CAUTION

1. Wear working clothing, including a cap, protective goggles, and protective shoes during operation.
2. Remove contamination including dirt and corrosion before removal, installation or disassembly.
3. Keep the disassembled parts in order and protect them from dust or dirt.
4. Before removal, installation or disassembly, be sure to clarify the failure. Avoid unnecessary removal, installation, disassembly, and replacement.
5. Use SUBARU genuine grease etc. or the equivalent. Do not mix grease etc. with that of another grade or from other manufacturers.
6. Be sure to tighten fasteners including bolts and nuts to the specified torque.
7. Place shop jacks or safety stands at the specified points.
8. Apply grease onto sliding or revolution surfaces before installation.
9. Before installing O-rings or snap rings, apply sufficient amount of grease to avoid damage and deformation.
10. Before securing a part on a vise, place cushioning material such as wood blocks, aluminum plate, or shop cloth between the part and the vise.
11. Before disconnecting electrical connectors, be sure to disconnect the ground cable from battery.

Scheme 45

Scheme 46

Scheme 47

Scheme 48

Scheme 49

Scheme 50

Scheme 51

Scheme 52

Scheme 53

Scheme 54

Scheme 55

Scheme 56

Scheme 57

Scheme 58

Scheme 59

Scheme 60

Scheme 61

Scheme 62

1. Set the vehicle on a lift.
2. Disconnect the ground cable from battery.
3. Move the select lever to "N" position
4. Lift-up the vehicle.
5. Remove the rear exhaust pipe and muffler. Except 2.5 L U5 model Refer to «REMOVAL»(ref-208361-S17585007752005120700000) , Rear Exhaust Pipe and «REMOVAL»(ref-208361-S00413986862005120700000) , Muffler. 2.5 L U5 model Refer to «REMOVAL»(ref-208369-S20556856332005120700000) , Rear Exhaust Pipe and «REMOVAL»(ref-208369-S22475579312005120700000) , Muffler. 3.0 L model Refer to «REMOVAL»(ref-208386-S03690047052005120700000) , Rear Exhaust Pipe and «REMOVAL»(ref-208386-S40817313242005120700000) , Muffler. TURBO model Refer to «REMOVAL»(ref-208376-S18574141742005120700000) , Rear Exhaust Pipe and «REMOVAL»(ref-208376-S18819972022005120700000) , Muffler.
6. Remove the heat shield cover. (If equipped)
7. Disconnect the cable from select lever, and then remove the cable bracket.
8. Lower the vehicle.
9. Remove the console box. Refer to «REMOVAL»(ref-216282-S15871558132006011800000) , Console Box.
10. Disconnect the connectors, then remove the four bolts to take out the select lever assembly from body.

Scheme 63

1. Mount the select lever onto the vehicle body.
2. Tighten the four bolts to install the select lever to vehicle body, then connect the connector. Tightening torque: 13 N.m (1.3 kgf-m, 9.4 ft-lb)
3. Install the console box. Refer to «INSTALLATION»(ref-216282-S03661748772006011800000) , Glove Box.
4. Set the location of select lever at "N" position.
5. Lift-up the vehicle.
6. Set the location of range select lever to "N" position.
7. Insert the thread portion of the other inner cable and into connector hole of the select lever, and fix the other outer cable end to bracket. Tightening torque: 18 N.m (1.8 kgf-m, 13.0 ft-lb)
8. Adjust the select cable position. Refer to «ADJUSTMENT»(ref-208392-S24954581922005120700000) , Select Cable.
9. After completion of fitting, make sure that the select lever operates smoothly all across the operating range.
10. Install the heat shield cover. (If equipped)
11. Install the rear exhaust pipe and muffler. Except 2.5 L U5 model Refer to «INSTALLATION»(ref-208361-S21912926732005120700000) , Rear Exhaust Pipe and «INSTALLATION»(ref-208361-S41100021962005120700000) , Muffler. 2.5 L U5 model Refer to «INSTALLATION»(ref-208369-S39698120092005120700000) , Rear Exhaust Pipe and «INSTALLATION»(ref-208369-S32210117812005120700000) , Muffler. 3.0 L model Refer to «INSTALLATION»(ref-208386-S39855252692005120700000) , Rear Exhaust Pipe and «INSTALLATION»(ref-208386-S35967598162005120700000) , Muffler. TURBO model Refer to «INSTALLATION»(ref-208376-S18278122642005120700000) , Rear Exhaust Pipe and «INSTALLATION»(ref-208376-S42649748292005120700000) , Muffler.
12. Inspect the following items. If the following inspection reveals problems, adjust the select cable and inhibitor switch. Refer to «ADJUSTMENT»(ref-208392-S24954581922005120700000) , Select Cable and «ADJUSTMENT»(ref-208395-S01670835762005120700000) , Inhibitor Switch. The engine starts operating when select lever is in position "P" or "N", but not in other positions. The back-up light is lit when the select lever is in position "R", but not in other positions. Select lever and indicator positions are matched.

Scheme 64

Scheme 65

Scheme 66

Scheme 67

Scheme 68

Scheme 69

Scheme 70

Scheme 71

Scheme 72

Scheme 73

Scheme 74

Scheme 75

Scheme 76

Scheme 77

Scheme 78

Scheme 79

Scheme 80

Scheme 81

Scheme 82

Scheme 83

Scheme 84

Scheme 85

Scheme 86

1. EXCEPT SPORT SHIFT MODEL Remove four washers and then detach rubber boot. Remove bolts and then remove cable bracket and plate. Remove select lever grip. Detach indicator cover and pattern plate. Disconnect solenoid assembly connector. While pressing shift lock cancel button, remove shift lock solenoid assembly. Remove indicator light. Remove indicator bulb. Remove indicator light cover. Remove cushion. Tilt lever forward and pull down to separate it from frame. Remove clip, and "P" position switch with harness. Remove detent spring Remove spring. CAUTION: Wear goggles. Do not allow spring to fly out during removal. Remove bolt and then disconnect lever upper and lever lower.
2. SPORT SHIFT MODEL Remove the packing. Remove the grip. Remove the indicator light, and then remove the indicator cover. NOTE: Be careful not to break the indicator light during removal. Remove the blind. Remove the clips, and then remove the guide plate. Remove the clamp, shift lock solenoid and cushion. Move select lever to "1" range. Remove the bolt. Remove the lock plate A, B, C and bushing. Remove the screw. Remove the bushing. Remove the clip, and then remove the rod and the spring. Remove the bolt. Remove the bracket guide ASSY. Remove the grommet, and then extract spring pin from the top. Remove the arm and then take away the lever and arm bracket from plate. Remove the spring, and then remove the detent arm.

Scheme 87

Scheme 88

1. Clean all parts before assembly.
2. Apply grease [SUNLIGHT 2 (Part No. 003602010) or equivalent] and SUNCALL or equivalent to each parts. Refer to «COMPONENT»(ref-208392-S10478032362005120700000) and «COMPONENT»(ref-208392-S10478032362005120700000) . NOTE: Do not apply SUNCALL to area except following parts.
3. Assembly is in the reverse order of disassembly. NOTE: Refer to "COMPONENT". Refer to «COMPONENT»(ref-208392-S10478032362005120700000) . Tighten the lock plate bolt uniformly. After installation, locate the base plate upside down, and then push the lock plate up. Make sure the lock plate falls by its weight when releasing it. If not, retighten the bolt.
4. After completion of fitting, transfer the select lever to range "P" - "1", then check whether the indicator and select lever agree, whether the pointer and position mark agree and what the operating force is.
