INSTALLATION

Install in the reverse order of removal.

Identifying Combination Switch Terminals. Scheme 15

Scheme 15: Identifying Combination Switch Terminals

Move combination switch to respective positions and check continuity between terminals.

Checking Continuity Between Lighting Switch Terminals. Scheme 16

Scheme 16: Checking Continuity Between Lighting Switch Terminals

Checking Continuity Between Dimmer & Passing Switch Terminals. Scheme 17

Scheme 17: Checking Continuity Between Dimmer & Passing Switch Terminals

Checking Continuity Between Turn Signal Switch Terminals. Scheme 18

Scheme 18: Checking Continuity Between Turn Signal Switch Terminals

Checking Continuity Between Parking Switch Terminals. Scheme 19

Scheme 19: Checking Continuity Between Parking Switch Terminals

Scheme 20

Scheme 20: REMOVAL

Scheme 21

Scheme 21

Scheme 22

Scheme 22
  1. Remove duct (A) (when right side headlight is removed). (Scheme 20): Removing Duct (When Right Side Headlight Is Removed)
  2. Disconnect headlight bulb connector. (Scheme 21): Disconnecting Headlight Bulb Connector
  3. Remove three bolts and disconnect connectors, and then detach headlight assembly. (Scheme 22): Removing Bolts & Disconnecting Connectors

Install in the reverse order of removal.

REMOVAL

CAUTIONBecause the tungsten halogen bulb operates at a high temperature, dirt and oil on the bulb surface reduces the bulb's service life. Hold the flange portion when replacing the bulb. Never touch the glass portion. Do not leave the headlight without a bulb for a long time. Dust, moisture, etc. entering the headlight may affect its the performance.

Scheme 23

Scheme 23: SINGLE-BULB TYPE
  1. Remove duct (A) (when right side headlight is removed). (Scheme 23): Removing Duct (When Right Side Headlight Is Removed)
  2. Disconnect harness connector.
  3. Remove rubber cover.
  4. Push to remove spring retainer, and then detach the headlight bulb.

Scheme 24

Scheme 24: DUAL-BULB TYPE

Scheme 25

Scheme 25

Scheme 26

Scheme 26
  1. Remove duct (A) (when right side headlight is removed). (Scheme 24): Removing Duct (When Right Side Headlight Is Removed)
  2. Remove back cover (A). (Scheme 25): Removing Back Cover
  3. Disconnect harness connector.
  4. Push to remove spring retainer (A) (low beam) or turn bulb assembly (B) counterclockwise (high beam), and then detach headlight bulb. (Scheme 26): Removing Spring Retainer (Low Beam) Or Turning Bulb Assembly Counterclockwise (High Beam)

Install in the reverse order of removal.

Scheme 27

Scheme 27: REMOVAL
  1. Remove headlight assembly. See «REMOVAL»(ref-176259-S05188155322005051200000), Headlight Assembly.
  2. Turn the socket and remove the bulb. (Scheme 27): Removing Front Turn Signal Bulb

Install in the reverse order of removal.

Scheme 28

Scheme 28: REMOVAL
  1. Remove headlight assembly. See «REMOVAL»(ref-176259-S05188155322005051200000), Headlight Assembly.
  2. Turn the socket and remove the bulb. (Scheme 28): Removing Parking & Side Bulb

Install in the reverse order of removal.

Scheme 29

Scheme 29: EXCEPT OUTBACK

Scheme 30

Scheme 30
  1. Remove two clips and lower the mudguard. (Scheme 29): Removing Front Fog Light Assembly Clips (Except Outback)
  2. Disconnect harness connector.
  3. Remove mounting bolts, and then detach fog light assembly. (Scheme 30): Detaching Fog Light Assembly (Except Outback)

Scheme 31

Scheme 31: OUTBACK

Scheme 32

Scheme 32

Scheme 33

Scheme 33

Scheme 34

Scheme 34
  1. Turn stone guard counterclockwise, and then remove it. (Scheme 31): Removing Front Fog Light Assembly Stone Guard (Outback)
  2. Remove mounting bolts. (Scheme 32): Removing Front Fog Light Assembly Bolts (Outback)
  3. Remove two clips and lower the mudguard. (Scheme 33): Removing Front Fog Light Assembly Clips (Outback)
  4. Disconnect harness connector (a).
  5. Remove nut (b) then detach fog light assembly. (Scheme 34): Detaching Fog Light Assembly (Outback)

Install in the reverse order of removal.

Scheme 35

Scheme 35: EXCEPT OUTBACK

Scheme 36

Scheme 36
  1. Remove the two clips and lower the mudguard. (Scheme 35): Removing Front Fog Light Assembly Clips (Except Outback)
  2. Remove back cover (A). (Scheme 36): Removing Front Fog Light Assembly Back Cover (Except Outback)
  3. Disconnect harness connector.
  4. Remove spring retainer then detach fog light bulb.

Install in the reverse order of removal.

Scheme 37

Scheme 37: SEDAN

Scheme 38

Scheme 38

Scheme 39

Scheme 39
  1. Remove clips and then detach trunk rear trim. (Scheme 37): Removing Clips & Detaching Trunk Rear Trim (Sedan)
  2. Remove hook (A) and then turn over the trunk side trim of rear portion. (Scheme 38): Removing Hook & Turning Over Trunk Side Trim Of Rear Portion (Sedan)
  3. Remove harness clip (A).
  4. Remove three nuts and then detach rear combination light while disconnecting connector. (Scheme 39): Removing Nuts & Rear Combination Light (Sedan)

Install in the reverse order of removal.

Scheme 40

Scheme 40: SEDAN
  1. Open the trunk lid.
  2. Remove cover (A).
  3. Disconnect connector (B) from rear finisher light.
  4. Remove ten nuts and then detach rear finisher light from trunk lid. (Scheme 40): Detaching Rear Finisher Light (Sedan)

Scheme 41

Scheme 41: WAGON

Scheme 42

Scheme 42
  1. Remove rear gate lower trim. See «REMOVAL»(ref-175480-S27356980662005042100000), Rear Gate Trim.
  2. Remove rear gate trim lower (A). (Scheme 41): Removing Rear Gate Trim Lower (Wagon)
  3. Disconnect connector from rear finisher light.
  4. Remove nuts (A) and then remove rear finisher light from rear gate. (Scheme 42): Removing Rear Finisher Light (Wagon)

Install in the reverse order of removal.

Scheme 43

Scheme 43: SEDAN (COMBINATION LIGHT)
  1. Open trunk lid and remove cover. (Scheme 43): Removing Combination Light Cover (Sedan)
  2. Turn the socket and remove the bulb.

Scheme 44

Scheme 44: SEDAN (FINISHER LIGHT)
  1. Open trunk lid and remove cover. (Scheme 44): Removing Finisher Light (Sedan)
  2. Turn the socket and remove the bulb.

Scheme 45

Scheme 45: WAGON (COMBINATION LIGHT)
  1. Remove rear combination light assembly. See «WAGON»(ref-176259-S00136721332005051200000), REMOVAL, Rear Combination Light Assembly.
  2. Turn the socket and remove the bulb. (Scheme 45): Removing Combination Light (Wagon)

Scheme 46

Scheme 46: WAGON (FINISHER LIGHT)
  1. Open rear gate lower trim cover. (Scheme 46): Opening Rear Gate Lower Trim Cover (Wagon)
  2. Turn the socket and remove the bulb.

Install in the reverse order of removal.

Scheme 47

Scheme 47: SEDAN
  1. Open trunk lid and remove cover. (Scheme 47): Removing Cover For Back-Up Light Bulb (Sedan)
  2. Turn the socket and remove the bulb.

Scheme 48

Scheme 48: WAGON
  1. Open rear gate lower trim cover. (Scheme 48): Opening Cover For Rear Gate Lower Trim (Wagon)
  2. Turn the socket and remove the bulb.

Install in the reverse order of removal.

Scheme 49

Scheme 49: SEDAN
  1. Open trunk lid and remove cover. (Scheme 49): Removing Cover For Rear Turn Signal Light Bulb (Sedan)
  2. Turn the socket and remove the bulb.

Scheme 50

Scheme 50: WAGON
  1. Remove rear combination light assembly. See «WAGON»(ref-176259-S00136721332005051200000), REMOVAL, Rear Combination Light Assembly.
  2. Remove the light cover mounting screws then detach the cover.
  3. Turn the socket and remove the bulb. (Scheme 50): Removing Bulb For Rear Turn Signal (Wagon)

Install in the reverse order of removal.

Scheme 51

Scheme 51: REMOVAL
  1. Remove license plate light mounting screw (A) and then remove the lens (B) (Scheme 51): Removing License Plate Light Mounting Screw & Lens
  2. Remove the bulb.

Install in the reverse order of removal.

Scheme 52

Scheme 52: SEDAN WITHOUT REAR SPOILER
  1. Disconnect connector of high-mounted stop light from body harness.
  2. Remove bolts, then detach high-mounted stop light assembly. (Scheme 52): Removing High-Mounted Stop Light Assembly (Sedan Without Rear Spoiler)

Install in the reverse order of removal.

Scheme 53

Scheme 53: REMOVAL
  1. Remove lens (A) and spot light mounting screw (B). (Scheme 53): Removing Lens & Spot Light Mounting Screw
  2. Disconnect harness connectors and remove spot light.

Install in the reverse order of removal.

Install in the reverse order of removal.

Checking Continuity Between Terminals. Scheme 54

Scheme 54: Checking Continuity Between Terminals

Check continuity between terminals.

Checking Continuity Between Terminals Chart. Scheme 55

Scheme 55: Checking Continuity Between Terminals Chart

Scheme 56

Scheme 56: REMOVAL
  1. Remove lens (A) and luggage room light mounting screws (B). (Scheme 56): Removing Lens & Luggage Room Light Mounting Screws
  2. Disconnect harness connectors and remove luggage room light.

Install in the reverse order of removal.

Turning Switch Each Position & Checking Continuity Between Terminals. Scheme 57

Scheme 57: Turning Switch Each Position & Checking Continuity Between Terminals

Turn the switch each position and check continuity between terminals.

Checking Continuity Between Terminals Chart. Scheme 58

Scheme 58: Checking Continuity Between Terminals Chart

Disconnect harness connectors and remove trunk room light.

Removing Trunk Room Light. Scheme 59

Scheme 59: Removing Trunk Room Light

Install in the reverse order of removal.

Scheme 60

Scheme 60: REMOVAL
  1. Remove glove box. See «REMOVAL»(ref-175480-S35498381682005042100000), Glove Box.
  2. Disconnect harness connector.
  3. Remove glove box light. (Scheme 60): Removing Glove Box Light

Install in the reverse order of removal.

Remove the lens then detach the bulb.

Removing Lens & Detaching Bulb. Scheme 61

Scheme 61: Removing Lens & Detaching Bulb

Install in the reverse order of removal.
