Engine Exhaust System: Other Suzuki Equator I

Checking Exhaust System

Check exhaust pipes, muffler and mounting for improper attachment, leaks, cracks, damage or deterioration.

Scheme 4

1. If anything is found, repair or replace damaged parts.

Scheme 5

Scheme 6

Scheme 7

Scheme 8

1. Release fuel pressure. Refer to [ «FUEL PRESSURE CHECK: QR25DE»(ref-375719-S33684214322010102800000) ]
2. Remove quick connector cap, and disconnect quick connector at the engine side. Refer to «AIR CLEANER AND AIR DUCT: REMOVAL AND INSTALLATION»(ref-375720-S00045471172010102800000) .
3. Remove air duct, PCV hose (between air duct and rocker cover) and electric throttle control actuator. Refer to «INTAKE MANIFOLD: REMOVAL AND INSTALLATION»(ref-375720-S41952777752010102800000) .
4. Disconnect harness connector of air fuel ratio sensor 1, and harness from bracket and middle clamp.
5. Remove air fuel ratio sensor 1 using Tool. Tool number: - (J-44626) CAUTION: Be careful not to damage air fuel ratio sensor 1. Discard any air fuel ratio sensor 1 which has been dropped from a height of more than 0.5 m (19.7 in) onto a hard surface such as a concrete floor; replace with a new one.
6. Remove exhaust front tube. Refer to [ «EXHAUST SYSTEM: EXPLODED VIEW»(ref-375741-S34517681292010102800000) ].
7. Remove exhaust manifold cover.
8. Remove bracket between exhaust manifold-three way catalyst assembly and transmission assembly.
9. Loosen nuts in reverse order as shown to remove exhaust manifold and three way catalyst assembly.
10. Remove gasket. CAUTION: Cover engine openings to avoid entry of foreign materials.

Scheme 9

1. Check the surface distortion of exhaust manifold and three way catalyst assembly mating surface with straightedge and feeler gauge. Limit: 0.3 mm (0.012 in)
2. If it exceeds the limit, replace exhaust manifold and three way catalyst assembly.

Air Fuel Ratio Sensor 1

Tool number: - (J-43897-12)

(J-43897-18)

Exhaust Manifold Gasket

Install the exhaust manifold gasket in direction as shown.

Scheme 10

1. <==: Front
2. A: Identification hole

Scheme 11

1. * If exhaust manifold studs were removed, install them and tighten to specification.
2. Install exhaust manifold and tighten nuts in numerical order as shown. CAUTION: Use new exhaust manifold nuts for installation. NOTE: Tighten nuts No. 1 and 2 in two steps. The numerical order No. 7 and 8 show second step.

1. <==: Front

Scheme 12

1. Remove three way catalyst (RH). Refer to [ «Three Way Catalyst: Removal and Installation [VQ40DE]»(ref-375741-S24501766442010111100000) ].
2. Remove heat shield from lower dash panel.
3. Remove support bolts from A/T fluid charging pipe (A/T models). Refer to «TRANSMISSION ASSEMBLY: COMPONENT»(ref-375705-S19453451932010102800000) .
4. Loosen nuts in reverse order as shown. <==: Front NOTE: Disregard the numerical order No. 7 and 8 in removal.
5. Remove exhaust manifold (RH) and exhaust manifold cover (RH) together.
6. Remove gaskets. CAUTION: Cover engine openings to avoid entry of foreign materials.

Scheme 13

1. Check the surface distortion of the exhaust manifold mating surface with straightedge and feeler gauge. Limit: 0.3 mm (0.012 in)
2. If it exceeds the limit, replace exhaust manifold.

Install the exhaust manifold gaskets in direction as shown.

Scheme 14

1. <==: Front
2. A: Identification hole

Scheme 15

1. If exhaust manifold studs were removed, install them and tighten to specification.
2. Install exhaust manifold and tighten nuts in numerical order as shown. CAUTION: Use new exhaust manifold nuts for installation. NOTE: Tighten nuts No. 1 and 2 in two steps. The numerical order No. 7 and 8 show second step.

1. <==: Front

Scheme 16

Scheme 17

Special Service Tool

Refer to [ SPECIAL SERVICE TOOL ].

Commercial Service Tool

Refer to [ COMMERCIAL SERVICE TOOL ].
