A/t Control Systems: Removal & Installation Subaru Tribeca WX рестайлинг

REMOVAL

Note. For removal of the mode change switch and the shift button switch, refer to the Select Levers. Ref. to DISASSEMBLY , Select Lever.

Scheme 57

Scheme 58

1. Remove the console box. Ref. to «REMOVAL»(ref-356698-S01131733162010022700000) , Console Box.
2. Disconnect the connector.
3. Remove the connector from the base plate using a flat-tip screwdriver.
4. Disconnect the terminal of "P" range switch from connector, using a flat-tip screwdriver with thin tip.
5. Remove the clip while being careful not to break the pin, then remove the P range switch.

Scheme 59

Scheme 60

1. Remove the console box. Ref. to «REMOVAL»(ref-356698-S01131733162010022700000) , Console Box.
2. Disconnect the connector.
3. Remove the connector from the base plate using a flat-tip screwdriver.
4. Remove the AT shift lock solenoid.
5. Disconnect the terminal of AT shift lock solenoid from the connector, using a flat-tip screwdriver.

INSTALLATION

Note. For installation of the mode change switch and the shift button switch, refer to the Select Levers. Ref. to ASSEMBLY , Select Lever.
