INSTALLATION

Install in the reverse order of removal.

Tightening torque

1. Throttle body: 22 N.m (2.2 kgf-m, 15.9 ft-lb)

Scheme 11

Scheme 12

1. Disconnect battery ground cable. (Scheme 11): Disconnecting Battery Ground Cable
2. Remove lower inner trim of passenger side. See «REMOVAL»(ref-175480-S38119270582005042100000), Lower Inner Trim.
3. Disconnect connectors from main relay.
4. Remove bolt which holds main relay bracket on body. (Scheme 12): Removing Bolt Holding Main Relay Bracket

Install in the reverse order of removal.

Scheme 13

Scheme 14

1. Disconnect battery ground cable. (Scheme 13): Disconnecting Battery Ground Cable
2. Remove lower cover. See «REMOVAL»(ref-175480-S26123408442005042100000), Instrument Panel Assembly.
3. Disconnect connector from fuel pump relay. (Scheme 14): Disconnecting Connector From Fuel Pump Relay
4. Remove fuel pump relay from mounting bracket.

Install in the reverse order of removal.
