Washer System & Wiper System: Removal & Installation Subaru Outback BP

Wiper/washer Systems 8 illustrations ~463 words

INSTALLATION

Install in the reverse order of removal.

Scheme 29

Scheme 29: INSPECTION
  1. Inspect the continuity between each connector terminal. TERMINAL NUMBER SPECIFICATION CHART Switch position Terminal No. Standard FRONT OFF 7 and 16 7 and 17 8 and 17 2 and 11 More than 1 ohm. INT 7 and 16 Less than 1 ohm LO 7 and 17 Less than 1 ohm HI 8 and 17 Less than 1 ohm Washer ON 2 and 11 Less than 1 ohm REAR Washer ON 2 and 10 10 and 12 2 and 12 Less than 1 ohm OFF 2 and 10 10 and 12 2 and 12 More than 1 Mohm ON 2 and 10 Less than 1 ohm Washer ON 2 and 10 10 and 12 2 and 12 Less than 1 ohm If continuity is not as specified, replace the switch.
  2. Intermittent operation inspection

Scheme 30

Scheme 30
  1. Turn the wiper switch to INT.
  2. Adjust the intermittent control switch to MAX.
  3. Apply battery voltage to switch terminals 17 and 2, and inspect the voltage of terminals 7 and 2. (Measure the voltage from after the second time the wiper stops.)

If operation is not as specified, replace the switch.

REMOVAL

While pushing locking clip (A) up, pull out blade from arm to arrow direction.

Scheme 31

Scheme 31: REMOVAL
  1. Install in the reverse order of removal.
  2. Confirm that clip was locked securely.

Install in the reverse order of removal.

Tightening torque

5.9 N.m (0.6 kgf-m, 4.3 ft-lb)

Install in the reverse order of removal.

Tightening torque

Refer to COMPONENT in General Description. Refer to FRONT WIPER .

Scheme 32

Scheme 32: INSPECTION

Scheme 33

Scheme 33

Scheme 34

Scheme 34

Scheme 35

Scheme 35
  1. When battery is connected to terminal of connectors, confirm that motor operates at low speed.
  2. When battery is connected to terminal of connectors, confirm that motor operates at high speed.
  3. Connect battery to terminals of connector, and remove terminal connection with motor rotated at low speed, and stop wiper motor through operation.
  4. Connect battery and confirm that motor stops automatic stop position after motor operates at low speed again.

Scheme 36

Scheme 36: REMOVAL
  1. Remove the washer hose from the washer nozzle.
  2. Open the clips on the underside of the front hood with a thin screwdriver or other tool, and remove the washer nozzle.
  1. Install in the reverse order of removal.
  2. Adjust the position of the washer liquid sprayer. Refer to «ADJUSTMENT»(ref-216276-S34158873772006011800000) , Front Washer Nozzle.
  1. Remove the high-mount stop light. Refer to «REMOVAL»(ref-216275-S42269764682006011800000) , High-mounted Stop Light.
  2. Remove the washer hose from the washer nozzle.
  3. Open the clips on the underside of the rear gate with a thin screwdriver or other tool, and remove the washer nozzle.
  1. Install in the reverse order of removal.
  2. Adjust the position of the washer liquid sprayer. Refer to «ADJUSTMENT»(ref-216276-S07040315582006011800000) , Rear Washer Nozzle.
