Parts Requiring Angle Tightening
- For the final tightening of the following engine parts use Tool: Tool number: KV10112100 (BT-8653-A) Cylinder head bolts Lower cylinder block bolts Connecting rod cap bolts Crankshaft pulley bolt (No angle wrench is required as bolt flange is provided with notches for angle tightening)
- Do not use a torque value for final tightening.
- The torque value for these parts are for a preliminary step.
- Ensure thread and seat surfaces are clean and coated with engine oil.
Scheme 204
- After removing nuts and bolts, separate the mating surface and remove old liquid gasket sealing using Tool. Tool number: KV10111100 (J-37228) CAUTION: Be careful not to damage the mating surfaces.
- Tap seal cutter to insert it (1), and then slide it by tapping on the side (2) as shown.
- In areas where Tool is difficult to use, use plastic hammer to lightly tap the parts, to remove it. CAUTION: If for some unavoidable reason tool such as screwdriver is used, be careful not to damage the mating surfaces.
Scheme 205
Scheme 206
Scheme 207
- Remove the old liquid gasket adhering to the gasket application surface and the mating surface using suitable tool. Remove liquid gasket completely from the groove of the gasket application surface, bolts, and bolt holes.
- Thoroughly clean the mating surfaces and remove adhering moisture, grease and foreign materials.
- Attach liquid gasket tube to the Tool. Tool number: WS39930000 (-) Use Genuine RTV Silicone Sealant or equivalent. Refer to [ «RECOMMENDED CHEMICAL PRODUCTS AND SEALANTS»(ref-375700-S13998640382010102800000) ].
- Apply the liquid gasket without breaks to the specified location with the specified dimensions. If there is a groove for the liquid gasket application, apply the liquid gasket to the groove. As for bolt holes, normally apply the liquid gasket inside the holes. Occasionally, it should be applied outside the holes. Make sure to read the text of this manual. Within five minutes of liquid gasket application, install the mating component. If the liquid gasket protrudes, wipe it off immediately. Do not retighten nuts or bolts after the installation. Wait 30 minutes or more after installation, before refilling the engine with engine oil and engine coolant. CAUTION: If there are specific instructions in this manual, observe them.
Scheme 208
GENERAL SPECIFICATIONS
GENERAL SPECIFICATIONS Cylinder arrangement V-6 Displacement cm 3 (cu in) 3,954 (241.30) Bore and stroke mm (in) 95.5 x 92.0 (3.76 x 3.622) Valve arrangement DOHC Firing order 1-2-3-4-5-6 Number of piston rings Compression 2 Oil 1 Number of main bearings 4 Compression ratio 9.7 Compression pressure kPa (kg/cm 2 , psi)/300 RPM Standard 1,275 (13.0, 185) Minimum 981 (10.0, 142) Differential limit between cylinders 98 (1.0, 14) Cylinder number Valve timing (Intake valve timing control - "OFF")
Scheme 209
Scheme 210
| Unit: degree | |||||
|---|---|---|---|---|---|
| A | B | C | D | E | F |
| 244 | 240 | 4 | 64 | 6 | 58 |
UNIT DEGREE REFERENCE
