MAINTENANCE
- Maintenance instructions for serviceable parts describe work area and detailed step with illustration. It also describes the use of special tool, tightening torque, caution for each procedure.
- If many serviceable parts are included in one service procedure, appropriate reference is provided for each parts.
Example
Scheme 34
BRAKE FLUID
If brake fluid gets in your eyes or on your skin, do the following
- Wash eyes and seek immediate medical attention.
- Wash your skin with soap and then rinse thoroughly with water.
Follow all government regulations concerning disposal of refuse when disposing.
PROTECTING VEHICLE UNDER MAINTENANCE
Make sure to attach the fender cover, seat covers, etc. before work.
FLUID
Use the fluids specified in the table below. Do not mix two different kinds or makes of fluid.
| CAUTION | Always use the recommended or equivalent ATF. Using material except recommended one or substitute would cause trouble. |
| Fluid | Recommended materials | Alternative | Remarks |
|---|---|---|---|
| Automatic transmission fluid | SUBARU ATF HP | IDEMITSU: ATF HP | |
| Power steering fluid | DEXRON III or SUBARU ATF | ||
| Brake fluid | FMVSS No. 116DOT3 | DOT4 |
RECOMMENDED MATERIALS REFERENCE
MAINTENANCE SCHEDULE 1
| Maintenance interval Number of months or km (miles), whichever occurs first] | |||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Months | 3 | 7.5 | 15 | 22.5 | 30 | 37.5 | 45 | 52.5 | 60 | 67.5 | 75 | 82.5 | 90 | 97.5 | 105 | 112.5 | 120 | Remarks | |
| X 1,000 km | 4.8 | 12 | 24 | 36 | 48 | 60 | 72 | 81.4 | 96 | 108 | 120 | 132 | 144 | 156 | 168 | 180 | 192 | ||
| X 1,000 miles | 3 | 7.5 | 15 | 22.5 | 30 | 37.5 | 45 | 52.5 | 60 | 67.5 | 75 | 82.5 | 90 | 97.5 | 105 | 112.5 | 120 | ||
| 1 | Engine oil | R | R | R | R | R | R | R | R | R | R | R | R | R | R | R | R | R | |
| 2 | Engine oil filter | R | R | R | R | R | R | R | R | R | R | R | R | R | R | R | R | R | |
| 3 | Spark plug | R | R | ||||||||||||||||
| 4 | Drive belt(s) | I | I | I | R | ||||||||||||||
| 5 | Fuel line | (I) | (I) | (I) | I | Note (1) | |||||||||||||
| 6 | Air cleaner element | R | R | R | R | Note (2) | |||||||||||||
| 7 | Cooling system | I | I | I | I | ||||||||||||||
| 8 | Engine coolant | Replace after the first 11 years or 220,000 km (137,500 miles), and every six years or 120,000 km (75,000 miles) thereafter | |||||||||||||||||
| 9 | ATF | I | I | I | I | Note (3) | |||||||||||||
| 10 | Front and rear differential oil | I | I | I | I | ||||||||||||||
| 11 | Brake line | I | I | I | I | I | I | I | I | ||||||||||
| 12 | Brake fluid | R | R | R | R | ||||||||||||||
| 13 | Disc brake pad and disc | I | I | I | I | I | I | I | I | ||||||||||
| 14 | Parking brake | I | I | I | I | I | I | I | I | ||||||||||
| 15 | Suspension | I | I | I | I | I | I | I | I | ||||||||||
| 16 | Wheel bearing | (I) | (I) | ||||||||||||||||
| 17 | Axle boots and joints | I | I | I | I | I | I | I | I | ||||||||||
| 18 | Tire rotation | I | I | I | I | I | I | I | I | I | I | I | I | I | I | I | I | Note (4) | |
| 19 | Steering system (Power steering) | I | I | I | I | I | I | I | I | ||||||||||
| 20 | Supplemental Restraint System "Airbag" | Inspect every 10 years | |||||||||||||||||
| 21 | A/C filter | Replace every 15 months or 24,000 km (15,000 miles). | Note (5) | ||||||||||||||||
| Symbols used: R: Replace I: Inspection (R) or (I): Recommended service for safe vehicle operation. | |||||||||||||||||||
| (1) This inspection is not required to maintain emission warranty eligibility and it dose not affect the manufacturer's obligations under EPA's in-use compliance program. (2) When the vehicle is used in extremely dusty conditions, the air cleaner element should be replaced more often. (3) ATF filter is maintenance free part. ATF filter needs replacement, when it has physically rust, damaged or ATF leaked. (4) A tire should be replaced when the tread wear indicator appears as a solid band across the tread. The indicators appear when the remaining tread has been worn to 1.8 mm (0.071 in) or less. (5) When the A/C filter is mounted | |||||||||||||||||||
| (1) | This inspection is not required to maintain emission warranty eligibility and it dose not affect the manufacturer's obligations under EPA's in-use compliance program. |
| (2) | When the vehicle is used in extremely dusty conditions, the air cleaner element should be replaced more often. |
| (3) | ATF filter is maintenance free part. ATF filter needs replacement, when it has physically rust, damaged or ATF leaked. |
| (4) | A tire should be replaced when the tread wear indicator appears as a solid band across the tread. The indicators appear when the remaining tread has been worn to 1.8 mm (0.071 in) or less. |
| (5) | When the A/C filter is mounted |
MAINTENANCE SCHEDULE 1
MAINTENANCE SCHEDULE 2
| Item | Maintenance interval | Repeat short distance drive | Repeat rough/muddy road drive | Extremely cold weather area | Salt or other corrosive used or coastal area | High humidity or mountain area | Repeat towing trailer |
|---|---|---|---|---|---|---|---|
| Engine oil | 3.75 months | R | R | R | |||
| 6,000 km | |||||||
| 3,750 miles | |||||||
| Engine oil filter | 3.75 months | R | R | R | |||
| 6,000 km | |||||||
| 3,750 miles | |||||||
| Fuel line | 7.5 months | I | |||||
| 12,000 km | |||||||
| 7,500 miles | |||||||
| ATF | 15 months | R | |||||
| 24,000 km | |||||||
| 15,000 miles | |||||||
| Front & rear differential oil | 15 months | R | |||||
| 24,000 km | |||||||
| 15,000 miles | |||||||
| Brake line | 7.5 months | I | |||||
| 12,000 km | |||||||
| 7,500 miles | |||||||
| Brake fluid | 15 months | R | |||||
| 24,000 km | |||||||
| 15,000 miles | |||||||
| Disc brake pad & disc | 15 months | I | I | I | I | ||
| 24,000 km | |||||||
| 15,000 miles | |||||||
| Parking brake | 15 months | I | I | I | I | ||
| 24,000 km | |||||||
| 15,000 miles | |||||||
| Suspension | 7.5 months | I | I | I | |||
| 12,000 km | |||||||
| 7,500 miles | |||||||
| Axle boots & joints | 7.5 months | I | I | I | I | I | |
| 12,000 km | |||||||
| 7,500 miles | |||||||
| Steering system (Power steering) | 7.5 months | I | I | I | |||
| 12,000 km | |||||||
| 7,500 miles |
MAINTENANCE SCHEDULE 2
POWER STEERING FLUID LEVEL
Note. At power steering fluid temperature 20°C (68°F); read the fluid level on the "COLD" side. At power steering fluid temperature 80°C (176°F); read the fluid level on the "HOT" side.
Scheme 35
- Place the vehicle with engine "OFF" on a level surface.
- Check the fluid level using the scale on the outside of the reservoir tank. If the level is below "MIN", add fluid to bring it up to "MAX". NOTE: If fluid level is at MAX level or above, drain fluid to keep the level in the specified range of indicator by using a syringe or the like. Recommended fluid: Refer to «FLUID»(ref-356682-S31460915222010022700000) , RECOMMENDED MATERIALS, Recommended Materials. Fluid capacity: 0.9 l (1.0 US qt, 0.8 lmp qt)
POWER STEERING FLUID FOR LEAKS
Inspect the underside of oil pump and gearbox of power steering system, hoses, pipes and their couplings for fluid leaks.
If the fluid leaks are found, retighten their fitting bolts (or nuts) and/or replace their parts.
Note. Wipe the leaked fluid off after correcting fluid leaks. Also pay attention to clearances between hoses (or pipes) and other parts when inspecting fluid leaks.
