Coolant Level Check

To check level, lift hood and look at "see-through" coolant reservoir.

It is not necessary to remove radiator cap to check coolant level.

When engine is cool, check coolant level in reservoir (1).

A normal coolant level should be between FULL mark (2) and LOW mark (3) on reservoir (1).

If coolant level is below LOW mark (3), remove reservoir cap (4) and add proper coolant to reservoir to bring coolant level up to FULL mark (2). Then, reinstall cap (4) and align match marks (5) on reservoir and cap.

Note. If proper quality antifreeze is used, there is no need to add extra inhibitors or additives that claim to improve system. They may be harmful to proper operation of system, and are unnecessary expense. When installing reservoir cap, align arrow marks on reservoir and cap.

Scheme 21

1. Check cooling system for leakage or damage.
2. Wash radiator cap and filler neck with clean water by removing radiator cap when engine is cold.
3. Check coolant for proper level and freeze protection.
4. Using a pressure tester (1), check system and radiator cap (2) for proper pressure holding capacity. If replacement of cap is required, use a proper cap for this vehicle. Cooling system and radiator cap holding pressure (for inspection) 110 kPa (1.1 kg/cm 2 , 15.6 psi) NOTE: After installing radiator cap to radiator, make sure that the ear of cap lines is parallel to radiator.
5. Inspect all hoses. Replace hoses whenever cracked, swollen or deteriorated.
6. Clean frontal area of radiator core.

Scheme 22

Scheme 23

1. Remove radiator cap when engine is cool. Turn cap counterclockwise slowly until it reaches a "stop". (Do not press down while turning it). Wait until pressure is relieved (indicated by a hissing sound) then press down on cap and continue to turn it counterclockwise. WARNING: To help avoid danger of being burned, do not remove radiator cap while engine and radiator are still hot. Scalding fluid and steam can be blown out under pressure if cap is taken off too soon.
2. With radiator cap removed, run engine until upper radiator hose is hot (this shows that thermostat is open and coolant is flowing through system).
3. Stop engine and drain coolant.
4. Close drain plug. Add water until system is filled and run engine until upper radiator hose is hot again.
5. Repeat Steps 3 ) and 4 ) several times until drained liquid is nearly colorless.
6. Drain system and then close radiator drain plug (1) tightly.
7. Remove reservoir (1) and remove cap (2) from reservoir and pour out any fluid, scrub and clean inside of reservoir with soap and water. Flush it well with clean water and drain. Reinstall reservoir.
8. Add coolant that is a mixture of good quality ethylene glycol antifreeze and water to radiator and reservoir. For coolant specification, refer to «COOLANT DESCRIPTION»(ref-251063-S03325278782007032000000) . Fill radiator to the bottom of filler neck and reservoir to FULL level mark (3).
9. Reinstall reservoir cap and align match marks (4) on reservoir and cap.
10. Run engine with radiator cap removed, until radiator inlet hose is hot.
11. With engine idling, add coolant to radiator until level reaches the bottom of filler neck. Install radiator cap, making sure that the ear of cap lines is parallel to radiator.

Cleaning

Clean frontal area of radiator cores.

Scheme 24
