Motor Operation in Low Speed

  1. Connect battery positive (+) terminal to terminal "L" and its negative (-) terminal to terminal "E".
  2. Check if motor revolution speed is as specification. If check result is not as specified, replace motor. Specification 44 - 52 r/min (RPM)

Motor Operation in High Speed

  1. Connect battery positive (+) terminal to "H" and its negative (-) terminal to terminal "E".
  2. Check if motor revolution speed is as specification. If check result is not as specified, replace motor. Specification 64 - 78 r/min (RPM)

Scheme 1

Scheme 1: Automatic Stop Operation
  1. Connect battery positive (+) terminal to terminal "L" and its negative (-) terminal to terminal "E" and let the motor turn.
  2. Disconnect terminal "L" from battery positive (+) terminal, and let the motor stop.
  3. Connect terminals "L" and "S" with a jumper wire, and connect terminal "B" to battery positive (+) terminal. Observe the motor turns once again then stops at a specified position.
  4. Repeat Step 1 ) to 3 ) several times and check that the motor stops at the specified position every time. If check result is not satisfied, replace motor.

Motor Operation

  1. Connect battery positive terminal to terminal "L" and its negative terminal to terminal "E".
  2. Check motor revolution speed as specification. If check result is not as specified, replace motor. Specification 35 - 45 r/min (RPM)

Scheme 2

Scheme 2: Automatic Stop Operation
  1. Connect battery positive (+) terminal to terminal "L" and its negative (-) terminal to terminal "E" and let the motor turn.
  2. Disconnect terminal "L" from battery positive (+) terminal and let the motor stop.
  3. Connect terminal "B" to battery positive (+) terminal. Observe the motor turns once again then stops at a specified position.
  4. Repeat Step 1 ) to 3 ) several times and check that the motor stops at the specified position every time. If check result is not satisfied, replace motor.

Scheme 3

Scheme 3: Removal

Scheme 4

Scheme 4
  1. Disconnect negative (-) cable at battery.
  2. Remove steering column hole cover (1).
  3. Remove steering column covers (2). Turn steering wheel to access steering column cover rear end screws.
  4. Remove windshield wiper and washer switch (1) from combination switch assembly (2) and disconnect its coupler (3).
