ONE WINDOW MOTOR DOES NOT OPERATE
Turn ignition on. Access malfunctioning window motor. Disconnect window motor harness connector. Connect test light between window motor harness connector terminals. Press malfunctioning window switch on master power window switch to UP and DOWN positions. If test light illuminates in both positions, replace window motor. If test light does not illuminate in both positions, inspect and repair circuit as necessary. See WIRING DIAGRAMS .
MASTER POWER WINDOW SWITCH
Disconnect suspect power window switch connector. Using an ohmmeter, ensure continuity exists across specified switch terminals with switch in appropriate position. See appropriate MASTER POWER WINDOW SWITCH CONTINUITY table. (Scheme 4), (Scheme 5) or (Scheme 6). If continuity does not exist, replace master power window switch.
| Appliation & Switch Position | Check Continuity Between Terminals No. | ||
|---|---|---|---|
| Left Front Window | |||
| Up | 1 & 3; 2 & 11 | ||
| Off | 1, 2 & 11 | ||
| Down | 2 & 3; 1 & 11 | ||
| Right Front Window | |||
| Unlocked | |||
| Up | 3 & 5; 6 & 11 | ||
| Off | 5, 6 & 11 | ||
| Down | 3 & 6; 5 & 11 | ||
| Locked | |||
| Up | 3 & 5 | ||
| Off | 5 & 6 | ||
| Down | 3 & 6 | ||
| Left Rear Window | |||
| Unlocked | |||
| Up | 3 & 7; 8 & 11 | ||
| Off | 7, 8 & 11 | ||
| Down | 3 & 8; 7 & 11 | ||
| Locked | |||
| Up | 3 & 7 | ||
| Off | 7 & 8 | ||
| Down | 3 & 8 | ||
| Right Rear Window | |||
| Unlocked | |||
| Up | 3 & 9; 10 & 11 | ||
| Off | 9, 10 & 11 | ||
| Down | 3 & 10; 9 & 11 | ||
| Locked | |||
| Up | 3 & 9 | ||
| Off | 9 & 10 | ||
| Down | 3 & 10 | ||
MASTER POWER WINDOW SWITCH CONTINUITY (ESTEEM)
| Application & Switch Position | Check Continuity Between Terminals | ||
|---|---|---|---|
| Left Front Window | |||
| Window Lock Off Or On | |||
| Up | A & G; C & H | ||
| Off | A & G; A & H | ||
| Down | A & H; C & G | ||
| Right Front Window | |||
| Window Lock Off | |||
| Up | A & B; C & E; A & F | ||
| Off | A & B; A & E; A & F | ||
| Down | A & E; B & C; A & F | ||
| Window Lock On | |||
| Up | C & E | ||
| Off | B & E | ||
| Down | B & C | ||
MASTER POWER WINDOW SWITCH CONTINUITY (VITARA 2-DOOR)
| Application & Switch Position | Check Continuity Between Terminals | ||
|---|---|---|---|
| Left Rear Window | |||
| Window Lock Off | |||
| Up | C & H; G & K | ||
| Off | C & G; C & H | ||
| Down | C & G; H & K | ||
| Window Lock On | |||
| Up | G & K | ||
| Off | G & H | ||
| Down | H & K | ||
| Right Rear Window | |||
| Window Lock Off | |||
| Up | I & K; C & J | ||
| Off | C & I; C & J | ||
| Down | J & K; C & I | ||
| Window Lock On | |||
| Up | I & K | ||
| Off | I & J | ||
| Down | J & K | ||
| Left Front Window | |||
| Window Lock Off Or On | |||
| Up | A & K; B & C | ||
| Off | A & C; B & C | ||
| Down | A & C; B & K | ||
| Right Front Window | |||
| Window Lock Off | |||
| Up | C & F; E & K | ||
| Off | C & E; C & F | ||
| Down | C & E; F & K | ||
| Window Lock On | |||
| Up | E & K | ||
| Off | E & F | ||
| Down | F & K | ||
MASTER POWER WINDOW SWITCH CONTINUITY (GRAND VITARA & VITARA 4-DOOR)
Scheme 4
Scheme 5
Scheme 6
INDIVIDUAL POWER WINDOW SWITCH
Disconnect individual power window switch harness connector. Using an ohmmeter, ensure continuity exists across specified switch terminals with switch in appropriate position. See appropriate INDIVIDUAL POWER WINDOW SWITCH CONTINUITY table. (Scheme 7)or (Scheme 8). If continuity does not exist, replace individual power window switch.
| Switch Position | Check Continuity Between Terminals No. |
|---|---|
| UP | 1 & 2; 3 & 5 |
| OFF | 1 & 2; 4 & 5 |
| DOWN | 1 & 3; 4 & 5 |
INDIVIDUAL POWER WINDOW SWITCH CONTINUITY (ESTEEM)
| Switch Position | Check Continuity Between Terminals |
|---|---|
| UP | A & B; C & D |
| OFF | A & B; D & E |
| DOWN | A & C; D & E |
INDIVIDUAL POWER WINDOW SWITCH CONTINUITY (GRAND VITARA & VITARA)
