Engine Ignition System (H6DO): Removal & Installation Subaru Outback BR рестайлинг

REMOVAL

Spark plug

Refer to SPECIFICATION .

Scheme 17

Scheme 18

Scheme 19

Scheme 20

1. Remove the collector cover. NOTE: Follow the steps below when removing the collector cover. Pull up the two points at the rear (A). Pull up the two points at the front (B) while moving them forward.
2. Disconnect the ground cable from battery.
3. Remove the air cleaner case. Refer to «REMOVAL»(ref-565165-S02004603892013071000000) .
4. Remove the engine harness stay (A).
5. Disconnect the connector (B) from ignition coil.
6. Remove the ignition coil. NOTE: Turn the #5 ignition coil to remove it.
7. Remove the spark plug with a spark plug socket.

Scheme 21

Scheme 22

Scheme 23

Scheme 24

1. Remove the collector cover. NOTE: Follow the steps below when removing the collector cover. Pull up the two points at the rear (A). Pull up the two points at the front (B) while moving them forward.
2. Remove the battery and battery carrier. Refer to «REMOVAL»(ref-565199-S16388899782013071000000) .
3. Remove the engine harness stay (A).
4. Disconnect the connector (B) from ignition coil.
5. Remove the ignition coil. NOTE: Turn the #6 ignition coil to remove it.
6. Remove the spark plug with a spark plug socket.

Direct ignition type has been adopted. Refer to REMOVAL .

INSTALLATION

Install in the reverse order of removal.

Tightening torque

16 N.m (1.6 kgf-m, 11.8 ft-lb)
