GENERATOR SPECIFICATIONS
| Application (1) | Specification |
|---|
| Brush Length |
| Standard | .728" (18.5 mm) |
| Limit | .197" (5 mm) |
| Brush Spring Pressure |
| New | 17.26-21.60 oz. (4.8-6.0 N) |
| Replace | 7.91 oz. (2.2 N) |
| (1) See BRUSH under BENCH TESTING. |
| Application | Specification |
|---|
| Slip Ring Continuity Test |
| Specified Resistance | 1.8-2.2 Ohms |
| Slip Ring Outer Diameter |
| Standard | .894" (22.7 mm) |
| Limit | .87" (22.1 mm) |
ROTOR ASSEMBLY SPECIFICATIONS
Scheme 1
TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) |
|---|
| Generator (1) |
| Bearing Retainer Screw (T1) | (2) |
| Nut-To-Rear Cover (T1) | (2) |
| Pulley Nut (T2) | 47 (64) |
| Through-Bolt & Screw-To-Front Cover (T1) | (2) |
| Through-Bolt-To-Rear Cover (T1) | (2) |
| V-Belt |
| Lock Bolt Through Bolt (Generator Belt Tensioner Lock Bolt) | 18 (25) |
| Slider Bolt (Generator Belt Tensioner Adjustment Bolt) | (3) |
| (1) See COMPONENT LOCATIONS . (2) Tighten to 18 INCH (2 N.m). (3) Tighten to 71 INCH (8 N.m). |
| (1) | See COMPONENT LOCATIONS . |
| (2) | Tighten to 18 INCH (2 N.m). |
| (3) | Tighten to 71 INCH (8 N.m). |
