Transfer: Other Suzuki Aerio I

Remounting

Remount transfer assembly by reversing dismounting procedure noting the following points.

Scheme 78

Scheme 79

1. Tighten bolts and nuts to specified torque as follows. Tightening torque Engine rear mounting bracket nut a: 20 N.m (2.0 kg-m, 14.5 lb-ft) Transfer mounting bolt b: 50 N.m (5.0 kg-m, 36.5 lb-ft) Transfer to engine stiffener bolt c: 50 N.m (5.0 kg-m, 36.5 lb-ft) Transfer to transaxle stiffener bolt d: 50 N.m (5.0 kg-m, 36.5 lb-ft) Propeller shaft No.1 bolt e: 23 N.m (2.3 kg-m, 17.0 lb-ft) Exhaust No.2 pipe to muffler bolt f: 43 N.m (4.3 kg-m, 31.5 lb-ft) Suspension frame bolt g: 90 N.m (9.0 kg-m, 65.0 lb-ft) Engine rear mounting nut h: 55 N.m (5.5 kg-m, 40.2 lb-ft) Ball stud lock nut i: 60 N.m (6.0 kg-m, 43.5 lb-ft) Exhaust No.2 pipe to No.1 pipe bolt j: 43 N.m (4.3 kg-m, 31.5 lb-ft) Exhaust No.1 pipe stay bolt k: 50 N.m (5.0 kg-m, 36.5 lb-ft) Engine front mounting nut l: 45 N.m (4.5 kg-m, 32.5 lb-ft) Mounting member to body bolt m: 55 N.m (5.5 kg-m, 39.5 lb-ft) Wheel nut: 85 N.m (8.5 kg-m, 61.5 lb-ft)
2. Pour transfer oil to transfer referring to «TRANSFER OIL CHANGE»(ref-251077-S24406507472007032000000) .
3. Pour automatic transaxle fluid to automatic transaxle referring to «A/T FLUID CHANGE»(ref-251085-S41100126212007032000000) .
4. Check oil level and leakage.

Scheme 80

Reference: TRANSFER DISMOUNTING AND REMOUNTING

Reference: TRANSFER ASSEMBLY COMPONENTS

Recommended Service Material

SERVICE MATERIAL SPECIFICATION
