Maintenance Reminder Light Reset Procedures: Maintenance Subaru Outback BR

EGR WARNING LIGHT RESET - PROCEDURE 1

EGR warning light will come on every 60, 000 miles as a reminder to service EGR system. To reset light after servicing, remove left cover under instrument panel. Pull down connectors behind fuse panel. Unplug connector from Blue connector, and plug it into Green connector.

MAINTENANCE REMINDER DISPLAY

Note. To determine the appropriate reset procedure, refer to MAINTENANCE REMINDER DISPLAY RESET INDEX . Only vehicles listed in this index have a Maintenance Reminder Display reset procedure.

MAINTENANCE REMINDER DISPLAY RESET INDEX

MAINTENANCE REMINDER DISPLAY RESET - PROCEDURE 1

To reset the Maintenance Reminders in the multi-function display see the procedure below. The resettable maintenance items are

1. Engine Oil
2. Oil Filter
3. Tires
4. Maintenance Schedule

1. Turn the ignition switch to the ON position.
2. Pull and hold the steering wheel SET switch toward you to show the SETTING screen. (Scheme 1)and (Scheme 3). NOTE: On models with multi-function display controls on the center console, pushing the ENTER button replaces references to the SET switch. (Scheme 2)
3. After the SETTING screen is displayed, operate the ARROW buttons to highlight the MAINTENANCE item. Then, pull the SET switch toward you.
4. Operate the ARROW buttons to highlight the maintenance item you wish to reset. Then, pull the SET switch toward you.
5. Operate the ARROW buttons to highlight either category: DATE or DISTANCE. Then, pull the SET switch toward you.
6. Operate the ARROW buttons to enter a date or distance. Then, pull the SET switch toward you. NOTE: If you wish to set the other category, operate the ARROW buttons to highlight that category, pull the SET switch toward you, and proceed as before.
7. Highlight "Set" by operating the ARROW buttons, and confirm the setting by pulling the SET switch toward you.
8. The system will notify you that the setting is complete.

Scheme 1

Scheme 2

Scheme 3

TPMS RESET - PROCEDURE 1

Note. If tires are rotated, tire pressure sensor or TPM control module is replaced, or when wheels are changed (i.e., when snow tires are installed), the tire pressure sensor IDs must be registered.

Note. If tires were rotated, the performance and function of TPM system is not affected. However, correct tire positions will not displayed in the Subaru Select Monitor.

Note. In the following procedures, the Subaru Select Monitor and Transmitter Registration Tool (TPM-00012 or Kent-Moore Part No. FJ45295) must be used.

TPMS RESET - PROCEDURE 2

Note. If tires are rotated, tire pressure sensor or TPM control module is replaced, or when wheels are changed (i.e., when snow tires are installed), the tire pressure sensor IDs must be registered.

Note. If tires were rotated, the performance and function of TPM system is not affected. However, correct tire positions will not displayed in the Subaru Select Monitor.

Note. In the following procedures, the Subaru Select Monitor (SSM3) and Transmitter Registration Tool (TPM-00012 or Kent-Moore Part No. FJ45295) must be used.
