SPECIAL TOOL
SPECIAL TOOL DESCRIPTION ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 398477701 HANDLE Used for installing the front and rear bearing cones. 398477702 DRIFT Used for press-fitting the bearing race of differential carrier (front). (T-type) Used for press-fitting bearing race of differential carrier (rear). (VA1-type) Used for press-fitting side bearing race. (VA1-type) 398217700 ATTACHMENT SET Stand for rear differential carrier disassembly and assembly. 498447120 INSTALLER Used for installing the front oil seal. 498427200 FLANGE WRENCH Used for stopping rotation of companion flange when removing and tightening self-lock nut. 398467700 DRIFT Used for removing pinion, pilot bearing and front bearing cone. For T-type and VA1-type 399780104 WEIGHT Used for installing the front bearing cone and the pilot bearing companion flange. 899580100 INSTALLER Used for press-fitting the front bearing cone and pilot bearing. 899904100 STRAIGHT PIN REMOVER Used for removing the spring pin of the differential pinion shaft. 498247001 MAGNET BASE Used for measuring backlash between side gear and pinion, and hypoid gear. Used together with DIAL GAUGE (498247100). 498247100 DIAL GAUGE Used for measuring backlash between side gear and pinion, and hypoid gear. Used together with MAGNET BASE (498247001). 398507704 BLOCK Used for adjusting pinion height and preload. For T-type and VA1-type 398177700 INSTALLER Used for installing the rear bearing cone. For T-type and VA2-type 398457700 ATTACHMENT Used for removing the side bearing retainer. For T-type 398477703 DRIFT 2 Used for press-fitting bearing race (rear) of differential carrier. For T-type and VA2-type 398437700 DRIFT Used for installing the side oil seal. For T-type and VA2-type 398507702 DUMMY SHAFT Used for adjusting pinion height and preload. For T-type 398507703 DUMMY COLLAR Used for adjusting pinion height and preload. For T-type 398517700 REPLACER Used for removing rear bearing cone. For T-type and VA2-type 398487700 DRIFT Used for press-fitting side bearing cone. For T-type and VA2-type 398507701 DIFFERENTIAL CARRIER GAUGE Used for adjusting pinion height. For T-type 398527700 PULLER ASSY Used for removing front oil seal. Used for removing side bearing cup. (T-type) 398417700 DRIFT Used for installing side bearing race. For T-type and VA2-type 28099PA090 OIL SEAL PROTECTOR Used for installing the rear drive shaft to the rear differential. For oil seal protection 28099PA100 DRIVE SHAFT REMOVER Used for removing the rear drive shaft from rear differential. For T-type 399703600 PULLER ASSY Used for removing companion flange. 899874100 INSTALLER Used for installing the companion flange. 498077000 REMOVER Used for removing the differential side bearing cone. For VA2-type 899864100 REMOVER Used for removing the differential side bearing. 499277200 INSTALLER Used for installing the front bearing cone. For VA2-type 18758AA000 PULLER Used for removing side bearing cup. For VA2-type 18759AA000 PULLER ASSY Used for removing the differential side bearing cone. For T-type 18678AA000 DUMMY SHAFT Used for adjusting pinion height and preload. For VA2-type 18831AA010 DIFFERENTIAL CARRIER GAUGE Used for adjusting pinion height. For VA2-type 18630AA010 WRENCH COMPL RETAINER Used for removing and installing the side oil seal holder. For VA-type WRENCH ASSY (499787000) can also be used. 498175500 INSTALLER Used for installing the rear bearing cone. For VA1-type 498447100 INSTALLER Used for installing the oil seal. For VA1-type 399520105 SEAT Used for removing the side bearing cone. Used together with PULLER SET (899524100). For VA-type 899524100 PULLER SET Used for removing the differential side bearing cone. For VA-type Puller Cap 498485400 DRIFT Used for installing side bearing cone. For VA1-type 498505501 DIFFERENTIAL CARRIER GAUGE Used for adjusting pinion height. For VA1-type 498447110 DRIFT Used for press-fitting the bearing race (front) of the differential carrier. For VA1-type 498447150 DUMMY SHAFT Used for adjusting pinion height and preload. For VA1-type 498515500 REPLACER Used for removing rear bearing cone. For VA1-type 499705404 SEAT Used for removing the side bearing race. Used together with PULLER ASSY (499705401). For VA1-type 499705401 PULLER ASSY Used for removing the side bearing race. Used together with SEAT (499705404). For VA-type 18270KA020 SOCKET (E20) Used for removing and installing the hypoid driven gear. For VA2-type 18854AA000 ANGLE GAUGE Used for installing the hypoid driven gear. For VA2-type 41399FG000 SPECIAL TOOL ASSY Used for removing and installing the rear differential mount bushing. Use (1), (3), (5), (6), (7), (8) and (9) for removal. Use (2), (4), (5), (6), (7), (8) and (9) for installation. SPECIAL TOOL A (41399FG010) SPECIAL TOOL B (41399FG020) SPECIAL TOOL C (41399FG030) SPECIAL TOOL D (41399FG040) SPECIAL TOOL SLEEVE (41399FG050) SPECIAL TOOL RING (41399FG060) SPECIAL TOOL NUT (41399FG070) SPECIAL TOOL BEARING (41399FG080) SPECIAL TOOL SHAFT (41399FG090) 41399FG010 SPECIAL TOOL A Used for removing the rear differential mount bushing. For combination of tools for removal, refer to Fig. SPECIAL TOOL ASSY (41399FG000). 41399FG020 SPECIAL TOOL B Used for installing the rear differential mount bushing. For combination of tools for installation, refer to Fig. SPECIAL TOOL ASSY (41399FG000. 41399FG030 SPECIAL TOOL C Used for removing the rear differential mount bushing. For combination of tools for removal, refer to Fig. SPECIAL TOOL ASSY (41399FG000). 41399FG040 SPECIAL TOOL D Used for installing the rear differential mount bushing. For combination of tools for installation, refer to Fig. SPECIAL TOOL ASSY (41399FG000). 41399FG050 SPECIAL TOOL SLEEVE Used for removing and installing the rear differential mount bushing. For combination of tools for removal and installation, refer to Fig. SPECIAL TOOL ASSY (41399FG000). 41399FG060 SPECIAL TOOL RING Used for removing and installing the rear differential mount bushing. For combination of tools for removal and installation, refer to Fig. SPECIAL TOOL ASSY (41399FG000). 41399FG070 SPECIAL TOOL NUT Used for removing and installing the rear differential mount bushing. For combination of tools for removal and installation, refer to Fig. SPECIAL TOOL ASSY (41399FG000). 41399FG080 SPECIAL TOOL BEARING Used for removing and installing the rear differential mount bushing. For combination of tools for removal and installation, refer to Fig. SPECIAL TOOL ASSY (41399FG000). 41399FG090 SPECIAL TOOL SHAFT Used for removing and installing the rear differential mount bushing. For combination of tools for removal and installation, refer to Fig. SPECIAL TOOL ASSY (41399FG000). 41399YC000 SOCKET WRENCH (17) Used for tightening the self-locking nut. 1B022XU0 SUBARU SELECT MONITOR III KIT Used for troubleshooting the electrical system
