Engine Cooling System (2.5L): Overview Subaru Outback BH

Cooling System (Mechanical) 3 illustrations

Specifications Chart. Scheme 8

Scheme 8: Specifications Chart
Scheme 8: Specifications Chart

Exploded View Of Water Pump Components. Scheme 9

Scheme 9: Exploded View Of Water Pump Components
Scheme 9: Exploded View Of Water Pump Components
  1. Tightening torque: N.m (kgf-m, ft-lb) T1: First: 12 (1.2, 8.7) Second: 12 (1.2, 8.7) T2: 6.4 (0.65, 4.7)

Exploded View Of Radiator & Radiator Fan Components. Scheme 10

Scheme 10: Exploded View Of Radiator & Radiator Fan Components
Scheme 10: Exploded View Of Radiator & Radiator Fan Components

Tightening torque: N.m (kgf-m, ft-lb)

  1. T1: 4.4 (0.45, 3.3)
  2. T2: 12 (1.2, 8.7)
  3. T3: 18 (1.8, 13.0)
  4. T4: 3.4 (0.35, 2.5)
  5. T5: 4.9 (0.50, 3.6)
