Engine Intake System (H6DO): Other Subaru Tribeca WX рестайлинг

CAUTION

1. Wear appropriate work clothing, including a cap, protective goggles and protective shoes when performing any work.
2. Remove contamination including dirt and corrosion before removal, installation or disassembly.
3. Keep the disassembled parts in order and protect them from dust and dirt.
4. Before removal, installation or disassembly, be sure to clarify the failure. Avoid unnecessary removal, installation, disassembly and replacement.
5. Vehicle components are extremely hot after driving. Be wary of receiving burns from heated parts.
6. Be sure to tighten fasteners including bolts and nuts to the specified torque.
7. Place shop jacks or rigid racks at the specified points.
8. Before disconnecting connectors of sensors or units, be sure to disconnect the ground cable from the battery.

Scheme 18

Scheme 19

Scheme 20

1. Disconnect the ground cable from battery.
2. Disconnect the connector from the mass airflow and intake air temperature sensor.
3. Loosen the clamps (A) which connect the air cleaner case (rear) to intake duct.
4. Remove the clip (B) securing the upper side of air cleaner case.
5. Pull the air cleaner case (rear) backward of the vehicle, and remove the air cleaner element.
