Brake System: Overhaul Subaru Outback BR рестайлинг

DISASSEMBLY

Scheme 76

Scheme 77

Scheme 78

Scheme 79

1. Remove mud and foreign matter from the caliper body.
2. Remove the piston. Place a wooden block in the caliper body as shown in the figure to prevent the piston from jumping out and being damaged. Using an air gun, gradually apply compressed air via the brake hose installation hole to push the piston out.
3. Remove the piston boot from caliper body cylinder.
4. Remove the piston seal from caliper body cylinder. CAUTION: Do not damage the cylinder and piston seal groove.
5. Remove the guide pin, lock pin, bushing pin, and pin boot from the support.

Scheme 80

Scheme 81

Scheme 82

1. Before assembly, check each part. Refer to «INSPECTION»(ref-565173-S23190653102013071000000) .
2. Clean the inside of the caliper body cylinder using brake fluid.
3. Apply a coat of brake fluid to piston seal and install the piston seal to the caliper body cylinder groove.
4. Apply a coat of brake fluid to the inner surface of caliper body cylinder and the entire outer surface of the piston.
5. Apply grease contained in the piston seal kit to the piston boot, and install it to the groove at the end of the cylinder.
6. Insert the piston into caliper body cylinder. CAUTION: Do not force the piston into caliper body cylinder.
7. Position the piston boot in the grooves on caliper body cylinder and piston.
8. Apply grease contained in the piston seal kit to the lock pin, guide pin outer surface, support cylinder inner surface, and pin boot grooves.
9. Install the pin boot to the lock pin and guide pin, and insert it into the support cylinder. CAUTION: Insert the lock pin and guide pin into specified position, and make sure that they slide and seat properly.

Scheme 83

Scheme 84

Scheme 85

Scheme 86

1. Remove mud and foreign matter from the caliper body.
2. Remove the piston boot from caliper body cylinder.
3. Remove the piston. Place a wooden block in the caliper body as shown in the figure to prevent the piston from jumping out and being damaged. Using an air gun, gradually apply compressed air via the brake hose installation hole to push the piston out.
4. Remove the piston seal from caliper body cylinder. CAUTION: Do not damage the cylinder and piston seal groove.
5. Remove the guide pin, lock pin, bushing pin, and pin boot from the support.

Scheme 87

Scheme 88

1. Before installation, check each part. Refer to «INSPECTION»(ref-565173-S03118774172013071000000) .
2. Clean the inside of the caliper body cylinder using brake fluid.
3. Apply a coat of brake fluid to piston seal and install the piston seal to the caliper body cylinder groove.
4. Apply a coat of brake fluid to the inner surface of caliper body cylinder and the entire outer surface of the piston.
5. Apply grease contained in the piston seal kit to the piston boot, and install it to the groove at the end of the cylinder.
6. Insert the piston into caliper body cylinder. CAUTION: Do not force the piston into caliper body cylinder.
7. Position the piston boot in the grooves on caliper body cylinder and piston.
8. Apply grease contained in the piston seal kit to the lock pin, guide pin outer surface, support cylinder inner surface, and pin boot grooves.
9. Install the pin boot to the lock pin and guide pin, and insert it into the support cylinder. CAUTION: Insert the lock pin and guide pin into specified position, and make sure that they slide and seat properly.
