CHECK OF CAN SYSTEM TYPE (HOW TO USE CAN SYSTEM TYPE SPECIFICATION CHART)
Determine CAN system type based on vehicle equipment. Then choose the correct diagnosis sheet.
Note. There are two styles for CAN system type specification charts. Depending on the number of available system types, either style A or style B may be used.
CAN System Type Specification Chart (Style A)
Note. CAN system type is easily checked with the vehicle equipment identification information shown in the chart.
Scheme 1
CAN System Type Specification Chart (Style B)
Note. CAN system type is easily checked with the vehicle equipment identification information shown in the chart.
Scheme 2
CAN System Specification Chart
Determine CAN system type from the following specification chart. Then choose the correct diagnosis sheet.
Note. Refer to [ LAN SYSTEM: BASIC INSPECTION ] for how to use CAN system specification chart.
| Body type | Truck | ||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Axle | 2WD | 4WD | |||||||||||||
| Engine | QR25DE | VQ40DE | |||||||||||||
| Transmission | M/T | A/T | M/T | A/T | M/T | A/T | |||||||||
| Brake control | ABS | ABLS | ABS | ABLS | ABS | ABLS | ABS | ABLS | VDC | ||||||
| Electronic locking rear differential | X | X | X | X | |||||||||||
| CAN system type | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 | 11 | 12 | 13 | 14 | 15 |
| Diagnosis sheet | LAN System: Diagnosis Sheet (CAN Type 1) | LAN System: Diagnosis Sheet (CAN Type 2) | LAN System: Diagnosis Sheet (CAN Type 3) | LAN System: Diagnosis Sheet (CAN Type 4) | LAN System: Diagnosis Sheet (CAN Type 5) | LAN System: Diagnosis Sheet (CAN Type 6) | LAN System: Diagnosis Sheet (CAN Type 7) | LAN System: Diagnosis Sheet (CAN Type 8) | LAN System: Diagnosis Sheet (CAN Type 9) | LAN System: Diagnosis Sheet (CAN Type 10) | LAN System: Diagnosis Sheet (CAN Type 11) | LAN System: Diagnosis Sheet (CAN Type 12) | LAN System: Diagnosis Sheet (CAN Type 13) | LAN System: Diagnosis Sheet (CAN Type 14) | LAN System: Diagnosis Sheet (CAN Type 15) |
| X: Applicable | |||||||||||||||
CAN SYSTEM SPECIFICATION CHART
