Airbag System (Diagnostics): Component Locations Subaru Outback BP рестайлинг

SPECIAL TOOL

SPECIAL TOOL DESCRIPTION ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 1B021XU0 SUBARU SELECT MONITOR III KIT Used for troubleshooting for electrical system

Scheme 143

Scheme 144

Scheme 145

Scheme 146

Scheme 147

Scheme 148

Scheme 149

Scheme 150

Scheme 151

Scheme 152

Scheme 153

Scheme 154

Scheme 155

Scheme 156

Scheme 157

Scheme 158

Scheme 159

Scheme 160

Scheme 161

1. TEST HARNESS F ILLUSTRATION TOOL NUMBER DESCRIPTION ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299FC010 TEST HARNESS F Used when measuring voltage and resistance of airbag module harnesses.
2. TEST HARNESS H ILLUSTRATION TOOL NUMBER DESCRIPTION ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299FA030 TEST HARNESS H Used when measuring voltage and resistance of front sub sensor and satellite safing sensor.
3. TEST HARNESS N ILLUSTRATION TOOL NUMBER DESCRIPTION ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299SA000 TEST HARNESS N Used when measuring voltage and resistance of driver's airbag module and seat belt pretensioner.
4. TEST HARNESS P ILLUSTRATION TOOL NUMBER DESCRIPTION ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299SA020 TEST HARNESS P Used when measuring voltage and resistance of driver's airbag module harness and passenger's airbag module harness.
5. TEST HARNESS Q ILLUSTRATION TOOL NUMBER DESCRIPTION ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299SA040 TEST HARNESS Q Used when measuring voltage and resistance of driver's airbag module.
6. TEST HARNESS AG ILLUSTRATION TOOL NUMBER DESCRIPTION ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299AG070 TEST HARNESS AG Used when measuring voltage and resistance of airbag control module.
7. TEST HARNESS V ILLUSTRATION TOOL NUMBER DESCRIPTION ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299AG010 TEST HARNESS V Used when measuring voltage and resistance of side airbag sensor and curtain airbag sensor.
8. TEST HARNESS AB ILLUSTRATION TOOL NUMBER DESCRIPTION ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299XA000 TEST HARNESS AB Used when measuring voltage and resistance of occupant detection system.
9. TEST HARNESS AC ILLUSTRATION TOOL NUMBER DESCRIPTION ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299XA010 TEST HARNESS AC Used for diagnosing seat belt tension sensor.
10. TEST HARNESS AD ILLUSTRATION TOOL NUMBER DESCRIPTION ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299XA020 TEST HARNESS AD Used when measuring voltage and resistance of the seat belt tension sensor.
11. TEST HARNESS AE ILLUSTRATION TOOL NUMBER DESCRIPTION ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299XA030 TEST HARNESS AE Used for diagnosing seat belt tension sensor. Used together with the test harness Y.
12. AIRBAG RESISTOR ILLUSTRATION TOOL NUMBER DESCRIPTION ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299PA040 AIRBAG RESISTOR Used in replacement of airbag module for which resistance value is same as airbag module. Two ST are required for diagnosis of two-stage inflator type airbag module.
13. TEST HARNESS AI ILLUSTRATION TOOL NUMBER DESCRIPTION ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299AG090 TEST HARNESS AI Used when diagnosing the side airbag sensor and curtain airbag sensor. Used together with the test harness V.
