SI UNITS

Measurements in these manuals are according to the SI units. Metric and yard/pound measurements are also included.

Example

Tightening torque: 44 N.m (4.5 kgf-m, 33 ft-lb)

SI UNITS REFERENCE

The figure used in these manuals are described in the SI units and conventional units are described in ( ).

EXPLANATION OF TERMINOLOGY

AAI : Air Assist Injection

A/B : Airbag

ABS : Anti-lock Brake System

A/C : Air Conditioner

ACC : Accessory

A/F : Air Fuel Ratio

ALT : Generator

ASSY : Assembly

AT : Automatic Transmission

ATF : Automatic Transmission Fluid

AUX : Auxiliary

AUX : Auxiliary Storage Unit

AWD : All Wheel Drive

BATT : Battery

CAN : Controller Area Network

CD : Compact Disc

CPU : Central Processing Unit

DOHC : Double Overhead Camshaft

DOJ : Double Offset Joint

DTC : Diagnostic Trouble Code

DVD : Digital Versatile Disc

EBJ : High-efficiency Compact Ball Fixed Joint

ECM : Engine Control Module

EDJ : High-efficiency Compact Double Offset Joint

EGR : Exhaust Gas Recirculation

EX : Exhaust

F/B : Fuse & Joint Box

Ft : Front

FWD : Front Wheel Drive

GPS : Global Positioning System

HI : High

HID : High Intensity Discharge

H/L : Headlight

H/U : Hydraulic Unit

I/F : Interface

I/O : Input/Output

IG : Ignition

INT : Intermittent

ISC : Idle Speed Control

LCD : Liquid Crystal Display

LH : LH (Left Hand)

LSD : Limited Slip Differential

M/B : Main Fuse & Relay Box

MFI : Multi Point Injection

MT : Manual Transmission

NA : Natural Aspiration

OP : Option Parts

P/W : Power Window

PCV : Positive Crankcase Ventilation

PTJ : Pillow Tripod Joint

RH : RH (Right Hand)

ROM : Read Only Memory

Rr : Rear

SOHC : Single Overhead Camshaft

SRS : Supplemental Restraint System

SSM : Subaru Select Monitor

ST : Special Tool

SW : Switch

TCS : Traction Control System

TCM : Transmission Control Module

TPMS : Tire Pressure Monitoring System

VDC : Vehicle Dynamics Control

VTD : Variable Torque Distribution

DIMENSION

PART DIMENSION CHART

ENGINE

ENGINE SPECIFICATION

ELECTRICAL

IGNITION TIMING REFERENCE

TRANSMISSION

TRANSMISSION CHART

STEERING

STEERING SPECIFICATION

SUSPENSION

SUSPENSION SPECIFICATION

BRAKE

BRAKE SPECIFICATION

TIRE

TIRE SPECIFICATION

WEIGHT

ITEM WEIGHT

ITEM WEIGHT

CAUTION

Please clearly understand and adhere to the following general precautions. They must be strictly followed to avoid any injury to the person doing the work or people in the area.

VEHICLE DYNAMICS CONTROL (VDC)

Handle the VDC as a total system. Do not disassemble or attempt to repair individual parts. Doing so could prevent the VDC system from operating when needed or cause it to operate incorrectly and result in injury.

RADIATOR FAN

The radiator fan may rotate without warning, even when the engine is not ON. Do not place your hand, cloth, tools or other items near the fan at any time.

AIRBAG

To prevent bodily injury from unexpected deployment of airbags and unnecessary maintenance, follow the instructions in this manual when performing maintenance on or near the airbag components, around front of the vehicle (radiator panel, front wheel apron, front side frame, bumper, hood, front fender), around side of the vehicle (front door, rear door, center pillar, rear fender, side sill, rear wheel apron), and on or near the airbag wiring harnesses. To prevent unexpected deployment, turn the ignition switch to OFF and disconnect the ground cable from battery, then wait at least 20 seconds before starting work.

AIRBAG AND SEAT BELT PRETENSIONER DISPOSAL

To prevent bodily injury from unexpected airbag deployment, do not dispose the airbag modules and seat belt pretensioner in the same way as other waste. Follow all government regulations concerning disposal of refuse.

AIRBAG MODULE

Carefully observe the following when handing and storing the airbag module to prevent bodily injury from unexpected deployment

1. Do not hold the harnesses or connectors to carry the module.
2. Do not face the bag in the direction that it opens towards yourself or other people.
3. Do not face the bag in the direction that it opens towards the floor or walls.

WINDOW

Always wear safety glasses when working around any glass to prevent glass fragments from damaging your eyes.

WINDOW ADHESIVE

Always use the recommended or equivalent adhesive when attaching glass to prevent it from coming falling, resulting in accidents and injury.

OIL

When handling oil, follow the rules below to prevent unexpected accidents.

1. Prepare a container and cloth when performing work which oil possibly spills. If oil spills, wipe it off immediately to prevent from penetrating into floor or flowing out, to protect the environmental.
2. Follow all government regulations concerning disposal of refuse when disposing.

FUEL

When handling and storing fuel, carefully observe the following to prevent unexpected accidents.

1. Be careful of fires.
2. Prepare a container and cloth to prevent scattering of fuels when performing work where fuels can be spilled. If the fuel spills, wipe it off immediately to prevent it from penetrating the floor or flowing out, to protect the environmental.
3. Follow all government and local regulations concerning disposal of refuse when disposing.

ENGINE COOLANT

When handling engine coolant, adhere to the following to prevent from unexpected accident.

1. Never remove the radiator cap because of the danger of engine coolant blowing out when the engine coolant is hot.
2. Prepare a container and cloth to prevent spraying of engine coolant when performing work in which engine coolant can be spilled. If the fuel spills, wipe it off immediately to prevent from penetrating into floor or flowing out for environmental protection.
3. Follow all government and local regulations concerning disposal of refuse when disposing.

AIR CONDITIONER REFRIGERANT

In order to prevent from global warming, avoid releasing air conditioner refrigerant into the atmosphere. Using a refrigerant recovery system, discharge and reuse it.

NOTE

This information will improve the efficiency of maintenance and assure that the finished work is of a good quality.

FASTENERS NOTICE

Fasteners are used to prevent the parts from damage, dislocation and play due to looseness. Fasteners must be tightened to the specified torque.

Do not apply paint, lubricant, rust retardant or other substance to the surface around bolts, nuts, etc. Doing so will make it difficult to obtain the correct torque and result in looseness and other problem.

STATIC ELECTRICITY DAMAGE

Do not touch the control modules, connectors, logic boards and other such parts when there is a possibility of static electricity. Always use a static electricity prevention cord or touch grounded metal for the elimination of static electricity before conducting work.

BATTERY

When removing the battery terminal, always be sure to turn the ignition to OFF to prevent electrical damage of the control module from overcurrent. Be sure to remove the battery ground cable first.

When removing the battery terminal, memories such as the stereo and control unit DTC are erased. Therefore, the content of each memory should be recorded first.

SERVICE PARTS

Use genuine parts for maximum performance and maintenance when conducting repairs. Subaru/FHI will not be responsible for poor performance resulting from the use of parts except for genuine parts.

ENSURING SECURITY DURING WORK

When working in a group of two or more, perform the work with calling each other to ensure mutual safety.

LIFT AND JACK

When using a lift or shop jack raise a vehicle or using rigid rack to support a vehicle, always follow instructions concerning jack-up points and weight limits to prevent the vehicle from falling, which could result in injury. Be especially careful that the vehicle is balanced before raising it. Be sure to set the wheel stoppers when jacking-up only the front or rear side of the vehicle.

Note. When using a lift, follow its operation manual before work. Do not work or leave unattended while the vehicle is supported with jack, support it with rigid racks. Be sure to use the rigid racks with rubber attached to cradle to support the vehicle. When using a plate lift, use a rubber attachment. Align the cushion rubber end of plate lift with the end of rubber attachment (Portion b). Also, align the protrusion portion of the supporting locations with the end of attachment (Portion a). Do not use the plate lift whose attachment does not reach the supporting locations.

Scheme 36

TIE-DOWNS

Tie-downs are used when transporting vehicles and when using the chassis dynamo. Attach tie-down only to the specified locations on the vehicle.

Scheme 37

Scheme 38

Scheme 39

Scheme 40

1. TIE-DOWN LOCATION
2. CHAIN DIRECTION AT TIE-DOWN CONDITION NOTE: Pull the chains LH and RH in the same direction, but front and rear side in the counter direction. Pull all the chains in a same moment.
3. CHAIN PULLING RANGE AT TIE-DOWN CONDITION
4. VEHICLE SINKING VOLUME AT TIE-DOWN CONDITION Measure the distance between the highest tire point and highest arch point before and after tie-down. Difference of measured values (sinking volume) should be within 50 mm (1.97 in) and make sure to fix the vehicle securely.

TOWING

Avoid towing vehicles except when the vehicle cannot be driven. For models with AWD, AT or VTD, use a loader instead of towing. When towing other vehicles, pay attention to the following to prevent hook or vehicle damage resulting from excessive weight.

Scheme 41

Scheme 42

Scheme 43

Scheme 44

Scheme 45

1. Do not tow other vehicles with a front tie-down hook.
2. Make sure the vehicle towing is heavier than the vehicle being towed.
3. Remove the hook cover, and then install the hook. CAUTION: Pull the screwdriver which is inserted into the hook cover. Do not remove the hook cover holding the slit of the hook cover.
4. NOTES TOWING PRECAUTIONS Towing Precautions AT Lifting up four wheels (On a trailer) Towing the vehicle after lifting up all four wheels is a basic rule for AWD model. o Rope Check if both front and rear wheels are rotated normally. Driving speed 30 km/h (19 MPH) or less Allow driving distance 50 km (31 miles) or less delta Raising the front wheels Prohibition X Lifting up the front wheels Prohibited, due to damage on bumper, front grille, etc. Do not raise the vehicle with bumper. X Marked o: OK, Marked X : Prohibited, Marked delta : Conditionally OK. CAUTION: Check ATF, gear oil and rear differential oil before driving. Place the shift lever in "N" position during towing. Do not lift up the rear wheels to avoid unsteady rotation. Turn the ignition key to "ACC", then check the steering wheel moves freely. Release the parking brake to avoid tire dragging. Since the power steering does not work, be careful for the heavy steering effort. (When engine is stopped) Since the servo brake does not work, be careful that the brake is not applied effectively. (When engine is stopped) In case of the malfunction of internal transmission or drive system, lift up four wheels (on a trailer) for towing.

Scheme 46

Scheme 47

1. AT THE CHECK AND GENERAL MAINTENANCE
2. WHEN WIDER HOOD OPENING IS NECESSARY Set the damper stay below as shown in the figure.

AWD CIRCUIT MEASURES

Since VTD type is used in the center differential, cut-off of AWD circuit cannot be carried out.

Scheme 48

Scheme 49

1. Rear wheel free roller system Set the free roller on the floor of rear wheel side securely according to the wheel base and rear tread of the vehicle. Let the vehicle ride on the tester and free roller gently. CAUTION: Fix the vehicle using a pulling metal (chain or wire) to the front and rear towing hooks or tie-down hook to prevent the lateral runout of front wheels and springing out of vehicle. Set the speedometer tester. Conduct the speedometer test work. CAUTION: Do not suddenly accelerate or decelerate while working.
2. Rear wheel jack-up system Set the vehicle on speedometer tester. CAUTION: Fix the vehicle using a pulling metal (chain or wire) to the front and rear towing hooks or tie-down hook to prevent the lateral runout of front wheels and springing out of vehicle. Jack up the rear wheels and set the rigid racks to the specified locations of side sill. Conduct the speedometer test work. CAUTION: Do not suddenly accelerate or decelerate while working.

Scheme 50

1. Keep the front or rear wheels on the ground during measurement.
2. When the brake dragging force is large, inspect whether there is dragging in the brake or brake shoe. Specifications: BRAKING FORCE SPECIFICATION Braking force Rear wheel total 10% or more of load on front or rear wheels Difference between right and left wheels 8% or less of load on front or rear wheels Grand total 50% or more of vehicle weight at the time of test When measurement is difficult to carry out because both of front wheels are locked, check if braking force measurement in this condition conforms to standard grand total.

ON THE CAR WHEEL BALANCING

Scheme 51

1. Set the rigid rack to the specified locations of side sill, jack up the front or rear two wheels of non-measuring side and set the pickup stands to two wheels of measuring side.
2. For drive wheel, drive the tires with engine for measurement.
3. For non-drive wheel, drive the tires from the on the car wheel balancer for measurement.

MEANING OF V.I.N

The meaning of the V.I.N, is as follows

]4S4WX92DX94400001[

The starting and ending brackets (] [) are stop marks.

CODE REFERENCE

MODEL NUMBER LABEL

The model number label indicates the type, V.I.N. Ref. to MEANING OF V.I.N. , IDENTIFICATION, Identification, applied model, option code, trim code, engine type, transmission type and the exterior color code.

WXFDY2U

CODE REFERENCE

The engine and transmission type are as follows.

ENGINE

EZ36DBC3LB

CODE REFERENCE

TRANSMISSION

TG5D9CJCAA

CODE REFERENCE

REAR DIFFERENTIAL

XB

REDUCTION GEAR RATIO CHART

OPTION

C0CQ

CODE CHART

OPTION LIST

OPTION LIST REFERENCE

To insure the best performance, always use the specified oil, gasoline, adhesive, sealant, etc. or a substitute of equivalent quality.

Always use gasoline of the same or higher octane value than specified in the owner's manual. Ignoring the specifications below will result in damage or poor performance of engine and fuel injection system. Use the specified gasoline to correct performance.

Unleaded gasoline

In order to reduce air pollution, use unleaded gasoline for the vehicle equipped with catalytic converter. Using leaded gasoline may damage the catalytic converter.

LUBRICANTS

Use either lubricants in the chart below or equivalent lubricants. See the table below to choose the correct SAE viscosity.

LUBRICANTS CHART Lubricants Recommended materials API standard ILSAC Standard Engine oil Choose oil suitable for the standard from the right. SM "Energy-saving type" GF-4 AT front differential gear oil GL-5 - Rear differential gear oil GL-5

Scheme 52

Scheme 53

Scheme 54

Scheme 55

COOLANT

Use genuine coolant to protect the engine.

RECOMMENDED MATERIALS REFERENCE

REFRIGERANT

Standard air conditioners on Subaru vehicles use HFC134a refrigerant. Do not mix it with other refrigerants. Also, do not use any compressor oil other than DENSO OIL 8.

RECOMMENDED MATERIALS REFERENCE

GREASE

Use grease and supplementary lubricants shown in the table below.

RECOMMENDED MATERIALS REFERENCE

ADHESIVE

Use the adhesives shown in the table below, or equivalent.

RECOMMENDED MATERIALS REFERENCE

SEAL MATERIAL

Use the seal material shown in the table below, or equivalent.

RECOMMENDED MATERIALS REFERENCE

ATF FILTER

Note. Basically, the ATF filter is maintenance free, but when it is rusted or physically damaged or leaking, the ATF filter needs to be replaced.

For the replacement procedure of ATF filter, refer to ATF FILTER .

FRONT DIFFERENTIAL

Scheme 56

Scheme 57

1. Drain the differential gear oil by removing drain plug using TORX® bit T70. NOTE: Before starting work, cool off the differential gear oil well.
2. Replace the gasket with new part, and then tighten the drain plug to specified torque. Tightening torque: 70 N.m (7.1 kgf-m, 51.6 ft-lb)
3. Fill differential gear oil through the oil level gauge hole up to the upper point of level gauge. Recommended gear oil: Refer to «LUBRICANTS»(ref-356682-S03822014042010022700000) , RECOMMENDED MATERIALS, Recommended Materials. NOTE: Each oil manufacturer has its base oil and additives. Thus, do not mix two or more brands. Gear oil capacity: 1.3 - 1.5 l (1.4 - 1.6 US qt, 1.1 - 1.3 lmp qt)

Scheme 58

1. Drain the oil by removing drain plug.
2. Remove the filler plug for quick draining oil.
3. Tighten the drain plug after draining oil and replacing with a new gasket. Tightening torque: 50 N.m (5.1 kgf-m, 36.9 ft-lb)
4. Pour oil to the bottom end of filler plug hole. Recommended gear oil: Refer to «LUBRICANTS»(ref-356682-S03822014042010022700000) , RECOMMENDED MATERIALS, Recommended Materials. Oil capacity: 0.8 l (0.8 US qt, 0.7 lmp qt) NOTE: Each oil manufacturer has its base oil and additives. Thus, do not mix two or more brands.
5. Replace the gasket with a new part and tighten the filler plug. Tightening torque: 50 N.m (5.1 kgf-m, 36.9 ft-lb)

Scheme 59

Scheme 60

1. Check for scratches, swelling, corrosion, traces of fluid leakage on the brake hoses or pipe joints.
2. Check the possibility of adjacent parts interfering with brake pipes/hoses during driving, and loose connections/clamps.
3. Check any trace of fluid leakage, scratches, etc. on master cylinder, wheel cylinder and pressure control valve. NOTE: When the brake fluid level in the reservoir tank is lower than specified limit, the brake warning light on the combination meter will come on. Visually check the brake hose for damage. (Use a mirror where it is difficult to see)

Scheme 61

Scheme 62

Scheme 63

1. Check the free play of brake pedal with pulling up the force of less than 10 N (1 kgf, 2 lb). Brake pedal free play (Pulling up direction of pedal) 0.5 - 2.0 mm (0.02 - 0.08 in)
2. If the free play is out of specifications above, adjust the brake pedal as follows. Make sure the engine is off. (No vacuum is applied to brake booster.) There should be play between brake booster clevis and pin at brake pedal installing portion. [Pulling up the brake pedal pad with a force of 10 N (1 kgf, 2 lb) or less to a stroke of 0.5 to 2.0 mm (0.02 to 0.08 in).] If there is no free play between clevis pin and clevis, turn brake switch adjusting nut until the clearance between stopper and screw of brake switch becomes 0.8 mm (0.031 in).
3. Check the pedal stroke. While the engine is idling, depress the brake pedal with a 500 N (51 kgf, 112 lb) load and measure the distance between the brake pedal and steering wheel. With the brake pedal released, measure the distance between pedal and steering wheel again. The difference between the two measured values must be less than specified value. If the measured value is more than specification, there is possibility of entering air in hydraulic unit. Brake pedal stroke A: 115 mm (4.5 in)/500 N (51 kgf, 112 lb) or less
4. Check to see if air is in the hydraulic brake line by the feel of pedal operation. If air appears to exist in the line, bleed it from the system.
5. Check for even operation of all brakes, using a brake tester or by driving the vehicle for a short distance on a straight road.

Scheme 64

1. With the engine off, depress the brake pedal several times applying the same pedal force. Make sure the travel distance should not change.
2. With the brake pedal depressed, start the engine. Make sure the pedal should move slightly toward the floor.
3. With the brake pedal depressed, stop the engine and keep the pedal depressed for 30 seconds. Make sure the pedal height should not change.
4. A check valve is incorporated into the vacuum hose part. Disconnect the vacuum hose to inspect function of check valve. Make sure air flows from the booster end to engine end but does not flow in the opposite direction in the check valve.
5. Check the vacuum hose for cracks or other damage. NOTE: When installing the vacuum hose on the engine and brake booster, do not use soapy water or lubricating oil on their connections.
6. Check the vacuum hose to make sure it is tightly secured.

Scheme 65

Scheme 66

1. Either jack-up the vehicle and place a rigid rack under it, or lift up the vehicle.
2. Remove all the wheels.
3. Drain the brake fluid from master cylinder.
4. Refill the reservoir tank with recommended brake fluid. Recommended brake fluid: Refer to «FLUID»(ref-356682-S31460915222010022700000) , RECOMMENDED MATERIALS, Recommended Materials. NOTE: Avoid mixing different brands of brake fluid to prevent degrading the quality of fluid. Be careful not to allow dirt or dust to get into the reservoir tank. Bleeding sequence (1) --> (2) --> (3) --> (4)
5. Install one end of a vinyl tube onto the air bleeder and insert the other end of the tube into a container to collect the brake fluid. NOTE: Cover the bleeder with cloth, when loosening it, to prevent brake fluid from being splashed over surrounding parts. While bleeding air, keep the reservoir tank filled with brake fluid to prevent entry of air. Operate the brake pedal slowly. For convenience and safety, perform work with 2 people. The amount of brake fluid required is approx. 600 m l (20.3 US fl oz, 21.1 lmp fl oz) for total brake system.
6. Instruct your co-worker to depress the brake pedal slowly two or three times and then hold it depressed.
7. Loosen the bleeder screw approximately 1/4 turn until a small amount of brake fluid drains into the container, and then quickly tighten the screw.
8. Repeat steps 6 ) and 7 ) until there are no air bubbles in drained brake fluid and new fluid flows through vinyl tube. NOTE: Add brake fluid as necessary while bleeding air, so that the brake fluid in the tank is always between MAX and MIN.
9. After completing the bleeding operation, hold the brake pedal depressed and tighten the screw and install bleeder cap. Tightening torque: 8 N.m (0.8 kgf-m, 5.8 ft-lb)
10. Bleed air from each wheel cylinder by following steps from 5 ) to 9 ).
11. Depress the brake pedal with a force of approx. 294 N (30 kgf, 66 lb) and hold it there for approx. 20 seconds. At this time check the pedal to see if it makes any unusual movement. Visually inspect the bleeder screws and brake pipe joints to confirm there is no fluid leakage.
12. Install the wheels, and drive the vehicle for a short distance between 2 to 3 km (1 to 2 mile) to confirm brakes are operating properly.

Scheme 67

Scheme 68

Scheme 69

1. Jack-up the vehicle and support with rigid racks. Then remove the wheels.
2. Visually check the pad thickness through inspection hole of disc brake assembly. Replace the pad if necessary. NOTE: When replacing a pad, always replace the pads for both the left and right wheels at the same time. Also replace the pad clips if they are twisted or worn. Front PAD THICKNESS CHART Pad thickness mm (in) Standard value 11 (0.43) Wear limit 1.5 (0.059) Rear PAD THICKNESS CHART Pad thickness mm Standard value 11 (0.43) Wear limit 1.5 (0.059)
3. Check the disc rotor, and correct or replace if it is damaged or worn. Front DISC ROTOR THICKNESS CHART Disc rotor thickness mm (in) Standard value 30 (1.18) Wear limit 28 (1.10) Rear DISC ROTOR THICKNESS CHART Disc rotor thickness mm (in) Standard value 18 (0.71) Wear limit 16 (0.63)
4. Remove the caliper body. Ref. to «FRONT DISC BRAKE ASSEMBLY»(ref-356689-S38870480632010022700000) . Ref. to «REAR DISC BRAKE ASSEMBLY»(ref-356689-S25523142722010022700000) .
5. Tighten the wheel nuts to secure disc rotor.
6. Set a dial gauge at a point of 10 mm (0.39 in) or less from outer periphery of the rotor, and then measure the disc rotor runout. Disc rotor runout limit: Front: 0.05 mm (0.002 in) Rear: 0.05 mm (0.002 in)

FRONT, REAR SUSPENSION BUSHING

Apply pressure with tire lever etc. to inspect the bushing for abnormal fatigue or damage. Replace the bushings and the arm assembly or link assembly if there is abnormal fatigue or damage.

Scheme 70

WHEEL ARCH HEIGHT

1. Unload the cargoes and set the vehicle in curb weight (empty) condition.
2. Check the wheel arch height of the front and rear suspensions to ensure that they are within specified values. Ref. to «WHEEL ALIGNMENT»(ref-356690-S01746904132010022700000) .
3. When the wheel arch height is out of standard, visually inspect following components and replace deformed parts. Suspension components [Front strut assembly and rear shock absorber assembly] Parts connecting suspension and body
4. When no components are deformed, adjust wheel arch height by replacing coil spring in the suspension whose wheel arch height is out of standard. Ref. to «WHEEL ALIGNMENT»(ref-356690-S01746904132010022700000) . Ref. to «WHEEL ALIGNMENT»(ref-356691-S05856686962010022700000) .

OIL LEAKAGE OF STRUT AND SHOCK ABSORBER

Visually inspect the front strut and rear shock absorber for oil leakage. Replace the front strut and rear shock absorber if oil leaks excessively.

TIGHTNESS OF BOLTS AND NUTS

Check the bolts and nuts for looseness. Retighten the bolts and nuts to specified torque. If the self-locking nuts and bolts are removed, replace them with new parts.

1. Front suspension Ref. to «GENERAL DESCRIPTION»(ref-356690-S02651504512010022700000) .
2. Rear suspension Ref. to «GENERAL DESCRIPTION»(ref-356691-S11583207042010022700000) .

DAMAGE TO SUSPENSION PARTS

Check the following parts and the fastening portion of the vehicle body for deformation or excessive rusting which impairs the suspension. If necessary, replace the damaged parts with new parts. If minor rust formation, pitting, etc. are noted, remove the rust and take rust prevention measure.

1. Front suspension Front arm Crossmember Strut
2. Rear suspension Upper arm Front lateral link Rear lateral link Rear trailing link Rear sub frame Shock absorber
3. In the area where salt is sprayed to melt snow on a road in winter, check suspension parts for damage caused by rust every 12 months after lapse of 60 months. Take rust prevention measures as required.

FRONT WHEEL BEARING

Note. Inspect the condition of front wheel bearing grease.

Scheme 71

1. Jack-up the front side of vehicle.
2. While holding the front wheel by hand, swing it in and out to check bearing free play.
3. Loosen the wheel nuts, and remove the front wheel.
4. If the bearing free play exists in step 2 ) above, attach a dial gauge to the hub and measure axial play in axial direction. Service limit: Straight-ahead position within 0.05 mm (0.0020 in)
5. Remove the bolts and self-locking nuts, and extract the front arm from front crossmember.
6. Remove the PTJ of front drive shaft from transmission. Ref. to «FRONT DRIVE SHAFT»(ref-356692-S03870673382010022700000) .
7. While supporting the front drive shaft horizontally with one hand, turn the hub with the other hand to check for noise or binding. If the hub is noisy or binds, replace the front axle.

REAR WHEEL BEARING

1. Jack-up the rear side of vehicle.
2. While holding the rear wheel by hand, swing it in and out to check bearing free play.
3. Loosen the wheel nuts, and remove the rear wheel.
4. If the bearing free play exists in step 2 ) above, attach a dial gauge to the hub and measure axial play in axial direction. Service limit: Straight-ahead position within 0.05 mm (0.0020 in)
5. Remove the DOJ of rear drive shaft from rear differential. Ref. to «REAR DRIVE SHAFT»(ref-356692-S36292863892010022700000) .
6. While supporting rear drive shaft horizontally with one hand, turn the hub with the other hand to check for noise or binding. If the hub is noisy or binds, replace the rear axle.

FRONT AND REAR AXLE BOOTS

Inspect the front axle boots (A) and rear axle boots (B) for deformation, damage or failure. If faulty, replace with a new part. Ref. to FRONT DRIVE SHAFT . Ref. to REAR DRIVE SHAFT .

Scheme 72

Scheme 73

1. Front
2. Rear

PROPELLER SHAFT

Inspect the propeller shaft for damage or failure. If faulty, replace with a new part. Ref. to PROPELLER SHAFT .

Scheme 74

Scheme 75

Scheme 76

1. When the tread has worn down to 1.8 mm (0.071 in) or the wear indicator appears across the tread, replace the tire. (Replace the right and left tire as a set.)
2. If the tire appears to be worn unevenly, adjust the wheel alignment.
3. Rotate tires periodically (12,000 km/7,500 miles) as shown in the figure, in order to prevent them from uneven wear and to prolong their life. Without instruction for the direction of tire rotation With instruction for the direction of tire rotation

Scheme 77

1. Set the steering wheel in a straight-ahead position, and check the wheel spokes to make sure they are correctly set in their specified positions.
2. Lightly turn the steering wheel to the left and right to determine the point where front wheels start to move. Measure the distance of the movement of steering wheel at the outer periphery of wheel. Steering wheel free play: 0 - 17 mm (0 - 0.67 in) Move the steering wheel vertically toward the shaft to ascertain if there is play in the direction. Maximum permissible play: 0.5 mm (0.020 in)
3. Drive the vehicle and check the following items during operation. Steering force: The effort required for steering should be smooth and even at all points, and should not vary. Pulled to one side: Steering wheel should not be pulled to either side while driving on a level surface. Wheel runout: Steering wheel should not show any sign of runout. Return factor: Steering wheel should return to its original position after it has been turned and then released.

STEERING SHAFT JOINT

When the steering wheel free play is excessive, disconnect the universal joint of steering shaft and check it for any play and yawing torque (at the point of the crossing direction). Also inspect for any damage to sealing or worn serrations. If the joint is loose, retighten the mounting bolts to the specified torque.

Tightening torque: 24 N.m (2.4 kgf-m, 17.7 ft-lb)

Scheme 78

Scheme 79

Scheme 80

1. With the vehicle placed on a level surface, turn the steering wheel 90° in both the left and right directions. While the wheel is being rotated, reach under the vehicle and check for looseness in gearbox. Tightening torque: 60 N.m (6.1 kgf-m, 44.1 ft-lb)
2. Check the boot for damage, cracks or deterioration.
3. With the vehicle placed on a level surface, quickly turn the steering wheel to the left and right. While steering wheel is being rotated, check the gear backlash. If any noise is noticed, adjust the gear backlash.
4. Apply liquid gasket to at least 1/3 of entire perimeter of adjusting screw thread.
5. Tighten the adjusting screw to 25 N.m (2.5 kgf-m, 18.1 ft-lb) and then loosen.
6. Tighten the adjusting screw to 5.9 N.m (0.60 kgf-m, 4.4 ft-lb) and then loosen 20°.
7. Install the lock nut. While holding the adjusting screw with wrench, tighten the lock nut using ST. ST 926230000 SPANNER Tightening torque (lock nut): 25 N.m (2.5 kgf-m, 18.4 ft-lb) Hold the adjusting screw with wrench to prevent it from turning while tightening the lock nut.

Scheme 81

1. Check the tie-rod and tie-rod ends for bends, scratches or other damage.
2. Check the connections of knuckle ball joints for play, inspect for damage on dust seals, and check free play of ball studs. If the castle nut is loose, re-tighten it to the specified torque, then tighten it further up to 60° until the cotter pin hole is aligned. Tightening torque: 27 N.m (2.75 kgf-m, 19.9 ft-lb)
3. Check the lock nut on the tie-rod for tightness. If it is loose, retighten it to the specified torque. Tightening torque: 85 N.m (8.7 kgf-m, 63 ft-lb)

HOSES OF OIL PUMP FOR DAMAGES

Check the pressure hose and return hose of oil pump for crack, swell or damage. Replace the hose with a new part if necessary.

Note. Prevent hoses from turning and/or bending when installing hoses.

Scheme 82

POWER STEERING PIPES FOR DAMAGES

Check the power steering pipes for corrosion and damage.

Replace the pipes with new parts if necessary.

GEARBOX BOOTS

Inspect both sides of the gearbox boot as follows, and correct the defects if necessary.

Scheme 83

1. Positions (A) and (B) of the gearbox boot are fitted correspondingly in grooves (A) and (B) of the gearbox and rod (C).
2. Clips are fitted outside of positions (A) and (B) of boot.
3. Boot does not have crack or hole. NOTE: Rotate (B) position of gearbox boot against the torsion produced by the adjustment of toe-in etc. Apply grease to the groove (C).

FITTING BOLTS AND NUTS

Inspect the fitting bolts and nuts of oil pump and bracket for looseness, and retighten them if necessary.

Inspect and/or retighten them when engine is cold.
