Generators & Regulators: Removal & Installation Subaru Outback BH

INSTALLATION (2.5L)

Install in the reverse order of removal.

Identifying Adjutment Bolts. Scheme 2

Scheme 3

Scheme 4

Scheme 5

1. Disconnect battery ground cable. (Scheme 3): Disconnecting Battery Ground Cable
2. Disconnect connector and terminal from generator. (Scheme 4): Disconnecting Connector & Terminal From Generator
3. Remove V-belt. See «V-BELT»(ref-159212-S05394343082005061700000).
4. Remove bolt (A), and loosen bolt (B). Then, remove generator from bracket. (Scheme 5): Removinge Generator

INSTALLATION (3.0L)

Install in the reverse order of removal.

Identifying Generator. Scheme 6
