Body Electric Control System: Removal & Installation Suzuki Equator I

Communication Devices 1 illustration ~219 words

REMOVAL

Note. If possible, before removing BCM, retrieve current BCM configuration to use for reference when configuring brand-new BCM after installation. Refer to [ ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT ].

Scheme 78

Scheme 78: REMOVAL
  1. Disconnect the battery negative terminal.
  2. Remove the lower instrument panel LH. Refer to [ «INSTRUMENT PANEL ASSEMBLY: EXPLODED VIEW»(ref-375695-S16229198292010102800000) ]
  3. Remove the knee protector. Refer to [ «INSTRUMENT PANEL ASSEMBLY: EXPLODED VIEW»(ref-375695-S16229198292010102800000) ]
  4. Remove the BCM screws and release the BCM.
  5. Disconnect the BCM connectors and then remove the BCM.

INSTALLATION

Installation is in the reverse order of removal.

Note. When replacing the BCM, it must be configured. Refer to [ BODY CONTROL SYSTEM: CONFIGURATION ]. When replacing the BCM, perform initialization of immobilizer system and registration of all immobilizer system ignition key IDs. Refer to [ BODY CONTROL SYSTEM: CONFIGURATION ]. When replacing the BCM, perform ID registration procedure of low tire pressure warning system. Refer to [ ID REGISTRATION PROCEDURE ]. When replacing the BCM, if equipped with remote keyless entry, register the remote keyless entry system keyfob ID codes. Refer to [ ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT ]. When replacing the BCM, if equipped with VOC, perform adjustment procedure for the steering angle sensor. Refer to [ ADJUSTMENT OF STEERING ANGLE SENSOR NEUTRAL POSITION ].
