Lighting Systems: Other Subaru Outback BH

PRECAUTIONS

1. Before disassembling or reassembling parts, always disconnect battery ground cable. When replacing radio, control module, and other parts provided with memory functions, record memory contents before disconnecting the battery ground cable. Otherwise, the memory will be erased.
2. Reassemble in reverse order of disassembly, unless otherwise indicated.
3. Adjust parts to the given specifications.
4. Connect connectors and hoses securely during reassembly.
5. After reassembly, make sure functional parts operate smoothly.

Identifying General Tools. Scheme 62

Headlight & Tail Light Schematic (Headlight 2-Light Model). Scheme 63

Headlight & Tail Light Schematic (Headlight 4-Light Model). Scheme 64

Clearance Light & Illumination Light Schematic (1 Of 3). Scheme 65

Clearance Light & Illumination Light Schematic (2 Of 3). Scheme 66

Clearance Light & Illumination Light Schematic (3 Of 3). Scheme 67

HEADLIGHT RELAY

Check continuity between terminals when terminal No. 4 is connected to battery and terminal No. 3 is grounded.

Headlight Relay Diagnostic Chart. Scheme 68

Identifying Headlight Relay Terminals. Scheme 69

TAIL & ILLUMINATION RELAY

Check continuity between terminals (indicated in table below) when terminal No. 4 is connected to battery and terminal No. 3 is grounded.

Headlight Relay Diagnostic Chart. Scheme 70

Identifying Headlight Relay Terminals. Scheme 71

Front Fog Light 4 Cylinder Engine Schematic. Scheme 72

Front Fog Light 6 Cylinder Engine Schematic. Scheme 73

Checking Continuity Between Front Fog Light Switch Terminals. Scheme 74

Check continuity between terminals when operating the switch.

Front Fog Light Switch Continuity Chart. Scheme 75

FRONT FOG LIGHT RELAY

Check continuity between terminals (indicated in table below) when terminal No. 4 is connected to battery and terminal No. 3 is grounded.

Front Fog Light Relay Continuity Chart. Scheme 76

Identifying Front Fog Light Relay Terminals. Scheme 77

Turn Signal Light & Hazard Light Schematic (1 Of 2). Scheme 78

Turn Signal Light & Hazard Light Schematic (2 Of 2). Scheme 79

TURN SIGNAL SWITCH

See INSPECTION , Combination Switch (Light).

Identifying Hazard Switch Terminals. Scheme 80

Check continuity between hazard switch terminals.

Checking Continuity Between Hazard Switch Terminals. Scheme 81

Connecting Battery & Turn Signal Light Bulb To Module. Scheme 82

Connect battery and turn signal light bulb to the module, as shown in the figure. (Scheme 82) The module is properly functioning if it blinks when power is supplied to the circuit.

Back-Up Light Schematic. Scheme 83

BACK-UP LIGHT SWITCH (M/T)

Check continuity between terminals.

Checking Continuity Between Back-Up Light Switch Terminals (M/T). Scheme 84

Checking Continuity Between Inhibitor Switch Terminals. Scheme 85

Check continuity between terminals.

Inhibitor Switch Continuity Chart (A/T). Scheme 86

Stop Light Schematic (Sedan Model). Scheme 87

Stop Light Schematic (Wagon Model). Scheme 88

Checking Continuity Between Stop Light Terminals. Scheme 89

Check continuity between terminals.

Stop Light Continuity Chart. Scheme 90

Interior Light Schematic (1 Of 3). Scheme 91

Interior Light Schematic (2 Of 3). Scheme 92

Interior Light Schematic (3 Of 3). Scheme 93

Checking Continuity Between Door Switch Terminals. Scheme 94

Check Continuity Between Terminals.

Door Switch Continuity Chart. Scheme 95

REAR GATE LATCH SWITCH

Check continuity between terminals.

Checking Continuity Between Rear Gate Latch Switch Terminals. Scheme 96

TRUNK ROOM LIGHT SWITCH

Check continuity between terminals.

Checking Continuity Between Trunk Room Light Switch Terminals. Scheme 97

Scheme 98

Scheme 99

1. Remove instrument panel lower cover. See «REMOVAL»(ref-175480-S26123408442005042100000), Instrument Panel Assembly.
2. Remove screws which secure upper column cover to lower column cover. (Scheme 98): Removing Column Cover Screws
3. Disconnect connector from combination switch.
4. Remove screws which secure switch and remove switch. (Scheme 99): Removing Switch Screws & Removing Combination Switch

HEADLIGHT AIMING

Note. As this headlight is the "VISUAL AIMING TYPE", it is possible to adjust aiming only in the vertical direction. It cannot be adjusted in the horizontal direction.

Note. Before checking the headlight aiming, be sure of the following: The area around the headlight has not sustained any accident, damage or other type of deformation. Vehicle is parked on level ground. The inflation pressure of tires is correct. Vehicle's gas tank is fully charged. Bounce the vehicle several times to normalize the suspension. Make certain that someone is seated in the driver's seat.

Turn the headlight on and then adjust the low beam pattern to the following positions on the screen.

Note. Adjust the headlight aiming by turning the adjusting screw (a).

Identifying Headlight Adjusting Screw. Scheme 100

Single-Bulb Headlight Adjusting Headlights. Scheme 101

Dual-Bulb Headlight Adjusting Headlights. Scheme 102

OUTBACK

1. Remove fog light assembly. See «OUTBACK»(ref-176259-S11987353462005051200000) , REMOVAL, Front Fog Light Assembly.
2. Disconnect harness connector.
3. Loosen screws and turn the bulb assembly counterclockwise, and then detach the bulb.

WAGON

1. Remove two rear quarter trim covers.
2. Remove two nuts and then remove rear combination light while disconnecting connector.

Note. Before removing the nuts, apply a few turns of butyl tape to the tip of the service tool. This prevents the nuts from falling during removal.

Removing Nuts & Rear Combination Light (Wagon). Scheme 103

SEDAN WITH REAR SPOILER

1. Remove two screws and then detach high-mounted stop light assembly while disconnecting connector.

Scheme 104

1. Remove cap (a) by prying on the edge with a screwdriver.
2. Remove screws (b) and then detach cover (c).
3. Remove screws (d) and then detach high-mounted stop light while disconnecting connector. (Scheme 104): Removing High-Mounted Stop Light Assembly (Wagon)
