Audio System: Component Description
| Part name | Description |
|---|---|
| Audio unit | Controls audio system functions |
| Front door speakers | Outputs audio signal from audio unit Outputs high, mid and low range sounds |
| Front tweeters | Outputs audio signal from audio unit Outputs high range sounds |
| Rear door speakers | Outputs audio signal from audio unit Outputs high, mid and low range sounds |
PARTS DESCRIPTION
Scheme 1
Scheme 2
Scheme 3
Scheme 4
Description
The audio unit sends audio signals to the front door speakers using the front door speaker circuits.
The audio unit sends audio signals to the front tweeters using the front tweeter circuits.
The audio unit sends audio signals to the rear door speakers using the rear door speaker circuits.
| Part name | Description |
|---|---|
| Audio unit | Controls audio system and satellite radio system functions |
| Audio amp. | Receives power (amp ON) and audio signals from Audio unit and outputs audio signals to each speaker. |
| Steering wheel audio control switches | Start a voice recognition session Answer and end telephone calls Adjust the volume level |
| Front door speakers | Outputs audio signal from audio amp. Outputs high, mid and low range sounds |
| Front tweeters | Outputs audio signal from audio amp. Outputs high range sounds |
| Rear door speakers | Outputs audio signal from audio amp. Outputs high, mid and low range sounds |
| Satellite radio tuner | Receives radio signals from satellite antenna Sends audio signals to Audio unit |
| Satellite antenna | Audio signal (satellite radio) is received and output to Audio unit. |
PARTS DESCRIPTION
Hands-Free Phone System: System Description
Refer to the Owner's Manual for Bluetooth telephone system operating instructions.
Note. Cellular telephones must have their wireless connection set up (paired) before using the Bluetooth telephone system.
Bluetooth telephone system allows users who have a Bluetooth equipped cellular telephone to make a wireless connection between their cellular telephone and the Bluetooth control unit. Hands-free cellular telephone calls can be sent and received. Some Bluetooth cellular telephones may not be recognized by the Bluetooth control unit. When a cellular telephone or the Bluetooth control unit is replaced, the telephone must be paired with the Bluetooth control unit. Different cellular telephones may have different pairing procedures. Refer to the cellular telephone operating manual.
Diagnosis Description
The Bluetooth control unit has two diagnostic checks. The first diagnostic check is performed automatically every ignition cycle during control unit initialization. The second diagnostic check is performed by the technician using the steering wheel audio control switches prior to trouble diagnosis.
The audio unit sends audio signals to the front door speakers using the audio signal circuits.
The audio unit sends audio signals to the tweeters using the audio signal circuits.
The audio unit sends audio signals to the rear door speakers using the audio signal circuits.
When one of the steering wheel audio control switches is pushed, the resistance in the steering wheel audio control switch circuit changes depending on which button is pushed.
Communication signals are exchanged between the audio unit and satellite radio tuner using the communication circuits.
Left and right channel audio signals are supplied from the satellite radio tuner to the audio unit through the sound signal circuits.
Voice signals are transmitted from the microphone to the Bluetooth control unit using the microphone signal circuits.
| Part name | Description |
|---|---|
| Audio unit | Controls audio system and satellite radio system functions |
| Audio amp. | Receives power (amp ON) and audio signals from Audio unit and outputs audio signals to each speaker. |
| Steering wheel audio control switches | Start a voice recognition session Answer and end telephone calls Adjust the volume level |
| Front door speakers | Outputs audio signal from audio amp. Outputs high, mid and low range sounds |
| Front tweeters | Outputs audio signal from audio amp. Outputs high range sounds |
| Rear door speakers | Outputs audio signal from audio amp. Outputs high, mid and low range sounds |
| Rear door tweeters | Outputs audio signal from audio amp. Outputs high range sounds |
| Subwoofer | Outputs audio signal from audio amp. Outputs low range sounds |
| Satellite radio tuner | Receives radio signals from satellite antenna Sends audio signals to Audio unit |
| Satellite antenna | Audio signal (satellite radio) is received and output to Audio unit. |
PARTS DESCRIPTION
Refer to the Owner's Manual for Bluetooth telephone system operating instructions.
Note. Cellular telephones must have their wireless connection set up (paired) before using the Bluetooth telephone system.
Bluetooth telephone system allows users who have a Bluetooth equipped cellular telephone to make a wireless connection between their cellular telephone and the Bluetooth control unit. Hands-free cellular telephone calls can be sent and received. Some Bluetooth cellular telephones may not be recognized by the Bluetooth control unit. When a cellular telephone or the Bluetooth control unit is replaced, the telephone must be paired with the Bluetooth control unit. Different cellular telephones may have different pairing procedures. Refer to the cellular telephone operating manual.
The Bluetooth control unit has two diagnostic checks. The first diagnostic check is performed automatically every ignition cycle during control unit initialization. The second diagnostic check is performed by the technician using the steering wheel audio control switches prior to trouble diagnosis.
The audio unit sends audio signals to the audio amp. The audio amp. amplifies the audio signals before sending them to the front door speakers using the audio signal circuits.
The audio unit sends audio signals to the audio amp. The audio amp. amplifies the audio signals before sending them to the tweeters using the audio signal circuits.
The audio unit sends audio signals to the audio amp. The audio amp. amplifies the audio signals before sending them to the rear door speakers using the audio signal circuits.
The audio unit sends audio signals to the audio amp. The audio amp. amplifies the audio signals before sending them to the rear door tweeters using the audio signal circuits.
The audio unit sends audio signals to the audio amp. The audio amp. amplifies the audio signals before sending them to the subwoofer using the audio signal circuits.
When the audio system is turned on, a voltage signal is supplied from the audio unit to the audio amp. When this signal is received, the audio amp. will turn on.
Refer to " DESCRIPTION " in [Steering Switch Circuit Check].
Refer to " DESCRIPTION " in [Communication Signal Circuit Check [Satellite Radio Tuner]].
Refer to " DESCRIPTION " in [Sound Signal Circuit Check [Satellite Radio Tuner]].
Refer to " DESCRIPTION " in [Microphone Signal Circuit Check].
