PREPARATION TOOL
SPECIAL TOOL
SPECIAL TOOL DESCRIPTION ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 1B022XU0 SUBARU SELECT MONITOR III KIT Troubleshooting for the electrical system
Scheme 61
CAUTION
- Wear appropriate work clothing, including a cap, protective goggles and protective shoes when performing any work.
- Remove contamination including dirt and corrosion before removal, installation or disassembly.
- Keep the disassembled parts in order and protect them from dust and dirt.
- Before removal, installation or disassembly, be sure to clarify the failure. Avoid unnecessary removal, installation, disassembly and replacement.
- Use SUBARU genuine fluid, grease etc. or equivalent. Do not mix fluid, grease, etc. of different grades or manufacturers.
- Be sure to tighten fasteners including bolts and nuts to the specified torque.
- Place shop jacks or rigid racks at the specified points.
- Apply grease onto sliding or revolving surfaces before installation.
- Before installing the O-ring or snap ring, apply a sufficient amount of fluid to avoid damage and deformation.
- Before securing a part in a vise, place cushioning material such as wood blocks, aluminum plate or cloth between the part and the vise.
- Before disconnecting electrical connectors, be sure to disconnect the negative terminal from battery.
Scheme 62
Scheme 63
Scheme 64
| Item | To connector No. | Terminal No. | Input/Output signal |
|---|---|---|---|
| Measured value and measuring condition | |||
| Battery power supply | B281 | 1 | 9 - 16V |
| 2 | |||
| B280 | 7 | ||
| Ignition power supply | I84 | 1 | 10 - 15V when ignition switch is at ON or START. |
| ACC power supply | I84 | 24 | 10 - 15V when ignition switch is at ACC. |
| TCM ("P" range) | B280 | 20 | Pulse signal |
| B280 | 30 | ||
| Stop light switch | B281 | 23 | 9 - 16V when stop light switch is ON. 0 V when stop light switch is OFF. |
| "P" range switch | B281 | 13 | 0 V when select lever is in "P" range. 9 - 16 V when select lever is in other positions than "P" range. |
| Shift lock solenoid signal | B280 | 6 | 8.5 - 16V when shift lock is released. 0 V when shift lock is operating. |
| Key warning switch signal | B281 | 7 | 9 - 16 V when key is inserted. 0 V when key is removed. |
| Key lock solenoid signal | B280 | 5 | 7.5 - 16 V when ignition switch is turned ON, with select lever in "P" range and brake switch ON. 0 V at other conditions than above. |
| Ground | B280 | 22 | |
| I84 | 21 | ||
| B281 | 8 | ||
| 9 |
CONNECTOR TERMINALS REFERENCE
Scheme 65
"P" RANGE SWITCH
Install in the reverse order of removal.
Note. Connect the "P" range switch terminal to connector.
Scheme 66
AT SHIFT LOCK SOLENOID
Install in the reverse order of removal.
Note. Connect the AT shift lock solenoid switch terminal to connector.
Scheme 67
NOTE
Refer to "Body Integrated Unit" for removal and installation procedure. Ref. to BODY INTEGRATED UNIT .
