Cellular / Entertainment / Navigation / Audio: Removal & Installation Suzuki Equator I

Entertainment Systems 27 illustrations ~1418 words

INSTALLATION

Installation is in the reverse order of removal.

REMOVAL

CAUTIONUse a suitable tool to prevent damage to the front tweeter speaker grille trim and the instrument panel.

Scheme 98

Scheme 98
Scheme 98
  1. Remove the front tweeter grille.
  2. Remove the front tweeter screws (A).
  3. Pull out the front tweeter speaker (1) and disconnect front tweeter connector, then remove the front tweeter speaker (1).

Installation is in the reverse order of removal.

Scheme 99

Scheme 99: REMOVAL
Scheme 99: REMOVAL
  1. Remove the front door finisher. Refer to [ «DOOR FINISHER: REMOVAL AND INSTALLATION»(ref-375698-S35870222642010102800000) ]
  2. Remove the front door speaker screws (A).
  3. Pull out the front door speaker (1), and disconnect the front door speaker connector and remove the front door speaker (1).

Installation is in the reverse order of removal.

Scheme 100

Scheme 100: REMOVAL
Scheme 100: REMOVAL
  1. Remove the rear door finisher. Refer to [ «DOOR FINISHER: REMOVAL AND INSTALLATION»(ref-375698-S35870222642010102800000) ]
  2. Remove the rear door speaker screws (A).
  3. Remove rear door speaker (1), disconnect rear door speaker connector (B). NOTE: King cab shown, crew cab similar.

Installation is in the reverse order of removal.

  1. Remove lower glove box. Refer to [ «INSTRUMENT PANEL ASSEMBLY: REMOVAL AND INSTALLATION»(ref-375695-S37538787532010102800000) ]
  2. Disconnect audio antenna cable from antenna feeder.
  3. Remove antenna rod.
  4. Remove rubber seal.
  5. Remove cowl top. Refer to [ «COWL TOP: REMOVAL AND INSTALLATION»(ref-375736-S19652960172010102800000) ]
  6. Remove fender protector. Refer to [ «FRONT FENDER PROTECTOR: REMOVAL AND INSTALLATION»(ref-375735-S35289178892010102800000) ]
  7. Remove antenna base bolts.
  8. Remove antenna base and cable.

Installation is in the reverse order of removal.

CAUTIONAlways properly tighten the antenna rod during installation or the antenna rod may bend or break during vehicle operation.

Installation is in the reverse order of removal.

CAUTIONUse a suitable tool to prevent damage to the front tweeter speaker grille trim and the instrument panel.

Scheme 101

Scheme 101
Scheme 101
  1. Remove the front tweeter grille.
  2. Remove the front tweeter screws (A).
  3. Pull out the front tweeter speaker (1) and disconnect front tweeter connector, then remove the front tweeter speaker (1).

Installation is in the reverse order of removal.

Scheme 102

Scheme 102: REMOVAL
Scheme 102: REMOVAL
  1. Remove the front door finisher. Refer to [ «DOOR FINISHER: REMOVAL AND INSTALLATION»(ref-375698-S35870222642010102800000) ]
  2. Remove the front door speaker screws (A).
  3. Pull out the front door speaker (1), and disconnect the front door speaker connector and remove the front door speaker (1).

Installation is in the reverse order of removal.

Scheme 103

Scheme 103: REMOVAL
Scheme 103: REMOVAL
  1. Remove the rear door finisher. Refer to [ «DOOR FINISHER: REMOVAL AND INSTALLATION»(ref-375698-S35870222642010102800000) ]
  2. Remove the rear door speaker screws (A).
  3. Remove the rear door speaker (1) and disconnect rear door speaker connector (B).

Installation is in the reverse order of removal.

Scheme 104

Scheme 104: Steering Switch: Removal and Installation
Scheme 104: Steering Switch: Removal and Installation
  1. Remove the driver air bag module. Refer to [ «DRIVER AIR BAG MODULE: REMOVAL AND INSTALLATION»(ref-375693-S22960868372010102800000) ]
  2. Remove the steering wheel. Refer to [ «STEERING WHEEL: ON-VEHICLE INSPECTION AND SERVICE»(ref-375696-S09204462132010102800000) ]
  3. Remove the steering wheel rear cover.
  4. Remove the steering wheel audio control switch assembly screws.
  5. Disconnect the steering wheel audio control switches connector and remove the steering wheel audio control switches.

Installation is in the reverse order of removal.

Scheme 105

Scheme 105: Tel Antenna: Removal and Installation
Scheme 105: Tel Antenna: Removal and Installation
  1. Remove the RH front seat. Refer to [ «FRONT SEAT: REMOVAL AND INSTALLATION»(ref-375694-S39892786552010102800000) ]
  2. Disconnect the Bluetooth antenna harness connector.
  3. Remove the Bluetooth antenna screws, then remove the Bluetooth antenna.

Installation is in the reverse order of removal.

Scheme 106

Scheme 106: Bluetooth Control Unit: Removal and Installation
Scheme 106: Bluetooth Control Unit: Removal and Installation

Scheme 107

Scheme 107: REMOVAL
Scheme 107: REMOVAL
  1. Remove the RH front seat. Refer to [ «FRONT SEAT: REMOVAL AND INSTALLATION»(ref-375694-S39892786552010102800000) ]
  2. Disconnect the Bluetooth control unit harness connector (B).
  3. Remove the Bluetooth control unit screws (A), then remove the Bluetooth control unit assembly.
  4. Remove the Bluetooth control unit bracket screws and remove the Bluetooth control unit (1) front and rear brackets.

Installation is in the reverse order of removal.

Scheme 108

Scheme 108: REMOVAL
Scheme 108: REMOVAL
  1. Remove the front roof console finisher. Refer to [ «HEADLINING: REMOVAL AND INSTALLATION»(ref-375698-S17522321752010102800000) ]
  2. Detach the Bluetooth microphone (1) from the front console finisher tabs (A).
  3. Detach the Bluetooth microphone connector (B) and remove the Bluetooth microphone (1).

Installation is in the reverse order of removal.

Scheme 109

Scheme 109: REMOVAL
Scheme 109: REMOVAL
  1. Remove lower glove box. Refer to [ «INSTRUMENT PANEL ASSEMBLY: REMOVAL AND INSTALLATION»(ref-375695-S37538787532010102800000) ]
  2. Disconnect audio antenna cable from antenna feeder.
  3. Remove antenna rod.
  4. Remove rubber seal.
  5. Remove cowl top. Refer to [ «COWL TOP: REMOVAL AND INSTALLATION»(ref-375736-S19652960172010102800000) ]
  6. Remove fender protector. Refer to [ «FRONT FENDER PROTECTOR: REMOVAL AND INSTALLATION»(ref-375735-S35289178892010102800000) ]
  7. Remove antenna base bolts.
  8. Remove antenna base and cable.

Installation is in the reverse order of removal.

CAUTIONAlways properly tighten the antenna rod during installation or the antenna rod may bend or break during vehicle operation.

Scheme 110

Scheme 110: REMOVAL
Scheme 110: REMOVAL
  1. Remove the roof console. Refer to [ «HEADLINING: REMOVAL AND INSTALLATION»(ref-375698-S17522321752010102800000) ]
  2. Disconnect the satellite radio antenna connector.
  3. Remove the satellite radio antenna nut.
  4. Remove the satellite radio antenna.

Installation is in the reverse order of removal.

Scheme 111

Scheme 111: REMOVAL
Scheme 111: REMOVAL
  1. Disconnect the battery negative terminal.
  2. Remove the lower instrument panel. Refer to [ «INSTRUMENT PANEL ASSEMBLY: REMOVAL AND INSTALLATION»(ref-375695-S37538787532010102800000) ]
  3. Disconnect the satellite radio tuner connectors.
  4. Remove satellite radio tuner screws (A), and remove satellite radio tuner.

Installation is in the reverse order of removal.

Audio Unit: Removal and Installation

Refer to AUDIO UNIT: REMOVAL AND INSTALLATION .

Scheme 112

Scheme 112: REMOVAL
Scheme 112: REMOVAL
  1. Remove the RH front seat. Refer to [ «FRONT SEAT: REMOVAL AND INSTALLATION»(ref-375694-S39892786552010102800000) ]
  2. Remove the audio amp and kick shield screws.
  3. Disconnect the audio amp connectors (1) and remove the audio amp. <==: Vehicle front

Installation is in the reverse order of removal.

CAUTIONUse a suitable tool to prevent damage to the front tweeter speaker grille trim and the instrument panel.

Scheme 113

Scheme 113
Scheme 113
  1. Remove the front tweeter grille.
  2. Remove the front tweeter screws (A).
  1. Pull out the front tweeter speaker (1) and disconnect front tweeter connector, then remove the front tweeter speaker (1).

Installation is in the reverse order of removal.

Scheme 114

Scheme 114: REMOVAL
Scheme 114: REMOVAL
  1. Remove the front door finisher. Refer to [ «DOOR FINISHER: REMOVAL AND INSTALLATION»(ref-375698-S35870222642010102800000) ]
  2. Remove the front door speaker screws (A).
  3. Pull out the front door speaker (1), and disconnect the front door speaker connector and remove the front door speaker (1).

Installation is in the reverse order of removal.

Scheme 115

Scheme 115: REMOVAL
Scheme 115: REMOVAL
  1. Remove the rear door finisher. Refer to [ «DOOR FINISHER: REMOVAL AND INSTALLATION»(ref-375698-S35870222642010102800000) ]
  2. Remove the rear door speaker screws (A).
  3. Disconnect the rear door speaker connector (B) and remove rear door speaker (1).

Installation is in the reverse order of removal.

  1. Remove the rear door finisher. Refer to [ «DOOR FINISHER: REMOVAL AND INSTALLATION»(ref-375698-S35870222642010102800000) ]
  2. Remove the rear door tweeter screws (A) and remove the rear door tweeter (1).

Installation is in the reverse order of removal.

Scheme 116

Scheme 116: Steering Switch: Removal and Installation
Scheme 116: Steering Switch: Removal and Installation
  1. Remove the driver air bag module. Refer to [ «DRIVER AIR BAG MODULE: REMOVAL AND INSTALLATION»(ref-375693-S22960868372010102800000) ]
  2. Remove the steering wheel. Refer to [ «STEERING WHEEL: ON-VEHICLE INSPECTION AND SERVICE»(ref-375696-S09204462132010102800000) ]
  3. Remove the steering wheel rear cover.
  4. Remove the steering wheel audio control switch assembly screws.
  5. Disconnect the steering wheel audio control switches connector and remove the steering wheel audio control switches.

Installation is in the reverse order of removal.

Scheme 117

Scheme 117: Subwoofer: Removal and Installation
Scheme 117: Subwoofer: Removal and Installation
  1. Position the LH rear seat cushion in the folded up position.
  2. Remove storage box RH (crew cab). Refer to [ «FLOOR TRIM: REMOVAL AND INSTALLATION»(ref-375698-S33580022382010102800000) ]
  3. Remove the subwoofer screws.
  4. Disconnect the connector and remove the subwoofer.

Installation is in the reverse order of removal.

Scheme 118

Scheme 118: Tel Antenna: Removal and Installation
Scheme 118: Tel Antenna: Removal and Installation
  1. Remove the RH front seat. Refer to [ «FRONT SEAT: REMOVAL AND INSTALLATION»(ref-375694-S39892786552010102800000) ]
  2. Disconnect the Bluetooth antenna harness connector.
  3. Remove the Bluetooth antenna screws, then remove the Bluetooth antenna.

Installation is in the reverse order of removal.

Scheme 119

Scheme 119: Bluetooth Control Unit: Removal and Installation
Scheme 119: Bluetooth Control Unit: Removal and Installation

Scheme 120

Scheme 120: REMOVAL
Scheme 120: REMOVAL
  1. Remove the RH front seat. Refer to [ «FRONT SEAT: REMOVAL AND INSTALLATION»(ref-375694-S39892786552010102800000) ]
  2. Disconnect the Bluetooth control unit harness connector (B).
  1. Remove the Bluetooth control unit screws (A), then remove the Bluetooth control unit assembly.
  2. Remove the Bluetooth control unit bracket screws and remove the Bluetooth control unit (1) front and rear brackets.

Installation is in the reverse order of removal.

Scheme 121

Scheme 121: REMOVAL
Scheme 121: REMOVAL
  1. Remove the front roof console finisher. Refer to [ «HEADLINING: REMOVAL AND INSTALLATION»(ref-375698-S17522321752010102800000) ]
  2. Detach the Bluetooth microphone (1) from the front console finisher tabs (A).
  3. Detach the Bluetooth microphone connector (B) and remove the Bluetooth microphone (1).

Installation is in the reverse order of removal.

Scheme 122

Scheme 122: REMOVAL
Scheme 122: REMOVAL
  1. Remove lower glove box. Refer to [ «INSTRUMENT PANEL ASSEMBLY: REMOVAL AND INSTALLATION»(ref-375695-S37538787532010102800000) ]
  2. Disconnect audio antenna cable from antenna feeder.
  3. Remove antenna rod.
  4. Remove rubber seal.
  5. Remove cowl top. Refer to [ «COWL TOP: REMOVAL AND INSTALLATION»(ref-375736-S19652960172010102800000) ]
  6. Remove fender protector. Refer to [ «FRONT FENDER PROTECTOR: REMOVAL AND INSTALLATION»(ref-375735-S35289178892010102800000) ]
  7. Remove antenna base bolts.
  8. Remove antenna base and cable.

Installation is in the reverse order of removal.

CAUTIONAlways properly tighten the antenna rod during installation or the antenna rod may bend or break during vehicle operation.

Scheme 123

Scheme 123: REMOVAL
Scheme 123: REMOVAL
  1. Remove the roof console. Refer to [ «HEADLINING: REMOVAL AND INSTALLATION»(ref-375698-S17522321752010102800000) ]
  2. Disconnect the satellite radio antenna connector.
  3. Remove the satellite radio antenna nut.
  4. Remove the satellite radio antenna.

Installation is in the reverse order of removal.

Scheme 124

Scheme 124: REMOVAL
Scheme 124: REMOVAL
  1. Disconnect the battery negative terminal.
  2. Remove the lower instrument panel. Refer to [ «INSTRUMENT PANEL ASSEMBLY: REMOVAL AND INSTALLATION»(ref-375695-S37538787532010102800000) ]
  3. Disconnect the satellite radio tuner connectors.
  4. Remove satellite radio tuner screws (A), and remove satellite radio tuner.

Installation is in the reverse order of removal.
