Automatic Transmission (Diagnostics) (H4SO): Overview Subaru Outback BP

Scheme 539

Scheme 540

OPERATION

Shift the select lever to D range, and drive continuously for 10 seconds or more at 60 km/h (37 MPH).

1. WITHOUT SUBARU SELECT MONITOR Current DTC shown on display are cleared by turning the ignition switch to OFF after conducting onboard diagnostics operation. Previous DTC, however, cannot be cleared since they are stored in the TCM memory which is operating on back-up power supply. These DTC can be cleared by removing the specified TCM connector for at least two minutes. CLEAR MEMORY: Without VDC system and SPORT shift Remove the TCM connector (B55) for at least two minutes. With VDC system or SPORT shift Remove the TCM connector (B56) for at least two minutes. TCM connector is located in the line to memory back-up power supply of TCM. Removal of this connector clears the previous DTC stored in TCM memory. Be sure to remove TCM connector for at least the specified length of time. Otherwise, the DTC may not be cleared.
2. WITH SUBARU SELECT MONITOR Refer to Subaru Select Monitor for information about how to clear DTC. Refer to «SUBARU SELECT MONITOR»(ref-208397-S24197036892005120700000) .
