SPECIFICATIONS
| WARNING | Vehicle is equipped with Supplemental Inflatable Restraint (SIR) system. When servicing vehicle, use care to avoid accidental air bag deployment. SIR system-related components are located in various locations throughout interior and exterior of vehicle, depending on application. Do not use electrical test equipment on or near these circuits. If necessary, deactivate SIR system before servicing components. See appropriate AIR BAG RESTRAINT SYSTEMS article in RESTRAINTS. |
| Application | Specification |
|---|
| Compressor Type | Zexel DKV-14G 5-Vane |
| Compressor Belt Deflection (1) |
| New Belt (2) | 19/64-21/64" (7.5-8.5 mm) |
| Used Belt | 23/64-13/32" (9.0-10.0 mm) |
| System Oil Capacity | (3) 4.0 ozs |
| Refrigerant (R-134a) Capacity | 21-25 ozs. |
| System Operating Pressures (4) |
| High Side | 399-455 psi (28.0-32.0 kg/cm 2 ) |
| Low Side | (5) 27-37 psi (1.95-2.60 kg/cm 2 ) |
| (1) With 22 lbs. (10 kg) pressure applied at center of longest span. (2) Readjust belt tension after running engine for 5 minutes. (3) Use ZXL200PG oil. If replacing compressor, drain oil from old and new compressor. Add the same amount of oil drained from old compressor to the new compressor. (4) Operating range of dual-pressure switch. (5) Off-to-on operating pressure listed. On-to-off operating pressure is 22-29 psi (1.55-2.05 kg/cm 2 ) |
| (1) | With 22 lbs. (10 kg) pressure applied at center of longest span. |
| (2) | Readjust belt tension after running engine for 5 minutes. |
| (3) | Use ZXL200PG oil. If replacing compressor, drain oil from old and new compressor. Add the same amount of oil drained from old compressor to the new compressor. |
| (4) | Operating range of dual-pressure switch. |
| (5) | Off-to-on operating pressure listed. On-to-off operating pressure is 22-29 psi (1.55-2.05 kg/cm 2 ) |
TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) |
|---|
| Compressor Bolts | 21 (29) |
| Compressor Lines | 10 (14) |
| INCH Lbs. (N.m) |
| Condenser Bolts | 86 (7) |
| Condenser Lines | 176 (15) |
| Receiver-Drier Lines | 86 (7) |
Manual A/C-Heater System Wiring Diagram (2000-01 Legacy & Outback 2.5L). Scheme 1
Scheme 1: Manual A/C-Heater System Wiring Diagram (2000-01 Legacy & Outback 2.5L)
Manual A/C-Heater System Wiring Diagram (2001 Outback 3.0L). Scheme 2
Scheme 2: Manual A/C-Heater System Wiring Diagram (2001 Outback 3.0L)
