Engine Ignition System (H4DO): Removal & Installation Subaru Outback BR рестайлинг

REMOVAL

Spark plug

Refer to SPECIFICATION .

Scheme 7

Scheme 8

1. Disconnect the ground cable from battery.
2. Remove the air cleaner case. Refer to «REMOVAL»(ref-565164-S08661706992013071000000) .
3. Disconnect the connector from ignition coil.
4. Remove the ignition coil.
5. Remove the spark plug with a spark plug socket.

Scheme 9

1. Disconnect the ground cable from battery.
2. Disconnect the connector from ignition coil.
3. Remove the ignition coil.
4. Remove the spark plug with a spark plug socket.

Direct ignition type is adopted. Refer to REMOVAL .

INSTALLATION

Direct ignition type is adopted. Refer to INSTALLATION .
