prying the cable eyelet from the post on the controller. Unsnap the cable housing from the mechanical slide. Note the location of the cable and the housing for ease of installation.
  6. Pull out the center molding.
  7. Remove the 4 controller retaining screws.
  8. Remove the control assembly from the center molding.
