Starters: Specifications Suzuki Esteem I

Starter 4 illustrations

STARTER SPECIFICATIONS

Application			Specification
Brush Length
A/T
Standard			.65" (16.5 mm)
Wear Limit			.35" (9.0 mm)
M/T
Standard			.69" (17.5 mm)
Wear Limit			.47" (12.0 mm)
Commutator Outside Diameter
Standard Diameter			1.16" (29.4 mm)
Wear Limit			1.13" (28.8 mm)
Armature Maximum Runout			.015" (.40 mm)
Insulator Depth
Standard Depth			.015-.023" (.40-.60 mm)
Wear Limit			.008" (.20 mm)
Cold Cranking Amperage & Voltage			300 Amps @ 7.7 Volts
No-Load Maximum Current Draw At 11 Volts			90 Amps

STARTER SPECIFICATIONS (ESTEEM)

Application		Specification
Brush Length
Standard		.44" (12.3 mm)
Wear Limit		.28" (7.0 mm)
Commutator Outside Diameter
Standard Diameter		1.16" (29.4 mm)
Wear Limit		1.13" (28.8 mm)
Armature Maximum Runout		.015" (.40 mm)
Insulator Depth
Standard Depth		.015-.023" (.40-.60 mm)
Wear Limit		.008" (.20 mm)
Cold Cranking Amperage & Voltage		300 Amps @ 7.5 Volts
No-Load Maximum Current Draw At 11 Volts		90 Amps

STARTER SPECIFICATIONS (GRAND VITARA & VITARA)

Application			Specification
Brush Length
A/T
Standard			.69" (17.5 mm)
Wear Limit			.47" (12.0 mm)
M/T
Standard			.67" (17.0 mm)
Wear Limit			.45" (11.5 mm)
Commutator Outside Diameter
A/T
Standard Diameter			1.16" (29.4 mm)
Wear Limit			1.13" (28.8 mm)
M/T
Standard Diameter			1.26" (32.0 mm)
Wear Limit			1.24" (31.4 mm)
Armature Maximum Runout			.015" (.40 mm)
Insulator Depth
Standard Depth			.015-.023" (.40-.60 mm)
Wear Limit			.008" (.20 mm)
Cold Cranking Amperage & Voltage
A/T			300 Amps @ 7.7 Volts
M/T			150 Amps @ 9.0 Volts
No-Load Maximum Current Draw At 11 Volts
A/T			50-75 Amps
M/T			60 Amps

STARTER SPECIFICATIONS (SWIFT)

TORQUE SPECIFICATIONS

Scheme 1: Starting System Wiring Diagram (Esteem)

Scheme 2: Starting System Wiring Diagram (Grand Vitara)

Scheme 3: Starting System Wiring Diagram (Swift)

Scheme 4: Starting System Wiring Diagram (Vitara)
