OUTLINE OF DIAGNOSIS
Detect the AVCS system malfunction.
Judge NG when the amount of AVCS actual timing advance does not approach to the amount of AVCS target timing advance.
DIAGNOSTIC METHOD
When the differences of target timing advance amount and actual timing advance amount is calculated during AVCS control, and the difference per predetermined time is the specified value or larger.
- Abnormality Judgment
Judge as NG when the following conditions are established within the predetermined time.
| Malfunction Criteria | Threshold Value |
|---|---|
| Sum(Target position - Actual position) | > 4000 °CA (Bank 1) |
| > 4000 °CA (Bank 2) | |
| Or | |
| Sum(Target position - Actual position) | < -4000 °CA (Bank 1) |
| < -4000 °CA (Bank 2) |
JUDGMENT VALUE (EXCEPT FOR U5 MODEL)
| Malfunction Criteria | Threshold Value |
|---|---|
| Sum(Target position - Actual position) | > 2000 °CA (Bank 1) |
| > 2000 °CA (Bank 2) | |
| Or | |
| Sum(Target position - Actual position) | < -2000 °CA (Bank 1) |
| < -2000 °CA (Bank 2) |
JUDGMENT VALUE (U5 MODEL)
Time Needed for Diagnosis: 25000 ms
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judge as OK and clear the NG if the following conditions are established within the predetermined time.
| Malfunction Criteria | Threshold Value |
|---|---|
| Sum(Target position - Actual position) | > or = 4000 °CA (Bank 1) < or = 4000 °CA (Bank 2) and > or = -4000 °CA (Bank 1) > or = -4000 °CA (Bank 2) |
JUDGMENT VALUE (EXCEPT FOR U5 MODEL)
| Malfunction Criteria | Threshold Value |
|---|---|
| Sum(Target position - Actual position) | > or = 2000 °CA (Bank 1) < or = 2000 °CA (Bank 2) and > or = -2000 °CA (Bank 1) > or = -2000 °CA (Bank 2) |
JUDGMENT VALUE (U5 MODEL)
Time Needed for Diagnosis: 25000 ms
Detect the exhaust AVCS system malfunction.
Judge NG when the amount of exhaust AVCS actual timing advance does not approach the amount of exhaust AVCS target timing advance.
When the differences of target timing advance amount and actual timing advance amount is calculated during exhaust AVCS control, and the difference per predetermined time is the specified value or larger.
- Abnormality Judgment
Judge as NG when the following conditions are established within the predetermined time.
| Malfunction Criteria | Threshold Value |
|---|---|
| Sum(Target position - Actual position) | > 4000 °CA (Bank 1) |
| > 4000 °CA (Bank 2) | |
| Or | |
| Sum(Target position - Actual position) | < -4000 °CA (Bank 1) |
| < -4000 °CA (Bank 2) |
JUDGMENT VALUE (EXCEPT FOR U5 MODEL)
| Malfunction Criteria | Threshold Value |
|---|---|
| Sum(Target position - Actual position) | > 2000 °CA (Bank 1) |
| > 2000 °CA (Bank 2) | |
| Or | |
| Sum(Target position - Actual position) | < -2000 °CA (Bank 1) |
| < -2000 °CA (Bank 2) |
JUDGMENT VALUE (U5 MODEL)
Time Needed for Diagnosis: 25000 ms
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judge as OK and clear the NG if the following conditions are established within the predetermined time.
| Malfunction Criteria | Threshold Value |
|---|---|
| Sum(Target position - Actual position) | > or = 4000 °CA (Bank 1) < or = 4000 °CA (Bank 2) and > or = -4000 °CA (Bank 1) > or = -4000 °CA (Bank 2) |
JUDGMENT VALUE (EXCEPT FOR U5 MODEL)
| Malfunction Criteria | Threshold Value |
|---|---|
| Sum(Target position - Actual position) | > or = 2000 °CA (Bank 1) < or = 2000 °CA (Bank 2) and > or = -2000 °CA (Bank 1) > or = -2000 °CA (Bank 2) |
JUDGMENT VALUE (U5 MODEL)
Time Needed for Diagnosis: 25000 ms
Note. For the detection standard, refer to P000A. < Refer to DTC P000A A CAMSHAFT POSITION SLOW RESPONSE (BANK 1) , Diagnostic Trouble Code (DTC) Detecting Criteria. >
Note. For the detection standard, refer to P000B. < Refer to DTC P000B B CAMSHAFT POSITION SLOW RESPONSE (BANK 1) , Diagnostic Trouble Code (DTC) Detecting Criteria. >
Detect the AVCS system malfunction.
Judge as NG when the conditions during which the differences of AVCS target timing advance amount and AVCS actual timing advance amount is large continues.
When the conditions during which the differences of AVCS target timing advance amount and AVCS actual timing advance amount is large continues for certain amount of time.
- Abnormality Judgment
Judge as NG when the following conditions are established within the predetermined time.
| Malfunction Criteria | Threshold Value |
|---|---|
| Normal | > 15 °CA |
| (Target position - Actual position) | Or |
| < -15 °CA | |
| Intermediate lock | > 15 °CA |
| (Target position - Actual position) | Or |
| < -15 °CA |
JUDGMENT VALUE
Time Needed for Diagnosis
- Normal: 5000 ms
- Intermediate lock: 1000 ms
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judge as OK and clear the NG if the following conditions are established within the predetermined time.
| Malfunction Criteria | Threshold Value |
|---|---|
| Normal | < or = 15 °CA |
| (Target position - Actual position) | And |
| > or = -15 °CA | |
| Intermediate lock | < or = 15 °CA |
| (Target position - Actual position) | And |
| > or = -15 °CA |
JUDGMENT VALUE
Time Needed for Diagnosis
- Normal: 5000 ms
- Intermediate lock: 1000 ms
Detect the exhaust AVCS system malfunction.
Judge as NG when the conditions during which the differences of exhaust AVCS target timing advance amount and exhaust AVCS actual timing advance amount is large continues.
When the conditions during which the differences of exhaust AVCS target timing advance amount and exhaust AVCS actual timing advance amount is large continues for certain amount of time.
- Abnormality Judgment
Judge as NG when the following conditions are established within the predetermined time.
| Malfunction Criteria | Threshold Value |
|---|---|
| (Target position - Actual position) | > 15 °CA or < -15 °CA |
JUDGMENT VALUE
Time Needed for Diagnosis: 5000 ms
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judge as OK and clear the NG if the following conditions are established within the predetermined time.
| Malfunction Criteria | Threshold Value |
|---|---|
| (Target position - Actual position) | < or = 15 °CA and > or = -15 °CA |
JUDGMENT VALUE
Time Needed for Diagnosis: 5000 ms
Detect the AVCS system malfunction.
Judge as NG when standard timing advance amount is far from learning angle.
Judge as NG when the absolute value of the difference between cam signal input position and learning value is out of specification.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
| Malfunction Criteria | Threshold Value |
|---|---|
| Crankshaft position when camshaft position sensor signal is input - Learning value | > 10 °CA |
JUDGMENT VALUE
Time Needed for Diagnosis: 3000 ms
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
Note. Initial standard learning value is the value of crank angle initially input at the production plant. And then it will be updated every time normal judgment has been completed. Learning value will not be updated if NG judgment occurs because timing belt or chain derails suddenly in process or because wrong assembly occurs during servicing.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
| Malfunction Criteria | Threshold Value |
|---|---|
| Crankshaft position when camshaft position sensor signal is input - Learning value | < or = 10 °CA |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
Detect the exhaust AVCS system malfunction.
Judge as NG when standard timing advance amount is far from learning angle.
Judge as NG when the absolute value of the difference between cam signal input position and learning value is out of specification.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
| Malfunction Criteria | Threshold Value |
|---|---|
| Crankshaft position when camshaft position sensor signal is input - Learning value | > 10 °CA |
JUDGMENT VALUE
Time Needed for Diagnosis: 3000 ms
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
Note. Initial standard learning value is the value of crank angle initially input at the production plant. And then it will be updated every time normal judgment has been completed. Learning value will not be updated if NG judgment occurs because timing belt or chain derails suddenly in process or because wrong assembly occurs during servicing.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
| Malfunction Criteria | Threshold Value |
|---|---|
| Crankshaft position when camshaft position sensor signal is input - Learning value | < or = 10 °CA |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
Note. For the detection standard, refer to DTC P0016. < Refer to DTC P0016 CRANKSHAFT POSITION - CAMSHAFT POSITION CORRELATION (BANK1) , Diagnostic Trouble Code (DTC) Detecting Criteria. >
Note. For the detection standard, refer to DTC P0017. < Refer to DTC P0017 CRANK AND CAM TIMING B SYSTEM FAILURE (BANK 1) , Diagnostic Trouble Code (DTC) Detecting Criteria. >
Note. For the detection standard, refer to DTC P0011. < Refer to DTC P0011 INTAKE CAMSHAFT POSITION - TIMING OVER-ADVANCED OR SYSTEM PERFORMANCE (BANK 1) , Diagnostic Trouble Code (DTC) Detecting Criteria. >
Note. For the detection standard, refer to DTC P0014. < Refer to DTC P0014 EXHAUST AVCS SYSTEM 1 (RANGE/PERFORMANCE) , Diagnostic Trouble Code (DTC) Detecting Criteria. >
Detect functional errors of the front oxygen (A/F) sensor heater.
Judge as NG when it is determined that the front oxygen (A/F) sensor impedance is large when looking at engine status such as deceleration fuel cut.
Scheme 2
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
| Malfunction Criteria | Threshold Value |
|---|---|
| Front oxygen (A/F) sensor impedance | > 50 ohms |
JUDGMENT VALUE
Time Needed for Diagnosis: 10000 ms
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
| Malfunction Criteria | Threshold Value |
|---|---|
| Front oxygen (A/F) sensor impedance | < or = 50 ohms |
JUDGMENT VALUE
Time Needed for Diagnosis: 10000 ms
Detect front oxygen (A/F) sensor heater open or short circuit.
The front oxygen (A/F) sensor heater performs duty control, and the output terminal voltage at ON is 0 V, and the output terminal voltage at OFF is the battery voltage.
Judge as NG when the terminal voltage remains Low.
Scheme 3
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage level | Low |
| Front oxygen (A/F) sensor heater control duty | < 87.5 % |
JUDGMENT VALUE
Time Needed for Diagnosis: 4 ms x 250 time(s)
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage level | High |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
Detect front oxygen (A/F) sensor heater open or short circuit.
The front oxygen (A/F) sensor heater performs duty control, and the output terminal voltage at ON is 0 V, and the output terminal voltage at OFF is the battery voltage.
Judge as NG when the terminal voltage remains High.
Scheme 4
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage level | High |
| Front oxygen (A/F) sensor heater control duty | > or = 12.5 % |
JUDGMENT VALUE
Time Needed for Diagnosis: 4 ms x 500 time(s)
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage level | Low |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
Detect the rear oxygen sensor heater open or short circuit.
The rear oxygen sensor heater performs duty control, and the output terminal voltage at ON is 0 V, and the output terminal voltage at OFF is the battery voltage.
Judge as NG when the terminal voltage remains Low.
Scheme 5
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage level | Low |
| Rear oxygen sensor heater control duty | < 75 % |
JUDGMENT VALUE
Time Needed for Diagnosis: 8 ms x 1250 time(s)
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage level | High |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
Detect the rear oxygen sensor heater open or short circuit.
The rear oxygen sensor heater performs duty control, and the output terminal voltage at ON is 0 V, and the output terminal voltage at OFF is the battery voltage.
Judge as NG when the terminal voltage remains High.
Scheme 6
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage level | High |
| Rear oxygen sensor heater control duty | > or = 20 % |
JUDGMENT VALUE
Time Needed for Diagnosis: 8 ms x 1250 time(s)
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage level | Low |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
Detect problems in the intake manifold pressure sensor output properties.
Judge as NG when the intake air pressure AD value is Low whereas it seemed to be High from the viewpoint of engine condition, or when it is High whereas it seemed to be Low from the engine condition.
Scheme 7
- Abnormality Judgment
Judge as NG when Low side or High side becomes NG.
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
| Malfunction Criteria | Threshold Value |
|---|---|
| Low | |
| Engine speed | < 2900 rpm |
| Throttle position | > or = 12 ° |
| Output voltage | < 1.44 V |
| Engine load | > 0.36 g/rev (0.01 oz/rev) |
| High | |
| Engine speed | 500 rpm - 950 rpm (CVT model) |
| 550 rpm - 950 rpm (MT model) | |
| Throttle position | < 5.2 ° (CVT model) |
| < 4.9 ° (MT model) | |
| Output voltage | > or = 2.53 V |
| Engine load | < 0.34 g/rev (0.01 oz/rev) (CVT model) |
| < 0.31 g/rev (0.01 oz/rev) (MT model) |
JUDGMENT VALUE (EXCEPT FOR U5 MODEL)
| Malfunction Criteria | Threshold Value |
|---|---|
| Low | |
| Engine speed | < 2900 rpm |
| Throttle position | > or = 12 ° |
| Output voltage | < 1.44 V |
| Engine load | > 0.36 g/rev (0.01 oz/rev) |
| High | |
| Engine speed | 400 rpm - 950 rpm (CVT model) |
| 450 rpm - 950 rpm (MT model) | |
| Throttle position | < 5.2 ° (CVT model) |
| < 4.9 ° (MT model) | |
| Output voltage | > or = 2.53 V |
| Engine load | < 0.34 g/rev (0.01 oz/rev) (CVT model) |
| < 0.31 g/rev (0.01 oz/rev) (MT model) |
JUDGMENT VALUE (U5 MODEL)
Time Needed for Diagnosis
Low side: 5000 ms
High side: 5000 ms
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judge as OK and clear the NG when both Low side and High side become OK.
If the duration of time while the following conditions are met is longer than the time indicated, judge as OK.
| Malfunction Criteria | Threshold Value |
|---|---|
| Low | |
| Engine speed | < 2900 rpm |
| Throttle position | > or = 12 ° |
| Output voltage | > or = 1.44 V |
| Engine load | > 0.36 g/rev (0.01 oz/rev) |
| High | |
| Engine speed | 500 rpm - 950 rpm (CVT model) |
| 550 rpm - 950 rpm (MT model) | |
| Throttle position | < 5.2 ° (CVT model) |
| < 4.9 ° (MT model) | |
| Output voltage | < 2.53 V |
| Engine load | < 0.34 g/rev (0.01 oz/rev) (CVT model) |
| < 0.31 g/rev (0.01 oz/rev) (MT model) |
JUDGMENT VALUE (EXCEPT FOR U5 MODEL)
| Malfunction Criteria | Threshold Value |
|---|---|
| Low | |
| Engine speed | < 2900 rpm |
| Throttle position | > or = 12 ° |
| Output voltage | > or = 1.44 V |
| Engine load | > 0.36 g/rev (0.01 oz/rev) |
| High | |
| Engine speed | 400 rpm - 950 rpm (CVT model) |
| 450 rpm - 950 rpm (MT model) | |
| Throttle position | < 5.2 ° (CVT model) |
| < 4.9 ° (MT model) | |
| Output voltage | < 2.53 V |
| Engine load | < 0.34 g/rev (0.01 oz/rev) (CVT model) |
| < 0.31 g/rev (0.01 oz/rev) (MT model) |
JUDGMENT VALUE (U5 MODEL)
Time Needed for Diagnosis
Low side: Less than 1 second
High side: Less than 1 second
Detect the malfunction of air flow sensor output properties.
Judge as a low side NG when the air flow voltage indicates a small value regardless of running in a state where the air flow voltage increases. Judge as a high side NG when the air flow voltage indicates a large value regardless of running in a state where the air flow voltage decreases. Judge air flow sensor property NG when the Low side or High side becomes NG.
Scheme 8
- Abnormality Judgment
Judge as NG when Low side or High side becomes NG.
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
| Malfunction Criteria | Threshold Value |
|---|---|
| Low | |
| Output voltage | < 1.33 V |
| Engine speed | > or = 1600 rpm |
| Throttle opening angle | > or = 12 ° |
| Intake manifold pressure | > or = 66.7 kPa (500 mmHg, 19.7 inHg) |
| High (1) | |
| Output voltage | > or = 1.86 V |
| Engine speed | 500 rpm - 950 rpm (CVT model) |
| 550 rpm - 950 rpm (MT model) | |
| Throttle opening angle | < 5.2 ° (CVT model) |
| < 4.9 ° (MT model) | |
| Intake manifold pressure | > or = 44.8 kPa (336.3 mmHg, 13.2 inHg) (CVT model) |
| > or = 44.4 kPa (332.9 mmHg, 13.1 inHg) (MT model) | |
| High (2) | |
| Output voltage | > or = 1.76 V |
| Engine speed | 500 rpm - 950 rpm (CVT model) |
| 550 rpm - 950 rpm (MT model) | |
| Throttle opening angle | < 5.2 ° (CVT model) |
| < 4.9 ° (MT model) | |
| Intake manifold pressure | > or = 44.8 kPa (336.3 mmHg, 13.2 inHg) (CVT model) |
| > or = 44.4 kPa (332.9 mmHg, 13.1 inHg) (MT model) | |
| Fuel system diagnosis | Rich side malfunction |
JUDGMENT VALUE (EXCEPT FOR U5 MODEL)
| Malfunction Criteria | Threshold Value |
|---|---|
| Low | |
| Output voltage | < 1.33 V |
| Engine speed | > or = 1600 rpm |
| Throttle opening angle | > or = 12 ° |
| Intake manifold pressure | > or = 66.7 kPa (500 mmHg, 19.7 inHg) |
| High (1) | |
| Output voltage | > or = 1.86 V |
| Engine speed | 400 rpm - 950 rpm (CVT model) |
| 450 rpm - 950 rpm (MT model) | |
| Throttle opening angle | < 5.2 ° (CVT model) |
| < 4.9 ° (MT model) | |
| Intake manifold pressure | > or = 44.8 kPa (336.3 mmHg, 13.2 inHg) (CVT model) |
| > or = 44.4 kPa (332.9 mmHg, 13.1 inHg) (MT model) | |
| High (2) | |
| Output voltage | > or = 1.76 V |
| Engine speed | 400 rpm - 950 rpm (CVT model) |
| 450 rpm - 950 rpm (MT model) | |
| Throttle opening angle | < 5.2 ° (CVT model) |
| < 4.9 ° (MT model) | |
| Intake manifold pressure | > or = 44.8 kPa (336.3 mmHg, 13.2 inHg) (CVT model) |
| > or = 44.4 kPa (332.9 mmHg, 13.1 inHg) (MT model) | |
| Fuel system diagnosis | Rich side malfunction |
JUDGMENT VALUE (U5 MODEL)
Time Needed for Diagnosis
Low: 5000 ms
High: 5000 ms
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judge as OK and clear the NG when both Low side and High side become OK.
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
| Malfunction Criteria | Threshold Value |
|---|---|
| Low | |
| Output voltage | > or = 1.33 V |
| Engine speed | > or = 1600 rpm |
| Throttle opening angle | > or = 12 ° |
| Intake manifold pressure | > or = 66.7 kPa (500 mmHg, 19.7 inHg) |
| High | |
| Output voltage | < 1.86 V |
| Engine speed | 500 rpm - 950 rpm (CVT model) |
| 550 rpm - 950 rpm (MT model) | |
| Throttle opening angle | < 5.2 ° (CVT model) |
| < 4.9 ° (MT model) | |
| Intake manifold pressure | < 44.8 kPa (336.3 mmHg, 13.2 inHg) (CVT model) |
| < 44.4 kPa (332.9 mmHg, 13.1 inHg) (MT model) | |
| Fuel system diagnosis | Rich side normal |
JUDGMENT VALUE (EXCEPT FOR U5 MODEL)
| Malfunction Criteria | Threshold Value |
|---|---|
| Low | |
| Output voltage | > or = 1.33 V |
| Engine speed | > or = 1600 rpm |
| Throttle opening angle | > or = 12 ° |
| Intake manifold pressure | > or = 66.7 kPa (500 mmHg, 19.7 inHg) |
| High | |
| Output voltage | < 1.86 V |
| Engine speed | 400 rpm - 950 rpm (CVT model) |
| 450 rpm - 950 rpm (MT model) | |
| Throttle opening angle | < 5.2 ° (CVT model) |
| < 4.9 ° (MT model) | |
| Intake manifold pressure | < 44.8 kPa (336.3 mmHg, 13.2 inHg) (CVT model) |
| < 44.4 kPa (332.9 mmHg, 13.1 inHg) (MT model) | |
| Fuel system diagnosis | Rich side normal |
JUDGMENT VALUE (U5 MODEL)
Time Needed for Diagnosis
Low: Less than 1 second
High: Less than 1 second
Detect open or short circuits of the air flow sensor.
Judge as NG if out of specification.
Scheme 9
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | > or = 0.22 V |
JUDGMENT VALUE
Time Needed for Diagnosis: 500 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | > 0.22 V |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
Detect open or short circuits of the air flow sensor.
Judge as NG if out of specification.
Scheme 10
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | > or = 4.442 V |
JUDGMENT VALUE
Time Needed for Diagnosis: 500 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | < 4.442 V |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
Detect the open or short circuit of intake manifold pressure sensor.
Judge as NG if out of specification.
Scheme 11
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | > or = 0.606 V |
JUDGMENT VALUE
Time Needed for Diagnosis: 2000 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | > 0.606 V |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
Detect the open or short circuit of intake manifold pressure sensor.
Judge as NG if out of specification.
Scheme 12
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | > or = 3.906 V |
JUDGMENT VALUE
Time Needed for Diagnosis: 2000 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | < 3.906 V |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
Detect the malfunction of intake air temperature sensor output property.
Judge as NG when the intake air temperature is not varied whereas it seemed to be varied from the viewpoint of engine condition.
Scheme 13
- Abnormality Judgment
Judge as NG when the following conditions are established.
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage difference between Max. and Min. | < 0.02 V(Equivalent to approximately 0.5°C (0.9°F) near 25°C) |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judge as OK and clear the NG if the following conditions are established.
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage difference between Max. and Min. | > or = 0.02 V |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
Detect open or short circuit of the intake air temperature sensor.
Judge as NG if out of specification.
Scheme 14
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | < 0.395 V |
JUDGMENT VALUE
Time Needed for Diagnosis: 500 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | > or = 0.395 V |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
Detect open or short circuit of the intake air temperature sensor.
Judge as NG if out of specification.
Scheme 15
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | > or = 4.712 V |
JUDGMENT VALUE
Time Needed for Diagnosis: 500 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | < 4.712 V |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
Detect the malfunction of the engine coolant temperature sensor characteristics.
When the ignition is ON after the specified period of soaking time has elapsed, compare the engine coolant temperature with intake air temperature. Judge as NG if the difference between two temperatures is larger than the predetermined value and the engine coolant temperature becomes the specified value or more.
Scheme 16
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
| Malfunction Criteria | Threshold Value |
|---|---|
| All of the following conditions are established. | |
| Engine coolant temperature - intake air temperature | > 15°C (27°F) |
| Engine coolant temperature | > 45 °C (113 °F) |
JUDGMENT VALUE
Time Needed for Diagnosis: 512 ms
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
| Malfunction Criteria | Threshold Value |
|---|---|
| When any one of the followings is established. | |
| Engine coolant temperature - intake air temperature | < or = 15°C (27°F) |
| Engine coolant temperature | < or = 45 °C (113 °F) |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
Detect the open or short circuit of the engine coolant temperature sensor.
Judge as NG if out of specification.
Scheme 17
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | < 0.464 V |
JUDGMENT VALUE
Time Needed for Diagnosis: 500 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | > or = 0.464 V |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
Detect the open or short circuit of the engine coolant temperature sensor.
Judge as NG if out of specification.
Scheme 18
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | > or = 4.702 V |
JUDGMENT VALUE
Time Needed for Diagnosis: 500 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | < 4.702 V |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
Detect the open or short circuit of throttle position sensor 1.
Judge as NG if out of specification.
Scheme 19
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
| Malfunction Criteria | Threshold Value |
|---|---|
| Sensor 1 input voltage | < or = 0.27 V |
JUDGMENT VALUE
Time Needed for Diagnosis: 24 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
| Malfunction Criteria | Threshold Value |
|---|---|
| Sensor 1 input voltage | > 0.27 V |
JUDGMENT VALUE
Time Needed for Diagnosis: 24 ms
Detect the open or short circuit of throttle position sensor 1.
Judge as NG if out of specification.
Scheme 20
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
| Malfunction Criteria | Threshold Value |
|---|---|
| Sensor 1 input voltage | > or = 4.858 V |
JUDGMENT VALUE
Time Needed for Diagnosis: 24 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
| Malfunction Criteria | Threshold Value |
|---|---|
| Sensor 1 input voltage | < 4.858 V |
JUDGMENT VALUE
Time Needed for Diagnosis: 24 ms
Detect the malfunction of engine coolant temperature output property.
Judge as NG when the engine coolant temperature does not rise in driving conditions where it should.
Scheme 21
- Abnormality Judgment
Judge as NG if the criteria below are met.
| Malfunction Criteria | Threshold Value |
|---|---|
| Engine coolant temperature | < 20 °C (68 °F) |
| Timer for diagnosis after engine start | > or = Judgment value of timer after engine start |
JUDGMENT VALUE
Timer for diagnosis after engine start
- Timer stop at fuel cut
- During the driving conditions except a) above, timer counts up as follows.
64 ms + TWCNT ms (when at 64 ms)
TWCNT is defined as follows
TWCNT = 0 at idle switch ON
TWCNT show on the following table at idle switch OFF.
| Vehicle speed km/h (MPH) | |||||||||
|---|---|---|---|---|---|---|---|---|---|
| 0 (0) | 8 (5) | 16 (9.9) | 24 (14.9) | 32 (19.9) | 40 (24.9) | 48 (29.8) | 56 (34.8) | ||
| Temperature °C (°F) | 20 (-4) | 0 ms | 32.076 ms | 39.977 ms | 47.879 ms | 82.544 ms | 117.209 ms | 154.214 ms | 185.26 ms |
| 10 (14) | 0 ms | 25.704 ms | 33.606 ms | 41.508 ms | 68.52 ms | 95.532 ms | 125.667 ms | 155.802 ms | |
| 0 (32) | 0 ms | 17.646 ms | 25.548 ms | 33.45 ms | 53.652 ms | 73.855 ms | 97.12 ms | 120.386 ms | |
| 10 (50) | 0 ms | 7.901 ms | 15.802 ms | 23.704 ms | 37.941 ms | 52.177 ms | 68.573 ms | 82.538 ms | |
| 20 (68) | 0 ms | 7.901 ms | 15.802 ms | 23.704 ms | 37.941 ms | 52.177 ms | 68.573 ms | 82.538 ms | |
Judgment value of timer after engine starting
t = 457355 ms - 26405 ms x Ti
Ti : The lowest coolant temperature after engine start
Time Needed for Diagnosis: Less than 1 second
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judge as OK and clear the NG when the malfunction criteria below are met.
| Malfunction Criteria | Threshold Value |
|---|---|
| Engine coolant temperature | > or = 20 °C (68 °F) |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
Detect malfunctions of the thermostat function.
Judge as NG when any one of the following conditions is established.
- When the actual engine coolant temperature does not reach the maximum temperature necessary to perform other OBDII diagnosis and Sum (Estimated engine coolant temperature - actual engine coolant temperature) exceeded the predetermined value. (Judgment 1)
- When the actual engine coolant temperature does not reach the range within -11°C (-19.8°F) from the regulated temperature and Sum (Estimated engine coolant temperature - actual engine coolant temperature) exceeded the predetermined value. (Judgment 2)
- When the difference between the estimated coolant temperature and the actual engine coolant temperature exceeds the predetermined value, and Sum (Estimated engine coolant temperature - actual engine coolant temperature) exceeded the predetermined value. (Judgment 3)
Scheme 22
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
| Malfunction Criteria | Threshold Value |
|---|---|
| When any one of the followings is established. | |
| < Judgment 1 > | |
| Actual engine coolant temperature | < Value of Map 4 |
| And | |
| Sum (Estimated engine coolant temperature - actual engine coolant temperature) | > Value of Map 5 |
| < Judgment 2 > | |
| Actual engine coolant temperature | < Regulated temperature - Value of Map 6 |
| And | |
| Sum (Estimated engine coolant temperature - actual engine coolant temperature) | > Value of Map 7 |
| < Judgment 3 > | |
| Estimated engine coolant temperature - actual engine coolant temperature | > Value of Map 8 |
| And | |
| Sum (Estimated engine coolant temperature - actual engine coolant temperature) | > Value of Map 9 |
JUDGMENT VALUE
| Estimate ambient temperature °C (°F) | 7 (19.4) | 8 (46.4) | 10 (50) | 25 (77) |
|---|---|---|---|---|
| Threshold Value °C (°F) | 60 (140) | 60 (140) | 60 (140) | 60 (140) |
ENABLE CONDITIONS - MAP 4
| Engine coolant temperature at engine starting °C (°F) | 7 (19.4) | 0 (32) | 8 (46.4) | 10 (50) | 25 (77) | 35 (95) |
|---|---|---|---|---|---|---|
| Threshold Value °C (°F) | 1731.6 (3116.9) | 1731.6 (3116.9) | 1731.6 (3116.9) | 1731.6 (3116.9) | 1731.6 (3116.9) | 1200 (2160) |
ENABLE CONDITIONS - MAP 5
| Estimate ambient temperature °C (°F) | 7 (19.4) | 8 (46.4) | 10 (50) | 25 (77) |
|---|---|---|---|---|
| Threshold Value °C (°F) | 16.7 (30.1) | 11.1 (20) | 11.1 (20) | 11.1 (20) |
ENABLE CONDITIONS - MAP 6
| Engine coolant temperature at engine starting °C (°F) | 7 (19.4) | 0 (32) | 8 (46.4) | 10 (50) | 30 (86) | 35 (95) |
|---|---|---|---|---|---|---|
| Threshold Value °C (°F) | 1731.6 (3116.9) | 1731.6 (3116.9) | 1731.6 (3116.9) | 1731.6 (3116.9) | 1731.6 (3116.9) | 1500 (2700) |
ENABLE CONDITIONS - MAP 7
| Estimate ambient temperature °C (°F) | 7 (19.4) | 8 (46.4) | 10 (50) | 25 (77) |
|---|---|---|---|---|
| Threshold Value °C (°F) | 11.1 (20) | 11.1 (20) | 11.1 (20) | 11.1 (20) |
ENABLE CONDITIONS - MAP 8
| Engine coolant temperature at engine starting °C (°F) | 7 (19.4) | 8 (46.4) | 10 (50) | 25 (77) |
|---|---|---|---|---|
| Threshold Value °C (°F) | 1731.6 (3116.9) | 1731.6 (3116.9) | 1731.6 (3116.9) | 1731.6 (3116.9) |
ENABLE CONDITIONS - MAP 9
Time Needed for Diagnosis: 300 - 700 seconds
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
| Malfunction Criteria | Threshold Value |
|---|---|
| All of the following conditions are established. | |
| < Judgment 1 > | |
| Actual engine coolant temperature | > or = Value of Map 4 |
| And | |
| Sum (Estimated engine coolant temperature - actual engine coolant temperature) | < or = Value of Map 5 |
| < Judgment 2 > | |
| Actual engine coolant temperature | > or = Regulated temperature - Value of Map 6 |
| And | |
| Sum (Estimated engine coolant temperature - actual engine coolant temperature) | < or = Value of Map 7 |
| < Judgment 3 > | |
| Estimated engine coolant temperature - actual engine coolant temperature | < or = Value of Map 8 |
| And | |
| Sum (Estimated engine coolant temperature - actual engine coolant temperature) | < or = Value of Map 9 |
| And | |
| Actual engine coolant temperature | > or = Regulated temperature - Value of Map 10 |
JUDGMENT VALUE
| Estimate ambient temperature °C (°F) | 7 (19.4) | 8 (46.4) | 10 (50) | 25 (77) |
|---|---|---|---|---|
| Threshold Value °C (°F) | 16.7 (30.1) | 11.1 (20) | 11.1 (20) | 11.1 (20) |
ENABLE CONDITIONS - MAP 10
Time Needed for Diagnosis: 300 - 700 seconds
Detect the open or short circuit of sensor.
Judge as NG, when the element voltage is out of the specified range.
Scheme 23
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
| Malfunction Criteria | Threshold Value |
|---|---|
| Input voltage (+) | < 1.128 V |
| Or | |
| Input voltage (-) | < 0.23 V |
| Or | |
| Input voltage (+) - Input voltage (-) | < 0.573 V |
JUDGMENT VALUE
Time Needed for Diagnosis
Input voltage (+): 1000 ms
Input voltage (-): 1000 ms
Input voltage (+) - Input voltage (-)|: 1000 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
| Malfunction Criteria | Threshold Value |
|---|---|
| Input voltage (+) | > or = 1.128 V |
| Input voltage (-) | > or = 0.23 V |
| Input voltage (+) - Input voltage (-) | > or = 0.573 V |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
Detect the open or short circuit of sensor.
Judge as NG, when the element voltage is out of the specified range.
Scheme 24
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
| Malfunction Criteria | Threshold Value |
|---|---|
| Input voltage (+) | > 3.589 V |
| Or | |
| Input voltage (-) | > 3.599 V |
JUDGMENT VALUE
Time Needed for Diagnosis
Input voltage (+): 1000 ms
Input voltage (-): 1000 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
| Malfunction Criteria | Threshold Value |
|---|---|
| Input voltage (+) | < or = 3.589 V |
| Input voltage (-) | < or = 3.599 V |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
Detect open circuits of the sensor.
Judge as NG when the impedance of the element is large.
Scheme 25
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
| Malfunction Criteria | Threshold Value |
|---|---|
| Battery voltage | > or = 10.9 V |
| Time of heater control duty at 70 % or more | > or = 36000 ms |
| Front oxygen (A/F) sensor impedance. | > 500 ohms |
JUDGMENT VALUE
Time Needed for Diagnosis: 5000 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
| Malfunction Criteria | Threshold Value |
|---|---|
| Battery voltage | > or = 10.9 V |
| Front oxygen (A/F) sensor impedance. | < or = 500 ohms |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
Detect continuity NG of the oxygen sensor. If the oxygen sensor voltage reading is not within the probable range considering the operating conditions, judge as NG.
Scheme 26
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
| Malfunction Criteria | Threshold Value | DTC |
|---|---|---|
| High | P0138 | |
| Sensor output voltage | > 1.2 V | |
| Low | P0137 | |
| Sensor output voltage | < 0.03 V |
JUDGMENT VALUE
Time Needed for Diagnosis
High: 2500 ms
Low (1): 20000 ms
Low (2): 40000 ms
Low (3): Value from Map
| Fuel cut time (ms) | 0 | 2000 | 10000 |
|---|---|---|---|
| Time Needed for Diagnosis (ms) | 40000 | 40000 | 60000 |
ENABLE CONDITIONS - MAP
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
| Malfunction Criteria | Threshold Value | DTC |
|---|---|---|
| High | P0138 | |
| Sensor output voltage | < or = 1.2 V | |
| Low | P0137 | |
| Sensor output voltage | < or = 0.03 V |
JUDGMENT VALUE
Time Needed for Diagnosis
High: Less than 1 second
Low (1): Less than 1 second
Low (2): Less than 1 second
Low (3): Less than 1 second
Note. For the detection standard, refer to DTC P0137. < Refer to DTC P0137 O2 SENSOR CIRCUIT LOW VOLTAGE (BANK 1 SENSOR 2) , Diagnostic Trouble Code (DTC) Detecting Criteria. >
Detect the slow response of rich --> lean for rear oxygen sensor output.
When the deceleration fuel cut has occurred, detect the trouble by calculating the time when the rear oxygen sensor output passes through the predetermined range of voltages.
Judge as NG when the response time is larger than the threshold value.
Scheme 27
Detect the trouble by calculating the response time of the rear oxygen sensor during fuel cut.
Scheme 28
- Abnormality Judgment
Judge as NG when the following conditions are established.
| Malfunction Criteria | Threshold Value |
|---|---|
| Time when rear oxygen sensor voltage changed from 0.5 V to 0.2 V. | > 491 ms |
JUDGMENT VALUE
Time Needed for Diagnosis: 10 seconds
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judge as OK and clear the NG if the following conditions are established.
| Malfunction Criteria | Threshold Value |
|---|---|
| Time when rear oxygen sensor voltage changed from 0.5 V to 0.2 V. | < or = 491 ms |
JUDGMENT VALUE
Time Needed for Diagnosis: 10 seconds
Detect the slow response of lean --> rich for rear oxygen sensor output.
After the deceleration fuel cut has occurred, detect the trouble by calculating the time when the rear oxygen sensor output passes through the predetermined range of voltages.
Judge as NG when the response time is larger than the threshold value.
Scheme 29
Detect the trouble by calculating the response time of the rear oxygen sensor after fuel cut.
Scheme 30
- Abnormality Judgment
Judge as NG when the following conditions are established.
| Malfunction Criteria | Threshold Value |
|---|---|
| Time when rear oxygen sensor voltage changed from 0.3 V to 0.5 V. | > 4000 ms |
JUDGMENT VALUE
Time Needed for Diagnosis: 10 seconds
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judge as OK and clear the NG if the following conditions are established.
| Malfunction Criteria | Threshold Value |
|---|---|
| Time when rear oxygen sensor voltage changed from 0.3 V to 0.5 V. | < or = 4000 ms |
JUDGMENT VALUE
Time Needed for Diagnosis: 10 seconds
Detect the delayed response of rear oxygen sensor output for rich --> lean.
After the deceleration fuel cut has started, detect the trouble by calculating the time when the rear oxygen sensor output decreases to the predetermined voltages.
Judge as NG when the response time is larger than the threshold value.
Scheme 31
Detect the trouble by calculating the time from the beginning of the fuel cut to the beginning of the rear oxygen sensor voltage starting to drop.
Scheme 32
- Abnormality Judgment
Judge as NG when the following conditions are established.
| Malfunction Criteria | Threshold Value |
|---|---|
| Time when rear oxygen sensor voltage changed to 0.5 V after the fuel cut started. | > 4000 ms |
JUDGMENT VALUE
Time Needed for Diagnosis: 10 seconds
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judge as OK and clear the NG if the following conditions are established.
| Malfunction Criteria | Threshold Value |
|---|---|
| Time when rear oxygen sensor voltage changed to 0.5 V after the fuel cut started. | > or = 4000 ms |
JUDGMENT VALUE
Time Needed for Diagnosis: 10 seconds
Detect the delayed response of rear oxygen sensor output for lean --> rich.
After the deceleration fuel cut has completed, detect the trouble by calculating the time when the rear oxygen sensor output increases to the predetermined voltages.
Judge as NG when the response time is larger than the threshold value.
Scheme 33
Detect the trouble by calculating the time from the completion of the fuel cut to the beginning of the rear oxygen sensor voltage starting to rise.
Scheme 34
- Abnormality Judgment
Judge as NG when the following conditions are established.
| Malfunction Criteria | Threshold Value |
|---|---|
| The number of times that the rear oxygen sensor voltage changed to 0.3 V after the fuel cut has completed (time counter) | > 3750 time(s) |
JUDGMENT VALUE
Time Needed for Diagnosis: 10 seconds
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judge as OK and clear the NG if the following conditions are established.
| Malfunction Criteria | Threshold Value |
|---|---|
| The number of times that the rear oxygen sensor voltage changed to 0.3 V after the fuel cut has completed (time counter) | < or = 3750 time(s) |
JUDGMENT VALUE
Time Needed for Diagnosis: 10 seconds
Detect the rear oxygen sensor open or short circuit. Judge as NG when the rear oxygen sensor voltage can be determined to be abnormal considering conditions such as intake air amount, engine coolant temperature, main feedback control and deceleration fuel cut.
Scheme 35
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
| Malfunction Criteria | Threshold Value |
|---|---|
| Minimum output voltage | > 0.15 V |
| Or | |
| Maximum output voltage | < 0.55 V |
JUDGMENT VALUE
Time Needed for Diagnosis: 200000 ms
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judge as OK and clear the NG if the following conditions are established.
| Malfunction Criteria | Threshold Value |
|---|---|
| Diagnosis of the rear oxygen sensor voltage low side | Incomplete |
| Minimum output voltage | < or = 0.15 V |
| Maximum output voltage | > or = 0.55 V |
JUDGMENT VALUE
Detect the malfunction of rear oxygen sensor heater.
While observing the engine condition, judge as NG if the rear oxygen sensor impedance is great.
Scheme 36
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
| Malfunction Criteria | Threshold Value |
|---|---|
| Output terminal for heater characteristics failure detection | Low |
JUDGMENT VALUE
Time Needed for Diagnosis: 4 ms x 2500 time(s)
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
| Malfunction Criteria | Threshold Value |
|---|---|
| Output terminal for heater characteristics failure detection | High |
JUDGMENT VALUE
Time Needed for Diagnosis: 4 ms x 2500 time(s)
Detect the slow response of front oxygen (A/F) sensor.
For diagnosis, detect the trouble by processing the lambda waveform in normal driving without forcibly changing the target air fuel ratio.
Scheme 37
DIAGNOSTIC METHOD 1
Detect the malfunction by checking "Cumulative value of time when lambda changes from lean --> rich" in comparison to "Time during which diagnosis is in progress".
Scheme 38
- Abnormality Judgment
Judge as NG when the following conditions are established.
| Malfunction Criteria | Threshold Value | DTC |
|---|---|---|
| (Cumulative value of time when lambda changes from lean --> rich) / (Time during which diagnosis is in progress) | < 0.39 (CVT models except for U5 model) < 0.35 (MT models except for U5 model) < 0.39 (U5 CVT model) < 0.39 (U5 MT model) | P014C |
| > 0.63 (CVT models except for U5 model) > 0.65 (MT models except for U5 model) > 0.63 (U5 CVT model) > 0.61 (U5 MT model) | P014D |
JUDGMENT VALUE
Time Needed for Diagnosis: 90 seconds
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judge as OK and clear the NG if the following conditions are established.
| Malfunction Criteria | Threshold Value | DTC |
|---|---|---|
| (Cumulative value of time when lambda changes from lean --> rich) / (Time during which diagnosis is in progress) | > or = 0.39 (CVT models except for U5 model) > or = 0.35 (MT models except for U5 model) > or = 0.39 (U5 CVT model) > or = 0.39 (U5 MT model) | P014C |
| < or = 0.63 (CVT models except for U5 model) < or = 0.65 (MT models except for U5 model) < or = 0.63 (U5 CVT model) < or = 0.61 (U5 MT model) | P014D |
JUDGMENT VALUE
Time Needed for Diagnosis: 90 seconds
DIAGNOSTIC METHOD 2
Detect the malfunction by the cumulative value obtained from the amount of variation in lambda change.
Scheme 39
- Abnormality Judgment
Judge as NG when the following conditions are established.
| Malfunction Criteria | Threshold Value | DTC |
|---|---|---|
| Cumulative value obtained from the amount of variation in lambda change Sum |(lambda(n) - lambda(n-1)) - (lambda(n-1) - lambda(n-2)) | < Value from Map | P014C and P014D |
JUDGMENT VALUE
| Cumulative value obtained from the amount of variation in lambda Sum |lambda(n) - lambda(n-1) | 0.00 | 3.00 |
|---|---|---|
| Cumulative value obtained from the amount of variation in lambda change | 0.50 | 2.00 |
ENABLE CONDITIONS - MAP (CVT MODELS EXCEPT FOR U5 MODEL)
| Cumulative value obtained from the amount of variation in lambda Sum |lambda(n) - lambda(n-1) | 0.00 | 4.00 |
|---|---|---|
| Cumulative value obtained from the amount of variation in lambda change | 0.00 | 2.00 |
ENABLE CONDITIONS - MAP (MT MODELS EXCEPT FOR U5 MODEL)
| Cumulative value obtained from the amount of variation in lambda Sum |lambda(n) - lambda(n-1) | 0.00 | 4.00 |
|---|---|---|
| Cumulative value obtained from the amount of variation in lambda change | 0.50 | 2.00 |
ENABLE CONDITIONS - MAP (U5 CVT MODEL)
| Cumulative value obtained from the amount of variation in lambda Sum |lambda(n) - lambda(n-1) | 0.00 | 5.00 |
|---|---|---|
| Cumulative value obtained from the amount of variation in lambda change | 0.00 | 3.25 |
ENABLE CONDITIONS - MAP (U5 MT MODEL)
Time Needed for Diagnosis: 90 seconds
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judge as OK and clear the NG if the following conditions are established.
| Malfunction Criteria | Threshold Value | DTC |
|---|---|---|
| Cumulative value obtained from the amount of variation in lambda change Sum |(lambda(n) - lambda(n-1)) - (lambda(n-1) - lambda(n-2)) | > or = Value from Map | P014C and P014D |
JUDGMENT VALUE
Time Needed for Diagnosis: 90 seconds
Note. For the detection standard, refer to DTC P014C. < Refer to DTC P014C O2 SENSOR SLOW RESPONSE - RICH TO LEAN (BANK 1 SENSOR 1) , Diagnostic Trouble Code (DTC) Detecting Criteria. >
Detect the slow response of front oxygen (A/F) sensor.
For diagnosis, detect the trouble by processing the lambda waveform in normal driving without forcibly changing the target air fuel ratio.
Scheme 40
Detect the malfunction depending on the average value of time necessary for lambda to inverse the air fuel ratio from "Lean --> Rich --> Lean" to "Rich --> Lean --> Rich".
Scheme 41
- Abnormality Judgment
Judge as NG when the following conditions are established.
| Malfunction Criteria | Threshold Value | DTC |
|---|---|---|
| Average value of time necessary for lambda to inverse the air fuel ratio to Lean --> Rich --> Lean. | > 220 ms (CVT models except for U5 model) > 500 ms (MT models except for U5 model) > 100 ms (U5 CVT model) > 380 ms (U5 MT model) | P015A |
| Average value of time necessary for lambda to inverse the air fuel ratio to Rich --> Lean --> Rich. | > 600 ms (CVT models except for U5 model) > 500 ms (MT models except for U5 model) > 240 ms (U5 CVT model) > 270 ms (U5 MT model) | P015B |
JUDGMENT VALUE
Time Needed for Diagnosis: 50 times of inversion
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judge as OK and clear the NG if the following conditions are established.
| Malfunction Criteria | Threshold Value | DTC |
|---|---|---|
| Average value of time necessary for lambda to inverse the air fuel ratio to Lean --> Rich --> Lean. | < or = 220 ms (CVT models except for U5 model) < or = 500 ms (MT models except for U5 model) < or = 100 ms (U5 CVT model) < or = 380 ms (U5 MT model) | P015A |
| Average value of time necessary for lambda to inverse the air fuel ratio to Rich --> Lean --> Rich. | < or = 600 ms (CVT models except for U5 model) < or = 500 ms (MT models except for U5 model) < or = 240 ms (U5 CVT model) < or = 270 ms (U5 MT model) | P015B |
JUDGMENT VALUE
Time Needed for Diagnosis: 50 times of inversion
Detect the malfunction by calculating the average amplitude of lambda.
Scheme 42
- Abnormality Judgment
Judge as NG when the following conditions are established.
| Malfunction Criteria | Threshold Value | DTC |
|---|---|---|
| Average value for lambda amplitude | > 0.048 (CVT models except for U5 model) > 0.1 (MT models except for U5 model) > 0.06 (U5 CVT model) > 0.1 (U5 MT model) | P015A and P015B |
JUDGMENT VALUE
Time Needed for Diagnosis: 11250 time(s) x 8 ms
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judge as OK and clear the NG if the following conditions are established.
| Malfunction Criteria | Threshold Value | DTC |
|---|---|---|
| Average value for lambda amplitude | < or = 0.048 (CVT models except for U5 model) < or = 0.1 (MT models except for U5 model) < or = 0.06 (U5 CVT model) < or = 0.1 (U5 MT model) | P015A and P015B |
JUDGMENT VALUE
Time Needed for Diagnosis: 11250 time(s) x 8 ms
DIAGNOSIS METHOD 3 (MT MODEL ONLY)
Change STFT (A/F compensation value) by interruption, and measure the reaction time of lambda value. When A/F sensor malfunctions, the reaction time takes longer than at normal condition. In this case, judge as abnormal.
Scheme 43
Measure reaction time (t1, t2, t3) and reaction time (t4, t5, t6). Use the average value of the reaction time to obtain the diagnostic value.
Scheme 44
- Abnormality Judgment
Judge as NG when the following conditions are established.
| Malfunction Criteria | Threshold Value | DTC |
|---|---|---|
| (t1 + t2 + t3)/3 | > 750 ms | P015A and P015B |
| And | ||
| (t4 + t5 + t6)/3 | > 750 ms |
JUDGMENT VALUE
Time Needed for Diagnosis: 1000 ms x [1 time(s)/2] + 1000 ms x 3 time(s) + 500 ms
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judge as OK and clear the NG if the following conditions are established.
| Malfunction Criteria | Threshold Value | DTC |
|---|---|---|
| (t1 + t2 + t3)/3 | < or = 750 ms | P015A and P015B |
| Or | ||
| (t4 + t5 + t6)/3 | < or = 750 ms |
JUDGMENT VALUE
Time Needed for Diagnosis: 1000 ms x [1 time(s)/2] + 1000 ms x 3 time(s) + 500 ms
Note. For the detection standard, refer to DTC P015A. < Refer to DTC P015A O2 SENSOR DELAYED RESPONSE - RICH TO LEAN (BANK 1 SENSOR 1) , Diagnostic Trouble Code (DTC) Detecting Criteria. >
Detect fuel system malfunction by the amount of main feedback control.
Fuel system is diagnosed by comparing the target air fuel ratio calculated by ECM with the actual air fuel ratio measured by sensor.
- Abnormality Judgment
Compare the diagnostic value (fsobd) with the threshold value, and if a condition meeting the malfunction criteria below continues for 10 s x 5 time(s) or more, judge that there is a fault in the fuel system.
| Malfunction Criteria | Threshold Value |
|---|---|
| Fsobd = (sglmd - tglmda) + faf + flaf In this case: sglmd = measured lambda tglmda = target lambda faf = main feedback compensation coefficient (every 64 milliseconds) flaf = main feedback learning compensation coefficient | < or = Value from Map 2 |
JUDGMENT VALUE
| Amount of air (g (oz)/s) | 0 (0) | 3.2 (0.11) | 6.4 (0.23) | 9.6 (0.34) | 12.8 (0.45) | 16 (0.56) | 19.2 (0.68) |
|---|---|---|---|---|---|---|---|
| FsobdL1 (%) | 1.4 | 1.4 | 1.332 | 1.25 | 1.25 | 1.25 | 1.25 |
ENABLE CONDITIONS - MAP 2
Time Needed for Diagnosis: 10 s x 5 time(s)
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
| Malfunction Criteria | Threshold Value |
|---|---|
| Fsobd = (sglmd - tglmda) + faf + flaf | < 1.15 |
JUDGMENT VALUE
Time Needed for Diagnosis: 10 s
Detect fuel system malfunction by the amount of main feedback control.
Fuel system is diagnosed by comparing the target air fuel ratio calculated by ECM with the actual air fuel ratio measured by sensor.
- Abnormality Judgment
Compare the diagnostic value (fsobd) with the threshold value, and if a condition meeting the malfunction criteria below continues for 10 s x 5 time(s) or more, judge that there is a fault in the fuel system.
| Malfunction Criteria | Threshold Value |
|---|---|
| Fsobd = (sglmd - tglmda) + faf + flaf In this case: sglmd = measured lambda tglmda = target lambda faf = main feedback compensation coefficient (every 64 milliseconds) flaf = main feedback learning compensation coefficient | < Value of Map 2 |
JUDGMENT VALUE
| Amount of air (g (oz)/s) | 0 (0) | 3.2 (0.11) | 6.4 (0.23) | 9.6 (0.34) | 12.8 (0.45) | 16 (0.56) | 19.2 (0.68) |
|---|---|---|---|---|---|---|---|
| FsobdL1 (%) | 0.6 | 0.6 | 0.668 | 0.735 | 0.735 | 0.735 | 0.735 |
ENABLE CONDITIONS - MAP 2
Time Needed for Diagnosis: 10 s x 5 time(s)
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judge as OK if the status that the criteria below are met continues for 10 seconds.
| Malfunction Criteria | Threshold Value |
|---|---|
| Fsobd = (sglmd - tglmda) + faf + flaf | > or = 0.85 |
JUDGMENT VALUE
Time Needed for Diagnosis: 10 s
Detect for abnormal values in the oil temperature sensor output properties.
Judge as NG when the oil temperature does not rise even though the engine is running under a condition where it should rise.
Scheme 45
- Abnormality Judgment
Judge as NG when the following conditions are established.
| Malfunction Criteria | Threshold Value |
|---|---|
| Engine oil temperature | < 50 °C (122 °F) |
| After engine start oil temperature sensor characteristic diagnosis timer. | > or = Judgment value for after engine start oil temperature sensor characteristic diagnosis timer |
JUDGMENT VALUE
After engine start oil temperature sensor characteristic diagnosis timer (timer for diagnosis).
- Timer stop at fuel cut
- During the driving conditions except a) above, timer counts up as follows.
64 ms + TOILCNT ms (when at 64 ms)
Where, TOILCNT is determined as follows
TOILCNT = 0 at idle switch ON
For TOILCNT at Idle switch off, refer to the following table.
| Vehicle speed km/h (MPH) | |||||||||
|---|---|---|---|---|---|---|---|---|---|
| 0 (0) | 8 (5) | 16 (9.9) | 24 (14.9) | 32 (19.9) | 40 (24.9) | 48 (29.8) | 56 (34.8) | ||
| Temperature °C (°F) | 30 (-22) | 39.8 ms | 47.3 ms | 55.9 ms | 66.0 ms | 79.7 ms | 96.5 ms | 117.8 ms | 145.7 ms |
| 20 (-4) | 31.6 ms | 38.6 ms | 46.6 ms | 56.0 ms | 68.7 ms | 84.7 ms | 104.8 ms | 131.3 ms | |
| 10 (14) | 21.6 ms | 27.9 ms | 35.1 ms | 43.6 ms | 55.4 ms | 70.1 ms | 88.8 ms | 113.6 ms | |
| 0 (32) | 11.8 ms | 17.4 ms | 23.9 ms | 31.5 ms | 42.3 ms | 55.9 ms | 73.3 ms | 96.8 ms | |
| 10 (50) | 9.9 ms | 15.4 ms | 21.9 ms | 29.5 ms | 40.4 ms | 54.5 ms | 72.4 ms | 97.4 ms | |
After engine start oil temperature characteristic diagnosis timer judgment value (t).
t = 2402277 ms - 55052 ms x Ti (t > or = 2400000)
Ti = The lowest coolant temperature after starting the engine.
Time Needed for Diagnosis: Less than 1 second
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judge as OK and clear the NG if the following conditions are established.
Time Needed for Diagnosis: Less than 1 second
| Malfunction Criteria | Threshold Value |
|---|---|
| Engine oil temperature | > or = 50 °C (122 °F) |
JUDGMENT VALUE
Detect the open or short circuit of the oil temperature sensor.
Judge as NG when outside of the judgment value.
Scheme 46
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | < 0.135 V |
JUDGMENT VALUE
Time Needed for Diagnosis: 500 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | > or = 0.135 V |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
Detect the open or short circuit of the oil temperature sensor.
Judge as NG when outside of the judgment value.
Scheme 47
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | > or = 4.876 V |
JUDGMENT VALUE
Time Needed for Diagnosis: 500 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | < 4.876 V |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
Based on the self-diagnostic result of the injector driving IC, judge the injector driving circuit as normal or abnormal.
Injector driving IC detects the status of "fuel remains injected" or "fuel is not injected" as a malfunction.
- Abnormality Judgment
Judge as NG when the following conditions are established.
| Malfunction Criteria | Threshold Value |
|---|---|
| Injector driving IC information | Malfunction |
JUDGMENT VALUE
Time Needed for Diagnosis: 2500 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the following conditions are established.
| Malfunction Criteria | Threshold Value |
|---|---|
| Injector driving IC information | Normal |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
Note. For the detection standard, refer to DTC P0201. < Refer to DTC P0201 INJECTOR #1 , Diagnostic Trouble Code (DTC) Detecting Criteria. >
Note. For the detection standard, refer to DTC P0201. < Refer to DTC P0201 INJECTOR #1 , Diagnostic Trouble Code (DTC) Detecting Criteria. >
Note. For the detection standard, refer to DTC P0201. < Refer to DTC P0201 INJECTOR #1 , Diagnostic Trouble Code (DTC) Detecting Criteria. >
Detect the open or short circuit of throttle position sensor 2.
Judge as NG if out of specification.
Scheme 48
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
| Malfunction Criteria | Threshold Value |
|---|---|
| Sensor 2 input voltage | < or = 1.15 V |
JUDGMENT VALUE
Time Needed for Diagnosis: 24 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
| Malfunction Criteria | Threshold Value |
|---|---|
| Sensor 2 input voltage | > 1.15 V |
JUDGMENT VALUE
Time Needed for Diagnosis: 24 ms
Detect the open or short circuit of throttle position sensor 2.
Judge as NG if out of specification.
Scheme 49
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
| Malfunction Criteria | Threshold Value |
|---|---|
| Sensor 2 input voltage | > or = 4.858 V |
JUDGMENT VALUE
Time Needed for Diagnosis: 24 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
| Malfunction Criteria | Threshold Value |
|---|---|
| Sensor 2 input voltage | < 4.858 V |
JUDGMENT VALUE
Time Needed for Diagnosis: 24 ms
Note. For the detection standard, refer to DTC P0301. < Refer to DTC P0301 CYLINDER 1 MISFIRE DETECTED , Diagnostic Trouble Code (DTC) Detecting Criteria. >
Detect the presence of misfire occurrence. (Revolution fluctuation method)
Monitoring Misfire which influences exhaust deterioration (1.5 times of FTP) and catalyst damage is made obligatory by the law. Misfire affecting these two has two patterns below
- Intermittent misfire (The same cylinder misfires in random, or different cylinders misfire in random.): FTP 1.5 times misfire
- Every time misfire (The same cylinder misfires every time.): FTP 1.5 times misfire, Catalyst damage misfire
The following detecting methods are adopted for these detection.
- Intermittent misfire: FTP 1.5 times misfire 180° Interval Difference Method (MT: 1, 800 rpm or less, AT: None) 360° Interval Difference Method (whole range) 720° Interval Difference Method (3, 000 rpm or more)
- Misfire every time: FTP 1.5 times misfire, Catalyst damage misfire 360° Interval Difference Method
When a misfire occurs, the engine speed will decrease and the crankshaft position speed will change. Calculate the interval difference value (diagnostic value) from crankshaft position speed by the following formula, and judge whether a misfire is occurring or not comparing the calculated result with judgment value. Count the number of misfires, if the misfire ratio is higher during 1000 revs. or 200 revs. judge corresponding cylinders as NG.
| Diagnostic value calculation (Calculate from angle speed) --> | Misfire detection every single ignition (Compare diagnostic value with judgment value) --> | NG judgment (Misfire occurrence judgment required by the law) (Compare number of misfire with judgment value) |
|---|---|---|
| 180° Interval Difference Method 360° Interval Difference Method 720° Interval Difference Method | FTP 1.5 times misfire NG judgment Catalyst damage misfire NG judgment |
As shown in the following figure, pick a cylinder as the standard and name it omg 0. And the former crankshaft position speed is named omg 1, the second former crankshaft position speed is named omg 2, the third is named omg 3, etc.
Scheme 50
| Diagnostic value | Domg 180 = (omg 1 - omg 0) - (omg 5 - omg 1)/4 |
|---|---|
| Judge as a misfire in the following cases. domg 180 > judgment value of positive side domg 180 < or = judgment value of negative side (Diagnostic value before 180° CA) | |
180° INTERVAL DIFFERENCE METHOD
Scheme 51
| Diagnostic value | Domg 360 = (omg 1 - omg 0) - (omg 3 - omg 2) |
|---|---|
| Misfire judgment | Domg 360 > Judgment value --> Judge as misfire |
360° INTERVAL DIFFERENCE METHOD
Scheme 52
| Diagnostic value | Domg 720 = (omg 1 - omg 0) - (omg 5 - omg 4) |
|---|---|
| Misfire judgment | Domg 720 > Judgment value --> Judge as misfire |
720° INTERVAL DIFFERENCE METHOD
Scheme 53
- FTP 1.5 times misfire (Misfire occurrence level which influences exhaust gas)
- Abnormality Judgment
| Malfunction Criteria | Threshold Value |
|---|---|
| FTP emission diagnostic value | > or = 42 x 100/2000% in 1000 revs. (except for XV model) > or = 47 x 100/2000% in 1000 revs. (XV model) |
JUDGMENT VALUE (EXCEPT FOR U5 MODEL) (JUDGE THAT MALFUNCTION OCCURS WHEN MISFIRE RATIO IS HIGH IN 1000 ENGINE REVS.)
| Malfunction Criteria | Threshold Value |
|---|---|
| FTP emission diagnostic value | > or = 17 x 100/2000% in 1000 revs. |
JUDGMENT VALUE (U5 MODEL) (JUDGE THAT MALFUNCTION OCCURS WHEN MISFIRE RATIO IS HIGH IN 1000 ENGINE REVS.)
Time Needed for Diagnosis: 1000 engine revs.
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
| Malfunction Criteria | Threshold Value |
|---|---|
| FTP emission diagnostic value | < 42 x 100/2000% in 1000 revs. (except for XV model) < 47 x 100/2000% in 1000 revs. (XV model) |
JUDGMENT VALUE (EXCEPT FOR U5 MODEL)
| Malfunction Criteria | Threshold Value |
|---|---|
| FTP emission diagnostic value | < 17 x 100/2000% in 1000 revs. |
JUDGMENT VALUE (U5 MODEL)
Time Needed for Diagnosis: 1000 engine revs.
- Catalyst damage misfire (Misfire occurrence level damaging catalyst)
- Abnormality Judgment
| Malfunction Criteria | Threshold Value |
|---|---|
| Catalyst damage misfire diagnostic value | > or = Value from Map 3 |
JUDGMENT VALUE
| Intake air (g(oz)/rev) | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| 0.2 (0.01) | 0.3 (0.01) | 0.4 (0.01) | 0.5 (0.02) | 0.6 (0.02) | 0.7 (0.02) | 0.8 (0.03) | 0.9 (0.03) | 1 (0.04) | 1.1 (0.04) | ||
| Engine speed (rpm) | 700 | 100 | 100 | 100 | 100 | 80 | 80 | 80 | 80 | 80 | 80 |
| 1000 | 100 | 100 | 100 | 100 | 80 | 80 | 57 | 44 | 80 | 80 | |
| 1200 | 100 | 100 | 100 | 100 | 100 | 80 | 67 | 57 | 57 | 57 | |
| 1600 | 100 | 100 | 80 | 80 | 80 | 57 | 44 | 36 | 44 | 44 | |
| 2000 | 100 | 80 | 80 | 80 | 80 | 57 | 44 | 27 | 44 | 44 | |
| 2400 | 100 | 80 | 80 | 80 | 80 | 57 | 31 | 36 | 36 | 36 | |
| 2800 | 80 | 80 | 80 | 80 | 57 | 44 | 44 | 36 | 36 | 36 | |
| 3200 | 80 | 80 | 57 | 57 | 44 | 36 | 36 | 36 | 36 | 36 | |
| 3600 | 57 | 57 | 57 | 44 | 44 | 44 | 44 | 44 | 44 | 44 | |
| 4000 | 57 | 57 | 57 | 36 | 36 | 36 | 44 | 44 | 44 | 44 | |
| 4400 | 44 | 44 | 44 | 44 | 44 | 44 | 44 | 44 | 44 | 44 | |
| 4800 | 44 | 44 | 44 | 36 | 36 | 36 | 36 | 36 | 36 | 36 | |
| 5200 | 36 | 36 | 36 | 36 | 36 | 36 | 36 | 44 | 44 | 44 | |
| 5600 | 27 | 27 | 27 | 31 | 36 | 36 | 36 | 44 | 44 | 44 | |
| 6000 | 44 | 44 | 44 | 44 | 44 | 44 | 44 | 44 | 36 | 36 | |
| 6400 | 24 | 24 | 24 | 21 | 21 | 21 | 25 | 31 | 31 | 31 | |
ENABLE CONDITIONS - MAP 3
Time Needed for Diagnosis: 200 engine revs.
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
| Malfunction Criteria | Threshold Value |
|---|---|
| Catalyst damage misfire diagnostic value | < Value of Map 3 |
JUDGMENT VALUE
Time Needed for Diagnosis: 200 engine revs.
Note. For the detection standard, refer to DTC P0301. < Refer to DTC P0301 CYLINDER 1 MISFIRE DETECTED , Diagnostic Trouble Code (DTC) Detecting Criteria. >
Note. For the detection standard, refer to DTC P0301. < Refer to DTC P0301 CYLINDER 1 MISFIRE DETECTED , Diagnostic Trouble Code (DTC) Detecting Criteria. >
Note. For the detection standard, refer to DTC P0301. < Refer to DTC P0301 CYLINDER 1 MISFIRE DETECTED , Diagnostic Trouble Code (DTC) Detecting Criteria. >
Detect the open or short circuit of knock sensor.
Judge as NG if out of specification.
Scheme 54
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | < 0.243 V |
JUDGMENT VALUE
Time Needed for Diagnosis: 1000 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | > or = 0.243 V |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
Detect the open or short circuit of knock sensor.
Judge as NG if out of specification.
Scheme 55
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | > or = 4.709 V |
JUDGMENT VALUE
Time Needed for Diagnosis: 1000 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | < 4.709 V |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
Detect the open or short circuit of the crankshaft position sensor.
Judge as NG when the crank signal is not input even though the starter was rotated.
Scheme 56
Scheme 57
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
| Malfunction Criteria | Threshold Value |
|---|---|
| Starter switch | ON |
| Crankshaft position sensor signal | Not detected |
| Battery voltage | > or = 8 V |
JUDGMENT VALUE
Time Needed for Diagnosis: 3000 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
| Malfunction Criteria | Threshold Value |
|---|---|
| Crankshaft position sensor signal | Input exists |
| Battery voltage | > or = 8 V |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
Detect for faults in crankshaft position sensor output properties.
Judge as NG when there is a problem in the number of crankshaft signals for every revolution of crankshaft.
Scheme 58
Scheme 59
- Abnormality Judgment
Judge as NG when the following conditions are established.
| Malfunction Criteria | Threshold Value |
|---|---|
| Cylinder number identification | Completed |
| Amount of crank sensor signal during 1 rev of crankshaft. | Not = 30 |
JUDGMENT VALUE
Time Needed for Diagnosis: 10 engine revs. engine revs.
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
| Malfunction Criteria | Threshold Value |
|---|---|
| Cylinder number identification | Completed |
| Amount of crank sensor signal during 1 rev of crankshaft. | = 30 |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
Detect the open or short circuit of the camshaft position sensor.
When there is no camshaft position signal input continuously, judge as NG.
Scheme 60
- Abnormality Judgment
Diagnosis 1
Judge as NG when no input of camshaft position sensor signal in TDC remains for 14 time(s).
| Malfunction Criteria | Threshold Value |
|---|---|
| No camshaft position sensor signal input in TDC | > or = 14 time(s) |
JUDGMENT VALUE
Time Needed for Diagnosis: TDC x 14 time(s)
Diagnosis 2
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
| Malfunction Criteria | Threshold Value |
|---|---|
| Camshaft position sensor signal | No input |
JUDGMENT VALUE
Time Needed for Diagnosis: 3000 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG when the malfunction criteria below are met.
| Malfunction Criteria | Threshold Value |
|---|---|
| No camshaft position sensor signal input in TDC | = 0 time(s) |
JUDGMENT VALUE
Time Needed for Diagnosis: TDC x 14 time(s)
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
| Malfunction Criteria | Threshold Value |
|---|---|
| Camshaft position sensor signal | Input exists |
JUDGMENT VALUE
Time Needed for Diagnosis: 32 ms
Detect the malfunction of camshaft position sensor property.
Judge as NG when the number of camshaft signals remains abnormal.
Scheme 61
- Abnormality Judgment
Judge as NG when the status where the number of camshaft position sensor signal in two crankshaft revolutions is other than 3 time(s).
| Malfunction Criteria | Threshold Value |
|---|---|
| Amount of camshaft sensor signal during 2 revs of crankshaft. | 3 time(s) |
JUDGMENT VALUE
Time Needed for Diagnosis: Two engine revs. x 4 time(s)
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG when the malfunction criteria below are met.
| Malfunction Criteria | Threshold Value |
|---|---|
| Camshaft position sensor signal | = 3 time(s) |
JUDGMENT VALUE
Time Needed for Diagnosis: Two engine revs.
Note. For the detection standard, refer to DTC P0340. < Refer to DTC P0340 CAMSHAFT POSITION SENSOR "A" CIRCUIT (BANK 1 OR SINGLE SENSOR) , Diagnostic Trouble Code (DTC) Detecting Criteria. >
Note. For the detection standard, refer to DTC P0341. < Refer to DTC P0341 CAMSHAFT POSITION SENSOR "A" CIRCUIT RANGE/PERFORMANCE (BANK 1 OR SINGLE SENSOR) , Diagnostic Trouble Code (DTC) Detecting Criteria. >
Based on the self-diagnostic result of the ignition coil driving IC, judge the ignition coil driving circuit as normal or abnormal.
The ignition coil driving IC detects "no ignition" status as a malfunction.
- Abnormality Judgment
Judge as NG when the following conditions are established.
| Malfunction Criteria | Threshold Value |
|---|---|
| Ignition driving IC information | Malfunction |
JUDGMENT VALUE
Time Needed for Diagnosis: 2500 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the following conditions are established.
| Malfunction Criteria | Threshold Value |
|---|---|
| Ignition driving IC information | Normal |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
Note. For the detection standard, refer to DTC P0351. < Refer to DTC P0351 IGNITION COIL A PRIMARY/SECONDARY CIRCUIT , Diagnostic Trouble Code (DTC) Detecting Criteria. >
Note. For the detection standard, refer to DTC P0351. < Refer to DTC P0351 IGNITION COIL A PRIMARY/SECONDARY CIRCUIT , Diagnostic Trouble Code (DTC) Detecting Criteria. >
Note. For the detection standard, refer to DTC P0351. < Refer to DTC P0351 IGNITION COIL A PRIMARY/SECONDARY CIRCUIT , Diagnostic Trouble Code (DTC) Detecting Criteria. >
Detect the open or short circuit of the camshaft position sensor.
When there is no camshaft position signal input continuously, judge as NG.
Scheme 62
- Abnormality Judgment
Judge as NG when no input of camshaft position sensor signal in TDC remains for 15 time(s).
| Malfunction Criteria | Threshold Value |
|---|---|
| No camshaft position sensor signal input in TDC | > or = 15 time(s) |
JUDGMENT VALUE
Time Needed for Diagnosis: TDC x 15 time(s)
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG when the malfunction criteria below are met.
| Malfunction Criteria | Threshold Value |
|---|---|
| No camshaft position sensor signal input in TDC | = 0 time(s) |
JUDGMENT VALUE
Time Needed for Diagnosis: Two engine revs.
Detect the malfunction of camshaft position sensor property.
Judge as NG when the number of camshaft signals remains abnormal.
Scheme 63
- Abnormality Judgment
Judge as NG when the status where the number of camshaft position sensor signal in two crankshaft revolutions is other than 2 time(s).
| Malfunction Criteria | Threshold Value |
|---|---|
| Amount of camshaft sensor signal during 2 revs of crankshaft. | 2 time(s) |
JUDGMENT VALUE
Time Needed for Diagnosis: Two engine revs. x 4 time(s)
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG when the malfunction criteria below are met.
| Malfunction Criteria | Threshold Value |
|---|---|
| Camshaft position sensor signal | = 2 time(s) |
JUDGMENT VALUE
Time Needed for Diagnosis: Two engine revs.
Note. For the detection standard, refer to DTC P0365. < Refer to DTC P0365 CAMSHAFT POSITION SENSOR "B" CIRCUIT (BANK 1) , Diagnostic Trouble Code (DTC) Detecting Criteria. >
Note. For the detection standard, refer to DTC P0366. < Refer to DTC P0366 CAMSHAFT POSITION SENSOR B CIRCUIT RANGE/PERFORMANCE (BANK 1) , Diagnostic Trouble Code (DTC) Detecting Criteria. >
Detect EGR system malfunction.
Intake manifold pressure (negative pressure) is constant because the throttle valve is fully closed during deceleration fuel cut. At this time, when the EGR valve is opened/closed, the intake manifold pressure will change. EGR System OK/NG is judged by the range of this change.
Scheme 64
Measure the pressure values when the enable conditions are established, and perform diagnosis by calculating those results.
- Label the intake manifold pressure value as PMOF1, which is observed when enable conditions are established, and set the EGR target step to 45 step(s) (nearly full open).
- Label the intake manifold pressure value as PMON, which is observed after 1000 ms has passed since EGR target step was set to 45 step(s) (when the enable conditions were established), and set the EGR target step to 0.
- Label the intake manifold pressure as PMOF2, which is observed after 1000 ms has passed since EGR target step was set to 0 (after (1000 ms + 1000 ms) have passed since the enable conditions were established).
- Abnormality Judgment
Judge as NG when the following conditions are established.
| Malfunction Criteria | Threshold Value |
|---|---|
| PMON - (PMOF1 + PMOF2)/2 | < 2.5 kPa (18.63 mmHg, 0.7 inHg) |
JUDGMENT VALUE
Time Needed for Diagnosis: 1 time
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
Scheme 65
- Normality Judgment
Judge as OK and clear the NG if the following conditions are established.
| Malfunction Criteria | Threshold Value |
|---|---|
| PMON - (PMOF1 + PMOF2)/2 | > or = 2.5 kPa (18.63 mmHg, 0.7 inHg) |
JUDGMENT VALUE
Time Needed for Diagnosis: 1 time
Detect the deterioration of the catalyst function.
Though the front oxygen sensor output would change slowly with a new catalyst, the sensor output with a deteriorated catalyst becomes high and the inversion time is shortened.
For this reason, the catalyst diagnosis is carried out by monitoring the front oxygen sensor output and comparing it with the front oxygen (A/F) sensor output.
Scheme 66
After the enable conditions have been established, calculate the front oxygen (A/F) sensor lambda value deviation sum value (Sum |(sglmdn - sglmdn-1)|), and rear oxygen sensor output voltage deviation sum value (Sum |(ro2sad n - ro2sad n-1 )|) in every 32 ms x 4 times. If the front oxygen (A/F) sensor lambda value deviation sum value (Sum |(sglmdn - sglmdn-1)|) is the predetermined value or more, calculate the diagnostic value.
- Abnormality Judgment
If the duration of time while the following conditions are met is within the time indicated, judge as NG.
| Malfunction Criteria | Threshold Value |
|---|---|
| Sum |(ro2sad n - ro2sad n-1 )| / Sum |(sglmdn - sglmdn-1) | > 8 |
JUDGMENT VALUE
Time Needed for Diagnosis: 30 - 55 seconds
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is within the predetermined time.
| Malfunction Criteria | Threshold Value |
|---|---|
| Sum |(ro2sad n - ro2sad n-1 )| / Sum |(sglmdn - sglmdn-1) | < or = 8 |
JUDGMENT VALUE
Time Needed for Diagnosis: 30 - 55 seconds
Detect the malfunction of purge flow by the change of ELCM pressure sensor output value before/after purge introduction.
First diagnosis
Pressure decreases when the purge is introduced compared with when the purge is not performed. By using this, judge if the purge is correctly performed. If there is no pressure decrease, go to the SECOND DIAGNOSIS .
Scheme 67
- Abnormality Judgment
Judge as NG when the following conditions are established.
| Malfunction Criteria | Threshold Value |
|---|---|
| ELCM pressure sensor output voltage when purge is not performed - ELCM pressure sensor output voltage when purge is performed | > 0.0045 V |
| The accumulated time while the above conditions are met: cpfokt | < 2000 ms |
JUDGMENT VALUE
Time Needed for Diagnosis: 26 seconds
- Normality Judgment
Judge as OK and clear the NG if the following conditions are established.
| Malfunction Criteria | Threshold Value |
|---|---|
| ELCM pressure sensor output voltage when purge is not performed - ELCM pressure sensor output voltage when purge is performed | > 0.0045 V |
| The accumulated time while the above conditions are met: cpfokt | > or = 2000 ms |
JUDGMENT VALUE
Time Needed for Diagnosis: 26 seconds
Second diagnosis
Close the ELCM switching valve, and close the fuel tank completely, and perform the forced purging. If pressure change amount is 0.7 kPa (5 mmHg, 0.2 inHg) or less, judge as malfunction of purge flow.
Scheme 68
- Abnormality Judgment
Judge as NG when the following conditions are established.
| Malfunction Criteria | Threshold Value |
|---|---|
| ELCM pressure sensor output voltage when purge is not performed - ELCM pressure sensor output voltage when purge is performed | < 0.7 kPa (5 mmHg, 0.2 inHg) |
| Time of negative pressure introduction | > or = 30000 ms |
JUDGMENT VALUE
Time Needed for Diagnosis: 21 seconds
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judge as OK and clear the NG if the following conditions are established.
| Malfunction Criteria | Threshold Value |
|---|---|
| ELCM pressure sensor output voltage when purge is not performed - ELCM pressure sensor output voltage when purge is performed | > or = 0.7 kPa (5 mmHg, 0.2 inHg) |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 21 seconds
Detect the malfunction of ELCM pressure sensor output properties.
Judge as NG when the ELCM pressure sensor output value is largely different from the intake manifold pressure when the ignition switch is ON.
Scheme 69
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
| Malfunction Criteria | Threshold Value |
|---|---|
| ELCM pressure sensor output value - intake manifold pressure (absolute pressure) when ignition switch is ON | > 4.3 kPa (32 mmHg, 1.3 inHg) |
JUDGMENT VALUE
Time Needed for Diagnosis: 328 ms
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
| Malfunction Criteria | Threshold Value |
|---|---|
| ELCM pressure sensor output value - intake manifold pressure (absolute pressure) when ignition switch is ON | < or = 4.3 kPa (32 mmHg, 1.3 inHg) |
JUDGMENT VALUE
Time Needed for Diagnosis: 262 ms
Detect the open or short circuit of the ELCM pressure sensor.
Judge as NG if out of specification.
Scheme 70
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | < 0.973 V |
JUDGMENT VALUE
Time Needed for Diagnosis: 1000 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | > or = 0.973 V |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
Detect the open or short circuit of the ELCM pressure sensor.
Judge as NG if out of specification.
Scheme 71
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | > or = 4.095 V |
JUDGMENT VALUE
Time Needed for Diagnosis: 1000 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | < 4.095 V |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
This diagnosis judges whether the ELCM operation is normal or not, and whether the evaporative emission system has leak and clogging or not.
To purge the canister, after driving, perform the five hours soaking after ignition switch OFF in order to stabilize the evaporative gas status. * After 5, 7 or 9.5 hours passed, ECM is activated by soaking timer, and the leak check is started.
Judges whether the ELCM operation is normal or not, by measuring the reference pressure status via reference orifice (0.02 inch orifice). Judge as malfunction if the reference pressure is out of specified range. Then, judge whether there is a leak or not, by comparing the pressure (leak pressure) when the reference pressure and the evaporative emission system are in negative pressure condition. Judge as system leak in the evaporative emission system if the leak pressure is higher than reference pressure. Judge as clogging of pipe if the leak pressure becomes lower than the reference pressure within the specified amount of time. 0.02 inch leak and 0.04 inch leak can be distinguished by measuring the leak pressure.
The diagnosis results are stored inside ECM until the engine is started again.
*: When the test conditions are not met in 5 hours, perform diagnosis at elapsed time of 7 hours. When the test conditions are not met in 7 hours, perform diagnosis at elapsed time of 9.5 hours.
| Diagnostic item | |
|---|---|
| ELCM system (ELCM body) | Vacuum pump stuck Switching valve stuck to open Switching valve stuck to close Reference orifice flow large Reference orifice flow small |
| Leak check | Large leak 0.04 inch leak Fuel cap loose Fuel cap off System malfunction |
| Very small leak 0.02 inch leak | |
| Clogging of pipe | |
Scheme 72
Note. For the detection standard, refer to DTC P0455. < Refer to DTC P0455 EVAPORATIVE EMISSION SYSTEM LEAK DETECTED (LARGE LEAK) , Diagnostic Trouble Code (DTC) Detecting Criteria. >
Detect open or short circuit of the purge control solenoid valve.
Judge as NG when the ECM output level differs from the actual terminal level.
Scheme 73
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
| Malfunction Criteria | Threshold Value |
|---|---|
| Duty ratio of "ON" | < 0.75 |
| Terminal output voltage | Low |
JUDGMENT VALUE
Time Needed for Diagnosis: 2500 ms
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
| Malfunction Criteria | Threshold Value |
|---|---|
| Terminal output voltage | High |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
Detect open or short circuit of the purge control solenoid valve.
Judge as NG when the ECM output level differs from the actual terminal level.
Scheme 74
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
| Malfunction Criteria | Threshold Value |
|---|---|
| Duty ratio of "ON" | > or = 0.25 |
| Terminal output voltage | High |
JUDGMENT VALUE
Time Needed for Diagnosis: 2500 ms
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Time Needed for Diagnosis: Less than 1 second
| Malfunction Criteria | Threshold Value |
|---|---|
| Terminal output voltage | Low |
JUDGMENT VALUE
Detect malfunctions of the fuel level sensor output property.
If the fuel level does not vary in a particular driving condition / engine condition where it should, judge as NG.
Scheme 75
- Abnormality Judgment
Judge as NG when the following conditions are established.
| Malfunction Criteria | Threshold Value |
|---|---|
| Accumulated amount of intake air | > or = 165375 g (5832.78 oz) |
| Max. - min. values of fuel level output | < 2.6 2 (0.69 US gal, 0.57 Imp gal) |
| Battery voltage | > or = 10.9 V |
| Engine speed | < 10000 rpm |
| Elapsed time after starting the engine | > or = 5000 ms |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judge as OK and clear the NG if the following conditions are established.
| Malfunction Criteria | Threshold Value |
|---|---|
| Accumulated amount of intake air | > or = 165375 g (5832.78 oz) |
| Max. - min. values of fuel level output | > or = 2.6 2 (0.69 US gal, 0.57 Imp gal) |
| Battery voltage | > or = 10.9 V |
| Engine speed | < 10000 rpm |
| Elapsed time after starting the engine | > or = 5000 ms |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
Detect the open or short circuit of fuel level sensor. Judge as NG if out of specification.
Scheme 76
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
| Malfunction Criteria | Threshold Value |
|---|---|
| Battery voltage | > or = 10.9 V |
| Elapsed time after starting the engine | > or = 3000 ms |
| Output voltage | < 0.383 V |
JUDGMENT VALUE
Time Needed for Diagnosis: 2500 ms
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
| Malfunction Criteria | Threshold Value |
|---|---|
| Battery voltage | > or = 10.9 V |
| Elapsed time after starting the engine | > or = 3000 ms |
| Output voltage | > or = 0.383 V |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
Detect the open or short circuit of fuel level sensor. Judge as NG if out of specification.
Scheme 77
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
| Malfunction Criteria | Threshold Value |
|---|---|
| Battery voltage | > or = 10.9 V |
| Elapsed time after starting the engine | > or = 3000 ms |
| Output voltage | > or = 6.632 V |
JUDGMENT VALUE
Time Needed for Diagnosis: 1000 ms
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
| Malfunction Criteria | Threshold Value |
|---|---|
| Battery voltage | > or = 10.9 V |
| Elapsed time after starting the engine | > or = 3000 ms |
| Output voltage | < 6.632 V |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
Judge as NG when outside of the judgment value.
Judge NG when the received data from VDCCM&H/U is abnormal vehicle speed, and the vehicle speed data is impossible.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
| Malfunction Criteria | Threshold Value |
|---|---|
| Front ABS wheel speed sensor status | Malfunction |
| Either of the following is established | |
| Front left wheel speed | > or = 300 km/h (186.4 MPH) |
| Front right wheel speed | > or = 300 km/h (186.4 MPH) |
JUDGMENT VALUE
Time Needed for Diagnosis: 2500 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
| Malfunction Criteria | Threshold Value |
|---|---|
| Front left wheel speed | > 0 km/h (0 MPH) |
| And | |
| < 300 km/h (186.4 MPH) | |
| Front right wheel speed | > 0 km/h (0 MPH) |
| And | |
| < 300 km/h (186.4 MPH) |
JUDGMENT VALUE
Time Needed for Diagnosis: 2500 ms
Detect the malfunction that actual engine speed is not close to target engine speed during idling. Judge as NG when actual engine speed is not close to target engine speed during idling.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
| Malfunction Criteria | Threshold Value |
|---|---|
| Actual engine speed - Targeted engine speed | < -100 rpm |
| Feedback compensation for ISC | Max. |
JUDGMENT VALUE
Time Needed for Diagnosis: 10 s x 3 time(s)
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
| Malfunction Criteria | Threshold Value |
|---|---|
| Actual engine speed - Targeted engine speed | > or = -100 rpm |
JUDGMENT VALUE
Time Needed for Diagnosis: 10 s
Detect the malfunction that actual engine speed is not close to target engine speed during idling. Judge as NG when actual engine speed is not close to target engine speed during idling.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
| Malfunction Criteria | Threshold Value |
|---|---|
| Actual - Target engine speed | > or = 200 rpm |
| Feedback compensation for ISC | Min. |
JUDGMENT VALUE
Time Needed for Diagnosis: 10 s x 3 time(s)
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
| Malfunction Criteria | Threshold Value |
|---|---|
| Actual - Target engine speed | < 200 rpm |
JUDGMENT VALUE
Time Needed for Diagnosis: 10 s
- When cold, the abnormality in the control of target engine speed increase is detected. (P050A)
Judge as NG if the exhaust gas temperature diagnosis or idle speed diagnosis is NG.
- Exhaust gas temperature diagnosis
Judge as NG when the estimated exhausted gas temperature in 14 seconds after the cold start is below the specified value.
- Idle speed diagnosis
Judge as NG when actual engine speed is not close to target engine speed at cold start.
- Detect malfunctions of the catalyst advanced idling retard angle control. (P050B)
Judge as NG when ECM is not controlling the angle properly during catalyst advanced idling retard angle control.
- Final ignition timing diagnosis
Judge as NG when actual retard amount is under the specified value at cold start.
- Exhaust gas temperature diagnosis
Note. For the detection standard, refer to DTC P050A. < Refer to DTC P050A COLD START IDLE AIR CONTROL SYSTEM PERFORMANCE , Diagnostic Trouble Code (DTC) Detecting Criteria. >
| DTC | Item | Outline of Diagnosis |
|---|---|---|
| P0513 | Incorrect Immobilizer Key | Incorrect immobilizer key (Use of unregistered key in body integrated unit) |
| P1570 | Antenna | Faulty antenna |
| P1571 | Reference Code Incompatibility | Reference code incompatibility between body integrated unit and ECM |
| P1572 | IMM Circuit Failure (Except Antenna Circuit) | Communication failure between body integrated unit and ECM |
| P1574 | Key Communication Failure | Failure of body integrated unit to verify key (transponder) ID code or transponder failure |
| P1576 | EGI Control Module EEPROM | ECM malfunctioning |
| P1577 | IMM Control Module EEPROM | Body integrated unit malfunctioning |
| P1578 | Meter Failure | Reference code incompatibility between body integrated unit and combination meter |
Judge as NG when the conditions for the outline of the diagnosis of the top are established.
Detect the open or short circuit of battery temperature sensor.
Judge as NG if out of specification.
Scheme 78
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | < 0.136 V |
JUDGMENT VALUE
Time Needed for Diagnosis: 500 ms
Malfunction Indicator Light Illumination: Does not illuminate even when malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the following conditions are established.
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | > or = 0.136 V |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
Detect the open or short circuit of battery temperature sensor.
Judge as NG if out of specification.
Scheme 79
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | > or = 4.671 V |
JUDGMENT VALUE
Time Needed for Diagnosis: 500 ms
Malfunction Indicator Light Illumination: Does not illuminate even when malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the following conditions are established.
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | < 4.671 V |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
Detect the open/short circuit of back-up power supply circuit.
Judge as NG when the backup power voltage is low.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
| Malfunction Criteria | Threshold Value |
|---|---|
| Voltage of back-up power supply | Low |
| Battery voltage | > or = 10.9 V |
| Engine condition | After engine starting |
JUDGMENT VALUE
Time Needed for Diagnosis: 2500 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
| Malfunction Criteria | Threshold Value |
|---|---|
| Voltage of back-up power supply | High |
| Battery voltage | > or = 10.9 V |
| Engine condition | After engine starting |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
Detect the malfunction of microcomputer (RAM).
When there is a problem in the CPU normal RAM, judge as NG.
If it is possible to write data to the whole area of RAM in the initial routine, and is possible to read the same data, it is judged as OK, and if not, NG.
- Abnormality Judgment
Judge as NG when the following conditions are established.
| Malfunction Criteria | Threshold Value |
|---|---|
| Write the specified value to RAM and then read. | The written value cannot be read. |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the following conditions are established.
| Malfunction Criteria | Threshold Value |
|---|---|
| Write the specified value to RAM and then read. | The written value can be read. |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
Judge as NG when SUM value of ROM is outside the standard value.
Judge as NG when any one of the followings is established.
- If the CPU operation is abnormal (instruction/flow check).
- If the output IC operation is abnormal (output driver malfunction).
Scheme 80
Judge as OK and clear the NG when the malfunction criteria below are met.
| Malfunction Criteria | Threshold Value |
|---|---|
| (1) Main CPU calculation result | The result and expected value match. |
| (2) Communication between output ICs | Possible to communicate |
JUDGMENT VALUE
Time Needed for Diagnosis
- 192 ms
- 2500 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
Judge as NG when the monitoring IC operation is abnormal. (Monitoring IC malfunction)
Scheme 81
Judge as OK and clear the NG when the malfunction criteria below are met.
| Malfunction Criteria | Threshold Value |
|---|---|
| Monitoring IC operation | The result and expected value match. |
JUDGMENT VALUE
Time Needed for Diagnosis: 200 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
Judge as NG when any one of the followings is established.
- If the input amplifier circuit of throttle position sensor 1 is abnormal (quadruple amplification problem).
- If the A/D converter operation is abnormal (ADC malfunction).
Scheme 82
Judge as OK and clear the NG when the malfunction criteria below are met.
| Malfunction Criteria | Threshold Value |
|---|---|
| (1) |Throttle position sensor 1 opening angle - (Throttle position sensor 1 opening angle after passing amplifier/4) | < 3 ° |
| (2) |Standard voltage - Readings of voltage value | < 0.078125 V |
JUDGMENT VALUE
Time Needed for Diagnosis
- 24 ms
- 200 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
Detect abnormal continuity in the starter SW.
Judge as OFF NG when the starter SW signal remains OFF.
- Abnormality Judgment
Judge as OFF NG when the following conditions are established.
| Malfunction Criteria | Threshold Value |
|---|---|
| Battery voltage | > or = 8 V |
| Vehicle speed | < 1 km/h (0.6 MPH) |
| Engine condition | Change from pre-start to post-start |
| Starter SW signal | No ON experience |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OFF OK and clear the NG if the following conditions are established.
| Malfunction Criteria | Threshold Value |
|---|---|
| Battery voltage | > or = 8 V |
| Vehicle speed | < 1 km/h (0.6 MPH) |
| Engine condition | Change from pre-start to post-start |
| Starter SW signal | ON Experience exists |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
Detect abnormal continuity in the starter SW.
Judge as ON NG when the starter SW signal remains ON.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
| Malfunction Criteria | Threshold Value |
|---|---|
| Battery voltage | > or = 8 V |
| Engine condition | After engine starting |
| Starter SW signal | ON |
JUDGMENT VALUE
Time Needed for Diagnosis: 30000 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
| Malfunction Criteria | Threshold Value |
|---|---|
| Battery voltage | > or = 8 V |
| Starter SW signal | OFF |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
Judge as NG when the EEPROM operation is abnormal. (EEPROM malfunction)
Scheme 83
Judge as OK and clear the NG when the malfunction criteria below are met.
| Malfunction Criteria | Threshold Value |
|---|---|
| EEPROM writing | Writing completed |
JUDGMENT VALUE
Time Needed for Diagnosis: 48 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
Judge as NG when there is CAN communication with the TCM and there is a MIL lighting request.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
| Malfunction Criteria | Threshold Value |
|---|---|
| Battery voltage | > or = 10.9 V |
| MIL lighting request from TCM | Yes |
JUDGMENT VALUE
Time Needed for Diagnosis: 2500 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
| Malfunction Criteria | Threshold Value |
|---|---|
| Battery voltage | > or = 10.9 V |
| MIL lighting request from TCM | None |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
Detect the open or short circuit of neutral SW.
Judge as NG when the ECM neutral terminal input differs from the reception data from TCM.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
| Malfunction Criteria | Threshold Value |
|---|---|
| Neutral switch signal in ECM when "P"/"N" range in TCM are "OFF" and when the other switches are "ON" | LOW (ON) |
JUDGMENT VALUE
Time Needed for Diagnosis: 100 time(s)
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
| Malfunction Criteria | Threshold Value |
|---|---|
| Neutral switch signal in ECM when "P"/"N" range in TCM are "OFF" and when the other switches are "ON" | HIGH (OFF) |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
Detect the open or short circuit of neutral SW.
Judge as NG when there is no change in the neutral SW even if the driving shift was applied. (There is neutral SW ON/OFF inversion from the vehicle speed and engine speed.)
- Abnormality Judgment
Judge NG when the malfunction criteria below are completed determined times or more after the neutral SW change.
| Malfunction Criteria | Threshold Value |
|---|---|
| Neutral switch signal (while changing from a to b below) | LOW (ON) continues. |
| Driving condition change | From a) to b) |
| Engine speed 500 rpm - 900 rpm & Vehicle speed = 0 km/h (0 MPH) Engine speed 1700 rpm - 2200 rpm & Vehicle speed > or = 64 km/h (39.8 MPH) |
JUDGMENT VALUE
Time Needed for Diagnosis: 3 time(s)
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judge as OK and clear NG when there is change in the neutral SW.
| Malfunction Criteria | Threshold Value |
|---|---|
| Neutral switch signal (while changing from a to b below) | Changes to HIGH (OFF). |
| Driving condition change | From a) to b) |
| Engine speed 500 rpm - 900 rpm & Vehicle speed = 0 km/h (0 MPH) Engine speed 1700 rpm - 2200 rpm & Vehicle speed > or = 64 km/h (39.8 MPH) |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
Detect the open or short circuit of neutral SW.
Judge as NG when the ECM neutral terminal input differs from the reception data from TCM.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
| Malfunction Criteria | Threshold Value |
|---|---|
| Neutral switch signal in ECM when "P"/"N" range in TCM are "ON" and when the other switches are "OFF" | HIGH (OFF) |
JUDGMENT VALUE
Time Needed for Diagnosis: 100 time(s)
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
| Malfunction Criteria | Threshold Value |
|---|---|
| Neutral switch signal in ECM when "P"/"N" range in TCM are "ON" and when the other switches are "OFF" | LOW (ON) |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
Detect the open or short circuit of neutral SW.
Judge as NG when there is no change in the neutral SW even if the driving shift was applied. (There is neutral SW ON/OFF inversion from the vehicle speed and engine speed.)
- Abnormality Judgment
Judge NG when the malfunction criteria below are completed determined times or more after the neutral SW change.
| Malfunction Criteria | Threshold Value |
|---|---|
| Neutral switch signal (while changing from a to b below) | HIGH (OFF) continues. |
| Driving condition change | From a) to b) |
| Engine speed 500 rpm - 900 rpm & Vehicle speed = 0 km/h (0 MPH) Engine speed 1700 rpm - 2200 rpm & Vehicle speed > or = 64 km/h (39.8 MPH) |
JUDGMENT VALUE
Time Needed for Diagnosis: 3 time(s)
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judge as OK and clear NG when there is change in the neutral SW.
| Malfunction Criteria | Threshold Value |
|---|---|
| Neutral switch signal (while changing from a to b below) | Changes to LOW (ON). |
| Driving condition change | From a) to b) |
| Engine speed 500 rpm - 900 rpm & Vehicle speed = 0 km/h (0 MPH) Engine speed 1700 rpm - 2200 rpm & Vehicle speed > or = 64 km/h (39.8 MPH) |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
Judge as NG when the valve is opened more than the default opening angle, but does not move to the close direction with the motor power stopped.
Scheme 84
- Abnormality Judgment
Judge as NG when the following conditions are established.
| Malfunction Criteria | Threshold Value |
|---|---|
| Opening variation after continuity is set to OFF | < 2 ° |
JUDGMENT VALUE
Time Needed for Diagnosis: 24 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the following conditions are established.
| Malfunction Criteria | Threshold Value |
|---|---|
| Opening variation after continuity is set to OFF | > or = 2 ° |
JUDGMENT VALUE
Time Needed for Diagnosis: 3400 ms
Detect the drain filter clogging by the pressure change during purge introduction.
Judge as drain filter clogging malfunction if the pressure in the evaporative emission system piping suddenly decreases by the purging.
Scheme 85
Note. For the detection standard, refer to DTC P0455. < Refer to DTC P0455 EVAPORATIVE EMISSION SYSTEM LEAK DETECTED (LARGE LEAK) , Diagnostic Trouble Code (DTC) Detecting Criteria. >
- Detects open or short circuit of EGR.
- Judge as NG when the ECM output level differs from the actual terminal level.
Scheme 86
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
| Malfunction Criteria | Threshold Value |
|---|---|
| Terminal voltage level when ECM outputs OFF signal | Low level |
| Or | |
| Terminal voltage level when EGR operates | Low level |
JUDGMENT VALUE
Time Needed for Diagnosis: 2500 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
| Malfunction Criteria | Threshold Value |
|---|---|
| Terminal voltage level when ECM outputs OFF signal | High level |
| Terminal voltage level when EGR operates | High level |
JUDGMENT VALUE
Time Needed for Diagnosis: 256 ms
- Detects open or short circuit of EGR.
- Judge as NG when the ECM output level differs from the actual terminal level.
Scheme 87
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
| Malfunction Criteria | Threshold Value |
|---|---|
| Terminal voltage level when ECM outputs ON signal | High level |
| Or | |
| Terminal voltage level when EGR operates | High level |
JUDGMENT VALUE
Time Needed for Diagnosis: 2500 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
| Malfunction Criteria | Threshold Value |
|---|---|
| Terminal voltage level when ECM outputs ON signal | Low level |
| Terminal voltage level when EGR operates | Low level |
JUDGMENT VALUE
Time Needed for Diagnosis: 256 ms
Note. For the detection standard, refer to DTC P1492. < Refer to DTC P1492 EGR SOLENOID VALVE SIGNAL #1 CIRCUIT MALFUNCTION (LOW INPUT) , Diagnostic Trouble Code (DTC) Detecting Criteria. >
Note. For the detection standard, refer to DTC P1493. < Refer to DTC P1493 EGR SOLENOID VALVE SIGNAL #1 CIRCUIT MALFUNCTION (HIGH INPUT) , Diagnostic Trouble Code (DTC) Detecting Criteria. >
Note. For the detection standard, refer to DTC P1492. < Refer to DTC P1492 EGR SOLENOID VALVE SIGNAL #1 CIRCUIT MALFUNCTION (LOW INPUT) , Diagnostic Trouble Code (DTC) Detecting Criteria. >
Note. For the detection standard, refer to DTC P1493. < Refer to DTC P1493 EGR SOLENOID VALVE SIGNAL #1 CIRCUIT MALFUNCTION (HIGH INPUT) , Diagnostic Trouble Code (DTC) Detecting Criteria. >
Note. For the detection standard, refer to DTC P1492. < Refer to DTC P1492 EGR SOLENOID VALVE SIGNAL #1 CIRCUIT MALFUNCTION (LOW INPUT) , Diagnostic Trouble Code (DTC) Detecting Criteria. >
Note. For the detection standard, refer to DTC P1493. < Refer to DTC P1493 EGR SOLENOID VALVE SIGNAL #1 CIRCUIT MALFUNCTION (HIGH INPUT) , Diagnostic Trouble Code (DTC) Detecting Criteria. >
Detect the open or short circuit of battery current sensor.
Judge as NG if out of specification.
Scheme 88
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | < 0.22 V |
JUDGMENT VALUE
Time Needed for Diagnosis: 500 ms
Malfunction Indicator Light Illumination: Does not illuminate even when malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the following conditions are established.
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | > or = 0.22 V |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
Detect the open or short circuit of battery current sensor.
Judge as NG if out of specification.
Scheme 89
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | > or = 4.722 |
JUDGMENT VALUE
Time Needed for Diagnosis: 500 ms
Malfunction Indicator Light Illumination: Does not illuminate even when malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the following conditions are established.
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | < 4.722 V |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
Detect the output property and malfunction of battery current sensor.
Judge as NG when there is no variation (stuck) under a condition where the battery current sensor output should have changed or when difference between output and battery current value is larger than expected (characteristics malfunction).
Scheme 90
- Abnormality Judgment
- Stuck
Judge as NG when the following conditions are repeated 10 time(s) or more.
| Malfunction Criteria | Threshold Value |
|---|---|
| Difference between maximum value and minimum value in output voltage | < 0.07 V |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
Malfunction Indicator Light Illumination: Does not illuminate even when malfunction occurs.
- Characteristics malfunction (Charge side)
Within 30000 ms from "enable condition not met" to "enable condition met", judge as NG when the time required for meeting the following conditions exceeds the predetermined time.
(When NG judgment is performed, NG status is retained during that driving cycle.)
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | 2.6 V < or = Output voltage < 5 V |
| And | |
| Battery voltage | < 13.2 V |
JUDGMENT VALUE
Time Needed for Diagnosis: 26000 ms
Malfunction Indicator Light Illumination: Does not illuminate even when malfunction occurs.
- Characteristics malfunction (Discharge side)
Within 30000 ms from "enable condition not met" to "enable condition met", judge as NG when the time required for meeting the following conditions exceeds the predetermined time.
(Within 30000 ms from "enable condition not met" to "enable condition met", the target duty > or = 60 % has not been experienced.)
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | 0 V > or = Output voltage < 2.4 V |
| And | |
| Battery voltage | > or = 13.7 V |
JUDGMENT VALUE
Time Needed for Diagnosis: 26000 ms
Malfunction Indicator Light Illumination: Does not illuminate even when malfunction occurs.
- Normality Judgment
- Stuck
Judge as OK and clear the NG if the following conditions are established.
| Malfunction Criteria | Threshold Value |
|---|---|
| Difference between maximum value and minimum value in output voltage | > or = 0.07 V |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
- Characteristics malfunction (Charge side)
Within 30000 ms from "enable condition not met" to "enable condition met", judge as OK and clear the NG when the time required for meeting the following conditions does not reach the predetermined time.
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | 2.6 V < or = Output voltage < 5 V |
| And | |
| Battery voltage | < 13.2 V |
JUDGMENT VALUE
Time Needed for Diagnosis: 26000 ms
- Characteristics malfunction (Discharge side)
Within 30000 ms from "enable condition not met" to "enable condition met", judge as OK and clear the NG when the time required for meeting the following conditions does not reach the predetermined time.
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | 0 V < or = Output voltage < 2.4 V |
| And | |
| Battery voltage | > or = 13.7 V |
JUDGMENT VALUE
Time Needed for Diagnosis: 26000 ms
Note. For the detection standard, refer to DTC P0513. < Refer to DTC P0513 INCORRECT IMMOBILIZER KEY , Diagnostic Trouble Code (DTC) Detecting Criteria. >
Note. For the detection standard, refer to DTC P0513. < Refer to DTC P0513 INCORRECT IMMOBILIZER KEY , Diagnostic Trouble Code (DTC) Detecting Criteria. >
Note. For the detection standard, refer to DTC P0513. < Refer to DTC P0513 INCORRECT IMMOBILIZER KEY , Diagnostic Trouble Code (DTC) Detecting Criteria. >
Note. For the detection standard, refer to DTC P0513. < Refer to DTC P0513 INCORRECT IMMOBILIZER KEY , Diagnostic Trouble Code (DTC) Detecting Criteria. >
Note. For the detection standard, refer to DTC P0513. < Refer to DTC P0513 INCORRECT IMMOBILIZER KEY , Diagnostic Trouble Code (DTC) Detecting Criteria. >
Note. For the detection standard, refer to DTC P0513. < Refer to DTC P0513 INCORRECT IMMOBILIZER KEY , Diagnostic Trouble Code (DTC) Detecting Criteria. >
Note. For the detection standard, refer to DTC P0513. < Refer to DTC P0513 INCORRECT IMMOBILIZER KEY , Diagnostic Trouble Code (DTC) Detecting Criteria. >
Detect the malfunction of tumble generator valve motor function.
Judge open fixing malfunction when the opening degree is large even after finishing the tumble generator valve closing driving.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
| Malfunction Criteria | Threshold Value |
|---|---|
| Tumble generator valve opening switch | = High |
| Tumble generator valve "close" signal output time | > or = 1600 ms |
JUDGMENT VALUE
Time Needed for Diagnosis: 4600 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the following conditions are established.
| Malfunction Criteria | Threshold Value |
|---|---|
| Tumble generator valve opening switch | = Low |
| Tumble generator valve "close" signal output time | > or = 1600 ms |
JUDGMENT VALUE
Time Needed for Diagnosis: 1600 ms
Detect the malfunction of tumble generator valve motor function.
Judge open fixing malfunction when the opening degree is large even after finishing the tumble generator valve closing driving.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
| Malfunction Criteria | Threshold Value |
|---|---|
| Tumble generator valve opening switch | = High |
| Tumble generator valve "close" signal output time | > or = 1600 ms |
JUDGMENT VALUE
Time Needed for Diagnosis: 4600 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the following conditions are established.
| Malfunction Criteria | Threshold Value |
|---|---|
| Tumble generator valve opening switch | = Low |
| Tumble generator valve "close" signal output time | > or = 1600 ms |
JUDGMENT VALUE
Time Needed for Diagnosis: 1600 ms
Detect the malfunction of tumble generator valve motor function.
Judge close fixing malfunction when the opening degree is small even after finishing the tumble generator valve open driving.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
| Malfunction Criteria | Threshold Value |
|---|---|
| Tumble generator valve opening switch | = Low |
| Tumble generator valve "open" signal output time | > or = 1600 ms |
JUDGMENT VALUE
Time Needed for Diagnosis: 4600 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the following conditions are established.
| Malfunction Criteria | Threshold Value |
|---|---|
| Tumble generator valve opening switch | = High |
| Tumble generator valve "open" signal output time | > or = 1600 ms |
JUDGMENT VALUE
Time Needed for Diagnosis: 1600 ms
Detect the malfunction of tumble generator valve motor function.
Judge close fixing malfunction when the opening degree is small even after finishing the tumble generator valve open driving.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
| Malfunction Criteria | Threshold Value |
|---|---|
| Tumble generator valve opening switch | = Low |
| Tumble generator valve "open" signal output time | > or = 1600 ms |
JUDGMENT VALUE
Time Needed for Diagnosis: 4600 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the following conditions are established.
| Malfunction Criteria | Threshold Value |
|---|---|
| Tumble generator valve opening switch | = High |
| Tumble generator valve "open" signal output time | > or = 1600 ms |
JUDGMENT VALUE
Time Needed for Diagnosis: 1600 ms
Detect the open or short circuit of tumble generator valve motor.
Judge as NG when the overcurrent signal is sent from IC after tumble generator valve driving IC diagnosis.
Scheme 91
- Abnormality Judgment
At the main IC, check the sent signal at each timing which occurs just before the tumble generator valve output is set to ON --> OFF, and judge open NG when the open NG signal is sent 96 ms x 10 time(s) in a row.
| Malfunction Criteria | Threshold Value |
|---|---|
| Overcurrent NG signal input | Low |
JUDGMENT VALUE
Time Needed for Diagnosis: 96 ms x 10 time(s)
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG when the OK signal is sent.
| Malfunction Criteria | Threshold Value |
|---|---|
| Overcurrent NG signal input | High |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
Detect the open or short circuit of tumble generator valve motor.
Judge as NG when the overcurrent signal is sent from IC after tumble generator valve driving IC diagnosis.
Scheme 92
- Abnormality Judgment
At the main IC, check the sent signal at each timing which occurs just before the tumble generator valve output is set to ON --> OFF, and judge open NG when the open NG signal is sent 96 ms x 10 time(s) in a row.
| Malfunction Criteria | Threshold Value |
|---|---|
| Overcurrent NG signal input | Low |
JUDGMENT VALUE
Time Needed for Diagnosis: 96 ms x 10 time(s)
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG when the OK signal is sent.
| Malfunction Criteria | Threshold Value |
|---|---|
| Overcurrent NG signal input | High |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
Detect open or short circuit of the oil control solenoid.
Judge as NG when the current is small even though the duty signal is large.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
| Malfunction Criteria | Threshold Value |
|---|---|
| Battery voltage | > or = 10.9 V |
| Oil control solenoid control duty | > or = 99.61 % |
| Oil control solenoid control present current | < 0.306 A |
JUDGMENT VALUE
Time Needed for Diagnosis: 2000 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
| Malfunction Criteria | Threshold Value |
|---|---|
| Battery voltage | > or = 10.9 V |
| Target current value of the oil control solenoid | > or = 0.14 A |
| Target current value of the oil control solenoid - oil control solenoid control current value | < 0.08 A |
JUDGMENT VALUE
Time Needed for Diagnosis: 2000 ms
Detect open or short circuit of oil control solenoid.
Judge as NG when the current is large even though the duty signal is small.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
| Malfunction Criteria | Threshold Value |
|---|---|
| Battery voltage | > or = 10.9 V |
| Oil control solenoid control duty | < 8 % |
| Oil control solenoid control present current | > or = 0.306 A |
JUDGMENT VALUE
Time Needed for Diagnosis: 2000 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
| Malfunction Criteria | Threshold Value |
|---|---|
| Battery voltage | > or = 10.9 V |
| Target current value of the oil control solenoid - oil control solenoid control current value | < 0.08 A |
JUDGMENT VALUE
Time Needed for Diagnosis: 2000 ms
Detect open or short circuit of the oil control solenoid.
Judge as NG when the current is small even though the duty signal is large.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
| Malfunction Criteria | Threshold Value |
|---|---|
| Battery voltage | > or = 10.9 V |
| Oil control solenoid control duty | > or = 99.61 % |
| Oil control solenoid control present current | < 0.306 A |
JUDGMENT VALUE
Time Needed for Diagnosis: 2000 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
| Malfunction Criteria | Threshold Value |
|---|---|
| Battery voltage | > or = 10.9 V |
| Target current value of the oil control solenoid | > or = 0.14 A |
| Target current value of the oil control solenoid - oil control solenoid control current value | < 0.08 A |
JUDGMENT VALUE
Time Needed for Diagnosis: 2000 ms
Detect open or short circuit of oil control solenoid.
Judge as NG when the current is large even though the duty signal is small.
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
| Malfunction Criteria | Threshold Value |
|---|---|
| Battery voltage | > or = 10.9 V |
| Oil control solenoid control duty | < 8 % |
| Oil control solenoid control present current | > or = 0.306 A |
JUDGMENT VALUE
Time Needed for Diagnosis: 2000 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
| Malfunction Criteria | Threshold Value |
|---|---|
| Battery voltage | > or = 10.9 V |
| Target current value of the oil control solenoid - oil control solenoid control current value | < 0.08 A |
JUDGMENT VALUE
Time Needed for Diagnosis: 2000 ms
Note. For the detection standard, refer to DTC P2088. < Refer to DTC P2088 INTAKE CAMSHAFT POSITION ACTUATOR CONTROL CIRCUIT LOW (BANK 1) , Diagnostic Trouble Code (DTC) Detecting Criteria. >
Note. For the detection standard, refer to DTC P2089. < Refer to DTC P2089 INTAKE CAMSHAFT POSITION ACTUATOR CONTROL CIRCUIT HIGH (BANK 1) , Diagnostic Trouble Code (DTC) Detecting Criteria. >
Note. For the detection standard, refer to DTC P2090. < Refer to DTC P2090 EXHAUST CAMSHAFT POSITION ACTUATOR CONTROL CIRCUIT LOW (BANK 1) , Diagnostic Trouble Code (DTC) Detecting Criteria. >
Note. For the detection standard, refer to DTC P2091. < Refer to DTC P2091 EXHAUST CAMSHAFT POSITION ACTUATOR CONTROL CIRCUIT HIGH (BANK 1) , Diagnostic Trouble Code (DTC) Detecting Criteria. >
Detect the malfunction of fuel system from the size of the sub feedback learning value.
Control the sub feedback learning and judge as NG when the learning value is in the lean zone.
Scheme 93
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
| Malfunction Criteria | Threshold Value |
|---|---|
| Sub feedback learning value | < -0.035 (CVT model) < -0.0295 (MT model) |
JUDGMENT VALUE (EXCEPT FOR U5 MODEL)
| Malfunction Criteria | Threshold Value |
|---|---|
| Sub feedback learning value | < -0.035 |
JUDGMENT VALUE (U5 MODEL)
Time Needed for Diagnosis: 1 s x 1 time(s)
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
| Malfunction Criteria | Threshold Value |
|---|---|
| Sub feedback learning value | > or = -0.035 + 0.005 (CVT model) > or = -0.0295 + 0.005 (MT model) |
JUDGMENT VALUE (EXCEPT FOR U5 MODEL)
| Malfunction Criteria | Threshold Value |
|---|---|
| Sub feedback learning value | > or = -0.035 + 0.005 |
JUDGMENT VALUE (U5 MODEL)
Time Needed for Diagnosis: 1 s
Detect the malfunction of fuel system from the size of the sub feedback learning value. Sub feedback learning is being performed. When the learning value goes to the rich side, judge as NG.
Scheme 94
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
| Malfunction Criteria | Threshold Value |
|---|---|
| Sub feedback learning value | > or = 0.012 |
JUDGMENT VALUE (EXCEPT FOR U5 MODEL)
| Malfunction Criteria | Threshold Value |
|---|---|
| Sub feedback learning value | > or = 0.021 |
JUDGMENT VALUE (U5 MODEL)
Time Needed for Diagnosis: 1 s x 1 time(s)
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
| Malfunction Criteria | Threshold Value |
|---|---|
| Sub feedback learning value | < 0.012 + 0 |
JUDGMENT VALUE (EXCEPT FOR U5 MODEL)
| Malfunction Criteria | Threshold Value |
|---|---|
| Sub feedback learning value | < 0.021 + 0 |
JUDGMENT VALUE (U5 MODEL)
Time Needed for Diagnosis: 1 s
Judge as NG when the motor current becomes large or drive circuit is heated.
Scheme 95
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
| Malfunction Criteria | Threshold Value |
|---|---|
| Motor current | > 8 A |
| Or | |
| Drive circuit inner temperature | > 175°C (347°F) |
JUDGMENT VALUE
Time Needed for Diagnosis: 512 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
| Malfunction Criteria | Threshold Value |
|---|---|
| Motor current | > or = 8 A |
| Drive circuit inner temperature | > or = 175°C (347°F) |
JUDGMENT VALUE
Time Needed for Diagnosis: 2000 ms
Judge as NG when the electronic throttle control power is not supplied even when ECM sets the electronic throttle control relay to ON.
Scheme 96
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
| Malfunction Criteria | Threshold Value |
|---|---|
| Motor power voltage | > or = 5 V |
JUDGMENT VALUE
Time Needed for Diagnosis: 352 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
| Malfunction Criteria | Threshold Value |
|---|---|
| Motor power voltage | > 5 V |
JUDGMENT VALUE
Time Needed for Diagnosis: 2000 ms
Judge as NG when the electronic throttle control power is supplied even when ECM sets the electronic throttle control relay to OFF.
Scheme 97
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
| Malfunction Criteria | Threshold Value |
|---|---|
| Motor power voltage | > or = 5 V |
JUDGMENT VALUE
Time Needed for Diagnosis: 600 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
| Malfunction Criteria | Threshold Value |
|---|---|
| Motor power voltage | < 5 V |
JUDGMENT VALUE
Time Needed for Diagnosis: 400 ms
Judge as NG when full close point learning cannot conducted or abnormal value is detected.
Scheme 98
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
| Malfunction Criteria | Threshold Value |
|---|---|
| Throttle sensor opening angle at full close point learning | < 9.884 ° |
| Or | |
| > 20.116 ° | |
| Or | |
| Throttle opening angle when the ignition switch is ON - Throttle minimum stop position | < 0.887 ° |
JUDGMENT VALUE
Time Needed for Diagnosis: 8 ms - 80 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
| Malfunction Criteria | Threshold Value |
|---|---|
| Throttle sensor opening angle at full close point learning | > or = 9.884 ° |
| And | |
| < or = 20.116 ° | |
| Throttle opening angle when the ignition switch is ON - Throttle minimum stop position | > or = 0.887 ° |
JUDGMENT VALUE
Time Needed for Diagnosis: 8 ms
Judge as NG when the target opening angle and actual opening angle is mismatched or the current to motor is the specified duty or more for specified time continuously.
Scheme 99
Judge as OK and clear the NG when the malfunction criteria below are met.
| Malfunction Criteria | Threshold Value |
|---|---|
| Difference between target opening angle and actual opening angle | Within OK range of Details of Judgment value |
| Output duty to drive circuit | < 95 % |
JUDGMENT VALUE
Time Needed for Diagnosis
- Difference between target opening angle and actual opening angle: NG judgment: See «DETAILS OF JUDGMENT TIME»(ref-560384-S34352371272013061300000) OK judgment: 2000 ms
- Output duty to driving circuit: 2000 ms
Scheme 100
Scheme 101
Note. Judgment time when actual opening angle < or = target opening angle is always 1000 milliseconds. Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
Detect the open or short circuit of accelerator pedal position sensor 1.
Judge as NG if out of specification.
Scheme 102
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
| Malfunction Criteria | Threshold Value |
|---|---|
| Sensor 1 input voltage | < 0.301 V |
JUDGMENT VALUE
Time Needed for Diagnosis: 100 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
| Malfunction Criteria | Threshold Value |
|---|---|
| Sensor 1 input voltage | > or = 0.301 V |
JUDGMENT VALUE
Time Needed for Diagnosis: 100 ms
Detect the open or short circuit of accelerator pedal position sensor 1.
Judge as NG if out of specification.
Scheme 103
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
| Malfunction Criteria | Threshold Value |
|---|---|
| Sensor 1 input voltage | > or = 4.783 V |
JUDGMENT VALUE
Time Needed for Diagnosis: 32 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
| Malfunction Criteria | Threshold Value |
|---|---|
| Sensor 1 input voltage | < 4.783 V |
JUDGMENT VALUE
Time Needed for Diagnosis: 32 ms
Detect the open or short circuit of accelerator pedal position sensor 2.
Judge as NG if out of specification.
Scheme 104
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
| Malfunction Criteria | Threshold Value |
|---|---|
| Sensor 2 input voltage | < 0.301 V |
JUDGMENT VALUE
Time Needed for Diagnosis: 100 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
| Malfunction Criteria | Threshold Value |
|---|---|
| Sensor 2 input voltage | > or = 0.301 V |
JUDGMENT VALUE
Time Needed for Diagnosis: 100 ms
Detect the open or short circuit of accelerator pedal position sensor 2.
Judge as NG if out of specification.
Scheme 105
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
| Malfunction Criteria | Threshold Value |
|---|---|
| Sensor 2 input voltage | > or = 4.783 V |
JUDGMENT VALUE
Time Needed for Diagnosis: 100 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
| Malfunction Criteria | Threshold Value |
|---|---|
| Sensor 2 input voltage | < 4.783 V |
JUDGMENT VALUE
Time Needed for Diagnosis: 100 ms
Judge as NG when the signal level of throttle position sensor 1 is different from the throttle position sensor 2.
Scheme 106
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
| Malfunction Criteria | Threshold Value |
|---|---|
| Signal difference between two sensors | Within the NG range of judgment value detail |
JUDGMENT VALUE
Scheme 107
Time Needed for Diagnosis: 212 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
| Malfunction Criteria | Threshold Value |
|---|---|
| Signal difference between two sensors | Within the OK range of judgment value detail |
JUDGMENT VALUE
Time Needed for Diagnosis: 24 ms
Judge as NG when the signal level of throttle position sensor 1 is different from the throttle position sensor 2.
Scheme 108
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
| Malfunction Criteria | Threshold Value |
|---|---|
| Signal difference between two sensors | Within the NG range of judgment value detail |
JUDGMENT VALUE
Scheme 109
Time Needed for Diagnosis: 116 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
| Malfunction Criteria | Threshold Value |
|---|---|
| Signal difference between two sensors | Within the OK range of judgment value detail |
JUDGMENT VALUE
Time Needed for Diagnosis: 116 ms
Detect that lambda value remains low.
Judge as NG when lambda value is abnormal in accordance with lambda value of front oxygen (A/F) sensor and running conditions such as vehicle speed, amount of intake air, engine coolant temperature, sub feedback control, etc.
| Lambda value = Actual air fuel ratio/Theoretical air fuel ratio lambda > 1: Lean lambda < 1: Rich |
Scheme 110
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
| Malfunction Criteria | Threshold Value |
|---|---|
| Lambda value | < 0.85 |
JUDGMENT VALUE
Time Needed for Diagnosis: 10000 ms
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
| Malfunction Criteria | Threshold Value |
|---|---|
| Lambda value | > or = 0.85 |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
Detect that lambda value remains high.
Judge as NG when lambda value is abnormal in accordance with lambda value of front oxygen (A/F) sensor and running conditions such as vehicle speed, amount of intake air, engine coolant temperature, sub feedback control, etc.
| Lambda value = Actual air fuel ratio/Theoretical air fuel ratio lambda > 1: Lean lambda < 1: Rich |
Scheme 111
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
| Malfunction Criteria | Threshold Value |
|---|---|
| Lambda value | > 1.15 |
JUDGMENT VALUE
Time Needed for Diagnosis: 10000 ms
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
| Malfunction Criteria | Threshold Value |
|---|---|
| Lambda value | > or = 1.15 |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
This diagnostic monitor performs a functional check of the fuel system to determine an air-fuel ratio cylinder imbalance.
This diagnosis is composed of two monitors.
The outline of "monitor A1" is as follows. When an air-fuel ratio cylinder imbalance occurs, the primary oxygen sensor output signal will oscillate with increased amplitude. This monitor utilizes this behavior to make a diagnosis. The monitor integrates the difference between the amplification value and the mean value of the first oxygen sensor output signal and compares it to a threshold to make a judgment.
The outline of "monitor B1" is as follows. Similarly, when an imbalance occurs, the engine speed also fluctuates with increased amplitude. This monitor utilizes this behavior to make a diagnosis. For reference, it should be noted that this imbalance monitor method is actually similar to the current misfire diagnostic monitor, and the parameter "domg360" (units: degrees CA) is shared between the imbalance and misfire monitors. The imbalance monitor is performed during idle condition when the engine is warm. The monitor integrates the count of "domg360" which exceeds a threshold in 1000 revolution.
When both the "monitor A1" value and the "monitor B1" value exceed a predetermined threshold, this monitor determines a malfunction and stores a fault code.
Judge as NG when Monitor A1 and Monitor B1 are both NG, and when either is OK, judge as OK.
- Abnormality Judgment
Detect the open or short circuit of the ELCM vacuum pump.
Judge as NG if out of specification.
Scheme 112
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
| Malfunction Criteria | Threshold Value |
|---|---|
| Battery voltage | > or = 10.9 |
| Terminal output voltage when ECM outputs OFF signal | Low |
JUDGMENT VALUE
Time Needed for Diagnosis: 2500 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
| Malfunction Criteria | Threshold Value |
|---|---|
| Battery voltage | > or = 10.9 |
| Terminal output voltage when ECM outputs OFF signal | High |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
Detect the open or short circuit of the ELCM vacuum pump.
Judge as NG if out of specification.
Scheme 113
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
| Malfunction Criteria | Threshold Value |
|---|---|
| Battery voltage | > or = 10.9 |
| Terminal output voltage when ECM outputs ON signal | High |
JUDGMENT VALUE
Time Needed for Diagnosis: 2500 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
| Malfunction Criteria | Threshold Value |
|---|---|
| Battery voltage | > or = 10.9 |
| Terminal output voltage when ECM outputs ON signal | Low |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
Note. For the detection standard, refer to DTC P0455. < Refer to DTC P0455 EVAPORATIVE EMISSION SYSTEM LEAK DETECTED (LARGE LEAK) , Diagnostic Trouble Code (DTC) Detecting Criteria. >
Detect the open or short circuit of the ELCM switching valve.
Judge as NG if out of specification.
Scheme 114
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
| Malfunction Criteria | Threshold Value |
|---|---|
| Battery voltage | > or = 10.9 |
| Terminal output voltage when ECM outputs OFF signal | Low |
JUDGMENT VALUE
Time Needed for Diagnosis: 2500 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
| Malfunction Criteria | Threshold Value |
|---|---|
| Battery voltage | > or = 10.9 |
| Terminal output voltage when ECM outputs OFF signal | High |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
Detect the open or short circuit of the ELCM switching valve.
Judge as NG if out of specification.
Scheme 115
- Abnormality Judgment
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
| Malfunction Criteria | Threshold Value |
|---|---|
| Battery voltage | > or = 10.9 |
| Terminal output voltage when ECM outputs ON signal | High |
JUDGMENT VALUE
Time Needed for Diagnosis: 2500 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
| Malfunction Criteria | Threshold Value |
|---|---|
| Battery voltage | > or = 10.9 |
| Terminal output voltage when ECM outputs ON signal | Low |
JUDGMENT VALUE
Time Needed for Diagnosis: Less than 1 second
Detect malfunction of soaking timer IC by the five diagnoses below.
| Monitor Number | Explanation | Time required for diagnosis |
|---|---|---|
| Monitor #1 < Timer diagnosis > | Perform diagnosis of the soaking timer IC accuracy | 196 ms |
| Monitor #2 < Full count diagnosis > | Perform diagnosis of the soaking timer IC counter function | 4000 ms |
| Monitor #3 < Soaking timer IC setting diagnosis > | Perform diagnosis of communication between ECM and soaking timer IC | 196 ms |
| Monitor #4 < Timer diagnosis (during soaking) > | Perform diagnosis of the soaking timer IC accuracy during soaking | 3000 ms |
| Monitor #5 < Wake-up diagnosis > | Perform diagnosis of wake-up function | 64 ms |
Scheme 116
< Timer diagnosis >
Start the count up operation of counters in ECM and in soaking timer IC when the engine is started. Judge as timer malfunction if the difference between the counter in ECM and counter in soaking timer IC exceeds the allowable limit when the ignition switch is OFF.
Scheme 117
- Abnormality Judgment
Judge as NG when the following conditions are established.
| Malfunction Criteria | Threshold Value |
|---|---|
| Osoaktimcpu - osoaktimic| / osoaktimcpu osoaktimcpu = Counter in ECM osoaktimic = Counter in soaking timer IC | > 0.24 |
JUDGMENT VALUE
- Normality Judgment
Judge as OK when the following conditions are established.
| Malfunction Criteria | Threshold Value |
|---|---|
| Osoaktimcpu - osoaktimic| / osoaktimcpu | < or = 0.24 |
JUDGMENT VALUE
< Full count diagnosis >
Reset the counter in soaking timer IC and start the count up operation.
Judge as full count diagnosis malfunction if counter in soaking timer IC is not $3FF (1023 count) after 4 seconds.
Scheme 118
- Abnormality Judgment
Judge as NG when the following conditions are established.
| Malfunction Criteria | Threshold Value |
|---|---|
| Osoakfcntic osoakfcntic = Counter in soaking timer IC | $3FF (1023 count) |
JUDGMENT VALUE
- Normality Judgment
Judge as OK when the following conditions are established.
| Malfunction Criteria | Threshold Value |
|---|---|
| Osoakfcntic | = $3FF (1023 count) |
JUDGMENT VALUE
< Soaking timer IC setting diagnosis >
When setting the activation setting time to soaking timer IC, compare the writing value to soaking timer IC with read out value. Judge as malfunction if the values do not match 3 times in a row.
Scheme 119
- Abnormality Judgment
Judge as NG when the following conditions are established.
| Malfunction Criteria | Threshold Value |
|---|---|
| Writing value and read out value when setting the soaking timer | Unmatch |
| Number of retrying the soaking timer setting | > or = 3 times |
JUDGMENT VALUE
- Normality Judgment
Judge as OK when the following conditions are established.
| Malfunction Criteria | Threshold Value |
|---|---|
| Writing value and read out value when setting the soaking timer | Match |
JUDGMENT VALUE
< Timer diagnosis (during soaking) >
Wake-up at the predetermined interval until 5, 7 or 9.5 hours have passed after the ignition switch is OFF, and compare the counter in soaking timer IC with the counter in ECM.
Judge as malfunction if the counter in soaking timer IC is counted up to maximum value (1023 count) when the counter in ECM is 1637 ms, or if the counter in soaking timer IC is not counted up to maximum value (1023 count) when the counter in ECM is 2455 ms.
Scheme 120
- Abnormality Judgment
Judge as NG when the following conditions are established.
| Malfunction Criteria | Threshold Value |
|---|---|
| When any one of the followings is established. | |
| All of the following conditions are established. | |
| Counter in ECM | < or = 1637 ms |
| Counter in soaking timer IC | = $3FF (1023 count) |
| All of the following conditions are established. | |
| Counter in ECM | > or = 2455 ms |
| Counter in soaking timer IC | $3FF (1023 count) |
JUDGMENT VALUE
- Normality Judgment
Judge as OK when the following conditions are established.
| Malfunction Criteria | Threshold Value |
|---|---|
| Following conditions are established. | |
| All of the following conditions are established. | |
| Counter in ECM | < or = 1637 ms |
| Counter in soaking timer IC | $3FF (1023 count) |
| All of the following conditions are established. | |
| Counter in ECM | > or = 2455 ms |
| Counter in soaking timer IC | = $3FF (1023 count) |
JUDGMENT VALUE
< Wake-up diagnosis >
Store the number of wake-up activation when the ECM wakes up by the soaking timer IC.
Next time when the ignition switch is ON, if the number of wake-up activation does not reach the predetermined value even though the counter in soaking timer IC operates 1 hour or more, judge as wake-up malfunction.
Scheme 121
- Abnormality Judgment
Judge as NG when the following conditions are established.
| Malfunction Criteria | Threshold Value |
|---|---|
| Number of wake-up | < Wake-up indication count |
JUDGMENT VALUE
- Normality Judgment
Judge as OK when the following conditions are established.
| Malfunction Criteria | Threshold Value |
|---|---|
| Number of wake-up | > or = Wake-up indication count |
JUDGMENT VALUE
- Abnormality Judgment
Judge as NG when the following conditions are established.
| Malfunction Criteria | Threshold Value |
|---|---|
| Ignition switch | ON |
| Driving cycle | Completed |
| When any one of the followings is established. | |
| Timer diagnosis | NG |
| Full count diagnosis | NG |
| Soaking timer IC setting diagnosis | NG |
| Timer diagnosis (during soaking) | NG |
| Wake-up diagnosis | NG |
JUDGMENT VALUE
Time Needed for Diagnosis: Approx. 5 - 9.5 hours
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgment
Judge as OK and clear the NG if the following conditions are established.
| Malfunction Criteria | Threshold Value |
|---|---|
| Ignition switch | ON |
| Driving cycle | Completed |
| All of the following conditions are established. | |
| Timer diagnosis | OK |
| Full count diagnosis | OK |
| Soaking timer IC setting diagnosis | OK |
| Timer diagnosis (during soaking) | OK |
| Wake-up diagnosis | OK |
JUDGMENT VALUE
Time Needed for Diagnosis: Approx. 5 - 9.5 hours
Detect malfunction of CAN communication.
Judge as NG when CAN communication failure has occurred.
- Abnormality Judgment
Judge as NG when the following conditions are established.
| Malfunction Criteria | Threshold Value |
|---|---|
| Battery voltage | > 10.9 V |
| Starter switch | OFF |
| Engine | Run |
| Bus off flag or error warning flag | Set (error) |
JUDGMENT VALUE
Time Needed for Diagnosis: 436 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
| Malfunction Criteria | Threshold Value |
|---|---|
| Engine | Run |
| Bus off flag or error warning flag | Clear (No error) |
JUDGMENT VALUE
Time Needed for Diagnosis: 1000 ms
Detect malfunction of CAN communication.
Judge as NG when CAN communication failure between TCM, VDC CM and combination meter has occurred.
- Abnormality Judgment
Judge as NG when the following conditions are established.
| Malfunction Criteria | Threshold Value |
|---|---|
| Battery voltage | > 10.9 V |
| Starter switch | OFF |
| Engine | Run |
| ID received from control module connected to CAN | None during 500 milliseconds |
JUDGMENT VALUE
Time Needed for Diagnosis: 500 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
| Malfunction Criteria | Threshold Value |
|---|---|
| Engine | Run |
| ID received from control module connected to CAN | Yes |
JUDGMENT VALUE
Time Needed for Diagnosis: 1000 ms
Note. For the detection standard, refer to DTC U0101. < Refer to DTC U0101 LOST COMMUNICATION WITH TCM , Diagnostic Trouble Code (DTC) Detecting Criteria. >
Note. For the detection standard, refer to DTC U0101. < Refer to DTC U0101 LOST COMMUNICATION WITH TCM , Diagnostic Trouble Code (DTC) Detecting Criteria. >
Detect malfunction of CAN communication.
Judge as NG when data received from TCM, VDC CM and combination meter is not normal.
- Abnormality Judgment
Judge as NG when the following conditions are established.
| Malfunction Criteria | Threshold Value |
|---|---|
| Battery voltage | > 10.9 V |
| Starter switch | OFF |
| Engine | Run |
| Data updated from control module connected to CAN | None during 2000 milliseconds |
JUDGMENT VALUE
Time Needed for Diagnosis: 2 seconds
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgment
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
| Malfunction Criteria | Threshold Value |
|---|---|
| Engine | Run |
| Data updated from control module connected to CAN | Yes |
JUDGMENT VALUE
Time Needed for Diagnosis: 1000 ms
Note. For the detection standard, refer to DTC U0402. < Refer to DTC U0402 INVALID DATA RECEIVED FROM TCM , Diagnostic Trouble Code (DTC) Detecting Criteria. >
Note. For the detection standard, refer to DTC U0402. < Refer to DTC U0402 INVALID DATA RECEIVED FROM TCM , Diagnostic Trouble Code (DTC) Detecting Criteria. >
