Fuel Injection System (Except Wrx): Specifications Subaru XV GP

Fuel System 12 illustrations ~252 words

SPECIFICATION

Fuel tankCapacityExcept for XV model55 L (14.5 US gal, 12.1 Imp gal)
XV model60 L (15.9 US gal, 13.2 Imp gal)
LocationUnder rear seat
Fuel pumpTypeImpeller
Shutoff discharge pressure677 kPa (6.9 kgf/cm 2 , 98.2 psi) or less
Discharge rate85 L (22.5 US gal, 18.7 Imp gal)/h or more [12 V at 300 kPa (3.06 kgf/cm 2 , 43.5 psi)]
Fuel filterIn-tank type

Scheme 34

Scheme 34: INTAKE MANIFOLD 1

Tightening torque: N.m (kgf-m, ft-lb)

T1: 3.4 (0.3, 2.5)

T2: 6 (0.6, 4.4)

T3: 6.4 (0.7, 4.7)

T4: 8.3 (0.8, 6.1)

T5: 25 (2.5, 18.4)

Scheme 35

Scheme 35: INTAKE MANIFOLD 2

Tightening torque: N.m (kgf-m, ft-lb)

T: 6.4 (0.7, 4.7)

Scheme 36

Scheme 36: THROTTLE BODY

Tightening torque: N.m (kgf-m, ft-lb)

T: 8 (0.8, 5.9)

Scheme 37

Scheme 37: CRANKSHAFT POSITION, CAMSHAFT POSITION AND KNOCK SENSORS

Tightening torque: N.m (kgf-m, ft-lb)

T1: 6.4 (0.7, 4.7)

T2: 24 (2.4, 17.7)

Scheme 38

Scheme 38: FUEL TANK

Tightening torque: N.m (kgf-m, ft-lb)

T1: 2 (0.2, 1.5)

T2: 2.5 (0.3, 1.8)

T3: 9 (0.9, 6.6)

T4: 18 (1.8, 13.3)

T5: 33 (3.4, 24.3)

T6: < Refer to INSTALLATION, Fuel Pump. >

T7: < Refer to INSTALLATION, Fuel Sub Level Sensor. >

Scheme 39

Scheme 39: FUEL LINE

Tightening torque: N.m (kgf-m, ft-lb)

T1: 7.5 (0.8, 5.5)

T2: 18 (1.8, 13.3)

Scheme 40

Scheme 40: FUEL FILLER PIPE

Tightening torque: N.m (kgf-m, ft-lb)

T: 7.35 (0.7, 5.4)

Scheme 41

Scheme 41: FUEL PUMP

Scheme 42

Scheme 42: ENGINE HARNESS

Scheme 43

Scheme 43

Scheme 44

Scheme 44
  1. Structural diagram 1 Tightening torque: N.m (kgf-m, ft-lb) T1: 7.5 (0.8, 5.5) T2: 19 (1.9, 14.0)
  2. Structural diagram 2

Throttle body is a non-disassembled part, so do not remove the throttle position sensor from throttle body. Refer to "Throttle Body" for removal and installation procedure. < Refer to REMOVAL, Throttle Body. > < Refer to INSTALLATION, Throttle Body. >

Scheme 45

Scheme 45
  1. Disconnect the ground cable from battery.
  2. Disconnect the connector (A) from the mass air flow and intake air temperature sensor, and remove the mass air flow and intake air temperature sensor.
